RCA RPJ129 User manual

MODEL NO.: RPJ129
Smart Android Wi-Fi Home Theater Projector
INSTRUCTION MANUAL
PLEASE READ BEFORE OPERATING THIS EQUIPMENT
This product is manufactured and sold by Curtis International Ltd.
RCA, the RCA logo, the two dogs (Nipper and Chipper) logo, are registered trademarks
or trademarks of RCA Trademark Management and are used under license by Curtis
International Ltd. Any other product, service, company, trade or product name and logo
referenced herein are neither endorsed nor sponsored by RCA Trademark Management or
its affiliates.

1
Important Safety Instrucons
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifier) that product heat.
9. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
10. Only use attachments/accessories specified by the manufacturer.
11. Unplug this apparatus during lightning storms or when unused for long periods of time.
12. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate normally, or has been dropped.
13. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.

2
Addional Warnings and Precauons
1. Do not look directly into the projector light.
2. Don’t touch the projector lens
3. Mains adapter is used as disconnect device and it should remain readily operable during
intended use. In order to disconnect the apparatus from the mains completely, the mains
plug should be disconnected from the mains socket outlet completely.
4. CAUTION: Use of controls or adjustments or performance of procedures other than
those specified may result in hazardous radiation exposure.
5. WARNING: Changes or modified to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
6. WARNING: Use of this unit near fluorescent lighting may cause interference regarding
use of the remote. If the unit is displaying erratic behavior move away from any
fluorescent lighting, as it may be the cause.
7. WARNING: Shock hazard - Do Not Open.
8. Caution and marking information is located at the rear or bottom of the apparatus.
9. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to
rain, moisture, dripping, or splashing.
10. Objects filled with liquids, such as vases, shall not be placed on the apparatus.

3
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
噝Reorient or relocate the receiving antenna.
噝Increase the separation between the equipment and receiver.
噝Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
噝Consult the dealer or an
Remote AC Power Adapter Lens Cover User Manual
Main unit
experienced radio/TV technician for help.
In The Box
FCC Warning FCC ID:2ANH7696PJ38
0
0
OK
SETUP
1 2 3
456
78 9
MODEL NO.: RPJ129
Smart Android Wi-Fi Home Theater Projector
INSTRUCTION MANUAL
PLEASE READ BEFORE OPERATING THIS EQUIPMENT
This product is manufactured and sold by Curtis International Ltd.
RCA, the RCA logo, the two dogs (Nipper and Chipper) logo, are registered trademarks
or trademarks of RCA Trademark Management and are used under license by Curtis
International Ltd. Any other product, service, company, trade or product name and logo
referenced herein are neither endorsed nor sponsored by RCA Trademark Management or
its affiliates.
The distance between user and products should be no less than 20cm

4
ImportantSafetyInstructions----------------------------
Table of Contents
P1
AdditionalWarningsandPrecautions---------------------- P2
FCCWarning----------------------------------------- P3
InTheBox----------------------------------------- P3
Table of Contents -- ----------------------------------- P4
Remove&ClosetheLensCover-------------------------- P5
PlacementofYourProjector----------------------------- P5
ToReduceImageDistortion -------------------- P6
DistanceBetweenTheProjectorAndScreen---------------- P6
Installing your projector in the Ceiling - - - - - - - - - - - - - - - - - - - - - P6
Adjust the Vertical Position - - - - - - - - - - - - - - - - - - - - - - - - - - - - P7
Adjust the Focus and Keystone - - - - - - - - - - - - - - - - - - - - - - - P7
ControlsofRemote ----------------------------------- P8
Install/RemoveBatteriesofRemote----------------------- P8
ControlsofProjector --------------------------------- P9
InstallPowerAdapter --------------------------------- P10
MainButtonOperation--------------------------------- P10
ConnectHDMIshowtheImageOnProjectorScreen --------- P11
ConnectAVShowTheImageOnProjectorScreen------------ P11
Connect VGA Show The Image On Projector Screen - - - - - - - - - - - P12
ConnectAudioOutput(AuxOut/LineOut)------------ P13
InstallUSBDevice------------------------- P13
UsingUSBPlayback(MediaPlayer)----------------------- P14
UsingProjectorMenu1------------------------------- P15
UsingProjectorMenu2------------------------------- P16
UsingProjectorMenu3------------------------------- P17
UsingProjectorMenu4------------------------------- P17
ProjectorHomeScreen------------------------------ P18
ConnecttoWi-Fi-------------------------------------- P18
TheMenuSettings------------------------------------- P19
InstallandUninstallApps-------------------------------- P20
Video Streaming (playing online TV and movies) - - - - - - - - - - - - - P20
BrowserFunction------------------------------------- P20
Multi-screen Interactive Connection for Phone and Projector - - - - P21
Specifications---------------------------------------- P22

5
Remove & Close The Lens Cover
Front Table:
Placement of Your Projector
Your projector can be installed in four different configurations ( see picture below):
Select this location with the projector placed near the floor in
front of the screen. This is the most common way to position the
projector for quick setup and portability.
Rear Table:
Select this location with the projector placed near the floor
behind the screen.
NOTE: A special rear projection screen is required.
Front Ceiling:
Select this location with the projector suspended upside-down
from the ceiling in front of the screen.
NOTE: A projector mount is required to install the projector in a
ceiling.
Rear Ceiling:
Select this location with the projector suspended upside-down
from the ceiling behind the screen.
NOTE: A projector mount is required to install the projector in a ceiling.
Aspecial rear projection screen is required.
LENS COVER
REMOVE CLOSE
LENS COVER
Front Ceiling
Rear Ceiling

6
To reduce Image Distoron
• Move the projector as close to the center of the screen as possible.
• The light beam from the projector should be perpendicular to the
screen for a rectangular or square image.
Distance Between The Projector and Screen
Measure the distance between the projector and where you want to position the
screen. This is the projection distance.
Installing Your Projector In the Ceiling
When installing the projector in the ceiling, please purchase a projector mount
recommended by an installation professional and follow the instructions that come with
the mount.
Before installing the projector in the ceiling, please check to make sure the ceiling
structure can support the weight of the projector and the mount. If in doubt, please ask
the advice from an installation professorial.
NOTE: Projector mount and screw(s) not included
Distance
2.0m
2.38m
2.74m
2.82m
3.27m
3.87m
4.7m
5.65m
Screen Size
60 inch
72 inch
84 inch
86 inch
100 inch
120 inch
140 inch
160 inch
CEILING
HANGER
SCREENSIZE
DISTANCE
FIX HANGER HOLES

7
Adjust the projector's vertical position by following the illustrations below:
Adjust The Vercal Posion
Keystone image is created when the projector lens is projected from above or below
the center of the screen. Keystone correction restores the distorted image to a
rectangular or square shape.
Adjust The Focus And Keystone
Follow below picture to adjust the focus and trapezoidal screen.
Adjust the focus by turning the lens while observing the image pixels near the center of
the screen. Optimal focus is obtained when the pixels are clearly visible. Depending on
the projected screen size, the focus near the screen edges may be less sharp than the
screen center.
SCREEN
VERTICAL
DIMENSION
PROJECTOR
VERTICAL
DIMENSION
PROJECTOR
SCREEN
VERTICAL
DIMENSION
PROJECTOR
SCREEN
Press the "PUSH" button (Button 3 page 9)
to extend the front leg and adjust the vertical
height of the projector.
DC IN
KEY STO NE
USB 1
USB 2
HDMI 1
HDMI 2
VGA
VIDEO
FOCUS ADJ. KNOB
KEYSTONE CORRECTION KNOB

8
Controls of Remote
Install / Remove Baeries of Remote
Remove the battery compartment cover on the back of the remote by carefully sliding
to open. The battery cover can then be lifted away. Fit the correct batteries (not
included), referring to the polarity markings. Finally, replace the cover.
NOTES:
l
l
l
l
l
l
AAA / UM4
AAA / UM4
BATTERY DOOR
0
OK
SETUP
1 2 3
456
78 9
POWER ON/OFF MUTE AUDIO SOUND
SEARCH FORWARD OR
REWIND
SHOW MOUSE CURSOR
ENTER TO MENU
NAVIGATOR
EXIT THE MENU
0~9 NUMERIC BUTTON
BACK SPACE
SKIP NEXT/PREVIOUS FILE
PLAY/PAUSE
SOURCE SELECTOR
SELECT VOLUME SOUND
TO HOME PAGE
TO SETUP PAGE
OK
OK
SETUP
Batteries shall not be exposed to
excessive heat such as placing under the
sunlight or near a fire.
Please make sure the batteries are
installed with their correct polarities.
Do not mix old and new batteries.
Use only the same type of batteries.
Do not dispose of the batteries in fire,
battery may explode or leak.
Do not recharge a non-rechargeable
battery.
+-
-+

9
1. IR Sensor ( Front Side)
2. LENS
3. ANGEL ADJ. Button
4. FOCUS ADJ. Knob
5. NAVIGATOR Buttons
6. RETURN Button
7. POWER on Indicator
8. POWER Button
9. SOURCE Button
10. SETUP Button
11. KEYSTONE ADJ. Knob
12. VIDEO IN Jack
13. USB1 / USB2 Port
14. HDMI 1/ HDMI 2 Port
15. DC IN jack
16. AUDIO OUT R/L Jack
17. IR Sensor (Rear Side)
18. AUDIO IN R/L Jack
19. VGA IN Jack
Controls of Projector
PUSH
32 1
4
5
7
6
8
95 10
DC IN
KEYSTONE
USB 1
USB 2
HDM I 1
HDM I 2
VGA
VID EO
11 12 13
15 16
14
17 18 19
