RCA VR556 User manual

VCR
User’s Guide
Changing Entertainment. Again.
VR556

This symbol indicates
"dangerous voltage" inside
the product that presents a
risk of electric shock or
personal injury.
WARNING
To reduce the risk of fire or
electric shock, do not expose
this product to rain or moisture.
To reduce the risk of electric shock, do not remove
cover (or back). No user serviceable parts inside.
Refer servicing to qualified service personnel.
This symbol indicates
important instructions
accompanying the product.
CAUTION
RISK OF ELECTRIC
SHOCK. DO NOT OPEN.
Caution: To prevent electric shock, match wide blade
of plug to wide slot, fully insert.
Attention: Pour éviter les chocs électriques,
introduire la lame la plus large de la fiche dans la
borne correspondante de la prise et pousser jusqú au
fond.
Refer to the identification/rating label located on the
back panel of your product for its proper operating
voltage.
FCC Regulations state that unauthorized changes or modifications to this
equipment may void the user’s authority to operate it.
Cable TV Installer: This reminder is provided to call your attention to
Article 820-40 of the National Electrical Code (Section 54 of the Canadian
Electrical Code, Part 1) which provides guidelines for proper grounding
and, in particular, specifies that the cable ground shall be connected to
the grounding system of the building as close to the point of cable entry
as practical.
Product Registration
Please fill out the product registration card and return it immediately. Returning the card allows us to contact
you if needed.
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record
the serial and model numbers in case you need them. The numbers are located on the back of the VCR.
Model No._______________________________________________________________________________________
Serial No. _______________________________________________________________________________________
Purchase Date:___________________________________________________________________________________
Dealer/Address/Phone: ___________________________________________________________________________
Important Information
VR556
i

1
Introduction
Introduction
Key Features Overview
Your VCR is equipped with features that will add to your recording experience. The following
information summarizes a few of these features. Chapter 3 provides more information about the rest
of the VCR’s features and how to use them.
VCR Plus+®SILVER System
The VCR Plus+ system allows for simple timer recording programming by using
a single PlusCode® programming number found in most TV program listings.
The VCR Plus+ SILVER system simplifies timer recordings by automatically
setting up and updating the VCR’s clock and channel list for you.
Requirements: Make sure that VCR Plus+ SILVER system is active, that Auto
Channel Search and time set features are correct.
Unified Remote Control
Description: The VCR’s remote control can operate most brands of TVs with a
few programming steps. This remote control can operate most RCA, GE, and
Proscan TVs without any programming at all.
Requirements: Point the remote control at the active component to see if it can
be operated. Program the remote if necessary following the steps in this manual.
Express Recording (XPR)
Description: XPR quickly records the remaining portion of a program already
in progress. XPR is a great way to capture the end of a sporting event that has
run into overtime or a live broadcast that runs long.
Requirements: Repeatedly press the Record button on the VCR front panel or
remote control to set the desired duration of time to record.
Timer Recordings
Description: Your VCR allows you to program up to eight different future
broadcasts to be recorded. You can catch a one-time, daily, or weekly broadcast
to record.
Requirements: The VCR’s clock must be set correctly. A tape with its safety tab
in place and enough tape to record a program must be inserted into the VCR.
For a cable box or satellite receiver, turn it on and tune it to the channel you
want to record before the recording is to begin.
VCR Plus+ and PlusCode are registered trademarks of the Gemstar Development Corporation.
The VCR Plus+ system is manufactured under the license from Gemstar Development Corporation.
I
N
P
U
T
T
V
•
V
C
R
PLAY FORWARD
RECORD STOP PAUSE
F.ADV
CLEAR MENU SPEED
TRACKING
1
4
7
2
5
8
3
6
9
0
C
H
A
N
V
O
L
V
O
L
C
H
A
N
INFO SEARCH
MUTE GO BACK
VCR
ON•OFF
TV
REVERSE
Rec Ch 36
Record Length 1:30
Press REC to set length
TIMER RECORDINGS
1 Create a New Program
2 Review Existing Progs.
3 Use VCR Plus+ Code
0 Exit

2
Introduction
ShowSaver™ Memory Protection
Description: Set timer programs are stored indefinitely using the VCR’s permanent memory.
This way, you’ll never have to worry about losing your programs due to an extended power
outage.
Requirements: Store a daily or weekly timer program in the VCR’s memory.
Pro-Tect Plus™ Locking
Description: Locks the VCR so that buttons on the front panel and remote control won’t
operate the VCR. This feature protects timer programs from frustrating accidents such as being
left on at the time of recording.
Requirements: Lock the VCR by pressing and holding the POWER button on the remote
control for six seconds. The front panel display will blink for several seconds. The VCR unlocks
by pressing and holding the POWER button on the remote control, again for six seconds. The
front panel display will blink again and release the lock on the system.
SQPB S-VHS Quasi Playback
Description: Your VCR will be able to play back tapes recorded in S-VHS or
S-VHS-ET mode (in VHS quality).
Requirements: Insert a tape recorded in S-VHS or S-VHS-ET mode and pressing the PLAY
button on the remote control or PLAY•PAUSE on the VCR.

3
Table of Contents
Product Registration ............................................................................................................. i
Introduction ............................................................................................................................ 1
Key Features Overview ......................................................................................................... 1
Connections & Setup ........................................................................................................... 5
Things to Consider Before Connecting Components .......................................................... 6
Cable Considerations ............................................................................................................6
Choose Your Connection ...................................................................................................... 7
Using the RF Coaxial Cable to Connect the VCR to a TV .............................................. 7
TV + VCR .......................................................................................................................... 8
TV + VCR + Satellite Receiver ......................................................................................... 9
Set the VCR’s CH 3/4 Switch ................................................................................................ 11
Plug in the VCR .................................................................................................................... 11
Put Batteries in the Remote Control .................................................................................. 11
Turn on the TV and VCR...................................................................................................... 11
Tune the TV.......................................................................................................................... 11
Using the Remote Control to Navigate On-Screen Menus ............................................... 12
Complete the QuickSet Guide ...................................................................................... 12
Accessing Menus ........................................................................................................... 12
VCR Basics ............................................................................................................................ 13
Playing a Tape ............................................................................................................... 13
Automatic Rewind ........................................................................................................ 13
Tape Eject ......................................................................................................................13
Recording ............................................................................................................................. 13
Check the Safety Tab .................................................................................................... 13
Using the VCR’s Menu System ....................................................................................... 15
Using On-Screen Menus to Set Up Features ...................................................................... 16
Language ....................................................................................................................... 16
Cable Box Setup ............................................................................................................ 16
VCR Channels List.......................................................................................................... 17
Auto Channel Searching ....................................................................................... 17
Changing the Signal Type ..................................................................................... 18
Adding or Removing Channels ............................................................................. 18
Time and Date ............................................................................................................... 19
Auto Clock Set Feature.......................................................................................... 19
To Turn Auto Clock Set ON .............................................................................. 19
Setting the Time Zone ..................................................................................... 19
Setting Daylight-Saving Time .......................................................................... 20
Setting Time and Date Manually .......................................................................... 20
Additional Set Up Features in the Preferences Menu ....................................................... 20
Remote VCR1/VCR2 Option .......................................................................................... 21
Auto Play .......................................................................................................................21
Auto TV/VCR.................................................................................................................. 21
EnergySaver................................................................................................................... 22
Front Panel Brightness (VCR Display) .......................................................................... 22
Tape Speed .................................................................................................................... 22
Set Auto Repeat ............................................................................................................ 23

Table of Contents
4
Using the Remote Control ............................................................................................... 25
Using the Remote Control .................................................................................................. 26
Buttons of the Remote Control ................................................................................... 26
Using the INPUT Button ........................................................................................ 27
Operating a TV with the VCR’s Remote Control ............................................................... 28
Do You Need to Program the Remote? ....................................................................... 28
Programming the Remote Control ....................................................................... 28
Operating the TV ................................................................................................... 28
Using the VCR’s Features .................................................................................................. 31
Recording Features ............................................................................................................. 32
Express Recording (XPR) ............................................................................................... 32
Timer Recording ............................................................................................................ 33
Stopping a Timer Recording ................................................................................. 33
Reviewing and Clearing Programs ....................................................................... 33
VCR Plus+ SILVER System .............................................................................................. 34
Turning ON or OFF the Auto VCR Plus+ download ............................................. 34
Mapping VCR Plus+ Channels Manually .............................................................. 35
VCR Plus+ System Worksheet .......................................................................... 37
Copying and Editing Tapes Using Two VCRs ............................................................... 38
Picture Search Options ........................................................................................................ 38
Forward and Reverse Search ........................................................................................ 38
Slow Motion .................................................................................................................. 39
Frame Advance ............................................................................................................. 39
Index Search .................................................................................................................. 39
Go-To Search ................................................................................................................. 40
Pro-Tect Plus™Locking Feature ......................................................................................... 40
Tracking................................................................................................................................ 41
Time Counter ....................................................................................................................... 41
On-Screen Displays ..............................................................................................................42
Other Information .............................................................................................................. 43
Troubleshooting Tips ........................................................................................................... 44
General VCR Problems .................................................................................................. 44
Recording Problems ...................................................................................................... 45
Playback Problems ........................................................................................................ 45
Specifications ....................................................................................................................... 47
Cleaning the VCR ................................................................................................................47
Front Panel .......................................................................................................................... 48
Display Panel ....................................................................................................................... 49
Back Panel ............................................................................................................................ 50
RCA VCR Limited Warranty................................................................................................. 51
How to Find Your TV’s Video Input Channel ..................................................................... 52
Advanced Connection ......................................................................................................... 53
TV + VCR + Satellite Receiver ....................................................................................... 53
Glossary ................................................................................................................................ 54
Index .................................................................................................................................... 55

5
Changing Entertainment. Again.
Connections & Setup
Chapter Overview:
•Things to Consider Before Connecting
•Cable Considerations
•Making the Connection
•Navigating On-Screen Menus
•Completing the QuickSet™Guide
•Basic Recording
Chapter 1

6Chapter 1
Connections & Setup
Things to Consider Before Connecting
Components
Protect Components From Power Surges
• Connect all components before plugging any power cords into the wall outlet.
• Always turn off the TV and other components before you connect or disconnect any cables.
Position Cables to Avoid Audio Hum or Interference
• Insert all cable plugs firmly into their jacks.
• Place any Audio/Video (A/V) cables to the side(s) of the TV’s back panel instead of straight
down the back after connecting components.
• Try not to coil any twin-lead cables and keep them away from all A/V cables as much as
possible.
• Make sure all antennas and cables are properly grounded. Refer to theSafety Tips sheet
packed with your unit for detailed information.
Protect Components From Overheating
• Never block ventilation slots in any component. Arrange the components so that air can
circulate freely.
• Do not stack components.
• Allow adequate ventilation when placing components in a stand.
• Place an amplifier or satellite receiver on the top shelf of a stand so heated air rising from it
will not flow around other components.
Cable Considerations
The RF coaxial cable supplied with your VCR carries both sound and picture information. This is
the cable used in all connection diagrams in this chapter.
If your TV has A/V input jacks, you should use A/V cables (not supplied) to connect the VCR to
the TV. A/V cables provide better picture and sound quality than an RF coaxial cable. If you
would like to hook up your VCR using A/V cables, refer to the Advanced Connection information
on page 53 in theOther Information chapter of the manual.

Chapter 1 7
Connections & Setup
Components Connection Go To
Title
TV + VCR page 8
TV + VCR +
Satellite Receiver page 9
TV + VCR +
Cable Box page 10
VCR
TV
Satellite
Cable Box
VCR
TV
VCR
TV
Using the RF Coaxial Cable to Connect the
VCR to a TV
The picture on the next page shows the RF coaxial cable supplied with your VCR.
This will be the cable used for the basic connections represented in this
chapter.
Notes: To hear stereo sound, you will need to purchase Audio/Video (A/V)
cables (not provided) and connect the VCR to the TV. A/V jacks and cables
also provide a superior image and sound quality. For details about using
this advanced setup, see the instructions on page 53.
Using A/V jacks to connect the VCR to the TV requires tuning to the TV’s
Video Line Input to see the VCR’s picture. For more information about
finding your TV’s Video Line Input, see page 52.
RF Coaxial Cable
Choose Your Connection
There are several ways to hook up your VCR depending on the components connected.
Please use the following chart to determine which connection is best for you and proceed
to the appropriate page.

8Chapter 1
Connections & Setup
TV + VCR
Note: Your television back panel may not look exactly like the model
shown here.
1. Connect the VCR to the TV
Connect one end of the supplied RF coaxial cable to the RF OUT jack on
the back of the VCR and the other end to the TV’s Antenna input jack.
2. Connect the antenna/cable feed to the VCR
Connect the satellite, cable, or antenna RF coaxial cable to the ANT. IN jack
on the back of the VCR.
NOTE: Flip the CH 3/4 switch on the back of the VCR to the channel that is
not used in your area. This will be the channel that the TV must be tuned
to in order to see the VCR’s picture.
Go To Page 11
VCR
TV
CH
ANT. IN
OUT IN
AUDIO
VIDEO
3 4
RF OUT
VCR
TV (back panel)
CABLE/
ANTENNA
VIDEO RL / MONO
S-VIDEO
AUDIO
L
IN
OUT
From Cable
or Antenna
1
2

Chapter 1 9
Connections & Setup
TV + VCR + Satellite Receiver
Note: Your television and satellite receiver back panel may not look
exactly like the models shown here.
1. Connect the VCR to the TV
Connect one end of the supplied RF coaxial cable to the RF OUT jack on
the back of the VCR and the other end to the TV’s Antenna input jack.
2. Connect satellite receiver to the VCR
Connect an RF coaxial cable to the antenna output jack on the satellite
receiver and to the ANT. IN jack on the back of the VCR.
3. Connect the antenna to your satellite receiver
If necessary, connect an antenna or cable box RF coaxial cable to the
antenna input jack on the satellite receiver.
4. Connect the satellite feed to the satellite receiver
Connect the satellite receiver’s RF coaxial cable feed to the satellite input
jack on the satellite receiver.
Go To Page 11
VCR
TV
Satellite
CABLE/
ANTENNA
VCR
TV
VIDEO RL / MONO
S-VIDEO
AUDIO
L
IN
OUT
CH3
CH4
SATELLITE
RECEIVER
S-VIDEO
L
R
VIDEO
OUT
IN FROM ANT
OUT TO TV SATELLITE
IN
From
Satellite
From Cable
or TV Antenna
CH
ANT. IN
OUT IN
AUDIO
VIDEO
3 4
RF OUT
1
2
34

10 Chapter 1
Connections & Setup
TV + VCR + Cable Box
Note: Your television and cable box back panel may not look exactly like
the models shown here.
1. Connect the VCR to the TV
Connect one end of the supplied RF coaxial cable to the RF OUT jack on
the back of the VCR and the other end to the TV’s Antenna input jack.
2. Connect the cable box to the VCR
Connect one end of an RF coaxial cable to the cable box’s antenna output
jack and the other end to the ANT. IN jack on the VCR.
3. Connect the cable feed to your cable box
Connect an RF coaxial cable feed to the antenna input jack on the cable
box.
Go To Page 11
CABLE/
ANTENNA
VCR
TV
VIDEO RL / MONO
S-VIDEO
AUDIO
L
IN
OUT
CH3
CH4
CABLE BOX
L
R
VIDEO
OUT
IN FROM ANT
OUT TO TV
From Cable Feed
CH
ANT. IN
OUT IN
AUDIO
VIDEO
3 4
RF OUT
2
1
3
VCR
TV
Cable Box

Chapter 1 11
Connections & Setup
Set the VCR’s CH 3/4 Switch
The CH 3/4 switch on back of the VCR determines what channel the TV must be tuned to see
the VCR’s image. Choose whichever channel is not used locally in your area.
Note: If you connected components using A/V jacks and cables, the VCR’s signal must be
viewed using the TV’s Video Line Input. To find the Video Line Input, refer to the manual
that came with the TV or see How to Find Your TV’s Video Line Input on page 52 in the
Other Information section of this manual.
Plug in the VCR
Your VCR’s power cord has a plastic band strung through the blades. Remove the plastic band
before plugging the cord into the power outlet. To remove the band, cut with a pair of
scissors and pull it free of the blades. Once the plastic is removed, match the wide blade of the
power cord to the wide slot in the AC outlet. Be sure to insert the plug completely.
Put Batteries in the Remote Control
1. Remove the battery compartment cover on the remote control.
2. Insert new batteries matching the polarities (+ and –) on the batteries with
the diagram in the battery compartment.
3. Put the battery compartment cover back on the remote.
Turn on the TV and VCR
Turn on the TV and press the VCR button on the remote control to turn it on.
Note: If you have an RCA, GE, or Proscan TV, your VCR’s remote control
may be able to operate it without being programmed. Press the TV button
on the remote control and then the ON•OFF button. If neither one turns on
the TV, see Using the Remote Control starting on page 25 for details about
programming the remote control to operate other brands of TVs.
Tune the TV
Tune the TV to the VCR viewing channel. The VCR viewing channel is channel
3, 4, or the TV’s video line input.
• If you connect your VCR using RF coaxial cable only, turn the TV to
channel 3 or 4 (whichever was set on the CH 3/4 switch).
• If you connected the VCR using A/V jacks and cables, select the TV’s video
line input. For more information see How to Find the TV’s Video Line Input
on page 52 in theOther Information section of this manual.

12 Chapter 1
Connections & Setup
Using the Remote Control to
Navigate On-Screen Menus
The technical term is “Navigation” – how you move through the on-screen menus. The theory is
the same for all the menu screens; use the corresponding number button on the remote control
select it.
To choose an on-screen item, press the remote control’s corresponding number button.
Note: Selecting a menu item can take you to another menu, activate a choice, or activate a
data entry field (such as the hour field in the Set Time menu).
Select a language.
Seleccione un idioma.
Choisissez une langue.
1 English
2 Español
3 Français
VCR MAIN MENU
1 VCR Plus+
2 Timer Recordings
3 Time
4 Channels
5 Setup
6 Preferences
7 Language
0 Exit
Complete the QuickSet Guide
The menu system in your VCR allows you to customize your preferences as
well as use all the VCR’s features. To help you use the VCR as quickly as
possible, there is an initial QuickSet Guide that walks you through several
important setup steps at one time.
The first time you turn on the VCR, you will be able to set up available
channels, time and date information, and more. The first menu you will see
asks which language you prefer to have the on-screen menus appear in.
Note: With numbered menu choices, you can also press the corresponding
number button on the remote control to automatically select it. In the case
of the language menu, press 1 for English, 2 for Español (Spanish), or 3 for
Français (French).
The remaining menus throughout the setup will appear in the languagechosen.
Just follow the step-by-step procedures until the QuickSet Guide is complete.
Accessing Menus
The series of preferences that are set in the QuickSet Guide can also be
handled individually using the VCR’s on-screen menu system. There are other
settings not covered in the initial setup that are also handled using the on-
screen menus.
For example, if you decide to run the QuickSet Guide again, you can access the
Setup menu by pressing the remote control’s MENU button. Once theMain Menu
is displayed, press the 5 button to chooseSetup. From there, you can start the
QuickSet Guide from the beginning.
All on-screen menus are accessed the same way, starting in theMain Menu
which is displayed by pressing the remote control’s MENU button.
Note: See chapter two, Using On-Screen Menus, for details about changing
the VCR’s individual settings.
All of the VCR’s menus are
accessed through the Main
Menu. Press the remote
control’s MENU button to
start.

Chapter 1 13
Connections & Setup
VCR Basics
Once your initial settings are complete, you can begin using your VCR. In order to begin, you
must first understand some basic concepts.
.
Safety Tab
Automatic Tracking
The VCR has automatic tracking
which adjusts the picture when
playing back a tape recorded on
another VCR. To adjust tracking
manually, use the TRACKING -/+
buttons on the remote control.
Playing a Tape
1. Tune the TV to your VCR viewing channel (03, 04, or the video line input).
2. Insert a tape in the VCR.
If the Auto Play feature is set to ON, the tape automatically begins playback
(if the safety tab on the tape is removed).
• Press FWD or REV (FORWARD or REVERSE on the remote control) to cue
the tape at the desired starting position.
• Press PLAY (if necessary) to begin tape play.
• Press PAUSE for stop action.
• Press TRACKING up or down (TRACKING + or – on the remote
control) to remove any streaks from the picture, if necessary.
• Press STOP to stop playback.
Automatic Rewind
The VCR automatically rewinds the tape if it reaches the end of the tape during
playback. While rewinding, you can press the ON•OFF button and the VCR will
turn off after finishing. If the tape has no safety tab, it will be ejected.
Tape Eject
Press the EJECT button on the VCR when stopped to eject the tape. You can also
press and hold the remote control’s STOP button for three seconds.
Recording
To Capture Programming with Basic Recording Methods:
1. Set the tape speed by pressing the SPEED button on the remote control
(see Recording Speed on page 22 for information about recording speeds).
2. Press the RECORD button to begin recording.
3. Press the STOP button to halt recording.
If you just want to pause the recording for a short time (like during a
commercial), press PAUSE instead of STOP.
Check the Safety Tab
No matter which recording option you use, make sure there is a tape in the VCR
with its safety tab in place. You cannot record on a tape with its safety tab
removed. If the safety tab is removed and you want to record, simply cover the
hole with adhesive tape.

This page left blank intentionally

15
Changing Entertainment. Again.
Using the VCR’s
Menu System
Chapter Overview:
•Setting Up the VCR’s Preferences
•Using On-Screen Menus
•Cable Box Setup
•Setting Time and Date
•Setting VCR Preferences
Chapter 2

16 Chapter 2
Using On-Screen Menus
Using On-Screen Menus to Set Up Features
You set up many of the VCR’s features by using the menu system as discussed in the previous
section. Each feature that appears in the QuickSet Guide is explained in this section as well as a
few other features you should set up to get the most out of your VCR.
Note: Not all the VCR screens are shown in this manual when explaining the features.
Language
Selecting your preferred language determines how the on-screen displays will
appear. To change the language:
1. Press MENU to display theVCR MAIN MENU.
2. Press the 7 button to selectLANGUAGE.
3. Select English, Spanish (Español), or French (Français).
Cable Box Setup
This set up applies only when all channels are received through a cable box. In
this case, the VCR will automatically enter the channel used to view cable box
programming. Your VCR will use this channel for all future timer recordings.
1. Press MENU to display theVCR MAIN MENU.
2. Press 4 to display theCHANNELS menu.
3. Press 5 to display theCABLE BOX SETUP menu.
LANGUAGE
Select a language.
1 English
2 Español
3 Français
Press MENU to continue
CHANNELS
1 Auto Channel Search
2 Add/Remove Channels
3 Signal Type: CABLE
4 Cable Box Setup
0 Exit
Is Something Missing?
These instructions will not show
all of the step-by-step on-screen
menus. Make sure to follow the
instructions completely to get
to the menus being discussed.

Chapter 2 17
Using On-Screen Menus
4. Select one of the three choices. If “ALL Channels” is selected, enter the
output channel of the cable box (usually 03 or 04), or if A/V jacks connect
the VCR to the TV, press the INPUT button on the VCR’s remote control.
5. Once you complete the setup, the VCR confirms that it will now receive all
signals on the designated channel.
VCR Channels List
Your VCR may come with a list of channels preset at the factory. Even though it
may come with such a list, you may want to add or delete certain channels.
Note: If you use a cable box to view all channels, this step is not necessary.
Auto Channel Searching
Note: Use Auto Channel Search to place all available channels in memory.
If you ever change cable or antenna signals, you may need to run the Auto
Channel Search feature again.
1. Press the MENU button to display theVCR MAIN MENU.
2. Press 4 to select CHANNELS.
3. Press 1 to selectAUTO CHANNEL SEARCH.
4. Select one of the three options:
Cable TV searches for cable stations.
Antenna searches for local broadcast stations.
Detect Automatically decides which input to use for you.
Notes: With Detect Automatically, a strong cable or antenna signal in your
area may cause channels to be detected inaccurately. If this should happen,
manually select the input signal for the system you have.
The VCR begins scanning for channels available in the area (taking about
one-to-two minutes). When scanning is complete, the VCR tunes to the
lowest channel available. After completing Auto Channel Search, pressing
the remote control’s CHAN + or - buttons should only select active
channels.
CABLE BOX SETUP
Do you use your cable
box to receive ALL
channels or only SOME
channels?
1 ALL channels
2 Only SOME channels
3 Cancel setup
CABLE BOX SETUP
On what channel does
the VCR receive signals
from the cable box?
(usually 3, 4, or Video)
--
Enter 01-13 or INPUT
Press MENU to cancel
AUTO CHANNEL SEARCH
What type of signal
are you using?
1 Cable TV
2 Antenna
3Detect Automatically
0 Cancel

18 Chapter 2
Using On-Screen Menus
Changing the Signal Type
This feature is useful if your cable signal goes out; it allows you to switch to a
regular antenna for alternate television reception.
1. Press the MENU button to display theVCR MAIN MENU.
2. Press the 4 button to chooseCHANNELS.
3. Press 3 to choose betweenSignal Type: Cable and Antenna. When
finished, press 0 to exit back to the Main Menu and 0 again to exit to
normal viewing.
Adding or Removing Channels
You might want to add or remove channels after using Auto Channel Search,
especially if there are weak signals or channels with content you don’t care for.
1. Press the MENU button to display theVCR MAIN MENU.
2. Press 4 to choose CHANNELS.
3. Press 2 to choose ADD/REMOVE CHANNELS. To go to the channel you
want to add or remove, use the remote control’s CHANNEL + or – buttons
or enter a specific channel number using the number buttons.
Once the desired channel is displayed, the on-screen menu will tell you if
the channel is currently in the VCR’s viewing list. Press the CLEAR button to
remove a channel from the available channels list or press the INFO button
to add it.
4. Once finished adding/deleting channels, press the MENU button to exit out
of the menus.
Note: To view active channels, use the remote control’s CHANNEL + and -
buttons. You can also access channels not available in the active channel
list by using the remote control’s number buttons to enter the specific
channel number.
CHANNELS
1 Auto Channel Search
2 Add/Remove Channels
3 Signal Type: CABLE
4 Cable Box Setup
0 Exit
ADD/REMOVE CHANNELS
Channel 115
is presently ADDED
Press CLEAR to remove
Press MENU to exit
