Rcom MAX 50 User manual

REV. 3.1

USER'S MANUAL
MAX 50
DIGITAL EGG INCUBATOR
W
A
T
E
R
P
U
LL
OP
EN

DIGITAL INCUBATOR 3
How to use Rcom MAX 50
(1) Rcom 50 Introduction
1. Introduction
4
(2) Safety Precautions
5
(3) Identification of Parts and Composition
6
(4) Function of Digital Control & How to Operate
7
(1) How to Assemble the Incubator / Egg-Turning plate
2. Before use
8
(2) What is an incubation room?/ Preparation for Incubation
9~10
3. Function Settings
(1)
(1)
(2) Change Cels.& Fahr.
11
(3) Temperature & Humidity Setting / How to Set Egg-Turning
12~13
(2) Dew Condensation
4. Incubation
14
(2) Troubleshooting
6. Product Information
18
(1) Servicing / Frequently Asked Questions (FAQ)
17
(3) Specification
19
Introduction
Before use
Function Settings
Incubation
How to Clean
Product Information
5. How to Clean
(1) How to Disassemble
(2) How to Clean
15
16
Humidity & Air Maintenance during Incubation /
Maintenance after Hatching
Contents
Incubator Start&Termination /
Return to Factory Setting
The result of Hatching can be changed by a large numbers of factors. Autoelex Co., Ltd. &
our distributors will not take any responsibility for ‘Loss of eggs or pet/animal lives’ under any
circumstances such as ‘Hatching/Brooding failures’, ‘User’s carelessness’, ‘Personal (un-certificated)
conversion / alteration’, ‘Arbitrary using out of the machine’s purpose’, ‘Electric power failure’, or
‘Malfunctioning’. Please be sure that the machine works without any problem before placing Eggs or
Pets(Animals). Also, we strongly recommend you to read the User’s Manual carefully to minimize of
any failure.
Caution : Caution mark against a fault that can cause damage, trouble, or failure of incubation.
Tip : References or useful suggestions in using Rcom product
Mark Explanation
Warning of actions which may be dangerous or cause damage to the incubator.
Prohibited
Do not disassemble.
Do not touch.
It is necessary to keep.
Remove the power cord from outlet.
Ground Connection for preventing electric shock.

DIGITAL INCUBATOR
4
[Main Features]
* Outer Temp. Sensor included for Automatic Adjustment of Heating rate responding to Incubation Room
Temperature
* Superior design with convenient operation
* Optimum air circulation technique with 5 strong BLDC fans
* Automatic Temp. & Humidity setting and control
* Body locking device
* Water supplement alarm function
* 48 eggs capacity for chicken size eggs ( 116 Quail egg size / 24 Goose egg size)
* Antiblastic Humidification method by heating water, which discourages bacterial growth
* Double-glazed view window for minimizing the influence of outside temperature
* Enhanced reliability by applying Swiss's Sensirion's 3rd generation temperature & humidity sensor
* Strong SMPS application for stable power supply
[Safety Features]
* Alarm and display function of abnormal incubator temperature caused by sudden fluctuation of ambient
temperature
* Incubation data memory function and power outage notification function in case of power failure
* Circulation fan cover for safety and electric safety cut-out switch on the upper main body for safety
* Heater supporter designed for heater tension control and its safety
* Safety cover applied for protecting humidification unit
* Humidification unit durability improved by water proof BLDC fan
* Alarm when water need replenishing
[Easy Features]
* No need of separate humidification unit as it included in main body
* ˚C or ˚F convertible
* Easy attachment and detachment of double-glazed viewing window
* Universal egg tray for various size eggs
* Slide plate with embossed feature for preventing skid
* Variable air vent for adjusting air supply
* Bottom body designed for easy cleaning
* Roller Dividers, which can safely apply egg turning for expensive or rare eggs. (Option)
1. Introduction
Rcom 50
Features
Thank you for choosing the Rcom incubator.
The Rcom 50 incubator is the first incubator with creditability to have a superior design and function
which help in controlling optimum incubation conditions. It has two sensors, one for detecting
surrounding environments and the another for internal incubator conditions.
The Rcom 50 is designed easy to use and simple to use as a customer orientated product, but please
remember that the user's incubation knowledge and proper operation are very important for the best
incubation result. Therefore, be sure to read this user's manual carefully before you use this incubator.
The Rcom 50 offers optimum incubation conditions, but users need to observe and manage all
incubation conditions such as species of eggs, temperature or humidity for each incubation period, and
an optimum incubation circumstances .
(1) Rcom 50 Introduction

DIGITAL INCUBATOR 5
1. Introduction
Electrical hazards Be careful the details below when you use.
Setting Cautions Be careful the details below when you use.
Do not pull the cord when
taking out the power cord, and
keep wet hands away from
connecting plug.
Do not use a damaged power
cord or loose outlet.
▶ Risk of electric shock or fire.
▶ Risk of electric shock or fire.
Do not insert multiple
connecting plugs in an outlet.
▶ Risk of fire or electrical
overload.
Never pull the plug out of the
outlet during the incubation
period.
▶Incubation will be interrupted.
Do not twist or crush electric
cord.
▶ Risk of electric shock or fire.
Cleaning Cautions Be sure to disconnect the electric cord
from the outlet before cleaning.
Clean the incubator by a soft
cloth with a neutral detergent.
Do not spray cleanser directly
on the incubator surface.
Do not use chemicals like wax,
benzene, alcohol, thinner,
aromatic, or lubricant, etc.
Brush away dust on the plug
with a dry cloth.
For special cleaning of inner
part per year, contact to the
service center.
▶ If you don't clean the inside of
incubator for a long time, dust
can cause some trouble or a fire.
Do not install under the direct
sunlight.
Do not install in dusty or dirty
environment.
▶ Risk of fire or interference
with the incubation process.
▶ Risk of damage or fire within
the incubator.
Do not install in excessively
cold or hot conditions,
cigarette smoke, etc.
Do not install in moist or
humid environment.
▶ Risk of interference with
the incubation process.
▶ Risk of fire or electric shock.
Do not use any other
non-standard parts except
those provided.
▶ Risk of damage or hatching
failure.
Please ensure that no small
objects get into
the holes on the incubator.
▶ Risk of electric shock or fire.
Do not disassemble or modify
the incubator in any way.
▶ Risk if electric shock or fire.
If the incubator sounds
strange or emits smoke
contact your service center.
▶ Risk of electric shock or fire.
If the incubator requires repair
disconnect from the power
supply and please contact to
your service center.
Clean the incubator thoroughly
before storing.
Install away from heat
sources.
▶ Risk of damage to the
incubator case and
interference with the
incubation process.
Do not turn the incubator
upside down.
▶ Water will pour out of the
incubator, and view window
can be dropped or damaged.
Ensure that the incubator is
installed on a stable surface
away from edges.
▶ Risk of damage to incubator
and eggs and user from
accidental knocks or drops.
Do not cover the ventilating
opening.
▶ Inner temperature can rise,
interrupting incubation. ▶ Risk of knocking the incubator
or accidental interference with
the controls.
Children should be supervised
to ensure that they do not play
with the appliance.
(2) Safety Precautions

DIGITAL INCUBATOR
6
1. Introduction (3) Identification of Parts and
Compositio
Water overflow hole
Hole that water flows out of the product
automatically when you pour water into the water
hole more than required amount(1300~1400cc).
Identification of Parts
Basic Components
Universal Tray Divider
Adjust the space of dividers
according to egg size.
Handle
Handle
W
AT
ER
P
ULL OPEN
Power Connecting (the rear)
For connecting power cord.
For inlet of air
from outside
Air inlet vent
For circulating warm air
Vents for air circulation
Serial No.
Water hole
To facilitate water top-up
for the humidity control.
Digital Control Center
See description of
the function and operation.
Main Body-1
Main Body-2
Locking Button
View Window
For a clear view of
the incubation process.
(Double Skin Viewing Window)
Water Cap
View Window
Main Body-1 Main Body-2
Universal Tray
Divider(10EA)
Universal Tray SET
Power Cord
Small egg
Tray
Standard egg
Tray
Large egg
Tray
User's Manual
Easy function
operation
Rolling Divider SET
Sold Separately
W
AT
E
Volt for window assembly
Duplicated
View Window
(EX:RCM0950278)
If you register your information with
your machine’s serial number on our
web-site(www.Rcom.co.kr),
you can get 2 year warranty service.
Egg-Turning Plate

Humidity UP Button
Setting Humidity Up
DIGITAL INCUBATOR 7
1. Introduction
(4) Function of Digital Control &
How to Operate
[ Function Operation & Explanation ]
Function of Digital Control & How to Operate
※If you want to change setting value, keep pressing "SET" button and change the value.
※put some water after take off label from the back and attach to the window.
How to OperateFunction Explanation
Changing
Cels. & Fahr. Changing Cels. & Fahr.
Temp.
Setting Setting of needed temp.
Humidity
Setting
Egg-Turning
Interval Setting
Setting of needed humidity.
How to OFF
Humidification
Function
Egg-Turning
Test Egg-Turning Test (once)
Initialization
(Factory setting) Initialization
Set Humidity as 20%
Egg-Turning Interval Setting
as required
2 Hours
once 2 times
3 Hours
3 times(OFF)
Lamp OFF
Default setting
every1 hour
(Lamp: ON)
4 times
every 1 hour
(Lamp ON)
repeat
20%
Temp. UP Button Temp. Display
Humidity Display
(Blink with water shortage)
Temp. DOWN Button
Setting Temp. Up
Setting Temp. Down
Turn on with automatic
egg-turning mode.
(Blink when working)
- Alarm for water supplement sounds in twice.
( First alarm with water shortage / Second alarm after 3 hours )
Water Supplement Lamp
Egg-Turning Lamp
(Lighting when working)
Heater Lamp
(Lighting when working)
Humidification working lamp
Power Failure Alarm Function
Blink with power failure
(to remove, press SET button)
Setting value check
Setting Button
Egg-Turning Setting Button
Automatic egg-turning setting
or cancellation
/ Egg-turning test
Humidity DOWN Button
Setting Humidity Dow Setting Humidity Down
Setting Temp. Down
Automatic egg-turning setting
or cancellation
/ Egg-turning test
Setting value check
What’s ‘Temperature&Humidity Setting’?
This is that you set up temp.&humi. As you want to have inside of the machine.

W
A
T
E
R
P
U
LL
OP
EN
W
AT
E
2
1
3
4
5
View Window
Egg-Turning Plate
Main Body-1
Universal Tray
Water Cap
Main Body-2
* Fit the water cap.
UNDERSIDE
110V~120V
* Fit the water cap.
6
BACK
7
Gear
connecting part
▶Lock the four locking buttons
at the front and rear of the
incubator.
DIGITAL INCUBATOR
8
2. Before use
(1) How to Assemble the Incubator /
Egg-turning plate
How to Assemble
▶Insert the power cord in the
socket at the back of the
main body.
Be careful when you assemble egg turning plate.
▶If you do not assemble egg turning place correctly,
it can cuase incubator failure.
▶Gear connecting part of egg turning plate must be
on the top side.

DIGITAL INCUBATOR 9
2. Before use
(2) What is an incubation room? /
Preparation for Incubation
※How to turn off Humidification Function : Set humidity level at RH 20%.
What's an Incubation Room? / Preparation for Incubation
1
2
Insert the electric cord in the connecting jack
in the back of the main body and put the main plug into a socket.
The FND display will light up and show temperature.
110V~120V
W
A
T
E
R
P
U
LL
OP
EN
LIMIT Indication
DISTILLED
WATER
Open the watercap and fill the hole with DISTILLED WATER and refill water after about 5 min.
again up to the limit line on its inside mark.
(If you refill water during the incubation period, humidity goes down temporarily.)
The Incubation Room is a confined space for setting and operating an incubator.
Because the incubation room environment has a considerable effect on hatch rate, it's recommended to
control the environment for setting up an incubator; there should be little noise and vibration around and
temperature ranging 28℃(82.4℉) with small variation in temperature. Especially, if there are frequent occasions
when the temperature drops suddenly at night, compared with daytime, be sure to check from time to time
and pay attention so that the incubator is not directly exposed to s
unlight during daytime.
After filling up with water, never shake or turn over the main body of the incubator, which would cause
water to spill inside the body and could cause a breakdown. Please close the water cap properly after fiilng.
In case you use the incubator without adding humidification water or intend to incubate eggs at low
humidity under RH 20%, you must stop its humidification function. please turn off the humidity unit if the
unit is empty water otherwise, humidity unit will be broke or you may not no longer use the unit.
(When using this function, the alarm for sensing water drop will go out.)
[See the description of humidification function OFF on Page 12]
During incubation period, check the DISTILLED WATER water levelabout every three days and refill water,
if necessary. (After you refill water, check again after 5min. and refill again.)
※When you pour water into the water hole more than required
amount, water flows out through the water overflow hole at the
bottom of the product as the picture. This is an intended design,
not a defect.
Please be noted that when you pour water, please pour it slowly,
several times into the water hole with the required amount
(1300~1400cc).
P
U
LL
OP
EN

W
A
T
E
R
P
U
LL
OP
EN
W
A
T
E
R
P
U
LL
OP
EN
W
A
T
E
R
P
U
LL
OP
EN
About 2mmAbout 2mm
2. Before use
(2) What is an incubation room? /
Preparation for Incubation
3Place the eggs to incubate in the egg groove and
then close the view window.
※When you use the 'universal rolling divider' which is sold separately, be careful to adjust the distance of rolling
divider so that eggs do not roll out of position. Refer to the picture rignt side.
If you use Mineral water or Tap water for humidification,
the humidity unit can be broken easily because of water
scales. We strongly recommend you to use only
“DISTILLED WATER” for your machine, and
Autoelex Co.,Ltd & our distributors do not indemnify for
warranty service not only if you have any problem with
using mineral water, regular water, tab water and the like
but also if you had improper management or handling
for your machine. In this case, Autoelex Co.,Ltd. & our
distributors will charge for your after service.
Some gap (about 2mm) around the eggs is needed for easy egg turning as shown on the below. ▼
Be careful to close the view window completely;
if not, the temperature and humidity will fail to go up.
The egg to incubate must be a fertilized egg.
(Refer to the guidebook.)
You can buy the ‘Distilled water’ in your local market,
and if you have any question, please contact the shop,
where you purchased your machine.
DIGITAL INCUBATOR
10

DIGITAL INCUBATOR 11
3. Function Settings
(1)Incubator Start&Termination /
Return to Factory Setting
(2) Changing Cels.&Fahr.
How to change Cels. & Fahr.
How to terminate incubation
Return to factory setting
How to start incubation
110V~120V
110V~120V
▶Press and buttons at the same time
and CA will show on Temp. display.
Then press button, it will change
as shown on the right.
repeat
▶It is for returning to the factory default setting.
▶It is for initializing the incubator setting or calibration to the factory settings when you handle the incubator
improperly so that the value has changed. Unplug the power supply and hold SET button and re-plug the
power supply as shown on picture. Then, rSt will show on the display, and the incubator will be initialized to
factory setting.
▶If you connect the incubator with power cord,
second dot " . " of temp. display is blink with alarm.
Press SET to remove blink and then it starts incubation with
existing temperature and humidity.
[Factory default setting - Temp. : 37.5℃(99.5℉), Humidity : RH 45%]
▶After all eggs are hatched, you should REMOVE
the power cord for incubation termination.
(The incubator has no separate power switch.)
▶Be sure to turn ON egg turning before incubation starts
and turn OFF before 3 days of hatching. At this time, it's
recommendable to raise humidity up to 60~70%.
[Refer to Egg Turning ON/OFF on Page 13.]
There can be some smell the first time you use the incubator,
that is normal.
Power Failure Notification : When firstly input power, or power
failure during incubation, second dot " . " of temp.
display is blink with alarm. Press SET to remove.
110V~120V
②
HOLD
①Keep pressing SET button Re-plug the power supply
"rSt" will show on the display as
below, and the incubator initialize to
factory setting.
③
TEMP+
TEMP-

DIGITAL INCUBATOR
12
3. Function Settings
TEMP+
▶In a state of button being pressed, press button to adjust humidity at RH 19% and, then,
humidification function will be OFF. On the contrary, if you adjust humidity above RH 20%, its function will
be ON.
How to Turn ON/OFF Humidification Function
How to Set Humidity
How to Set Temperature
▶In a state of button being pressed, adjust the
temperature you want with or button.
Temperature setting will be completed when you remove
your finger from the button, and the present
temperature of the incubator inside will be indicated.
①(Keep pressing the button)
▶In a state of button being pressed, adjust the
humidity you want with or button.
humidity setting will be completed when you remove your
finger from the button, and the present humidity
of the incubator inside will be indicated.
▶Be sure to set humidity RH 65 ~ 70% from 1~3 days before hatching.
①(Keep pressing the button)
Temperature and humidity can be different from normal setting levels according to the surrounding
environment. (Refer to a incubation guidebook which is supplied separately.)
If you press SET button, the present setting temperature and humidity will be indicated and, if you remove
your finger from the button, the present inner temperature and humidity indicated.
If you set the incubator under a direct ray of light or too cold spot, the incubator temperature can be higher
or lower than setting temperature.
In case you use the incubator without adding humidification water or intend to incubate eggs at low
humidity under RH 20%, you must stop its humidification function. please turn off the humidity unit if the
unit is empty water otherwise, humidity unit will be broke or you may not no longer use the unit.
Temperature and humidity is optimized when Rcom products are released.
We do no recommend customers to recalibrate by their own. If you need to recalibrate, please visit our
website (www.rcom.co.kr→Download→Manual) or ask purchase place.
Because of low price thermometers and hygrometers are not accurate, e recommend you to use special
calibrated thermo-hydrometer. (Poultry only thermo-hydrometer: check Rcom website: DigilogⅡ)
(3) Temperature & Humidity Setting /
How to Set Egg-Turning

How to Set Abnormal High or Low Temperatue Alarm
How to Set Egg Turning ON/OFF
▶In a state of button being pressed, press
button then the setting will be changed as required.
▶What is Abnormal High or Low Temperature Alarm?
It is alarm soulds when incubator temperature is higer or lower than setting value because of various reasons
such as room temperature change or disorder of temperature controlling system.
▶Egg Turning Test : If you press button for
about 5 seconds, egg turning test will be effected once.
①(Keep pressing the button)
Once (Lamp ON)
Egg turning Interval
: 2 hours
4Times (Lamp ON)
Egg turning Interval :
an hour
2Times (Lamp ON)
Egg turning Interval
: 3 hours
3Times (Lamp OFF)
Egg turning Interval
: OFF
repeat
* Max. abnormal temp. alarm limit (0.0 ~ 5.0℃Default Setting:2.0℃)
* Min. abnormal temp. alarm limit (0.0 ~ -5.0℃Default Setting:-3.0℃)
※ How to Set
5Sec. Set required
high range with
UP / DOWN button
Set required
low range with
UP / DOWN button
Save setting and
pass to current
temp. & humi.
indication
Save setting and
pass to
low humi. set
3. Function Settings
Be sure to set TURNING OFF 3 days before hatching.
▶Plese press button over 5 seconds
to turn ON or OFF egg turning melody.
Egg Turning Melody ON / OFF
(3) Temperature & Humidity Setting /
How to Set Egg-Turning
DIGITAL INCUBATOR 13

This is a naturally occurring phenomenon when there is a
significant difference in temperature between inside and
outside of the incubator during incubation period. If this occurs,
water may form in inside bottom of the main body of the
incubator(bottom part).
Maintenance after Hatching
Dew Condensation
Humidity & Air Maintenance During Incubation
▶As there is some difference in chick feed for each kind of bird, so it's desirable to obtain useful information
about the chicks before hatching.
▶When hatching, humidity should be relatively high to prevent the
thin membrane from drying out or hardening before hatching.
▶When hatching, it's recommended not to open the lid often.
This is because if you open the lid often humidity will be rapidly
decreased and it will take a long time to regain the proper humidity.
▶It's very important to maintain humidity higher 1~3 days before
hatching than the early and middle incubation periods. Humidity
requirements during incubation are RH 45~55% for waterfowl,
RH 40~45% for poultry and RH 35~45% for parrot, in general.
One day before hatching, all kinds of birds need about RH 65%
humidity and sometimes need higher than that.
However, in areas of high ambient humidity, lower levels of
humidity may be needed during incubation.
4. Incubation (1) Humidity & Air Maintenance during Incubation /
Maintenance after Hatching
(2) Dew Condensation
Incubator internal temperature is 37℃(99.5℉) or more, and
hatching room temperature is below 28℃, in that case, RH70%
humidity is may not be able. The difference of ±5% humidity
value may occur from the humidity sensors difference, and there
are no problems at hatching
Be sure to use a three-wavelength 20W bulb. If you use a bulb over 20W. temperature goes up, possibly
killing the chick or causing a fire. If there is too much water and a chick would falls into water, its feathers
get wet and it can be died of loss of body heat. Here, dry feathers with a hairdryer. etc
Be sure to use a three-wavelength 20W bulb :
In case breeding room size 370(mm) x 270(mm) x 130(mm)
It's very important to keep humidity higher than RH 60%
before hatching 3days.
※Air Controlling Lever : Outer fresh air can be flowed into incubator
inside without affecting insulation. When eggs start hatching,
open air controlling lever either fully or half-open.
DIGITAL INCUBATOR
14
W
ATE
R
P
ULLOP
EN
WATER
P
U
LL
OP
EN
W
A
T
E
R
P
U
LL
OP
EN
Air Vent
OPEN
CLOSE
When the baby chickens hatch out,
please move them into a brooder.
Hatcher : The machine for egg-hatching. Operate it 1~3 days before egg-hatching. (Rcom MARU H&B)
Brooder : The machine makes baby chickens or birds warm up against cold or cool environment. You can
set up proper temperature and humidity. (Rcom MARU H&B / Rcom Brooder Series)
Please do not try to egg-hatching in the incubator. It makes your incubator broken or faulty, and we do not
give you free warranty service. (Please move all the eggs 1~3 days before hatching into Hatcher or Brooder.)
▶It is necessary to use a brooder for baby chicken or bird since they are too week against cold or cool environment.
If you try egg-hatching in your incubator, there would be lots of germs, feathers, which causes of low egg hatching
possibility for your next hatching. Also, they can make your incubator broken or faulty.
We strongly recommend you to use independent Hatcher or Brooder for egg-hatching.
If you have any faulty or broken because of not using independent Hatcher or Brooder, we do not serve you the
free warranty service. In other words, you have to pay for the service charge.
To make a simple Hatcher or Brooder, please refer to the our web-site (www.Rcom.co.kr).

W
ATE
R
P
ULL OP
EN
AUTOELEXAUTOELEX
AUTOELEXAUTOELEX
AUTOELEXAUTOELEX
AUTOELEXAUTOELEX
AUTOELEXAUTOELEX
ⓐ
AUTOELEXAUTOELEX
AUTOELEXAUTOELEX
AUTOELEXAUTOELEX
AUTOELEXAUTOELEX
AUTOELEXAUTOELEX
ⓐ
110V~120V
Unlock and remove the locking buttons for
four parts at the front and back of incubator
by pulling them forward.
How to disassemble and clean the incubator
1
2
3
▶Pull out the electric cord from the connecting jack and also
take out the plug from the outlet.
▶When using humidification function, a lot of alien matter
sticks to the humidification heating element ⓐ. This may not
cause failure, but when terminating incubation please clean
the humidifying heater lightly with a soft brush.
▶If you place the main body(upper part) on the floor,
please don't let the humidification heating part touch with the
floor.
The bottom part of incubator should be thoroughly cleaned
with water and dried. The upper part should be naturally dried
in the well-ventilated place for about one day to remove
moisture left inside of the incubator after hatching thoroughly.
back
Don't turn off the power soon after using the incubator,
as this may cause a break down due to moisture left
inside the main controller. At this time, it's better to
firstly remove the water inside of the incubator and dry
by operating it for 1hour and then turn it off or open the
view window and dry it naturally for 2~3 hours and,
then, re-operate it, which may lengthen the life time of
incubator.
(Set humidification function OFF. / Refer to the page 12.)
Don't clean the product with organic solvents such as
benzene, thinner, etc. which may cause deformation or
decoloration of the plastic parts.
If you inflict impact on the humidification heating part or
scrape it with a sharp instrument, the humidifying heater
will be damaged.
We kindly recommend you to use distilled water
In order to reduce a foreign substance on the
humidifying heater device.
5. How to Clean
(1) How to Disassemble
110V~120V
DIGITAL INCUBATOR 15

5. How to Clean
W
A
T
E
R
P
ULL
OP
EN
4
5
Start the vacuum cleaner to remove the dust as shown on the
right and thoroughly shake out the minute dust with a fine brush.
If you finish cleaning the incubator, reassemble it in the reverse
order of disassembly. Wipe out outside the main body with a
wet cloth and dry it in a cool and well-ventilated place before
storage.
In case the incubator clean status is poor which may cause
fan noisy or stopping.
If the incubator goes through incubations several times,
feather, dust, shell, etc. accumulate inside the main body,
which may cause a break down, so be sure to clean
the product before storage.
Don't clean the product with organic solvents such as
benzene, thinner, etc. which may cause deformation or
decoloration.
[Refer to How to assemble on Page 8.]
(2) How to Clean
AUTOELEXAUTOELEX
AUTOELEXAUTOELEX
AUTOELEXAUTOELEX
AUTOELEXAUTOELEX
AUTOELEXAUTOELEX
Cleaning
the fan
DIGITAL INCUBATOR
16

Frequently Asked Questions (FAQ)
(1) Servicing /
Frequently Asked Questions (FAQ)
Servicing
All our Rcom digital incubators of Autoelex Co., Ltd. are made by precision systems under strict quality
control. But occasionally some defective products are found on the way of their distribution.
If any problem occurs, then please contact Rcom service center or distributorsin your country.
We will do our best to solve the problems, if any, for you. This product is designed in modular mode, so
for its repair, if any, a qualified person can replace the part concerned with ease.
* Complaint Department : 82-55-337-2560 ＊E-mail Receipt : [email protected]
Troubles Expected Causes (Possibility) Countermeasures
In case hatching rate
is low
When a chick hatches
out earlier than expected
or a deformed chick
hatches out
When a chick hatches
out later than
expected
When hatching dates
are so different from
each egg (When all
chicks don't hatch out at
the same time but over a
long period)
When intending to
hatching various eggs
at the same time
▶Setting temperature high
▶Egg turning was not operating normally
▶Setting temperature low
▶Eggs stored for different lengths of time
▶Diffferent incubation temperatures
▶Incubation days are different,
so hatching rate falls down.
▶Eggs might be contaminated by chicks
that hatched first.
▶When the egg is an unfertilized egg.
▶Getting infected by germs
▶Wrong incubation setting
▶Health condition of mother bird
▶Improper egg turning
▶Inspect the egg to check possibility
of egg surviving.
▶Disinfect the incubator.
▶Check all settings of incubator.
Especially, check them focusing
on the temperature.
▶Review care of health of mother bird.
▶Check if egg turning is normal.
▶Minimize the time to store egg properly.
▶Check Temperature difference
in the incubator.
(sunlight, temp of incubation room, etc.)
▶Mark hatching date on eggs and
move them to other incubator
(brooder) just on the marked date.
▶In case of putting in many eggs
at the same time, it's convenient
to prepare a spare incubator available
as a brooder
▶Lower temp. setting of the
incubator about 0.5℃(1℉)
ex) 37.5℃(99.5℉) →37.0℃(98.6℉)
▶Check if egg turning function is OFF
▶Raise temp. setting of the
incubator about 0.5℃(1℉)
▶
ex) 37.0℃(98.6℉) →37.5℃(99.5℉)
DIGITAL INCUBATOR 17
6. Product Information

DIGITAL INCUBATOR
18
6. Product Information
(2 ) Troubleshooting
Troubleshooting
CIRCUMSTANCE ITEMS TO BE CONFIRMED SOLUTIONS
Alarm sounds with
HI indication
(abnormal high temp.)
Alarm sounds with
LO indication
(abnormal low temp.)
▶Connect the cord again.
▶Check the main socket with any other
electric appliances.
▶Try to insert to another outlet.
▶Check electric cord is properly connected.
▶Check if there is a power outage.
▶Check whether the plug is damaged.
Temperature will
not go high enough.
No signs of power
to the incubator.
▶Check your setting temperature.
▶Check the air circulation FAN is working.
▶Initialize the incubator.
[Refer to the page 11]
▶ Set the temperature as required.
▶ Take the power plug out of the outlet, and
disassemble the main body for cleaning
around the air circulation fan with brush.
▶Supply water.
▶Set the humidity again as required.
▶Check your setting humidity.
▶Close the view window again after checking.
▶Initialize the incubator. [Refer to the page 11]
Humidity will not
go high enough.
Egg-Turning fails
to work.
▶Check that the Egg-turning stoppage is not
activated. (Egg-turning lamp lighting)
▶Check that there are no foreign items on the
egg turning tray.
▶Check if egg turning plate is assembled correctly.
[Refer to the page 9]
▶If you need to turn the eggs, you can
manually re-start egg-turning.
▶Unplug the power supply and
disassemble the main body for cleaning
the egg turning tray and gear.
▶Assemble egg turning plate as the picture on page 9.
Dew foams in
the incubator.
▶Check the incubator is not placed
too cold circumstances.
▶When you turn OFF incubator and then
turn on.
▶ Move the incubator to where the ambient air
temperature is over
28℃(82.4℉)
▶Dew condensation is normal.
▶Dry the incubator completely under well ventilated place.
▶ Take out the plug out of the outlet and
disassemble the main body and clean
around the air circulation fan with brush.
▶Check if there is any hatching debris such as
feather or eggs-shell in the incubator FAN.
The machine makes
some noise.
- It is normal that the machine
emits some sounds because
it uses air circulation fan
for working.
▶Check that you have not overfilled the incubator.
▶Check that the incubator placed on inclined
surface.
▶Check if it is Dew condensation
Water leaks from
the machine.
▶Do not fill water over LIMIT indication.
▶Place incubator under a level surface.
▶Check if room temperature is too high
▶Check if incubator is exposed to the direct
rays of sun
▶Check if room temperature is too low
▶Check if incubator heater(temperature controlling-
system) is normally working
▶Adjust room temperature 28℃(82.4℉)
▶Install incubator without the direct rays of sun
▶Return incubator to factory setting [Refer to page 11]
▶Adjust room temperature 28℃(82.4℉)
▶Place thermometer inside of incubator and check
if setting temperature is correct
▶Return incubator to factory setting [Refer to page 11]
Be sure that the incubator works without any problem before placing eggs in the incubator.
For more detail, please check our website at
www.Rcom.co.kr diagnosis

1-1 NAME : Rcom MAX 50
1-2 MODEL NO. : MX-50
Specification
Egg-Turning Interval
Temp. limits
Working Temperature Ideal:20 ~ 25[℃] Min. 15[℃] / Max. 30[℃]
Power
Humidity Limits
Power Consumption
20.0 ~ 42.0[℃]
AC 100 ~ 120[V], 50/60[Hz]
AC 220 ~ 240[V], 50/60[Hz]
20 ~ 70[%]
( It can be changed according to the conditions )
Various according to the tray
Capacity
Net Weight
Size
6.65[kg]
Fuse Standard 250[V] 2.0[A] (Ø5×20[mm])
(W)633×(L)523×(H)171 [mm]
Average. 65[W] MAX. 120[W]
For all size egg
Small
Standard
Large
:
:
:
:
:
:
:
:
Various sized egg incubation is
available
116 [EA] ( Quail egg size )
48 [EA] ( Chick egg size )
24 [EA] ( Goose egg size )
(Included)
(option)
(option)
(option)
Universal tray
Small egg tray
Standard egg tray
Large egg tray
※Register your product Serial No. on our website for free 2 years gurantee.
※Refer to website for how to register. (Free 1 years gurantee in case not registerd.)
DIGITAL INCUBATOR 19
6. Product Information
(3) Specification
You will be asking for service charge if you are in below cases.
1. Broken or Problem caused by ‘No cleaning’ or ‘Improper handling’
2. Broken or problem caused by ‘Not using distilled water’
3. Broken or problem caused by ‘Trying Bird hatching in incubator’
(Please don’t try bird hatching in incubator. Please use Hatcher during bird hatching.)
4. Broken or problem caused by ‘Wrong controling(Using)’
5. Broken or Problem caused by using the machine out of User’s Manual.
6. Broken or problem caused by ‘Customer’s mistake or fault’
※Product Registration Procedures
If you are a new member of Rcom, you need to log in our website at www.Rcom.co.kr
1. Click “SIGN UP” on top of the right corner.
2. Fill out the information on the blanks.
If you already registered your information on the Rcom website, please log in to
www.Rcom.co.kr.
1. Click “Login” on top of the right corner.
2. Select “Customer” and click “Register Products”.
3. Fill out the information on the blanks.
You will need below information to register on our website.
1. Your name
2. Your (home/company) address & Email address, country
3. Your product(model) name & Serial number
4. Date of purchase & Name of purchased shop you bought from

Names of goods
(*.Compatible)
Image P art N o Names of goods
(*.Compatible)
Image P art N o
Rcom USB 50, PRO 50, MAX 50 PART LIST
H50-H601-10 H50 Body
H50-A601UL-10
H50-A601UH-10
H50-A601PL-10
H50-A601PH-10
H50-A601ML-10
H50-A601MH-10
H50 USB Body
110ASM/
H50 USB Body
220ASM/
H50 PRO Body
110ASM/
H50 PRO Body
220ASM/
H50 MAX Body
110ASM/
H50 MAX Body
220ASM/
H50-A602-10 H50 Bottom ASM
H50-H606-10 H50 Slider
H50-A605L-10
H50-A605H-10
H50 Heater Frame
110ASM
H50 Heater Frame
220ASM
H50-AH604-10 50Window ASM
H50-A604P-10
H50-A604U-10
H50 PRO Main
PCB ASM
H50 USB Main
PCB ASM
H50-A604M-10 H50 MAX MAIN
PCB ASM
H50-A641-10 H50 SMPS
PCB ASM
RCM-A31-10 TH V2 Sensor
ASM
H50-H618-10 H50 Main PCB
Cover
H50-H611-10 H50 Humi
Heater Cover
H50-A610-10 H50 Humidity
Unit ASM
RCM-700-10 Silicon Tube
K20- H512-10
Heat Support -A
H50-H612-10 Heat Support- B
H50-A630L-10
H50-A630H-10
H50 Silicon 110
HEATER ASM
H50 Silicon 220
HEATER ASM
H50-AH613-10 H50 Body Lock
ASM
※Partly spare parts are not on the parts list.
