Raypak Professional PS10353ti-E-HC Manual

I STALLATIO & OPERATI G
I STRUCTIO S
Catalog o. 6000.554 Effective: 12-21-11 Replaces: EW P/ 241460 Rev. 1
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and
liquids or other combustible materials in the vicinity of this or any other appliance. To
do so may result in an explosion or fire.
Professional Series
PS10353ti-E-HC
PS10354ti-E-HC
PS10355ti-E-HC
Heat Pump
Pool & Spa
Heater
USC
L
I
S
T
E
D
R
OTE: The instructions in this manual are for the use of qualified individuals specially trained and experienced
in the installation and maintenance of this type of equipment and related system components. Installation and
service personnel are required by some states to be licensed. Persons not qualified shall not attempt to install,
service, or maintain this equipment.
This manual should be maintained in legible condition and kept adjacent to the heat pump pool heater or in a
safe place for future use.

2

3
Water Chemistry
(Corrosive water voids all warranties)
For your health and the protection of your pool e uipment, it is essential that your water be chemically
balanced. The following levels must be used as a guide for balanced water.
Recommended Level(s) Fiberglass Pools Fiberglass Spas Other Pool & Spa Types
Water Temp. (Deg. F) 68 to 88 89 to 104 68 to 104
pH 7.3 to 7.4 7.3 to 7.4 7.6 to 7.8
Total Alkalinity (PPM) 120 to 150 120 to 150 80 to 120
Calcium Hardness (PPM) 200 to 300 150 to 200 200 to 400
Salt (PPM) 4500 MAXIMUM 4500 MAXIMUM 4500 MAXIMUM
Free Chlorine (PPM)* 2 to 3 2 to 3 2 to 3
Total Dissolved Solids (PPM) 3000 MAXIMUM** 3000 MAXIMUM** 3000 MAXIMUM**
*Free Chlorine MUST OT EXCEED 5 PPM!
** In salt water chlorinated pools, the total TDS can be as high as 6000ppm.
• Occasional chemical shock dosing of the pool or spa water should not damage the heater providing
the water is balanced.
• Automatic chemical dosing devices and salt chlorinators are usually more efficient in heated water.
nless controlled, they can lead to excessive chlorine level which can damage your heater.
• Further advice should be obtained from your pool or spa builder, accredited pool shop, or chemical
supplier for the correct levels for your water.

4
Water Chemistry 3
Warnings 5
Pay Attention to These Terms 5
Introduction 6
Installation Considerations 6
Electrical Connections 7
Water Connections 9
Pressure Drop 9
Controls 10
Operating Instructions 10
To Select Pool or Spa Mode 10
To Increase the Desired Water
Temperature (Pool or Spa Mode) 10
To Lower Desired Water Temperature
(Pool or Spa Mode) 10
To Select Temperature in °C or °F 10
Heat/Cool Operation 11
System Start-Up 11
Seasonal Start-Up or
Annual Check 11
Summer Shutdown 11
Freeze Protection 12
System Drain-Down 12
Continuous Pump Operation 12
Maintenance 12
Air Coil Cleaning 12
Cabinet Care (optional) 12
Unplug Condensation Drain Holes 12
Troubleshooting 12
Service Call Verification 13
Power Supply 13
Water Flow 13
Time Clock Adjustment 14
Plumbing Diagrams 15
Wiring Diagram — 208V/230V
Three-Phase — 60 Hz 19
Wiring Diagram — 460V
Three-Phase — 60 Hz 20
Wiring Diagram — 380V
Three-Phase — 60 Hz 21
Installing a Remote Control
Device 22
Wiring 22
Heater Settings 22
CO TE TS

CAUTIO : Improper chemical content in a swim-
ming pool or spa can damage the heat pump pool
heater. DO OT add pool chemicals to the skimmer.
This will damage the heat pump pool heater and
could void the heat pump pool heater warranty.
ALWAYS follow the product manufacturer’s direc-
tions when adding any chemicals to your pool.
DA GER: Indicates the presence of immediate hazards which will cause severe personal injury, death
or substantial property damage if ignored.
WAR I G: Indicates the presence of hazards or unsafe practices which could cause severe personal
injury, death or substantial property damage if ignored.
CAUTIO : Indicates the presence of hazards or unsafe practices which could cause minor personal
injury or product or property damage if ignored.
OTE: Indicates special instructions on installation, operation, or maintenance which are important
but not related to personal injury hazards.
Warnings — Pay Attention to These Terms
This manual, as well as the pool/spa heat pump pool heater itself, contains A SI-approved product safety signs
and labels. Please read these signs and labels, as they convey important safety information about hazards that
may be potentially present in and around the heat pump pool heater.
CAUTIO : Elevated water temperature can be
hazardous. The .S. Consumer Product Safety
Commission has these guidelines:
1. Spa water temperatures should never exceed
104°F (40°C). A temperature of 100°F (38°C) is
considered safe for a healthy adult. Special cau-
tion is suggested for young children.
2. Drinking of alcoholic beverages before or during
spa or hot tub use can cause drowsiness which
could lead to unconsciousness and subsequently
result in drowning.
3. Pregnant Women Beware! Soaking in water over
102°F (39°C) can cause fetal damage during the
first three months of pregnancy resulting in the
birth of a brain-damaged or deformed child.
Pregnant women should stick to the 100°F (38°C)
maximum rule.
4. Before entering the spa or hot tub, users should
check the water temperature with an accurate
thermometer; spa or hot tub thermostats may err
in regulating water temperatures by as much as
4°F (2.2°C).
5. Persons with a medical history of heart disease,
circulatory problems, diabetes, or blood pressure
problems should obtain a physician's advice
before using pools or hot tubs.
6. Persons taking medications which induce drowsi-
ness, such as tranquilizers, antihistamines, or
anticoagulants, should not use spas or hot tubs.
5
WAR I G: These heat pump pool heaters are
charged with R-410A refrigerant. Ensure that all
service work is done with gauges and equipment
suitable for R-410A.

Introduction
This manual contains important information on the
use, maintenance and troubleshooting of your new
heat pump pool heater. This unit must be properly
installed, maintained and operated for optimal per-
formance.
This heat pump pool heater is an extremely efficient,
economical machine designed specifically for swim-
ming pool heating. It is similar in design and operation
to a typical residential air conditioning system. The unit
employs a hermetic motor/compressor operating in a
refrigeration cycle to extract heat from ambient air and
deliver it to the circulating pool water.
As with all heat pump pool heaters, compared to other
types of heaters such as gas or oil-fired, this heat
pump pool heater has lower heating capacity on a
BTUH/hr basis. As a result, it will be required to oper-
ate longer to accomplish the desired results. It may, at
certain times, operate as much as 24 hours per day.
However, this should not be of concern to the owner,
because the unit is designed to operate continuously.
Even though it may operate continuously for many
hours, it will still heat the pool with greater economy
than other types of fossil fuel heaters.
Place a cover or blanket over the pool at night and
other non-use periods. This will keep evaporation, the
cause of main heat loss, to a minimum, and will great-
ly reduce pool heating costs. During warmer weather,
the cover may be required only at night.
Installation Considerations
Situate the heat pump pool heater carefully to mini-
mize installation costs while providing maximum
efficiency of operation, and to allow adequate service
access, as follows:
• For unrestricted air intake and service access,
position each side of the unit at least 1 ft (30 cm)
from walls, pipes and other obstructions.
• Recirculation of cold discharge air back into the
evaporator coil will greatly reduce the unit’s heat-
ing capacity and efficiency.
• This unit features an ‘up-flow’ discharge for quiet
operation. Air is pulled up through the evaporator
coil and discharged through the top grill. Allow at
least 5 ft (1.5 m) clearance above the unit for unre-
stricted air discharge. DO NOT install the unit
under a porch or deck. Refer to Fig. 1.
• To minimize water piping, locate the unit as close
as possible to the existing pool pump and filter.
WAR I G: This pool/spa heat pump pool heater is
an electromechanical machine that incorporates a
pressurized refrigerant gas in a sealed system.
O LY trained and qualified service personnel are
authorized to install or service this equipment.
Without proper training and knowledge of such
equipment, any attempt to install or service the unit
could result in serious injury or even death.
WAR I G: Do not install the unit within 3 ft of
fossil fuel burning heaters. Air intake along the
sides of this heat pump pool heater could disturb
the combustion process of the unit, and could
cause damage or personal injury.
• Mount the unit on a level, sturdy base, preferably a
concrete slab or blocks. The size of the base should
be at least 3 ft by 3 ft.
• You must install the 4 black rubber sound iso-
lation pads (each 2 inches square) that ship with
the unit. The pads are shipped in a bag with the
unions, gaskets and the I&O manual. Install pads
under the 4 corners of the unit to reduce vibra-
tion and sound transmission to the base.
CAUTIO : The unit’s supporting base must be high
enough to keep it completely free of standing water
at all times.
WAR I G: This unit is designed for outdoor instal-
lation; DO NOT install it in an enclosed area such as
a shed or garage.
6

7
GAS
HEATER
AIR
FLOW
IN
AIR
FLOW
IN
AIR FLOW OUT
3 FT
MIN
12”
MIN
60”
MIN
Fig. 1: Installation Clearances
• When installed in areas where freezing tempera-
tures can be encountered, drain the water circuit
to prevent possible freeze-up damage. See the
Freeze Protection Section.
• For high wind installation requirements, refer to
the diagram on page 8.
Electrical Connections
Refer to the unit rating plate below the control panel for
precise power requirements for your unit, and for
ampacity and over-current protection requirements.
All wiring must be in accordance with the ational
Electrical Code, FPA o. 70, latest edition, and all
applicable state and local codes. Wiring diagrams are
located on pages 19 through 21.
• Locate the equipment disconnect means within 3
feet of the heater’s electrical enclosure, or as
close to the heater as possible. Always satisfy
applicable codes and standards.
• In sizing power wiring, be especially aware of up-
sizing requirements necessary due to wiring
distances. Always satisfy applicable codes and
standards.
• Electrical installation should be done by a licensed
electrician only.
OTE: Refer to the ational Electrical Code, Article
680, for general requirements for swimming pools
and equipment, and to Article 440 for special consid-
erations necessary for circuits supplying hermetic
refrigeration motor/compressors.

8
(SEE BRACKET HURRICANE
TIE DOWN DWG)
50-1/210353
10354 10355
50-1/2 50-1/2

9
This unit is pre-wired to work with external control sys-
tems, heat-on-demand options and other external time
clock overrides. Refer to the external control system’s
instructions, and page 22 of this manual, for installa-
tion information.
Water Connections
1. Connect the heat pump pool heater in the return
water line between the filter and the pool/spa. See
the lumbing Diagrams beginning on page 15.
2. Connect the filter outlet to the fitting marked
WATER IN at the bottom front of the unit.
3. Connect the fitting marked WATER OUT to the
return piping to the pool/spa. Unit inlet/outlet con-
nection fittings are 2-inch PVC unions.
Water connections from the unit to the main return
line can be PVC pipe or flexible pipe approved for
the purpose and, in either case, should be at least
equal in size to the main pool/spa circulation pip-
ing.
4. In cold weather (freeze zone) areas, shutoff valves
(ball or gate type) must be installed at the unit inlet
and outlet to facilitate service and cold weather
drain-down.
5. Operate the pump and check the system for leaks.
Pressure Drop
For system pressure drop information, refer to Table B
below.
CAUTIO : The heat pump pool heater inlet and
outlet connections are NOT interchangeable. They
must be connected as instructed below.
Fig. 2: Water Connections
WATER IN
WATER OUT
Table B: ressure Drop Across Heat ump ool Heater
Flow
(gpm)
Pressure Drop (psi)
10353HC 10354HC 10355HC
30 10 10 10
40 10 10 10
50 11 11 11
60 12 12 12
70 13 13 13
80 14 14 14
Model o. VAC - Phase - Hz Minimum Circuit
Ampacity (A)
Maximum Breaker
Size (A)
10353 208/230 - 3 - 60 42.0 70
10354 460 - 3 - 60 26.0 40
10355 380 - 3 - 60 29.0 45
Table A: Typical System Electrical ower Requirements
ote: Multiply the pressure drop in psi by 2.3067 to yield the pressure drop in Ft. H2O Head (TDH).

10
Controls
Your heat pump pool heater incorporates digital safety
controls and indicators to ensure its safe, reliable
operation.
Water ressure Switch: Prevents operation when the
pump is OFF. The unit requires 5 psi minimum pres-
sure.
Digital Water Temperature Control: The pool water
temperature is controlled by the heat pump pool
heater’s digital control system, which gives you the
option of two settings: one for the desired spa temper-
ature and the other for the desired pool temperature.
Additionally, as mentioned earlier, the unit is compati-
ble with most ‘2-wire’ and ‘3-wire’ control/automation
systems.
Defrost Sensor: Prevents unit operation if ambient air
temperature falls below a predetermined safe mini-
mum (approximately 42°–48°F (5.5°-8.8°C) based on
humidity). The compressor will shut OFF but the fan
will continue to run.
Delay Timer: Prevents compressor from short cycling,
which could damage or destroy the hermetic
motor/compressor. Upon water temperature control
satisfaction, or other circuit interruptions, this solid
state device will prevent compressor restart for
approximately 5 minutes.
Operating Instructions
The electronic board has the capability of memorizing
two different programmed temperature settings as fol-
lows (refer to Fig. 5):
• For a pool, maximum 95°F (35°C)
• For a spa, maximum 104°F (40°C)
To Select Pool or Spa Mode
To have access to either one of these programs, press
the SET key until you see _S and by pressing the
UP or DOW key you can switch to OL or S A.
To Increase the Desired Water
Temperature (Pool or Spa Mode)
Push the SET key until you see OL or S A. The pro-
grammed temperature will be displayed. Press the UP
arrow to increase the temperature setting one degree
at a time.
To Lower the Desired Water
Temperature (Pool or Spa Mode)
Push the SET key until you see OL or S A. The pro-
grammed temperature will be displayed. Press the
DOW arrow to decrease the temperature setting one
degree at a time.
Once the control has been programmed to the desired
pool water temperature, the programmed temperature
will be displayed for approximately 5 seconds. Then
the digital display will display the actual pool water
temperature.
To make the Board a ool ONLY Board, call 800-
260-2758 for instructions.
To Select Temperature in °C or °F
Press the SET key until you see F _C. By pressing the
UP or DOW key you can switch to °F or °C. Once the
temperature display mode has been programmed it
will be displayed for approximately 5 seconds, then
the digital display will return to the actual pool water
temperature in the mode that you have chosen.
Fig. 5: Digital Water Temperature Control
WAR I G: Install a check valve and/or a Hartford
loop AFTER the heat pump pool heater and
BEFORE any chlorinating devices. Install any auto-
matic chemical feeders AFTER the heat pump pool
heater. Improper installation of any type of auto-
matic chemical feeders can result in serious
damage to, or premature failure of, the heat
pump pool heater and will void the heat pump
pool heater warranty.

11
System Start-Up
1. Verify that the Digital Board is displaying a temper-
ature and the pool pump is running and water is
circulating properly.
2. Verify that the Board is programmed so that the
desired temperature of the Pool and Spa is higher
than the displayed current water temperature.
3. Allow the heat pump pool heater to operate for a
few minutes to stabilize operating pressures and to
allow various component temperatures to normal-
ize.
4. Verify that the discharge air temperature is approx-
imately 8°–10°F (4.5°–5.6°C) cooler than the air
entering the unit. If not, see the Troubleshooting
Section.
Heat/Cool Operation
The Raypak Professional models come standard with
heat/cool operation. The heat/cool model is designed
to both heat and cool the pool. To select heat or cool
mode, push the SET key until H/C is displayed. Press
the DOWN arrow key to select heating (hea), or the
U arrow key to select cooling (col). Set the desired
setpoint temperature as described earlier in this man-
ual.
When the unit has been operating in the heating mode
for a few minutes, the discharge air temperature
should be 8°–10°F (4.5°–5.6°C) cooler than the air
entering the unit.
When the unit has been operating in the cooling mode
for a few minutes, the discharge air temperature
should be 8°–10°F (4.5°–5.6°C) warmer than the air
entering the unit.
OTE: Once the control has been programmed to
the desired pool water temperature, the pro-
grammed temperature will be displayed for
approximately 5 seconds. The digital display will
then show the actual pool water temperature.
OTE: Remove the pool/spa blanket and turn on
any fountains, sprays or other water features to
speed cooling.
OTE: Heating is more efficient during warmer day-
light hours and cooling is more efficient during cooler
night time hours.
Seasonal Start-Up or Annual
Check
1. Remove leaves, pine needles, etc., from the evap-
orator coil. Clean the coil by gently applying a mild
solution of household liquid soap and water.
2. Gently rinse the coil with water; DO NOT use high
pressure.
3. Backwash or otherwise clean the pool filter. If nec-
essary, clean the skimmer basket and pump
strainer.
4. Set the valves to ensure proper water flow through
the unit.
Summer Shutdown
If you do not plan to use the heat pump pool heater
during the summer months, secure and protect it as
follows:
1. Turn the unit circuit breaker or disconnect switch to
OFF.
2. Leave the valves set the way they are unless addi-
tional circulation is required. DO NOT stop all flow
through the heat pump pool heater.
3. IM ORTANT: Remember to reset the valves
before the next heating season, or the unit will not
operate properly.
OTE: At the beginning of the heating season, or
whenever the pool water temperature is to be raised
several degrees, the pool pump and heat pump pool
heater may need to operate continuously for several
days. During summer months, only a few hours per
day may be necessary, or none at all.
OTE: If the pool pump and heat pump pool heater
shut OFF before the water temperature is raised to
the desired level, you must lengthen the running time
of both. To do this, reset the time clock dial for the
longer running time, or manually operate the pump
with the timer override switch. Since the heat pump
pool heater capacity and efficiency are both greater
at higher ambient air temperatures, run time should
be set to take advantage of all daylight hours, when
the air is generally warmer.

12
Cabinet Care (optional)
The stainless steel cabinet is designed for harsh out-
door use and requires little care. However, you can
clean it if you wish.
Wash the cabinet with soap and water.
Unplug Condensation Drain Holes
The unit extracts humidity from the air as it passes
through the coil, similar to the way a cold drink outside
“sweats” on a hot day. This condensation drains from
the bottom of the unit.
1. Routinely check to be sure the condensation drain
holes in the base of the unit are not plugged with
dirt or debris.
2. If condensation becomes a problem, optional drain
pans are available from your heat pump pool
heater distributor or pool dealer.
Troubleshooting
If your unit does not operate, or simply does not heat
your pool water, Fault Codes on the front control
panel, can provide valuable clues as to what is wrong,
and may even indicate precisely what the problem is.
Always observe these codes before calling a service
representative. By reporting on the telephone the Fault
Codes that are showing, the service rep may be able
to solve the problem without the expense of a service
call.
A. UNIT IS RUNNING, BUT NOT HEATING
•Is water flow through the unit adequate? Check
the unit for obstructions, such as a clogged filter
pump strainer, a dirty filter, or valves not posi-
tioned correctly. Check the operation of the flow
switch.
• Is the ejected air from the unit 8°–10°F
(4.5°–5.6°C) cooler than incoming air? If so, the
unit is extracting heat from the air and transferring
it to the pool.
•Is water condensing on the evaporator and inter-
nal copper pipes? This is also evidence of heat
removal from the air. When the air is cool with low
humidity, condensation may not be evident.
WAR I G: Shut OFF electricity to the unit before
cleaning.
Freeze Protection
If the unit is installed in a location subject to freezing
conditions, it is important to protect the water circuit
from freezing, just as should be done for the pump and
filter.
System Drain-Down
1. Turn the unit circuit breaker or disconnect switch
to OFF.
2. With the pool pump OFF, close the external shut-
off valves and loosen the inlet and outlet water
unions to allow water to drain. Use a Wet/Dry Vac
or air pressure to remove excess water.
3. Loosely re-attach the unions.
4. Cover the unit with a waterproof cover.
Continuous Pump Operation
It is also possible in some areas to prevent unit freeze
damage by operating the pump continuously during
freezing weather. However, this results in significantly
higher pump operating costs. Further, if a sustained
power failure occurs, the unit MUST be drained any-
way, or freeze damage could result.
Maintenance
The following maintenance procedures are designed
to keep your unit operating at a high level of reliability.
Maintenance must be performed on a periodic
basis to maintain warranty coverage and prevent
system failures and performance degradation.
Air Coil Cleaning
Efficient operation depends on free circulation of air
through the thin and tightly-spaced fins of the evapo-
rator coil(s). The evaporator must be cleaned
whenever it has a buildup of dirt or debris.
OTE: The heat pump pool heater MANUFACTUR-
ER IS NOT RES ONSIBLE for maintenance
adjustments.
CAUTIO : To clean the fins, spray gently with a
garden hose. DO NOT pressure wash. Doing so
will bend the fins and can void the warranty.

13
• How long has the unit been operating? During ini-
tial pool heating in cold weather, it may require a
week to elevate the water temperature to a com-
fortable level. ormally, it takes about 4 days.
How many hours per day is the unit operating?
Remember that the heat pump pool heater only
operates while the pool pump is running. Set the
time clock to permit 24 hour per day operation. After
the desired temperature is reached, return the unit to
normal operation of 8–10 hours per day.
•Is airflow through the unit being obstructed?
Restrictions such as shrubbery, tall grass, dirty
coils, or any other obstruction to airflow will reduce
performance.
• Is the pool blanket/cover being used?
Unblanketed pools can lose up to 10 degrees per
night compared to 4 degrees or fewer when a
blanket is used. Without a blanket, the total heat
gained during the day can be lost overnight.
•Are rapid heat losses occurring in some other way,
such as high wind, spillage, rainfall, flow through
solar panels at night, or a high water table?
B. UNIT IS NOT RUNNING
•Is the temperature display O ? If not, the circuit
breaker may be shut OFF or tripped. Reset the
breaker by switching it OFF, and then back O .
Verify that the breaker is set and operating
properly before calling for service.
•Is the thermostat setting and the Pool/Spa setting
correct? Verify that the temperature has been
properly set on the thermostat, and that it is high-
er than the current water temperature.
•Have you waited approximately 5 minutes for the
time delay? After the unit has been running and
then shut OFF for any reason, there is a delay
before operation can begin again.
OTE: If the pool pump and heat pump pool heater
shut OFF before the water temperature is raised to
the desired level, you must lengthen the running time
of both. To do this, reset the time clock dial for the
longer running time, or manually operate the pump
with the timer override switch. Since the unit capaci-
ty and efficiency are both greater at higher ambient
air temperatures, run time should be set to take
advantage of all daylight hours, when the air is gen-
erally warmer.
•Is the Heat Light O ? If not, then the thermostat
setting is not higher than the temperature of the
water. Raise the thermostat setting.
C. CONDENSATION SEEMS EXCESSIVE
Heat pump pool heaters can produce a large amount
of condensation (water) during operation. If you sus-
pect that the unit is leaking:
a. Use a pool chemistry test kit to confirm there is no
chlorine in the condensation. Or,
b. Shut the unit OFF and leave the filter pump run-
ning to see if the water stops dripping. If the water
stops dripping, the unit is not leaking.
Service Call Verification
NOTE: The Raypak Service number is 800-260-2758.
For units in Canada, call 800-268-6966.
Before you make a service call, first determine if the
problem is:
•Warranty Service
•Unit operation (power supply, water flow, or time
clock adjustment)
Power Supply
•Verify that all circuit breakers are reset and work-
ing properly.
•If the temperature display still does not light, con-
tact the installing dealer, since it may be a power
problem requiring an electrician.
Water Flow
•Verify that the pool filter is clean to provide good
flow.
•Verify that valves are properly positioned to allow
adequate water flow through the unit.
OTE: The heat pump pool heater will not run when
the Remote position is selected on the Pool/Spa
selector switch and there is no remote control sys-
tem attached.
OTE: The MANUFACTURER IS NOT RES ON-
SIBLE for these adjustments.

14
Fault Code Meaning of Code
OFF The desired programmed temperature point is lower than 50°F (10°C).
LP There is a shortage of refrigerant gas in the unit or a faulty low pressure control, or the
ambient air is too cold.
LP3 The unit has encountered 3 LP faults within the same call for heat and shut down the unit
for protection. If this occurs, you should call for service.
HP There is low water flow in the unit or a faulty high pressure control. Check water
flow/backwash.
HP6 The unit has encountered 6 HP faults within the same call for heat and shut down the unit
for protection. If this occurs, you should call for service.
PSd The water temperature sensor is open or may be defective.
dSd The suction line temperature sensor is open or may be defective.
FLO
Possible causes:
• The filter is in backwash position.
• The filter pump is stopped.
• The filter is dirty.
• Shortage of water to pool pump.
• FIL parameter must be set to activate pool pump.
• Water flow switch may be broken.
FL3 The unit has encountered 3 FLO faults within the same call for heat and shut down the
unit for protection. If this occurs, you should call for service.
FS Unit is in the defrosting cycle.
FS5 The unit has gone into the defrosting cycle 5 times within the same call for heat and shut
down the unit for protection.
COL The unit is in the cooling mode.
HEA The unit is in the heating mode.
HOT The unit has gone into a fault mode during cooling.
- - Keypad is pressing down on both buttons. Replace keypad.
Table C: Control Board Fault Codes
Time Clock Adjustment
Verify that the time clock is set to permit the unit to run long enough to heat properly.

15
Plumbing Diagrams
WATER IN (FROM POOL OR SPA)
FILTER
CHECK
VALVE
CHEMICAL
INTRODUCTION
WATER OUT
(TO POOL OR SPA)
Fig. 6: For systems with pumps of less than 2 H (under 80 gpm), no external
bypass is required. Connections are 2-inch unions. lumb the heat
pump pool heater AFTER the filter and BEFORE any chlorinators.

WATER IN (FROM POOL OR SPA)
FILTER
CHECK
VALVE
CHEMICAL INTRODUCTION
WATER OUT (TO POOL OR
SPA)
Fig. 7: For systems with pumps of 2 H or greater (over 80 gpm), an external
bypass is required. Adjust the bypass valve to divert a minimum of 40
gpm through the heat pump pool heater. Connections are 2-inch unions. lumb the
heat pump pool heater AFTER the filter and BEFORE any chlorinators.
16

Fig. 8: ool iping for Heat ump ool Heater and Gas ool Heater
17

Fig. 9: ool iping for Heat ump ool Heaters, Multiple, rimary/Secondary
BRANCH MAIN BRANCH MAIN BRANCH MAIN
15 GPM 2" 2" 15 GPM 2" 2" 15 GPM 2" 2"
30 2" 2" 30 2" 2-1/2" 30 2" 3"
45 2" 2" 45 2" 3" 45 2" 4"
60 2" 2-1/2" 60 2" 3" 60 2" 4"
80 2" 3" 80 2" 4" 80 2" 5"
*Sizing based on 10 ft/sec flow rates
MINIMUM PIPE SIZES
2 UNITS
3-4 UNITS
5-6 UNITS
18

19
Wiring Diagram
208V/230V 3Ph,
60Hz Models

Wiring Diagram
460V 3Ph, 60 Hz
Models
20
