RCA 27F534T User manual

www.rca.com/television
User’s Guide
Changing Entertainment. Again.
Model 27F534T is pictured here.
Find Inside:
• Connecting .............. page 5
• Remote Control ...... page 12
• KidPass ..................... page 26
• Favorite Channel .... page 35
• Troubleshooting ..... page 41

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Caution: To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer
servicing to qualified service personnel.
This symbol indicates “dangerous voltage“ inside
the product that presents a risk of electric shock or
personal injury.
This symbol indicates important instructions
accompanying the product.
Refer to the identification/rating label located on the back panel of your product for
its proper operating voltage.
FCC Regulations state that unauthorized changes or modifications to this equipment
may void the user’s authority to operate it.
Caution: To prevent electric shock, match wide blade of plug to wide slot, fully insert.
Caution: Using video games or any external accessory with fixed images for
extended periods of time can cause them to be permanently imprinted on the
picture tube (or projection TV picture tubes). ALSO, some network/program logos,
phone numbers, black borders (sides, top and bottom), etc. may cause similar
damage. This damage is not covered by your warranty.
Cable TV Installer: This reminder is provided to call your attention to Article 820-40
of the National Electrical Code (Section 54 of the Canadian Electrical Code, Part 1)
which provides guidelines for proper grounding and, in particular, specifies that the
cable ground shall be connected to the grounding system of the building as close to
the point of cable entry as practical.
Important Stand and Base Safety Information
Choose the location for your TV carefully. Place the TV on a stand or base that is of
adequate size and strength to prevent the TV from being accidentally tipped over,
pushed off, or pulled off. This could cause personal injury and/or damage the TV.
Refer to the Important Safety Instructions on page 1.
Product Registration
Please fill out the product registration card (packed separately) and return it immediately. For US customers: Your RCA Consumer
Electronics product can also be registered at www.rca.com/television. Registering this product allows us to contact you if needed.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and
model numbers in case you need them. These numbers are located on the product.
Model No. _________________ Serial No. _____________________Purchase Date: ________________________
Dealer/Address/Phone: __________________________________________________________________________
This symbol indicates that this product incorporates double insulation
between hazardous mains voltage and user accessible parts. When servicing
use only identical replacement parts.
WARNING
To reduce the risk of fire or electric
shock, do not expose this product to
rain or moisture.
The apparatus shall not be exposed
to dripping or splashing and no
objects filled with liquids, such as
vases, should be placed on the
apparatus.
Important Information

1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any of the ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding
type plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding
prong. The wide blade or third prong are provided for your safety.
When the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table specified by
the manufacturer or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as if the power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, or if the apparatus
has been exposed to rain or moisture, does not operate normally,
or has been dropped.
15. This product may contain lead and mercury. Disposal of these
materials may be regulated due to environmental considerations.
For disposal or recycling information, please contact your local
authorities or the Electronic Industries Alliance (www.eiae.org).
16. Damage Requiring Service - The appliance should be serviced by
qualified service personnel when:
A. The power supply cord or the plug has been damaged;
B. Objects have fallen or liquid has been spilled into the appliance;
C. The appliance has been exposed to rain;
D. The appliance does not appear to operate normally or exhibits a
marked change in performance;
E. The appliance has been dropped or the enclosure damaged.
17. Tilt/Stability - All televisions must comply with recommended
international global safety standards for tilt and stability proper ties
of its cabinet design.
• Do not compromise these design standards by applying
excessive pull force to the front, or top, of the cabinet, which could
ultimately overturn the product.
• Also, do not endanger yourself, or children, by placing electronic
equipment/toys on the top of the cabinet. Such items could
unsuspectingly fall from the top of the set and cause product
damage and/or personal injury.
18. Power Lines - An outdoor antenna should be located away from
power lines.
19. Outdoor Antenna Grounding - If an outside antenna is connected
to the receiver, be sure the antenna system is grounded so as to
provide some protection against voltage surges and built up static
charges.
Section 810 of the National Electrical Code, ANSI/NFPA No. 70-
1984, provides information with respect to proper grounding of the
mast and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding connectors, location of
antenna-discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode. See Figure below.
20. Object and Liquid Entry - Care should be taken so that objects
do not fall and liquids are not spilled into the enclosure through
openings.
21. Battery usage CAUTION - To prevent battery leakage that may
result in bodily injury, property damage, or damage to the unit:
• Install all batteries correctly, with + and - aligned as marked on
the unit.
• Do not mix batteries (old and new or carbon and alkaline, etc.).
• Remove batteries when the unit is not used for a long time.
22. Apparatus shall not be exposed to dripping or splashing and no
objects filled with liquids, such as vases, shall be placed on the
apparatus.
Note to the Cable TV system installer: This reminder is provided to call the Cable TV system installer’s attention to Article 820-40 of the NEC
(Section 54 of the Canadian Electrical Code, Part 1) that provides guidelines for proper grounding and, in particular, specifies that the cable ground
shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
IMPORTANT SAFETY INSTRUCTIONS
Read before operating equipment
Example of Antenna Grounding
as per NEC - National Electrical Code
GROUND CLAMP ANTENNA LEAD IN WIRE
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ELECTRIC SERVICE EQUIPMENT
GROUND CLAMPS
POWER SERVICE GROUNDING ELECTRODE SYSTEM
(NEC ART 250, PART H)
Important Information

2
Chapter 1: Connections & Setup
Things to Consider Before You Connect ......................................................................... 4
Protect Against Power Surges .................................................................................... 4
Protect Devices from Overheating ............................................................................4
Position Cables Properly to Avoid Audio Interference ............................................. 4
Use Indirect Light ........................................................................................................4
Get the Picture .................................................................................................................. 5
Receiving Digital Channels ......................................................................................... 5
What You Need ...........................................................................................................5
What You Need to Know ........................................................................................... 5
Receiving Analog Channels ........................................................................................ 6
What You Need ...........................................................................................................6
What You Need to Know ........................................................................................... 6
Choose Your Connection .................................................................................................. 7
Y Pb Pr Connection ..................................................................................................... 8
S-Video Connection .................................................................................................. 10
Using the Side Jacks ........................................................................................................ 11
Plug in the TV ..................................................................................................................12
Put batteries in the Remote ........................................................................................... 12
How to Use the Remote Control to Complete the Initial Setup ..................................12
Turn on the TV ................................................................................................................. 12
Complete the Initial Setup ............................................................................................. 13
Choose the Menu Language .................................................................................... 13
Tuning to a Channel ................................................................................................. 13
What to Expect ................................................................................................................ 14
Watching TV ..............................................................................................................14
Remote Buttons .............................................................................................................. 15
Using the INPUT Button .................................................................................................. 16
Explanation of Jacks ....................................................................................................... 17
Front Input Jacks ............................................................................................................19
Front/Side Buttons ......................................................................................................... 19
Chapter 2: Using the TV Features
Channel Banner ............................................................................................................... 20
Parental Controls and V-Chip ......................................................................................... 21
How V-Chip Works .................................................................................................... 21
Activate Parental Control ............................................................................................... 21
Resetting the Password ............................................................................................ 21
Set V-Chip TV Programming Limits .......................................................................... 22
The V-Chip Rating Screen .........................................................................................22
Blocking Age-Based Ratings ....................................................................................22
Blocking Specific Content Themes ........................................................................... 23
Table of Contents

Table of Contents
3
Blocking USA V-Chip Movie Ratings ........................................................................24
Blocking Canadian V-Chip Movie Ratings ............................................................... 25
V-Chip Exempt Program Block ................................................................................. 25
Activate KidPass ........................................................................................................ 26
Block Channel ........................................................................................................... 26
Front Panel Lock ....................................................................................................... 27
Change Your Password ............................................................................................. 27
Chapter 3: Using the TV’s Menu System
Sound Menu ....................................................................................................................28
Picture Menu ................................................................................................................... 30
Setup Menu .....................................................................................................................31
Parental Control Menu .................................................................................................. 36
Time Menu ....................................................................................................................... 37
Notepad Menu ................................................................................................................ 38
Chapter 4: Other Information
USA V-Chip Rating System .............................................................................................39
Canadian English V-Chip Rating System ....................................................................... 39
Canadian French V-Chip Rating System ........................................................................ 40
Troubleshooting ..............................................................................................................41
Limited Warranty ............................................................................................................ 43
Care and Cleaning ........................................................................................................... 45
FCC Information .............................................................................................................. 45

4 Graphics contained within this publication are for representation only.
Things to Consider Before You Connect
Protect Against Power Surges
• Connect all devices before you plug any of their power cords into the wall outlet.
• Turn off the TV and/or device before you connect or disconnect any cables.
• Using a surge protector can help prevent damage to your TV from electrical power surges. In
case of lightning, unplug your TV.
• Make sure all antennas and cables are properly grounded. Refer to the Important Safety
Instructions packed separately.
Protect Devices from Overheating
• Don’t block ventilation holes on any of the devices. Arrange the devices so that air can
circulate freely.
• Don’t stack devices.
• If you place devices in a stand, make sure you allow adequate ventilation.
• If you connect an audio receiver or amplifier, place it on the top shelf so the heated air from
it won’t flow around other devices. Position Cables Properly to Avoid Audio Interference
Position Cables Properly to Avoid Audio Interference
• Insert each cable firmly into the designated jack.
• If you place devices above the TV, route all cables down the side of the back of the TV
instead of straight down the middle of the TV.
• If your antenna uses 300-ohm twin lead cables, do not coil the cables. Also, keep the twin
lead cables away from audio/video cables.
Use Indirect Light
Don’t place the TV where sunlight or room lighting will be directed toward the screen. Use soft
or indirect lighting.
Chapter 1: Connections & Setup

Get the Picture
The first part of connecting your TV is to get a signal. The back
panel of your TV allows you to receive analog channels by using the
ANTENNA/CABLE ANALOG INPUT and digital channels by using the
ANTENNA/CABLE DIGITAL INPUT. The graphic to the left shows
these inputs.
ANTENNA
button
VIDEO OUT
VIDEO IN
COMPONENT IN
VIDEO2 IN
S-VIDEO IN
ANTENNA/CABLE
ANALOG INPUT
ANTENNA/CABLE
DIGITAL INPUT
What You Need to Know
• This television is equipped with a QAM (Quadrature amplitude modulation) tuner that enables reception of
unscrambled digital cable content. Check with your cable provider for information about content availability in
your area.
• Visit www.antennaweb.org to get help deciding what type of antenna to use to receive the off-air local digital
channels available to you. By entering where you live, this mapping program tells you what local analog and
digital stations are available using a certain antenna.
• When you get to the Auto Channel Search screen in the Initial Setup, make sure you set the signal type for using
a digital signal source. (You can also choose Both, digital and analog). To complete a channel search now, go to
page 13.
• When you are ready to watch digital channels, make sure you are tuned to the Digital Input. Press the ANTENNA
button to tune to the Digital Input. Go to page 15 for more information.
When using both of these jacks, use the ANTENNA button on the
remote to toggle between the digital and analog signals.
or
Receiving Digital Channels
Coaxial cable
Indoor or Outdoor
Antenna
Continues on next page...
Note: You may experience a delay of several seconds before digital pictures appear, both when
you first turn on the digital signals and when you change channels. This is normal. Check with
your local cable company for available content.
What You Need
• Antenna (“rabbit ears”) or outdoor antenna with a coaxial cable. Plug the antenna
or coaxial cable from the wall outlet into the ANTENNA/CABLE DIGITAL INPUT to
receive free off-air local digital channels.
OR
• Coaxial cable from a cable outlet. Plug the coaxial cable into the ANTENNA/CABLE
DIGITAL INPUT to receive your digital cable channels.
OR
• You can use a signal splitter (shown at left) to divide the signal from one cable
or antenna source to connect to both the ANTENNA/CABLE ANALOG INPUT and
ANTENNA/CABLE DIGITAL INPUT jacks on the TV. When you get to the Auto
Channel Search screen in the Initial Setup, make sure you set the signal type to Both
(digital and analog).
or
Chapter 1 5
Connections & Setup

What You Need to Know
• Visit www.antennaweb.org to get help deciding what type of antenna to use to receive the local analog channels
available to you. By entering where you live, this mapping program tells you what local analog and digital stations
are available using a certain antenna.
• When you get to the Auto Channel Search screen in the Initial Setup, make sure you set the signal type for using
an analog signal source. (You can also choose Both, digital and analog). To complete a channel search now, go to
page 13.
• When you are ready to watch analog channels, make sure you are tuned to the analog input. Press the ANTENNA
button to tune to the analog input. Go to page 15 for more information.
What You Need
• Antenna (“rabbit ears”) or outdoor antenna with coaxial cable. Plug the antenna
or coaxial cable from the wall outlet into the ANTENNA/CABLE ANALOG INPUT
to receive analog channels.
OR
• Coaxial cable from a cable outlet. Plug the coaxial cable from the source outlet
into the ANTENNA/CABLE ANALOG INPUT to receive cable channels.
or
Receiving Analog Channels
Coaxial cable
Indoor or Outdoor
Antenna
ANTENNA
button
When using both of these jacks, use the ANTENNA button on the
remote to toggle between the digital and analog signals.
Connections & Setup
6 Chapter 1

Choose Your Connection
There are several ways to connect your TV, depending on the devices you want to connect and the quality of the
signal you want to achieve. A connection using Y Pb Pr jacks is excellent, S-Video is very good and antenna or cable
input is fair. Connections will vary according to the types of outputs jacks each external device can accommodate (i.e.,
DVD players usually have Y Pb Pr outputs but video game consoles do not).
Please use the following chart to determine which connection is best for you.
Note for U.S. customers: If you prefer, we can provide you with the name of an Authorized Service Representative
who will visit your home for a fee to install your electronic entertainment system and to instruct you in its operation.
For details about this service, call 1-888-206-3359. For additional assistance while using your RCA product, please visit
www.rca.com/customersupport.
Jacks Used Cables Needed Go to...
Component
video Cables page 8-9
page 11
Audio/Video
Cables
page 10
Y Pb Pr
Audio R and L
Video Input (side)
Audio R and L
L AUDIO R
VIDEO
Audio Cables
VIDEO OUT
VIDEO IN
COMPONENT IN
VIDEO2 IN
S-VIDEO IN
ANTENNA/CABLE
ANALOG INPUT
ANTENNA/CABLE
DIGITAL INPUT
S-Video
Audio R and L
VIDEO OUT
VIDEO IN
COMPONENT IN
VIDEO2 IN
S-VIDEO IN
ANTENNA/CABLE
ANALOG INPUT
ANTENNA/CABLE
DIGITAL INPUT
Audio Cables
S-Video Cable
Chapter 1 7
Connections & Setup

VIDEO OUT
VIDEO IN
COMPONENT IN
VIDEO2 IN
S-VIDEO IN
ANTENNA/CABLE
ANALOG INPUT
ANTENNA/CABLE
DIGITAL INPUT
COMPONENT IN
COMPONENT VIDEO
Y Pb Pr
VIDEO
INPUT
L R
AUDIO
VIDEO
OUTPUT
S-VIDEO
OUT
S-VIDEO
IN
L R
AUDIO
L R
AUDIO
VIDEO IN
Back of TV
DVD Player
23
Go to page 5 for
instructions on
getting a signal.
IMPORTANT - If you aren’t receiving a picture with this connection, the problem
might be with your DVD player. If the DVD player is a “progressive scan” DVD player,
you need to change the setting from progressive to interlace. The procedure for
changing this on a DVD player varies. Look for a button on the front of the DVD player
(it might be called resolution or display), or see if there is a switch on the back (it might
be labeled “int/prog” or something similar), or the item might be in the menu system of
the DVD player. Consult your DVD player owner’s manual for instructions.
Connecting the Device
This connection allows you to connect a device that has Y Pb Pr jacks, for example, a DVD
player. If the device you are connecting also has S-Video or composite video, we recommend
you use the component video input for better quality.
The illustration shows how to connect a DVD to your TV using component (Y Pb Pr) and
audio cables.
Y Pb Pr Connection
Continues on next page...
Connections & Setup
8 Chapter 1

Using the example of a DVD player:
1. Connect your cable and/or antenna as described on page 5.
2. Connect your Y Pb Pr component video cables.
Connect three video grade cables to the Y Pb Pr jacks on the back of the TV and
to the Y Pb Pr outputs on the DVD player. Y Pb Pr cables are colored green, blue
and red. Just match the colors on the cables to the Y Pb Pr jacks.
3. Connect your audio cables.
Connect the audio (white and red) cables to the AUDIO R and L (VIDEO IN input)
jacks on the back of the TV and to the audio output jacks on the DVD player. Just
match the colors.
Important - Y Pb Pr cables can only be used with the audio jacks from the VIDEO IN
input located on the back of the TV. You cannot use any other audio input jacks on
this TV for this connection.
4. Add a VCR to this connection.
Connect a coaxial cable to the ANTENNA/CABLE DIGITAL INPUT or ANTENNA/
CABLE ANALOG INPUT (choose one) on your TV to the Antenna Output jack on
your VCR (sometimes labeled OUT TO TV). For more details about the antenna
jacks go to page 5.
Note: If your VCR has Audio/Video output jacks, you can connect your TV to
the VCR using audio/video cables for better quality.
Viewing the Picture from the Connected Device
The device in this example, a DVD player, is connected to the TV’s Y Pb Pr jacks. To
view the DVD player:
1. Turn on the TV and the DVD player.
2. Press the INPUT button on the remote control to toggle through the Video Input
Channels until you see CVID1 displayed in the channel banner.
Component Video
cables (Y Pb Pr) are
color coded- Green,
Blue and Red
Audio cables are color
coded- Red= right audio;
white= left audio
INPUT
button
• To review other
connections, go to the next
page.
• If you are done connecting
devices to your TV, go to
page 13 to complete the
Initial Setup.
• If you want more details of
the jacks on your TV, go to
page 17.
Chapter 1 9
Connections & Setup

INPUT
button
S-Video Connection
Back of TV
VIDEO OUT
VIDEO IN
COMPONENT IN
VIDEO2 IN
S-VIDEO IN
ANTENNA/CABLE
ANALOG INPUT
ANTENNA/CABLE
DIGITAL INPUT
VIDEO
INPUT
L R
AUDIO
VIDEO
OUTPUT
S-VIDEO
OUT
S-VIDEO
IN
L R
AUDIO
L R
AUDIO
Device
2
3
Go to page 5 for
instructions on
getting a signal.
Connecting the Device
This connection allows you to connect a device that has an S-Video jack. S-Video
provides a clearer picture than the Video jack. Refer to the illustration which uses
S-Video and audio cables.
1. Connect your cable and/or antenna as described on page 5.
2. Connect your S-Video cable.
The S-Video cable fits into a special shaped jack which is labeled S-VIDEO IN.
Connect the S-Video cable to the jack on the TV and the jack on the device.
3. Connect your audio cables.
Connect the audio (white and red) cables to the R and L AUDIO jacks on the TV
and to the audio output jacks on the device. Just match the colors.
Viewing the Picture from the Connected Device
The device in this example could be a VCR, DVD player, satellite receiver or cable box.
It is connected to the TV’s S-Video jack. To view this device:
1. Turn on the TV and the device.
2. Press the INPUT button on the remote control to toggle through the Video Input
Channels until you see SVID2 displayed in the channel banner.
Remember: When you use the S-Video connection described here, you cannot use
the Video jack from the VIDEO 2 IN input for a connection at the same time.
Audio cables
S-Video cable
INPUT
button
Connections & Setup
10 Chapter 1

Using the Side Jacks
Connecting the Device
This connection allows you to connect a device such as a video game console, that has
Audio/Video jacks. Refer to the illustration which uses audio and video cables.
Using the example of a video game console:
1. Connect your cable and/or antenna as described on page 5.
2. Connect your video cable.
Video cables are usually yellow. Connect the Video cable to the VIDEO jack on the side
of the TV and the jack on the video game console.
3. Connect your audio cables.
Connect the audio (white and red) cables to the R and L AUDIO jacks on the side of the
TV and to the audio output jacks on the video game console. Just match the colors.
Audio/Video cables
Viewing the Picture from the Connected Device
The device in this example, a video game console, is connected to the TV’s video and
audio jacks located on the side of the TV. To view the video game console:
1. Turn on the TV and the video game console.
2. Press the INPUT button on the remote control to toggle through the Video Input
Channels until you see FRNT displayed in the channel banner.

INPUT
 


OUTPUT




 

 



Side of TV Go to page 5 for
instructions on
getting a signal.
23
INPUT
button
Video Game Console
Chapter 1 11
Connections & Setup

OK button
Arrow
buttons
Plug in the TV
Plug the end of the power cord into a grounded wall outlet. Insert the plug completely into the
outlet.
Put batteries in the Remote
• Remove the battery compartment cover from the back of the remote by pushing down
and sliding off the cover.
• Insert 2 fresh “AA” batteries. Make sure the polarities (+ and -) are aligned correctly to the
diagram inside the battery compartment.
• Replace the cover.
How to Use the Remote Control to
Complete the Initial Setup
The technical term is “Navigation” - how you move through the
on-screen menus. The method is the same throughout the menu screens:
highlight your choice and select it.
To highlight a menu item, press the arrow buttons on the remote to
highlight one of the items listed on the screen. Use the up or down
arrow button to move up or down. Use the right or left arrow button to
move right or left.
To select the item that you’ve highlighted, press OK.
Note: Highlighted means that the menu item stands out from
other menu items on the list (appears darker, brighter or a
different color).
Turn on the TV
Press ON•OFF on the remote, or press POWER on the TV’s front or side
panel.
Connections & Setup
12 Chapter 1

Go Back
Auto Ch. Search ...
List & Labels ...
Closed Caption ...
Favorite CH ...
Language English...
Auto. format 4:3
SETUP
< >
Go Back
Signal Source Both...
Analog Sig. Type Cable...
Digital Sig. Type Antenna...
Start Running...
Search percent 10
Analog Channel 0
Digital Channel 0
AUTO CHANNEL SEARCH
�
Tuning to a Channel
Analog station numbers display on your TV in a rectangle as you enter the numbers. You can
enter digits to access a channel. In the example below, you can enter 12 or 012 to get the
same channel. To enter a one-digit channel, such as channel 8, just press 8. After entering the
channel, press OK. The CLEAR button on the remote clears all entries.
Digital channels can have both primary channels (like the analog channel number) and
subchannels. Digital station numbers display in a larger rectangle that can contain up to eight
numbers. Numbers to the left of the - (dash) are the main channel number; numbers to the
right are the subchannel numbers for stations that broadcast more than one signal.
In the example to the left, press “1”, press “2” (although 012 is shown in the example,
pressing “0” isn’t required) and then press the right arrow button to move to the subchannel.
Press “1” and then “OK.” The TV tunes to channel 12-1. If channel 12 is broadcasting
subchannel signals, you would enter numbers that would access the other signals. (Example:
12-1, 12-2, 12-3). If the selection times out, you must start over. Once you’ve made all entries,
press OK. The CLEAR button on the remote clears all entries.
Notes: You may experience a delay of several seconds before digital pictures appear,
both when you first turn on the digital signals and when you change channels. This is
normal. Digital channels sometimes take longer to tune.
Complete the Initial Setup
AUTO CHANNEL SEARCH is the first menu you should see when you turn on
the TV. (It is located from this path Main Menu/Setup/Auto Ch Search). It allows
the TV to search for all channels viewable through your digital and analog
connections. This is sometimes called auto programming.
1. From the Auto Channel Search menu press the right arrow button to choose
the Signal Source (Digital, Analog, or Both). The default is Both.
2. With the Signal Source chosen, press the down arrow button to select Start
and press OK. AUTO CHANNEL SEARCH runs as it finds all the available
channels. (This step might take 10-15 minutes depending on your content
provider).
3. Once the search is complete, you can begin watching TV. For information
on customizing your channels or menu options, go to Chapter 3.
Note: After you complete the Auto Channel Search you may see an
additional screen. “Time stored in the TV may be incorrect after a loss of
power. Please check the time in the Time menu” may appear, reminding
you that the time setting is incorrect. Go to page 37 for more information.
Choose the Menu Language
To set the language, use the arrow buttons to highlight Language. The default
language is English. To choose another language, press the right arrow button
on the remote, choose the language and press OK.
Go Back
Auto Ch. Search ...
List & Labels ...
Closed Caption ...
Favorite CH ...
Language English...
Auto. format 4:3
SETUP
< >
_12
Analog channel
entry
012-1_ _
Digital channel
entry
Chapter 1 13
Connections & Setup

Connections & Setup
14 Chapter 1
Tuning to a Channel (continued)
Some channels might have been found during the channel search that are unavailable to
view and you might want to get rid of these so they don’t appear as you change channels.
To do this go to Main Menu/Setup Menu/List & Labels. Note that removing channels from
your channel list may be time consuming, so you might want to do it later. Go to page 32 for
details on editing your channel list.
What to Expect
Watching TV
• Remember: If you have an analog signal connected to your ANTENNA/CABLE ANALOG
INPUT, then view analog channels on your Analog Input. (The ANTENNA button on the
remote tunes to the analog/digital inputs). Analog channels are sent in a 4:3 format. You
can press the left arrow/ZOOM- and right arrow/ZOOM+ buttons on the remote to choose
different screen formats (4:3, 16:9 or stretch). This is also known as the aspect ratio. Go to
page 36 for examples of screen formats.
• Remember: If you have a digital signal connected to your ANTENNA/CABLE DIGITAL
INPUT, then view digital channels on your Digital Input. (The ANTENNA button on the
remote tunes to the analog/digital inputs). Most digital channels are sent in a 16:9 format;
it depends on how the station is formatting the video. If so, you’ll see gray or black
bars at the top and bottom of the screen. You can press the left arrow/ZOOM- and right
arrow/ZOOM+ buttons to choose different screen formats (4:3, 16:9 or stretch). This is
also known as the aspect ratio.
Note: Digital stations in native 4:3 format (you’ll see black or gray bars on the sides of the
picture sent as part of the signal from the broadcaster) might not have this function.

Note: If you need to
replace your remote, call
1-800-338-0376. A
shipping and handling
fee will be charged
upon ordering, and the
appropriate sales tax. Have
your Visa, MasterCard or
Discover Card ready.
Your remote part number
is R130A1.
Remote Buttons
ANTENNA Toggles to digital or analog channel sources. Refer to page 5 for a
full description.
Arrow buttons ( , ,) Use to highlight different items in the TV menu.
( /ZOOM-, /ZOOM+) Adjusts the menu controls. During normal TV viewing,
changes the screen format (aspect ratio). The zoom status appears momentarily.
Refer to page 36 for more information about different formats.
(0-9) Number buttons Enter channel numbers (refer to the previous page), time
settings (refer to page 37), labels (refer to page 32) and notepad messages (refer
to page 38).
CC Toggles closed captioning on and off when closed-caption menu option is
turned on.
CH + or CH - Scans up or down through all the available stations on analog
and/or digital connections. Press once to change the channel up or down; press
and hold to continuously change channels.
CLEAR Removes any menu or display from the screen and returns you to
normal TV viewing.
FAV (Favorite) Press to browse the channels in your Favorite List. Refer to page
35 for more information.
GO BACK Returns you to the previous channel or menu.
INFO Brings up the channel banner. Press again to remove. Refer to page 20
for more information.
INPUT Toggles through the available Video Input Channels (VID1, CVID1,
FRNT, SVID2 and current channel).
MENU Brings up the MAIN MENU system.
MUTE Reduces the TV’s volume to its minimum level. Press again to restore
the volume.
OK/FREEZE When in the menu system, selects highlighted items. FREEZE is
available only on some models.
ON•OFF Turns the TV on and off.
PRESETS Resets picture options to original factory settings.
SKIP Press once before changing channels; watch the screen for the
SKIP box (
SKIP 00:30
) to appear. Press the SKIP button again - 30 seconds
will appear. Enter the new channel number. The TV will change to the new
channel and return to the original channel in 30 seconds. Press repeatedly to add
more time.
SLEEP Allows you to activate/deactivate the sleep timer by taking you to the
Sleep Timer menu. Refer to page 37.
SOUND Press to select one of the five sound settings when viewing analog
signals (Standard, Music, Speech, Theatre or Personal). Refer to page 28 for more
information.
VOL - or VOL + Decreases or increases the TV’s volume.
Chapter 1 15
Connections & Setup

Using the INPUT Button
Use the INPUT button to scroll through the available Video Input Channels to view
components you have connected to the TV.
1. Make sure the component you want to view is turned ON.
2. Press INPUT to tune to an available Video Input Channel and view the component.
3. To return to the previous channel, continue pressing INPUT.
Connections & Setup
16 Chapter 1

DIGITAL INPUT Lets you connect a coaxial (RF) cable to receive digital
programming through your cable provider. Receive off-air digital programming via an
antenna. Refer to page 5 for more details.
S-VIDEO Lets you connect external devices which have S-Video outputs such as:
VCRs, DVD players, satellite receivers and cable boxes. When using S-Video, make sure
to connect the two audio cables as well as the S-Video connector.
• AUDIO-L Provides left audio connection. The left audio connector is usually
white.
• AUDIO-R Provides right audio connection. The right audio connector is usually
red.
To access the device when using these jacks, press the INPUT button on your remote
until SVID2 appears.
Explanation of Jacks
This section describes the jacks you can use to make connections. There are several
combinations available to connect devices to your TV.
VIDEO OUT
VIDEO IN
COMPONENT IN
VIDEO2 IN
S-VIDEO IN
ANTENNA/CABLE
ANALOG INPUT
ANTENNA/CABLE
DIGITAL INPUT
ANALOG INPUT Lets you connect a coaxial (RF) cable to receive analog
programming through your cable provider. Receive off-air programming via an
antenna. Refer to page 5 for more details.
Use the ANTENNA button to toggle between these RF inputs.
Continues on next page...
VIDEO OUT
VIDEO IN
COMPONENT IN
VIDEO2 IN
S-VIDEO IN
ANTENNA/CABLE
ANALOG INPUT
ANTENNA/CABLE
DIGITAL INPUT
VIDEO OUT
VIDEO IN
COMPONENT IN
VIDEO2 IN
S-VIDEO IN
ANTENNA/CABLE
ANALOG INPUT
ANTENNA/CABLE
DIGITAL INPUT
VIDEO OUT
VIDEO IN
COMPONENT IN
VIDEO2 IN
S-VIDEO IN
ANTENNA/CABLE
ANALOG INPUT
ANTENNA/CABLE
DIGITAL INPUT
VIDEO2 IN Lets you connect devices which have Audio/Video (composite) outputs such
as VCRs, DVD players, satellite receivers, cable boxes, camcorders and video game consoles.
Connect the left and right audio jacks for sound.
• VIDEO Provides composite video connection. The video connector is usually yellow.
• AUDIO-L Provides left audio connection. The left audio connector is usually white.
• AUDIO-R Provides right audio connection. The right audio connector is usually red.
To access the device when using these jacks, press the INPUT button on your remote until
VID2 appears.
VIDEO OUT
VIDEO IN
COMPONENT IN
VIDEO2 IN
S-VIDEO IN
ANTENNA/CABLE
ANALOG INPUT
ANTENNA/CABLE
DIGITAL INPUT
Chapter 1 17
Connections & Setup

Y, Pb, Pr Lets you connect devices which have component (Y Pb Pr) outputs such as
VCRs, DVD players, DVD-PVRs, DVD recorders, satellite receivers and cable boxes. This
connection provides optimum picture quality because the video is separated into three
signals. Use the AUDIO L and R jacks from the VIDEO IN input to connect for sound.
To access the device when using these jacks, press the INPUT button on your remote
until CVID1 appears.
Refer to page 8 for a detailed explanation of how to connect Y Pb Pr cables to your TV.
VIDEO OUT
VIDEO IN
COMPONENT IN
VIDEO2 IN
S-VIDEO IN
ANTENNA/CABLE
ANALOG INPUT
ANTENNA/CABLE
DIGITAL INPUT
VIDEO OUT
VIDEO IN
COMPONENT IN
VIDEO2 IN
S-VIDEO IN
ANTENNA/CABLE
ANALOG INPUT
ANTENNA/CABLE
DIGITAL INPUT
VIDEO IN Lets you connect devices which have Audio/Video (composite) outputs such
as VCRs, DVD players, satellite receivers, cable boxes, camcorders and video game consoles.
Connect the left and right audio jacks for sound.
• VIDEO Provides composite video connection. The video connector is usually yellow.
• AUDIO-L Provides left audio connection. The left audio connector is usually white.
• AUDIO-R Provides right audio connection. The right audio connector is usually red.
To access the device when using these jacks, press the INPUT button on your remote until
VID1 appears.
VIDEO OUT
VIDEO IN
COMPONENT IN
VIDEO2 IN
S-VIDEO IN
ANTENNA/CABLE
ANALOG INPUT
ANTENNA/CABLE
DIGITAL INPUT
VIDEO OUT Lets you connect your TV to external devices with inputs such as VCRs, Digital
recorders or secondary monitors. Audio/video (composite) cables are used for this connection
Notes: These connections are not available through the VIDEO OUT: digital
connections (ANTENNA/CABLE DIGITAL INPUT) and the component inputs (Y, Pb, Pr).
What is available through the VIDEO OUT: Analog connections (ANTENNA/CABLE
ANALOG INPUT), VIDEO IN and S-VIDEO.
Connections & Setup
18 Chapter 1
