RC4WD BEAST II User manual

1/14 Beast II 6 x 6 chassis with Mil-Spec Hard Body
Are you ready for the end of days?
The opportunities are limitless with
the Beast II Truck Kit! Sunday driver
to world domination. It’s up to the
imagination to complete your Beast
II.
The Beast II has unmatched scale detail,
allowing for a realistic model or a true
performance oriented 6x6 trail truck.
The Beast II is built with engineering
and design first. Packed with great
products like the R3 2 speed transmis-
sion, Yota II axles, Triton transfer case,
Mil-Spec ZXL tires and 1.9” Humvee
beadlock wheels.
There are no better options! Beast II...
What's in store for you?
SIX WHEEL DRIVE R3 TRANSMISSION BEAD LOCK WHEELS
FEATURES
RTR

1/14 Beast II 6 x 6 chassis with Mil-Spec Hard Body
The All New R3 Scale 2 Speed Transmission comes
with a tough cast metal case and new widened gears
to allow for more abuse along with a Delrin Spur with
slipper clutch. Also features a sturdy billet aluminum
motor mount for durability.
The Beast II includes the new Triton Transfer Case.
Packed with scale detail, the Triton features a cast metal
exterior and heavy duty 32P Widened Steel Gears for
durability.
Drawing on the success of the RC4WD MOA Gear
Sets, the Beast II Drivetrain has the most resistant
gears RC4WD has to offer so the Beast II can stay on
the trail day after day.
The most scale accurate axles on the market, the
RC4WD Cast Yota II Axles feature innovative 8 degree
round knuckles, unique removable diff covers, new
mounting points and a compact offset pumpkin in front.
The Drive Shafts for the Beast II are an all new
design featuring bulletproof steel universals and a
new high quality plastic shaft for great driveline angles
and durability on the trail.
RTR

The Beast II Chassis features multiple options to allow
you complete customization and personal setup for
your electronics. We also provide battery slots and
velcro straps for easy battery placement.
The Beast II includes a set of our RC4WD Dual Spring
Shocks. An all new design, these ultimate scale
shocks provide realistic looks and ultimate perfor-
mance. They’re machined from billet aluminum with
dual springs.
The All New Beast II Chassis is a machined billet
aluminum ladder frame with an all link suspension
design, scale shock hoops, chassis servo mounts and
hard body mounting points for maximum strength.
The Beast II includes a set of RC4WD Black Humvee
1.9” Internal Beadlock Wheels featuring super tough
black finish and aluminum internal locking rings.
The Beast II is a military specification truck. It must have
a tough set or rock grabbing tires and the included
Mil-Spec ZXL in Advanced X4 Medium Compound deliver
traction as well as perfect scale appearance in just the
right size.
RTR

The Beast II 6x6 Chassis with Mil-Spec Hard Body.
The Beast II Body has an amazing assortment of
scale details including mirrors, spare tire holder and
handles to replicate a 1:1 vehicle.
Military looks and details. The Beast II Body Set is a
detailed replica of the full scale vehicle! The Mil-Spec
Body allows everyone to know it means business.
The Beast II Body Set comes in durable hard plastic
with molded green color for that perfect military look.
Every detail from the molded body set is painstakingly
installed for an amazing finish.
The Mil-Spec Body Set is made up of 100 parts and
pieces. It’s all here to bring your build to next level. Metal
detail parts are included to bring the realism to life includ-
ing lenses for signal lights. Easy to add lighting kit (sold
separately).
All details were captured with the Mil-Spec Body Set to
make this a great scale body and an awesome scale
build!
RTR

RTR
The Beast II Chassis includes a high quality XR3 3
Channel 2.4Ghz Radio System. Use the third channel to
control the winch and add even more fun to your scale
adventure!
The Beast II Chassis is powered by the nearly inde-
structible RC4WD 55 Turn Crawler Motor. With its sealed
endbell for increased durability and long lasting perfor-
mance, you’re sure to get where you’re going!
The Beast II Chassis features the popular RC4WD
Outcry Brushed Speed Controller with built-in drag brake
and a separate 6V 5amp Turbo BEC for reliable, constant
power on demand. Anytime.
A great truck needs a great servo to get you out of
those tough spots and the Beast II Chassis features
the Twister. A high torque metal gear digital servo to
handle all your steering duties.
Featuring a massive 153oz@6V of torque and a full
metal geared drivetrain, the RC4WD Twister Metal Gear
Digital Servo has the power and performance you need
when the turning gets tough.

60MM (2.4")
226MM (8.9'')
408MM (16.1")
211MM (8.3'')
617MM (24.3'')
211MM (8.3'') 211MM (8.3'')
226MM (8.9'')
226MM (8.9'')
Triton Transfer Case
Ratio - 1:1 Gearing 32P Hardened Steel
Gears, 8 Bearing Design, Cast Casing
All New R3 Scale 2 Speed Transmission
Ratios: Pinion/Spur 14/64 = 4.57:1
Internal Ratios: 1.78:1 Gears - Wide Steel
32P, Delrin Spur, Slipper Clutch
All New Cast Yota II Axles
Ratio: 15/40 = 2.67:1 Width at Hex
180.5mm
Beast II Suspension
Double Triangulated 8 Link Rear Suspen-
sion
3 Link Front Suspension with Panhard Bar
Shock Absorbers
Dual Spring 80mm Shocks - Can be oil
filled
Wheels
Humvee 1.9” Internal Beadlock Wheel
Hub: Hex Type
Width: 25mm
Back Spacing: 16mm
Bumpers
Machined Billet Aluminum, Lightweight
Beast II Dimensions
Wheels Base F-R: 408mm (16.1”)
Wheels Base F-M: 292mm (11.496”)
Width: 211mm (8.3”)
Height: 226mm (8.9”)
Ground Clearance: 60mm (2.4”)
Final Drive Ratio: 1st - 62.1:1, 2nd - 22.75:1
