Raven AccuBoom User manual

AccuBoom™ Installation Manual
GVM Predator and Prowler (’08 & Older)

Manual # 016-0171-014
1
CHAPTER
I NTRODUCTION
Congratulations on your purchase of the Raven AccuBoom system! This
system is designed to provide worry free turn-on and turn-off of your
booms with respect to the as-applied coverage map. The following
instructions are designed to assist you in the proper installation of the
AccuBoom system. See the Viper Installation and Operators Manual for
instructions on setting up the software and using the AccuBoom system.
You will also need a valid AccuBoom Control Activation Key for your
Viper system in order to activate the AccuBoom system.
Components
Needed
• GVM Predator and Prowler CAN AccuBoom Kit - P/N 117-1001-014
Kit includes:
• CAN AccuBoom Control Node - P/N 063-0172-316
• Cable, CAN AccuBoom GVM Prowler/Predator - P/N 115-0171-591
• CAN Tee Cable, 12 foot - P/N 115-0171-362
• AccuBoom Control Activation Key - P/N 077-0180-010
• GVM Predator and Prowler CAN Installation Manual - P/N 016-0171-014
Important! All boom switches must remain in
the ON position while AccuBoom control is in
operation!

GVM Predator and Prowler ('08 & Older) CAN AccuBoom Installation Manual
2
Notes:

Manual # 016-0171-014
3
CHAPTER
I NSTALLATION
Use the following procedure to properly install the CAN AccuBoom on a
GVM Prowler or Predator sprayer:
1. Connect the AccuBoom cable to the AccuBoom node.
a. Connect the rectangular connectors from the AccuBoom
cable (P/N 115-0171-591) to the CAN AccuBoom node
(P/N 063-0172-316).
2. Mount the CAN AccuBoom node on the rear of the machine:
a. Remove the rectangular cover located on the back of the machine at
the center of the booms. This cover protects the hydraulic valves.
b. Drill three holes in the side of the cover and mount the Raven CAN
AccuBoom node (P/N 063-0172-316) on the inside of the cover.
c. Re-install the cover on the machine.

GVM Predator and Prowler ('08 & Older) CAN AccuBoom Installation Manual
4
3. Connect the AccuBoom cable to the sprayer boom harness:
a. Locate the boom valve connectors, which are on the left side of the
rectangular cover previously removed and re-installed.
b. Unplug the 4 pin boom cable for boom valve 1.
c. Tee in the boom connectors labeled boom 1 on the Raven AccuBoom
cable (P/N 115-0171-591).
d. Repeat for each of the other remaining boom valves.
Connectors

Manual # 016-0171-014
5
4. Fasten the AccuBoom cable (P/N 115-0171-591) with a loop as shown
in the picture, so that no rainwater can enter the cable.
Loop

GVM Predator and Prowler ('08 & Older) CAN AccuBoom Installation Manual
6
5. Route the CAN and power cables form the AccuBoom node to the cab:
a. Locate the CAN terminator behind the right corner of the machine
cab.
b. Remove the CAN terminator (P/N 063-0172-369) from the CAN
cable.
c. Connect the 24 foot CAN tee cable (P/N 115-0171-363) in place of
the CAN terminator previously removed.
d. Route the CAN tee cable (P/N 115-0172-363) back to the previously
installed CAN AccuBoom cable (P/N 115-0171-591).
6. Connect the CAN cable to the product CANbus.
a. Connect the CAN tee cable (P/N 115-0172-363) to the CAN
AccuBoom cable (P/N 115-0172-591).
b. Install the previously removed CAN terminator (P/N 063-0172-369)
to the other connector of the CAN tee cable (P/N 115-0171-363).
7. Connect power and ground:
a. Route the red power and white ground wire to the control box located
behind the right corner of the machine cab.
b. Connect the red power wire to a source of clean, switched battery
power.
c. Connect the white ground wire directly to the battery ground.
8. The GVM Prowler/Predator CAN AccuBoom installation is now
complete. Install the AccuBoom Activation Key in Viper and the
AccuBoom system is ready for operation.

Manual # 016-0171-014
7
CHAPTER
S YSTEM T ROUBLESHOOTING
The CAN AccuBoom node (P/N 063-0172-316) has additional features to
allow the user to diagnose the AccuBoom system. The CAN AccuBoom
node has a plastic window in the case that allows the user to view green
diagnostic lights. The picture below shows the positioning of the lights.
•Logic Power: Lit when 12VDC logic power is available at the node.
•Micro 1 Hz: Flashes at 1 Hz interval when processor is active.
•CAN Rx: Flashes when CAN messages are being received.
•CAN Tx: Flashes when CAN messages are being transmitted.
•High Current Power: Lit when High Current Power is applied to the node.
Logic Power
Micro 1 Hz
CAN Rx
CAN Tx
High Current
Power (HC)

Raven Industries will not assume any expense or liability for repairs
made outside our facilities without written consent. Raven Industries
is not responsible for damage to any associated equipment or
products and will not be liable for loss of profit or other special
damages. The obligation of this warranty is in lieu of all other
warranties, expressed or implied, and no person or organization is
authorized to assume any liability for Raven Industries.
Damages caused by normal wear and tear, misuse, abuse, neglect,
accident, or improper installation and maintenance are not covered
by this warranty.
What Does this Warranty Cover?
How Long is the Coverage Period?
How Can I Get Service?
What Will Raven Industries Do?
What is not Covered by this Warranty?
Bring the defective part and proof of purchase to your Raven Dealer.
If your Dealer agrees with the warranty claim, the Dealer will send the
part and proof of purchase to their distributor or to Raven Industries
for final approval.
Upon confirmation of the warranty claim, Raven Industries will, at our
discretion, repair or replace the defective part and pay for return
freight.
RAVENINDUSTRIES
Limited Warranty
This warranty covers all defects in workmanship or materials in your
Raven Applied Technology Product under normal use, maintenance,
and service.
Raven Applied Technology Products are covered by this warranty for
12 months after the date of purchase. This warranty coverage applies
only to the original owner and is nontransferable.
