Catalog No.: 6000.342D Effective: 9-01-09 Replaces: 6-22-08
Job:
Engineer:
Contractor:
Prepared By: Date:
Model: Indoor/Outdoor: MBTUH Input:
Sealed Combustion Chamber
100% Factory Fire Tested
Efficiency: 85%
Minimum Non-condensing Inlet Temperature: 105°F
Thermal Shock Proof Heat Exchanger
Limited Twenty-year Thermal Shock Warranty
Limited Five-year Heat Exchanger Warranty
Full Safety Diagnostics with Fault History
PolyTuf Powder Coated Cabinet
No Combustible Floor Shield Required
Fan-assisted
Non-ferrous Bypass
Patented Burner Security Blanket
Heat Exchanger
Brass Headers
ASME Inspected and Stamped
160 PSIG Working Pressure
National Board Approved
Cupro Nickel Finned Tubing
ASME Steel Tube Sheet
Silicone High Temp O-Rings
125 PSIG ASME Pressure Relief Valve
Temperature and Pressure Gauge
Water Connections
Left – Standard
Right – Option A-6
Bronze Pump, 120V, 60Hz
Non-ferrous Pool Bypass
Controls
120V, 60Hz, 1∅Power Supply
120/24V 60Hz Transformer
100% Shut-off/Lockout
Hot Surface Ignition Systems (2)
Remote Flame Sensors (2)
High Limit Control, Auto Reset
On/Off Power Switch
Manual Shut-off, Front-mounted
Flow Switch
Blocked Vent Pressure Switch
Combustion Air Proving Switches
Economaster Pump Time Delay
Poolstat
Diagnostic Panel with LCD Display
2 Lines, 20 Characters
Gas Train
Combination Valves
On/Off Firing
Low Gas Pressure Switch, Manual
Fuel
Natural Gas
Propane Gas
Design Certified ANSI Z21.56/
CSA 4.7 (P models)
Design Certified ANSI Z21.10.3/
CSA 4.3 (WHP models)
Burner
Ultra-low NOx:
Less than 20 PPM
Construction
Indoor/Outdoor Construction
Enclosed Front Controls
Venting
Vent Location
Top – Standard
Rear – Option D-14
Vent Termination Cap
Outdoor – Option D-11
Indoor, Horizontal –
Option D-15
Indoor, Vertical (by others)
Combustion Air
In-Line Filter Kit (TruSeal
only) – Option D-17
Air Intake Elbow –
Option D-16
Options
C-6 Ignition Module, Manual Reset
D-21 TruSeal™ Direct Vent
Right Side
Left Side (Model 1802B
Only)
F-10 Low Water Cut-off, Remote
Probe
P-__ Cold Water Run System
(See Page 3)
S-2 Dual High Gas Pressure
Switches, Manual Reset
X-1 SureRack Kit
X-2 SureRack Kit Above Grade
Add-on (used with X-1)
Y-241 Temperature Controller,
1-4 Stages
Regulatory Agency Requirements
G-1 CSD-1
Hi Delta®- Type P
Commercial Pool Heaters
Models 1802B-2342B
Standard “H” B
yp
ass Shown
Patent No. 7,044,124

Hi Delta – Type P
Models 1802B-2342B Model
** Requires separate circuit breaker
Model MBTUH Amp Draw
Input Output
A
Width K T W
Heater Pump
Pump
HP
Shipping
Weight (Lbs.)
P 1802B 1800 1530 91-1/8 14 10 28-1/8 <12 11 3/4 1350
WHP 2002B 1999 1699 102-1/2 14 10 31-15/16 <12 14** 1 1450
WHP 2072B 2070 1760 102-1/2 14 10 31-15/16 <12 14** 1 1450
WHP 2342B 2340 1989 113-7/8 16 10 35-11/16 <12 21** 1-1/2 1520
Dimensions are in inches.
Ratings shown are for elevations up to 4,500 feet and for natural or propane gas.
For installation at elevations over 4
,
500 feet
,
p
lease contact manufacturer.
Standard “H” Bypass
Max. Flow
Model GPM ∆P (ft) ∆T
P 1802B 132 18.3 23
WHP 2002B 132 19.0 26
WHP 2072B 132 19.0 27
WHP 2342B 132 21.4 30

Hi Delta – Type P
Models 1532B-2342B (Cold Water Run Option) Model
*Separate 120 VAC or 240 VAC 1Ø power required for Cold Water Run option
** Requires separate circuit breaker
Cold Water Run Option
MBTUH Amp Draw
Model Input Output
A
Width K T W Heater Pump
Pump
Hp
Injector
Pump
Hp
Shipping
Weight
(Lbs.)
P 1532B 1530 1301 79-7/8 12 10 24-3/8 <12 12 3/4 1/3 1225
P 1802B 1800 1530 91-1/8 14 10 28-1/8 <12 12 3/4 1/3 * 1460
WHP 2002B 1999 1699 102-1/2 14 10 31-15/16 <12 14 1** 3/4 * 1560
WHP 2072B 2070 1760 102-1/2 14 10 31-15/16 <12 14 1** 3/4 * 1560
WHP 2342B 2340 1989 113-7/8 16 10 35-11/16 <12 21 1-1/2** 3/4 * 1620
Dimensions are in inches.
Ratings shown are for elevations up to 4,500 feet and for natural or propane gas.
For installation at elevations
over
4
,
5
00 feet, please contact manufacturer.
Raypak, Inc. 2151 Eastman Avenue, Oxnard, CA 93030 [phone] Fax [phone] www.raypak.com
Max. Flow
Model GPM ∆P (ft) ∆T
P 1532B 132 16.5 20
P 1802B 132 18.3 23
WHP 2002B 132 19.0 26
WHP 2072B 132 19.0 27
WHP 2342B 132 21.4 30
