RCRCM DLG Ali User manual

Instruction Manual
Unpacking
• Please unpack the plane carefully making sure that you have retrieved all
of the small parts.
• Don’t throw the box out until you are 100% sure it’s empty!
• Check that all the parts are supplied.
• If any are missing please contact your vendor immediately.

Wings
TWO WAYS TO INSTALL THE AILERON SERVOS
INTO THE FUSELAJE WITH PUSH ROD INSIDE
USING INTERNAL CONTROL WING HORNS
AILERON
SERVOS
for the aileron control horns use
iron rod like the picrture show
and bronce tube at the end.
make the pushrod using 3 mm carbon
tube and iron rod

Wings
TRADITIONAL WAY
INSTALLING THE SERVOS INSIDE THE WINGS
for the aileron control horns use iron rod like the picrture show
make the pushrod using 2 mm carbon tube and iron rod

Tail
ELEVATOR AND RUDDER
CUT THE ELEVATOR AND RUDDER FLAPS AS SHOWN
ON THE PHOTOS USING ONE SIDE LIKE HINGE
CUT AND GLUE THE RUDDER SUPPORT AS SHOWN
IN THE PHOTOS AND AFTER THAT, JOIN IT THE RUDDER AL FUSELAGE
Using the 0.4mm push rod wire
up 2 staple-shaped torsion springs

Aileron
Elevator
Rudder
Soar
Launch setting
Rudder
Launch
Elevator
Launch
Reflex
Break
Setting
Specifications:
Wing span: 1492mm
Length: 1130mm
Wing aerofoil: RC series
Wing area: 22,9 dm2
Control surface: ailerons,
elevator, rudder
Fly weight: 290-330g
CG 60-70 mm
