RCA DS2122RD User manual

DIGITAL
Changing Entertainment. Again.
DS2122RD
DIRECTV1System
• Accelerated 32-Bit Processor
• SurfGuide™
• Interactive Channel Banner features:
– Guardian™
– AlphaSort™
– Scout™
– Home Control2
• Master Touch®Universal IR Remote3
• Satellite Dish Antenna
– 18" Wide
– Single Output LNB
Only 18 inches wide

1 DIRECTV is a trademark of DIRECTV, Inc., a unit of Hughes Electronics Corp.
2 When used in conjunction with our Home Control HCDSS10 accessory kit.
3 Controls the RCA DIRECTV System plus most brands of remote controllable
TVs. Feature compatibility varies by brand and model.
Residents of Alaska: The RCA DIRECTV receiver requires a larger dish antenna
(not included) to receive DIRECTV
®
programming. Signal reliability and
performance will be susceptible to degradation especially during adverse
weather conditions.
Check your local dealer or installer for information on larger antennas which
may be compatible with the RCA DIRECTV receiver.
©1999 Thomson Consumer Electronics, Inc.
Form S-DS2122RD
Trademark(s) ® Registered
Marca(s) Registrada(s)
Photos and features subject to change without
notice. Illustration of product finish may vary
from actual color.
PC12857
Changing Entertainment. Again.
Get more information on
RCA Consumer Electronics Products at www.rca.com
DS2122RD (Single Output LNB)
SATELLITE IN
OUT
TO
TV S-VIDEO
VIDEO
R
L
AUDIO
HOME
CONTROL
IN
FROM
ANT
PHONE JACK
Accelerated 32-Bit Processor
A 32-Bit processor is at the heart of this new
system. The accelerated performance allows
immediate access to all the new interactive
features.
Advanced On-Screen Program Guides
• SurfGuide™
The SurfGuide brings up seven channels of
programs at a time. Surf up and down the guide,
viewing the current 30-minute or up to a two-
hour time window of programming. You’ll never
miss out on any of the action of your current
show, because it stays active in the background
while you explore other channels.
• Information Guide
Lists five different channels of programming
at a glance. Details on the current highlighted
program are displayed in a banner at the top
of the screen. Program information changes
automatically as the consumer navigates through
the guide and highlights different programs.
• Full Seven-Line Program Guide
Provides channel and program title information
for seven different channels covering a two-hour
time window. Arrows help indicate programs
starting before or ending after the current time
shown on the grid.
Interactive Channel Banner
The new translucent, see-through Interactive
Channel Banner makes access to the key features
of the DIRECTV1System fast and easy. We’ve
taken the most exciting new features, created
icons for each of them, and positioned them in
the banner for direct access.
• The Guardian™
With this feature, parents have the ability to lock
out specific channels and set rating and spending
limits. They will be able to set specific viewing
times for both the weekdays and the weekends.
• AlphaSort™
AlphaSort allows you to sort the current guide
alphabetically, starting with any letter you choose.
Go directly to any listed show with the push of
one button.
• Scout™
The new Scout feature searches the entire
program guide to find matches to eight key
words or phrases that you enter. Great for
keeping track of your favorite movies, sports
teams, actors and actresses!
• Home Control2
Used in conjunction with our Home Control
accessories,2the receiver can control lights and
appliances directly, or while you’re away, through
the built-in timer function.
8-Event Scheduler
Allows you the ability to program your receiver to
turn on, tune to a specific channel, and turn off
at a pre-set time.
Master Touch®Universal IR Remote
(CRK17SA)3
Ergonomic design and color-coded buttons
provide complete satellite system operation plus
primary function control of virtually every brand
of remote controllable TV.
Satellite Dish Antenna
(DSA100RW)
• Single Output LNB
• Compact 18" Wide Metal Antenna
• Light Gray Satellite Finish
Receiver (DRD222RD)
• Dimensions: 121/4" W, 2" H, 101/4" D
Back Panel Connections
• RF In/Out Connectors with CH3/4 Switch
• One Set of Audio/Video Outputs
• S-Video Output
• Low Speed Data Port
• Phone Jack Connector
• Satellite In Connector
System Shipping Weight
• 7.0 lbs.
Plus
• Limited Warranty
See RCA dealer for complete details.
