RBCBioscience MagCore Super Installation guide

Ver. 2020.09.10.04

1
Handle the power cord carefully.
Hold the plug when unplugging the cord.
Keep the set free from moisture, water, and dust.
Unplug the power cord when not using the set for
long periods of time.
Do not obstruct the ventilation space.
Do not let foreign objects in the set.
Do not let insecticides, benzene, and thinner come in
contact with the set.
Never disassemble or modify the set in any way.
Avoid high temperatures.
Leave space for sufficient heat dissipation during the installation.
CAUTIONS
Risk Of Electric Shock Do Not Open
Safety Precautions
Before use
WARNINGS and CAUTIONS stated below are intended to ensure safe operation, please follow them carefully.
CAUTION:
Do not remove the covers to reduce the risk of electric shock. Refer to the qualified
service technician for replacement of any inner parts.
CAUTION:
1. Handle the power supply cord carefully
Do not damage or twist the power supply cord. Damaged or twisted cord may
cause electric shock or malfunction when used. When you remove it from the outlet,
be sure to remove by holding the plug and not by pulling the cord.
2. Do not open the top cover
In order to prevent electric shock, do not open the top cover.
3. Do not place anything inside
Do not place metal objects or spill liquid inside the MagCore® System and wipe
away all spilled liquid to minimize the risk of system error and electric shock.
Note On Use:
1. Read Instructions – All the safety and operating instructions should be read before operating
the instrument.
2. Keep the Instructions – Please keep the safety and operating instruction manual for future
reference.
3. Cautions and Warnings – All warning signs should be attached on the product and shown
in the user's manual.
4. Follow Instructions – All operating instructions should be followed.
5. Cleaning – Unplug this product from the wall outlet before cleaning. Use only 75% of EtOH to
clean the surface of instrument.
6. Attachments – Do not attach anything on the instrument.
7. Liquid and Moisture – Do not use this product near water and avoid moist areas.
8. Accessories – Do not place this product on an unstable cart, stand, tripod, bracket, or
table. The product may fall and cause serious injury to a child or adult, and serious damage
to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the
manufacturer, or sold with the product. Any mounting of the product should follow the
manufacturer’s instructions, and should use a mounting accessory recommended by the
manufacturer.
9. Ventilation – Slots and openings in the cabinet are provided for ventilation, which is required
for safe operation as it minimizes the risk of overheating. This product should be placed on
a hard surface to ensure proper ventilation. This product should not be placed in a built-in
installation such as a bookcase or rack unless instructed by the manufacturer.
10. Power Sources – This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply at your lab,
consult the seller or local power company. For products intended to operate from battery
power, or other sources, refer to the operating instructions.
11. Grounding or Polarization – This product may be equipped with a polarized alternating-
current line plug. This plug will fit into the power outlet in one way only. This is a safety feature.
If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should
still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
12. Power-Cord Protection – Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed near or against them. Pay extra attention to plugs,
convenience receptacles, and the connecting point where the cord extends out of the product.
13. Lightning – Unplug the product if it will not be used again for a long period or in the case of a
heavy storm. This will prevent damage to the product due to lightning and power surges.
14. Overloading – Do not overload wall outlets, extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
15. Object and Liquid Entry – Never push objects of any kind into this product as they may touch
dangerous voltage points or short-out parts that could result in a fire or electric shock. Never
spill liquid of any kind on the product.
16. Servicing – Do not attempt to repair this product by yourself. Refer all servicing to qualified
service technician.
17. Damage Requiring Service – Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally following the operating instructions. Adjust only
those controls that are mentioned on the operating instructions for an improper adjustment
of other controls may result in damage and will often require extensive work by a qualified
technician to restore the product to its normal operation,
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance
– this indicates a need for service.
18. Replace Parts – When replacement of parts is required, be sure that the service technician
uses replacement parts specified by the manufacturer or those with similar features as the
original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.
19. Safety Check – Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to confirm that the product is in proper operating
condition.
20. Heat – The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products that produce heat.
General Warning
Warning: Biological Hazard
Warning: High Temperature
Warning: Electricity
SAFETY INSTRUCTIONS

2
RBCBioscience
Model Super / HF16 Plus
Processing Capacity Max .16 samples per batch
System Components 1. Pipetting Unit: X and Y-axis movement for sample transfer and dispense.
2. Electric Control: PLC module and ARM-based main board embedded.
3. UV Light: Power 8W, life duration 1,000 Hrs .
4. D2 Lamp life: 800 hours. ( MagCore Super Only )
5. Heating Block: RT~90° C .
6. OD detection range: ABS <6. ( MagCore Super Only )
7. Detection source: D2 lamp. ( MagCore Super Only )
8. Detection wavelength: 260nm, 280nm,320nm.
9. Display Screen: 7 inch colored touch panel .
10. Accessories: T - Rack, Cartridge Rack .
11. Barcode Scanner(MagCore HF16 Plus optional), embedded thermal printer. (MagCore Super only)
Power Supply Voltage: AC 100V~ 240V; Frequency: 50/60Hz
Dimension W760 x D710 x H770 (mm) / W27.95 x D29.92 x H30.31 (inches)
Net Weight 76.5kg / 168.68LB (MagCore Super) / 68.5kg / 151LB (MagCore HF16 Plus)
Specification
━ Operating Parameters
━ Operating Environment
━ Applications
Applications: Applications: Whole Blood DNA (200µl/400µl/1,200µl), Viral Nucleic Acid (DNA/RNA 200µl/400µl/1,200µl), FFPE Genomic
DNA, Forensic DNA, Plasma and Circulating Cell-Free DNA (1,200µl), Tissue Genomic DNA, Plant Genomic DNA, Bacterial DNA, Whole
Blood total RNA, Cultured Cells total RNA.
Processing Capacity 1~16 samples per batch
Processing Time 30-90 minutes (depends on sample type and method)
Sample Volume 200/400/1200 μl
Elution Volume 60/100/150/200 μl
Purity DNA : O.D A260/280 ratio 1.8 ± 0.1
RNA : O.D A260/280 ratio 2.0 ± 0.2
Temperatures allowed
during transportation
storage
packaging
15°C-35°C
Temperatures allowed
during
operation
18°C-30°C
Pollution Degree Level 2

3
CONTENTS
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
━ Before Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
IQ/OQ/PQ Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
━ IQ Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
━ OQ Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
━ PQ Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
━ Module Position Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Prepare Unpacking Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Install MagCore® HF16 Plus/Super . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
━ Installation settings and test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Touch Panel and User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
━ Install MagCore® Cuvette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
━ Install Tube, Tip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
━ Install reagent cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
━ Emergency Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
━ Start Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
━ If the test result of the optic measurement is over detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
━ Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
━ Enable the barcode function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
━ Barcode scanning and editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
━ Optic data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Easy maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
━ Replace O-Ring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
━ Piston Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
━ Clean Piercing Needles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
━ Reject Tip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
━ Heater Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
━ Optic Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
━ UV sterilization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
━ Alarm History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
━ System Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
━ Update Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
━ Clean the Waste Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
━ Replace thermal paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
━ Replace fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Advanced maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Disassemble the back service lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Disassemble the top service lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Axis directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Replace the UV lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Replace LED Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Replace the optic lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

4
RBCBioscience
Replace optic lamp power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Replace the pistons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Replace the ejector rod module.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Replace the heater module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Replace the gas spring on the front door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Replace Door Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Replace the M-axis sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Replace the sensors of C, V, X and Y axes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Replace Cooling Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Replace the X-axis stepper motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Replace the Y-axis motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Replace the Y-axis belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Replace the V-axis motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Replace the C-axis motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Replace the C-axis timing belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Replace the lift motor of the base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Replace the timing belt of the lift motor of the base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Replace PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Replace PLC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Replace Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Replace Touch Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Replace Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Electrical control and engineering software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Main board configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
PLC configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Copy the engineering software to the desktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Install the HMI updating software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Create an uploading folder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Install the driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
HMI updating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
PLC updating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Position Teaching Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
The pre-operation before calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
X-axis calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Y-axis calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
C-axis calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81
Automatic Optical Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
Optical Calibration Flow Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
Empty Cuvette Test of standard cuvette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
Standard Cuvette Vaule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Adjust integration time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Start Optical Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Trouble Shooting for Alarm Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89

5
Accessories
1. T-Rack X 2
2. Cartridge Rack X 2
3. Power Cable X 2 (Europe standard and U.S.A standard)
4. Grease X 1
5. 3mm O-Rings X 16
6. 5mm O-Rings X 16
7. Empty Cartridge X 10
8. Sample Tube /Elution Tube X 20
9. Pipette Tip X 20
10. MagCore Cuvette Set(10pcs) X 1
11. Waste Box X 1
12. Barcode Scanner X 1 (MagCore Super Only)
1 2 3 4 5
7
6
8 9
10 11 12
You can purchase Cat. No.: MSC100 MagCore Cuvette Set (X100) from the
local distributor.
(MagCore Super Only) (MagCore HF16 Optional)
Specification

6
RBCBioscience
━ Before Installation
Installation
Please refer to the machine size shown in the above figure to prepare an appropriate position for the
machine and reserve space for heat dissipation.

7
━ IQ Documents
IQ/OQ/PQ Documents

8
RBCBioscience
━ OQ Documents

9
━ PQ Documents

10
RBCBioscience
System Overview
Slots
There are a total of 16 slots
(number 1~16 from left to
right)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

11
━Module Position Description
Liquid handling
module
Work
platform
Heating module
Optic module
(Super Only)
Frame
Gantry structure

12
RBCBioscience
Unpacking
Prepare Unpacking Tools
If the cargo is damaged, White Red If the cargo is upside down, Sliver Red
2. Phillips Screwdriver
1. Hex Wrench (3mm)
3. Scissors

13
Install MagCore® HF16 Plus/Super
Proceed installation procedures after placing the instrument on a solid bench-top.
1.Use screw drivers to loosen the screws as shown in the picture.
2.Remove the red fixing plates.
3.Save all the materials for maintenance for future use.

14
RBCBioscience
━ Installation settings and test
Step 1.
Please set up the local time.
Please refer to System Status chapter for the
information about the operation.
(Please refer to P.28)
Step 2.
Test piston
Please refer to Piston Test chapter for the
information about the operation.
(Please refer to P.23)
Step 3.
Test heater
Please refer to Heater Test chapter for the
information about the operation.
(Please refer to P.26)
Step 4
Test optic module
(MagCore® Super Only)
Please refer to Optic Test chapter for the
information about the operation.
When the optic module test is finished, please
compare the result with the reference sheet
to make sure the optic module is functioning
properly. (Please refer to P.82)

15
Touch Panel and User Interface
MagCore® Super / HF16 Plus provides 7-inch
full-color touch panel and easy-to-use user
interface. The operation screen will show the
current status, ending time and test report of the
machine. The above figure shows the function
list of the operation screen and the description
of the status icons.
Start
Barcode
Maintenance
Optics
Execute the
extraction process Easy maintenance and system settings
Optics data browsing and
output functions
(MagCore Super only)
Barcode scanning,
editing, printing
functions
(optional for MagCore HF16
Plus)

16
RBCBioscience
━ Install Tube, Tip
Warning :
Please do not use the Tips and Tubes that are not provided by the original manufacturer.
The test result may be not correct and the machine may be damaged due to different tip
designs.
━ Install reagent cartridge
━ Install MagCore® Cuvette
 
(MagCoreSuperOnly/foroptictest)
1. Please put MagCore® Cuvette into the
corresponding sample's well. The installation
of Cuvette is unidirectional. It is not possible to
put it into the well if the direction is not correct.
2. Put the 200 μl SP tip into the W4 of the T-Rack.
Please insert the front end of the cartridge into the space
below the fixing plate of the Cartridge Rack.
1. Put the tip into the corresponding well according to the left
figure.
2. Put the T-Rack into the machine.
Please install the Tip and Tube
according to the instructions on the
extraction kit user manual.
Please insert the Cartridge Rack before
the T-Rack.
W5 Elution Tube
W4 200μl SP Tip
W3 Pipette Tip
W2 DNase / Tip Holder set
W1 Sample Tube - FS Tip
When installing it,
please do not scratch
the optic test window.

17
━ Emergency Stop
Please read the security information to correctly stop the machine
when an accident takes place.
When an emergency situation occurs and the
machine is still running, please press the stop
button or open the door of the machine to stop
the machine immediately.

18
RBCBioscience
Please confirm the number of the reagent set
which you install.
Select the number of the cartridge.
Select DNase Treatment. (Only for RNA kit.)
Select Sample Volume.
Select Elution Buffer. (Only for tissue kit.)
Please pretreat the sample according to the
instructions on the MagCore® extraction kit user
manual and put consumables into the machine.
Press Start to go to the next step.
System will ask you whether or not to scan the
barcode.
If there is a barcode record from previous test
processes, the system will ask you whether or not
to delete the previous barcode record. If there is
no barcode record, the system will not ask you.
(MagCore Super only; optional for HF16 Plus)
━ Start Programs
!The number can be
found in the sticker on
the cartridge.
1
2
3
5
6
4

19
━ If the test result of the
optic measurement is over
detection
Select to enable or disable the optic measurement
function. (MagCore Super Only)
( 201, 202, 211, 105 without the function)
Please confirm the parameters and press the Start
button to execute the program.
Automatic extraction process.
The extraction process is completed.
If you select the optic measurement funtion, you
can browse, print or output the test result to a USB
Flash Drive (please refer to the optic data chapter).
f
A.Please record and save the
current measured data.
Please select YES.
Please check the value of each sample. If
there is a value showing DNA >300 ng/
μl or RNA > 240 ng/μl, please record
the number of the sample. It means the
sample needs to be diluted. After recording
the number of the slot, please insert the
USB Flash Drive and press the Save button
to save to current measured data. After
finishing the above steps, please press Next
Step.
10
7
8
9
1
The values are DNA >300 ng/μl /
RNA > 240 ng/μl
Please save the data in the USB Flash Drive
and transfer to computer, or the data in
the USB Flash Drive may be overwritten
later.
File name: OpticsSampleData.cvs
(MagCore Super Only)
