RCRCM TANGO F3B User manual

TANGO F3B/F3F - Instruction Manual
Unpacking
• Please unpack the plane carefully making sure that you have retrieved all
of the small parts.
• Don’t throw the box out until you are 100% sure it’s empty!
• Check that all the parts are supplied.
• If any are missing please contact your vendor immediately.

Wings
• Make up control rods and clevises using the parts supplied.
Control horns for ailerons and flaps
• Zero the servos by using your R/C unit.
• Remember! Aileron servo arms can be set to 90 degrees, but the flaps
need to have about a 10 degree offset towards the leading edge

• When the wiring harness is positioned inside the wing and accessible,
servos can be installed.
• First, check the position of the servos to make sure they are all
symmetrical (In the same place) in each wing.
• Install the control rods on to the servos and check that they do not bind,
are snug but not too loose or to tight.
• Tape the control surfaces flat with masking tape.
• Assemble the completed set of servos, and control rods.
• When you are satisfied that you have the correct position for the servo –
glue them in using a slow set epoxy,
• When cured and secure, connect the servos to the wring harness and
check for zeros, then for free and adequate movement. Adjust using the
clevises if needed. (See the control settings section a the back of this
manual for control movements)
• Finally, check the fit of the servo hatch covers and sand if not snug.
• Then put some double sided tape on the underside and install all on to
the servos hatches.

Fuselaje

Specifications:
Wing span: 2.90 m
Length: 1.44 m
Wing aerofoil: RC series
Wing area: 54.1 dm2
Control surface: ailerons, flaps,
elevator, rudder
Fly weight: 2100g
Ailerons :
Up 10 mm
Down 5mm
Elevator:
Up 4mm
Down 3mm
V tail /Rudder:
6 mm left/right
Center of Gravity (CG):
92-97 mm from leading edge
F3B/F3F
designed by carlos pisarello
