RCA RNSMU8220 User manual

Model:RNSMU8220

CONTENTS
Important Safety Instructions
Safety Information
Preparation
Menu Operation
Initial Setup
Sound
Function
Time
noitpO
LOCK
Channel
Network Setting
Digital Media Palyer
Introduction
Internet
Parental Control
Troubleshooting
2
3
4
4
5
6
6
6
8
9
Front View
Rear View
Installing the Base Stand
Removing the Stand for Wall-Mounting
Wall-Mounting Screws
Connections
PREPARATION
Remote Control
Basic Operations
WARRANTY CARD
10
10
12
13
15
16
18
19
20
21
23
26
30
30
31
32
32
33

1

3
POWER:Press to turn the unit on and off.

HEADPHONE:Connect a 3.5mm headset for personal audio.
OPTICAL:Digital TV sound output.
RJ-45:Connect the Internet
HDMI:(High-Definition Multimedia Interface)Provides an
uncompressed digital connection.
RF:Connect to receive the signal from your antenna or cable
through a coaxial cable.
USB:Connect the USB device such as the flash disk to
access the TVmedia function.
YPBPR/CVBS:Connect the YPBPR output jack of the DVD
orVCR
Audio L/R:.Audio should connect from this port.
USB2
HDMI1(HDCP2.2/ARC) USB1 USB2 YPBPR/CVBS AUDIO(L/R)
HEADPHONE OPTICAL RJ-45 HDMI3(HDCP2.2) HDMI2(HDCP2.2)
RF

Installing the Stand
1.
surface to avoid damaging or scratching.
2. Fix the Left Base Stand to the main unit
using 2pcs provided screws.
3. Fix the Right Base Stand to the main unit
using 2pcs provided screws.
Removing the Stand for Wall-Mounting
1.
surface to avoid damaging or scratching.
2. Untighten the 4 pcs screws holding the
stand assembly and remove them.
3. Attach the wall-mount bracket to the TV
using the mounting holes on the back of
the TV. Mount this TV according to the
instructions included in the wall-mount
bracket.
Wall-Mounting Screws
• Mount the VESA bracket using 4*M8*15 isometric threaded screws (not included).
accordance with the installation instruction.
WARNING:
Never place a television set in an unstable location. A television set may fall, causing serious
personal injury or death. Many injuries, particularly to children, can be acoided by taking
simple precautions such as:
• Using cabinets or stands recommended by the manufacturer of the television set.
• Only using furniture that can safely support the television set.
• Ensuring the television set is not overhanging the edge of the supporting furniture.
• Not placing the television set on tall furniture(for example, cupboards or bookcases) without
anchoring both the furniture and the television set to a suitable support.
• Not placing the television set on cloth or other materials that may be located between the
television set and supporting furniture.
• Attention should be drawn to the environmental aspects of battery disposal.
• Educating children about the dangers of climbing on furniture to reach the television set or
its controls.
If your existing television set is being retained and relocated, the same considerations as
above should be applied.
5

6

7

8

PREPARATION
Remote Control
1. : Turn the TV on and off.POWER
2. : This button is used to switch amongInput
different sources, Select a source and press
ENTER button to confirm.
3. : Directly select channelDigital Buttons(0-9, -)
with digital buttons.
4. Switch tothe previous program.:
11. : If network connects, press this keyNETFLIX
5. : Press this key to go to quick menu.Q.MENU
6. Menu: Display the main menu or exit the current menu.
9. : Validation key.ENTER
10. : Use to selectArrow buttons 
.seulavunemegnahcdnasmetiunemneercs-no
7. Return.Back:
8. : Exit the menu.Exit
14.
: Press these buttonsto adjust theVOL -+/
application（for US only）.
/
CH
1 2 OF
01020 3
0 4 0 5 0 6
0 8
0 7 0 9
0A 00
D3 82
89
83
2A
DA
67
34 30 33
20
48
84 1C
31
49 4A
A0 10
4B
13
D9 58
1D 19
80
1A
1 E
1 B
1 F
17
to view NETFLIX directly.
12.HOME: Press it togo to App home page.
13.pandora: Press this button to select pandora
2
1
3
4
65
78
9 10
11
1314
15
16
17 18
19
20
21 23
12
22
volume.
15.CH /:Press these buttonsto change
channelupward or downward.
16.Digital Media Player control button:Include play/
pause, stop,--previous, next, backward, forward isused in USB
mode .
Please refer to relevnat instructions inthe section of multimed
player.
17.CC:Press this button to adjust CC mode.
18.MTS/Audio:In USB modepress thisbutton to switch
auto track when movie is playing.
In TV mode press this button to switch MTS or
Audio Language.
19.Color buttons: It's used as or Program Edit menu.
20. TTS: Pree this button to adjust TTS onor off
22.YouTube: If network connects, press this key
the TV set temporarily, press again to resume.
or off （for US only）.
21.INFO:Display the program information.
to view YouTube directly
.
23.MUTE: Press this button to cut off the sound of
9

10
En -
Initial Setup
• Connect the power cord to the power socket after you have completed all the
physical connections. At this stage, the TV will enter Standby Mode and the red
LED indicator will illuminate.
• In Standby Mode, press the button on the main unit or on the remote control to
turn the TV on. The red LED indicator will turn off.
• The first time you turn the TV on, it will go into the Setup Wizard. Press
buttons to select your desired mode and press ENTER
Basic Operations
Country
Select the country.
US
Canada
Mexico
Confirm
OSD language
Config Menu language.
ENTER ENTER
Confirm
English
Francias
Español
BACK
Retum
[ ] ACCEPT AUTOMATIC UPDATES [ ] DECLINE ALL

11
En -
Initial Setup
Home Mode :
The picture mode will be Standard if you select this mode.
Retail Mode :
Select Dynamic Mode if you would like your picture to be brighter.
At times this mode may use more energy to operate the Volume/Sound Mode
and Picture Mode.
• The SLEEP-MODE Power should be less than 0.5 W.
9
ENTER
Confirm
Connect to the internet
Select the channel input
Scan Channels
Connection Devices
Select to connect the device.
BACK
Retum
8
7
6
5
Home or Store
Select where you will use the TV.
Store
Home
DST
Select Daylight saving time.
On
Off
ENTER
Confirm
BACK
Retum
Retum
ENTER Confirm
BACK
Time Zone
Select the time zone.
Pacific
Eastern
Atlantic
ENTER
Confirm
Confirm
Clock
Select to set the clock.
Manual
Auto
ENTER BACK
Retum

12
En -
Basic Operations
Menu Operation
Input Setup
2 Channels Selection
There are four ways to select channel:
1) Using number keys, and ENTER keys on the remote control
to select channel directly.
To select channel 90, press .
When you use the number buttons, you can directly select channels that were either erased
or not memorized.
2) Using CH / key on the remote control or on your TV to select channel.
When you press the CH /key, the TV changes channels in sequence. You will see all
the channels that the TV has memorized.
You will not see channels that were either erased or not memorized.
3) Press key to return to previous channel, press it again to return to
current channel.
To quickly switch between two channels that are far apart, tune to one channel, then use the
number keys to select the second channel. Then use the button to quickly
between them.
alternate
is not activated if no channel has been changed after TV turning on.
4)Select channels from "Channels List" or "Favorite List".
Press LIST key to choose from "Channel List" menu.
3 Volume Adjustment and Mute Setup
Volume adjustment
Press VOL / key on the remote control or the TV to display "Volume" menu,
adjust the volume of TV between 0 to 100 by using VOL / key:
Input Source
90ENT ER
1
Press INPUT key on the remote control to enter "INPUT SOURCE" menu. There are
these options for you to select: "TV","AV","Component", "HDMI1", “HDMI2",
“HDMI3",“USB".
Use /key to select a input source and press ENTER key to confirm.
Input Source
Input Source
TV HDMI 2 HDMI 3 USBAV Component HDMI 1

13
En -
Menu Operation
4 Current Channel Information
Press “INFO” key on the remote control to view current
channel information, the indications of channel
information are listed in the following table.
Press “EXIT” key on the remote control to exit this OSD.
01/ 012005 08:
Moving picture 480i 4:3480i 08:30 09:30
40
To increase the volume, press VOL key;
To decrease the volume, press VOL key;
Mute
Press “MUTE” and the sound cuts off. The MUTE icon will appear in the lower-right
corner of the screen.
To resume sound, press the “MUTE” button again, or simply press the key.
Mute
1. Press MENU key to display the main menu on the screen.
2. Press /key to select "Picture" option.
3. Press key to enter "Picture" submenu.
4. You can also press the PICTURE key on the
remote control to select one of the picture settings.
Picture Mode
Your TV has four picture settings (Vivid, Standard,Movie,Eco Save,
User) that are preset at the factory. Only "User" mode can be
set to your preference by adjusting particular items such as
Contrast, Brightness, Color, Sharpness.
1. Press /key to select "Picture Mode" option.
3. Press /key to select one picture mode.
VOL
14.1 ATSC-1
2. Press “” or "ENTER" key to confirm.
Sound
Function
Time
Option
Lock
Channel

14
En -
Menu system instruction
Picture Mode
Contrast 70
Brightness
Color
Sharpness
Tint
Backlight
Color Temperature
50
70
0
75
50
User settings for PICTURE
(Contrast, Brightness, Color, Sharpness,Tint)
Your set has several settings which allow you to control picture
quality.
1. Press ▲/▼key to select a particular item.
2. Press /key to decrease or increase the value of a particular
item.
Note: The adjusted values are stored according to the selected
particular item.
Backlight
You can Change the brightness of the entire screen according to your preference.
1. Press /key to select "Backlight" option.
2. Press/key to increace or decreace the backlight value.
Color Temperature
You can change the color of the entire screen according to your preference.
1. Press /key to select "Color Temperature" option.
3. Press /key to select one color temp.
Contrast: Adjusts the lightness and darkness between objects and the background.
Brightness: Adjusts the brightness of the picture.
Color: Adjusts the colors, making them lighter or darker.
Sharpness: Adjusts the outline of objects to either sharpen them or make them
more dull.
Tint: Adjusts the Tint of the picture.
Backlight: Adjusts the brightness of the whole screen.
Cool: Makes whites bluish.
Standard: Makes whites nature
Warm: Makes whites reddish.
2. Press “” or "ENTER" key to confirm.

15
En -
Menu system instruction
Sound Mode
Balance
AVL
Surround Sound
Digital Audio Output
Audio Language
0
1. Press MENU key to display the main menu on the
screen.
2. Press /key to select "Sound" option.
3. Press key to enter "Sound" submenu.
4. You can also press the SOUND key on the remote
control to select one of the sound.
Sound Mode
You can select the type of the special sound effect
to be used when watching a given broadcast.
Your TV has five sound settings (“Standard”, “Music”,“Movie”,
“Sports”,“User”) that are preset at the factory.
1. Press /key to select "Sound Mode" option.
3. Press /key to select one sound mode.
Balance
If the volumes of the left speaker and the right speaker are not the same, you can adjust
the "Balance" to suit your personal preference.
1. Press /key to select "Balance" option.
2. Press /key to decrease or increase the value of the item.
AVL
Each broadcasting station has its own signal conditions, and it is inconvenient to adjust the
volume every time the channel is changed. “AVL” automatically adjusts the volume of the
desired channel by lowering the sound output when the modulation signal is high or by
raising the sound output whenthe modulation signal is low.
1. Press /key to select “AVL” option.
3. Press /key to select “On” or “Off”.
Surround Sound
This is used to turn on surround sound to gain better sound effect.
1. Press /key to select "Surround sound” option.
3. Press /key to select “Surround” or “Off”.
1. Press /key to select " ” option.
Video Description
3. Press /key to select “On” or “Off”.
Sound
Standard: Selects the normal sound mode.
Music: Provides clear and live sound for music.
Movie: Provides live and full sound for movies.
Sports: Emphasizes bass over other sounds.
User: Selects your custom sound settings.
Video Description
Video Description
HDMI-ARC
Dolby Audio Process
2. Press “” or "ENTER" key to confirm.
2. Press “” or "ENTER" key to confirm.
2. Press “” or "ENTER" key to confirm.
2. Press “” or "ENTER" key to confirm.

16
En -
Menu system instruction
SOUND
Digital Audio Output
This is used to .set digital audio output
1. Press /key to select "Digital Audio Output” option.
3. Press /key to select “Auto” or “PCM”.
Audio Language
You can set the primary and secondary language for audio.
HDMI-ARC
Turn on or turn off the HDMI-ARC function.
1. Press MENU key to display the main menu
on the screen.
2. Press /key to select “Function” option.
3. Press key to enter “Function” submenu.
Noise Reduction
Press /key to select the
Press /key to select the Mpeg Noise Rdeuction
Noise Reduction mode. You can select the right
mode to match the pictures.
MPEG Noise Reduction
mode: off/low/middle/high. The picture will be better
when it is in “high” mode.
Aspect Ratio
1. Press /key to select “Aspect Ratio” option.
3. Press /key to change the size of the picture
on the size of the picture on the screen.
Function
Dolby Audio Process
You can set on the
Dolby Audio Process
Dolby Audio Process
submenu.
2. Press “” or "ENTER" key to confirm.
2. Press “” or "ENTER" key to confirm.
Noise Reduction
MPEG Noise Reduction
Aspect Ratio
Link Setup
Netflix Deactivate
HDMI EDID
Netflix ESN
Netflix Version
VUDU Deactivate
TTS
On
User
Off
Dolby Audio Process
Dolby Audio Process
Mode
Surrond Virtualizer
Dialog Enhancer
Auto Voulme Control
Off
Movie
High
High
Off

17
En -
Menu system instruction
Link Setup
Enable link
Auto Power On
Auto Standby
On
On
Off
Function
Link Setup
1. Press /key to select “Link Setup” option.
2. Press ENTER or key to enter “Link Setup”
submenu.
Enable Link: Press /to turn on/off the
link setup.
Auto Power On: When this option is “On” and the
TV is in standby mode. T
turn the
TV at the same time.
Auto Standby: When this Option is “On” and the TV
is on, to turn off
standby mode.
TTS
TTS
Verbosity
Rate Support
Pitch Support
Off
Low
Slow
Mid
Betty Say
1. Press “/" key to select “Netflix Deactivate" option.
2. Press “” or "ENTER" key to confirm.
3. Press "Yes" to confirm again, the Netflix will be activated.
1. Press “
This function is only used in HDMI mode.


/

" key to select “HDMI EDID" option.
2. Press “” or "ENTER" key to confirm.
3. Press / key to select “ 2K”,“ 4K” or “ AUTO”.
Netflix ESN
Display the Netflix Esn information.
Netflix Version
Display the Netflix version.
1. Press “/" key to select “VUDU Deactivate" option.
2. Press “” or "ENTER" key to confirm.
TTS
You can set TTS information in the TTS menu.
Netflix Deactivate
HDMI EDID
VUDU Deactivate
