In The Box

ROKU

Main unit

Lens Cover

Remote

User Manual

AC Power Adapter

Two AAA

Batteries

Roku Express+

USB Power Cable

RemoteRoku

HDMI Cable

Table of Contents

Important Safety Instructions - - - - - - - - - - - - - - - - - - - - - - - - - - - P1

Additional Warnings and Precautions - - - - - - - - - - - - - - - - - - - - - P2

FCC Warning - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P3

In The Box - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P3

Table of Contents - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P4

Remove & Close The Lens Cover - - - - - - - - - - - - - - - - - - - - - - - - P5

Placing of Your Projector - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P5

To Reduce Image Distortion - - - - - - - - - - - - - - - - - - - - - - - - - - - - P6

Distance Between The Projector And Screen - - - - - - - - - - - - - - - - P6

Installing your Projector in the Ceiling - - - - - - - - - - - - - - - - - - - - P6

Adjust the Vertical Location - - - - - - - - - - - - - - - - - - - - - - - - - - - - P7

Adjust the Focus And Keystone - - - - - - - - - - - - - - - - - - - - - - - P7

Controls of Remote - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P8

Install / Remove Batteries of Remote - - - - - - - - - - - - - - - - - - - - - P8

Controls of Projector - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P9

Install Power Adapter - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P10

Main Button Operation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P10

Setup / Install the Roku Express+ - - - - - - - - - - - -- - - - - - - - - - P11

Connect HDMI show The Image On Projector Screen - - - - - - - - - P12

Connect AV Show The Image On Projector Screen - - - - - - - - - - - P12

Connect VGA Show The Image On Projector Screen - - - - - - - - - - P13

Connect Audio Output (Aux Out / Line Out / Earphones) - - - - - - - P14

Install USB Device And TF card (Micro SD Card) - - - - - - - - - - - - P14

Using TF Card and USB Playback (Media Player)- - - - - - - - - - - - - P15

Using Bluetooth Playback - - - - - - - - - - - - - - - - - - - - - - - - P16

Using Projector Menu 1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P17

Using Projector Menu 2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P18

Using Projector Menu 3 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P18

Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P19

Warranty Card - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P20

EXIT

SKIP PREVIOUS/ NEXT FILE SEARCH REWIND OR

FORWARD

SETUP

ENTER TO HOME SCREEN

Remove & Close The Lens Cover

Remove the lens cover before using Close the lens cover when unit is not using

Placing of Your Projector

Your projector can be installed in four different configurations (see picture below):

Front Table:

Select this location with the projector placed near the floor in front

of the screen. This is the most common way to position the

projector for quick setup and portability.

Rear Table:

Select this location with the projector placed near the floor behind

the screen.

NOTE: That a special rear projection screen is required.

Front Ceiling:

Select this location with the projector suspended upside-down

from the ceiling in front of the screen.

NOTE: A projector mount is required to install the projector in a

ceiling.

Rear Ceiling:

Select this location with the projector suspended upside-down

from the ceiling behind the screen.

NOTE:

A projector mount is required to install the projector in a ceiling.

A special rear projection screen is required.

Front Ceiling

Rear Ceiling

Rear Table

Front Table

To reduce Image DistŽƌƟŽŶ

Distance Between The Projector And Screen

Measure the distance between the projector and where you want to position the

screen. This is the projection distance for reference.

Installing your Projector in the Ceiling

When installing the projector in the ceiling, please purchase a projector mount

recommended by an installation professional and follow the instructions that come with

the mount.

Before installing the projector in the ceiling, please check to make sure the ceiling

structure can support the weight of the projector and the mount. If in doubt, please ask

the advice from an installation professorial.

NOTE: Projector mount and screw(s) not included

Distance

1.16m

1.35m

1.51m

1.79m

2.15m

2.81m

3.43m

4.44m

Screen Size

36 inch

45 inch

50 inch

60 inch

72 inch

100 inch

120 inch

150 inch

120

100

THECENTEROFLENS

SCREEN

3URMHFWLRQ

'LVWDQFH

VHH WKH WDEOH

• Move the projector as close to the center

of the screen as possible.

• The light beam from the projector should

be perpendicular to the screen for a

rectangular or square image.

FIXED HANGER HOLE

(6mm diameter)

HANGER

CEILING

Adjust The VerƟcal LocaƟŽn

Follow below picture to adjust the vertical location.

Adjust The Focus And Keystone

Adjustthisknob( ANGLEADJ. knob)

to¿QH-tunHthHdisplayanglHtohighHr.

SCREEN

PROJECTOR VERTICAL

DIMENSION

VERTICAL

DIMENSION

SCREEN

PROJECTOR

VERTICAL

DIMENSION

SCREEN

PROJECTOR

,PDJH $GMXVWPHQW

)RFXV $GMXVWPHQW

,QFUHDVH RUUHGXFHWRLPDJH VL]HWRVKDUSHQLPDJH

.H\VWRQH $GMXVWPHQW

$GMXVW LPDJH FRUQHUV WR UHGXFH LPDJH GLVWRUWLRQ

KeystoneADJ. KNOB

FOCUS ADJ. KNOB

Then sharpen the image

by rotating focus knob.

Follow below picture to adjust the focus and trapezoidal screen.

Adjust the focus by turning the knob while observing the image pixels near the center of

the screen. Optimal focus is obtained when the pixels are clearly visible. Depending on

the projected screen size, the focus near the screen edges may be less sharp than the

screen center.

Keystone image is created when the projector lens is projected from above or below the

center of the screen. Keystone correction restores the distorted image to a rectangular or

square shape.

Controls of Remote

Install / Remove BaƩeries of Remote

Remove the battery compartment cover on the back of your remote by carefully sliding to

open. The battery cover can then be lifted away. Fit the correct batteries (not included),

referring to the polarity markings. Finally, replace the cover.

NOTES:

zBatteries shall not be exposed to excessive heat

such as placing under the sunlight or near a fire.

zPlease make sure the batteries are installed with

their correct polarities.

zDo not mix old and new batteries.

zUse only the same type of batteries.

zDo not dispose of the batteries in fire, battery may

explode or leak.

zDo not recharge a non-rechargeable battery.

ROODYRE

TTA

Controls of Projector

1 LENS

2 ANGEL ADJ. Knob

3 VGA IN Port

4 IR Sensor

5 FOCUS ADJ. Knob

6 KEYSTONE ADJ. Knob

7 MENU Button

8 Vol- Vol+ Buttons

9 RETURN Button

10 Buttons

11. POWER Button

12 POWER Indicator

13 Button

14 HOME Button

15 TF Card Slot

16 Audio Out Jack

17 AV IN Jack

18 HDMI 1 & 2 Ports

19 USB 1 Port

20 DC IN Jack

21 Roku Express+

22. USB 2 (For powering the Roku Express+)

23. HDMI 3 (Roku Express+ input)

15 1617 18 19 20

Right Side View

Front View Rear View

21 2223

Left Side View

Install Power Adapter

Main BuƩon OperaƟŽŶ

- Press the button to switch on unit, press again to standby.

/ HOME - Press the button to select input source.

/ MENU - Press the button to enter projector menu.

- Press the buttons to navigate and select screen item of menu.

/EXIT - Press the button to return to previous status or exit the menu.

- Press the buttons to fast search forward and rewind on USB / TF

- Press the buttons to search next or previous file on USB / TF

VOL+ / VOL - Press the buttons to select the sound level on the remote.

-Press the button to play/pause the playback of file on USB / TF card.

FLIP – Press the button to rotate / mirror projector screen on the remote

ZOOM - Press the button to select image scale on the remote

- Press to mute the audio. Press again to resume.

Follow below picture to connect power adapter

Connect small end of adapter FIRST. Plug the adapter body to power outlet.

WARNING:

Before connecting to the power supply, ensure that the supply corresponds to the

information on the rating label at the back of the apparatus.

Setup /Install the Roku Express+

Make your Projector smart! Stream almost anything across thousands of free or paid

streaming channels including hit movies, popular shows, live TV, news, sports and more.

Step 1: Install the Roku Express+.

Turn off the unit, use the included HDMI cable to plug into the HDMI port on your Roku

Express+ port and the other end plug into the HDMI3 port

on your projector.

Step 2: Connect to power

Use the included USB power cable plug into the USB port

on your Roku Express+ and the other end to plug into the

USB2 port on your projector.

Note: Unit has already installed the Roku Express+ before shipment.

Press the button to turn on the unit. The projector home screen will appear. Use the

arrow buttons to select the HDMI3 input.

Step 3: Pair your Roku

remote

On the back side of the remote, slide open the battery

cover. Insert included batteries placing the negative(-)

ends in first. Follow the on-screen instruction, your

remote should pair your Roku Express+ automatically.

For help pairing your remote, visit go.roku.com/remote

help

Note: To operate your Roku Express+, you must use the

included Roku remote.

Step 4: Complete on-screen setup and start streaming

Tip: Have your wireless network name and password

handy.

Follow the instructions on your TV screen. Activate

your streaming player by using your computer or

smartphone to link to a Roku account.

You need a Roku account to activate your Roku

Express+ and access entertainment across thousands

of streaming channels.

Note: Roku never charges for activation support.

Roku accounts are free and while a valid credit card number is not required to

create a Roku account, saving your credit card information makes renting,

purchasing, and subscribing to entertainment from the Roku Channel Store fast

and convenient.

Once connected to your account, your streaming player

will automatically update with the latest software, and you

can start streaming immediately.

If you aren’t ready to connect your streaming player to a

wireless network, you can still use the projector.

MODEL NO. RPJ133-B

Home Theater Projector

PLEASE READ BEFORE OPERATING THIS EQUIPMENT

Ideal for dark viewing environments for optimal performance.

Please note:Projector brightness is measured in ANSI lumens.

Your viewing environment is the deciding factor on how many lumens

your projector needs.

This product has been manufactured and sold under the responsibility of Curtis

International Ltd.

RCA, the RCA logo, the two dogs (Nipper and Chipper) logo, are registered

trademarks or trademarks of Technicolor (S.A.) or its affiliates and are used under

license by Curtis International Ltd.

ROKU, STREAMING STICK and the ROKU logo are the trademarks or registered

trademarks of Roku, Inc.

Any other product, service, company, trade or product name and logo referenced

herein are neither endorsed nor sponsored by

Technicolor (S.A.) or its Affiliates.

LENS COVER REMOVE CLOSE

LENS COVER

CAUTION

FOCUS

KEYSTONE

CAUTION

FOCUS

KEYSTONE

roku.com/link

CAUTION

FOCUS

KEYSTONE

789

Top View

NG THIS

MODELNO.

RPJ133_12DISP2

HomeTheater Projector

PLEASEREADBEFORE OPERATING THIS EQUIPMENT

Idealfordarkviewing environments for optimal performance.

Pleasenote:Projectorbrightnessis measured in ANSI lumens.

Yourviewingenvironmentis the deciding factor on how many lumens

yourprojectorneeds.

Thisproducthasbeen manufactured and sold under the responsibility of Curtis

InternationalLtd.

RCA,theRCAlogo, the two dogs (Nipper and Chipper) logo, are registered

trademarksortrademarksof Technicolor (S.A.) or its affiliates and are used under

licensebyCurtisInternational Ltd.

ROKU,STREAMINGSTICKand the ROKU logo are the trademarks or registered

trademarksofRoku,Inc.

Anyotherproduct,service, company, trade or product name and logo referenced

hereinareneitherendorsed nor sponsored by

Technicolor(S.A.)orits Affiliates.

NGTHIS
