RCS RCS-433T User manual

RCS - 433T
1A - General information
The radiocontrol RCS-433T has been designed for the
programmable telephone entry systems, anti-burglar systems
and access control systems.
It has a very high security coding system. (KeeLoq ® Hopping
code).
The code sent by the transmitter changes at each activation,
avoiding any scanning and copying risk. A special algorithm
CONTENTS
1A - General information
1B - Technical specifications
1C - Main features
1 - TRANSMITTER INTRODUCTION
2 - CODING
3 - MEMORIZATION
4 - BATTERY ACCESS
5 - TROUBLESHOOTING
GETTING
STARTED
1B - Technical specifications
Number of keys: 2
Supply : 2 lithium batteries CR 2016
Battery life: 18 - 24 months
Current consumption : 13 mA
Operating frequency : 433.92 MHz
64
Code combinations : 2
Modulation : AM / ASK
Rated e.r.p. : 50 - 100 mW
Range in free space: 100 - 200 m
Operating temperature: -20 ¸+55 °C
Overall dimensions: 61 x 36 x 16 mm
Weight: 20 gr.
allows to keep synchronyzed transmitter and receiver.
The operating frequency is 433,92 MHz.
The receiver RCS-433R type SELWR433, which operates with this
transmitter, has a Wiegand 26 bit format output, suitable with
any type of access control system, equipped with this type of
protocol.
The CR 2016 lithium batteries have a life of about 18 months.
The product fully complies with the European Directives
99/5/CE, 89/336/CEE, 73/23/CEE and with the Part 15 of FCC
Regulations.
1C - Main features
Push-button B
Red
LED
Key holder
ring
Battery
door
Push-button A
RCS
Thank you for choosing a RCS product. You are recommended to
read this manual carefully before installing the product.

3 - MEMORIZATION
2 - CODING
4 - BATTERY ACCESS
5 - TROUBLESHOOTING
FAULT SOLUTION
The transmitter led
blinks
Check the receiver supply.
Replace the transmitter
batteries
IS-TMWGXUK2 Rev. 1 del 12.12.2001
To access the battery turn clockwise the battery
door.
Place the 2 lithium CR2016 batteries inserting
a part of them under the door and taking care
to push them just on the internal ring plane.
NOTE:Please dispose of the batteries correctly,
they are hazardous waste.
Each transmitter is manufactured and sold with a different univocal serial
number set-in-factory. The real transmitted code is the result of a special
algorithm which combines a serial number, a manufacturer key and a
synchronization number.
The transmitter security code has to be stored onto the receiver or the
receivers memory available. Your own installer or reseller will perform this
operation during the installation or will give you the necessaries instructions
during the selling.
The radio emission isn’t verifiable
The transmitter led is OFF.
The radio emission isn’t verifiable
The transmitter led is ON.
Replace the transmitter
batteries
GUARANTEE
RCS-433T - Type : SETR2641AM2
FCC ID : PWJ T433
This device complies with FCC Rules
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept interference received, including
interference that may cause undesired operation.
Part. 15 of the
Notice
Any changes or modification to RCS equipment not expressly approved
by RCS could void the user's authority to operate the equipment.
REMOTE CONTROL SOLUTIONS
College Park Commerce Center
2042 N. Rio Grande Ave. Suite A
Orlando - FL 32804
U.S.A.
Office: (407)-426-8687
Fax: [phone]
e-mail: [email protected]
The guarantee period of all RCS transmitter batteries is 6 months,
beginning from the manufacturer date. During this period, if the product
does not work correctly, due to a defective component, the product will be
repaired or substituted at the discretion of the producer.
The guarantee does not cover the plastic container integrity.
