RDA FireSafe User manual

MANUAL
FireSafe control unit
Door control for:
Industrial doors with fire alarm contact
HW V 1.1
SW V 1.5
EN.

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 1
Contents
1 Description of control unit..............................................................................................2
2 Safety guidelines............................................................................................................4
3 Installation.....................................................................................................................5
4 Connections ...................................................................................................................6
5 Commissioning............................................................................................................14
6 Menu............................................................................................................................18
7 Messages......................................................................................................................25
8 Overview of control PC board......................................................................................28
Read this manual carefully and keep the manual together with the
appendices in a safe place!

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 2
1 Description of control unit
The FireSafe is a control unit intended for use (in combination with a GfA or Kostal electrical drive
that has a digital limit switch) on industrial doors that need to close in the event of an
emergency. When used in combination with an emergency power supply, the door will close
even if there is a power failure. The opening and closing movements in normal mode can be set
to deadman or automatic operation (impulse) via a menu. The buttons on the unit and the
external up-stop-down controls are used for operation. Operation is also possible using impulse
control. There is an input to turn the controls on or off.
The cover has an LED that lights up green in normal mode and red in the event of a fault, fire or
power failure. The cause of the red LED is then shown on the control PC board display.
The control unit can be fitted with an emergency power supply so that the door can still close
even if there is a power failure. The door will close if there is a fire or if the batteries of the
emergency power supply are nearly flat. A test function allows you to close the door using the
emergency power supply to check that it is working properly. An escape pushbutton can be used
to open the door in an emergency if there is still mains power and the emergency power supply
batteries have sufficient capacity. You can also specify that the door can still be opened with the
open button, and that when it is released the door immediately closes again. Here too, this is
only possible if there is still a mains power supply and the batteries have sufficient capacity.
In normal mode, the door will descend until the "closed" limit switch has been reached. You can
specify, for the event of a fire or when the battery voltage is low, whether the door should stop
when the normal "closed" limit switch is reached or when the "overclose" limit switch is reached.
The "overclose" limit switch position is set via the menu. It should be set further on than the
"closed" limit switch so that the door closes further than in normal mode.
If the door is moving, a potential-free make-and-break contact to which a siren or other alarm
signal can be connected, is switched. The contact will also be switched if you specify in the menu
settings that a pre-warning should be issued before the door closes. This stops when the door
stops moving.
A potential-free make-and-break contact, to which a siren or other alarm signal can also be
connected, will also switch in the event of a fire or if the battery for the emergency power supply
is nearly flat.
There are also a number of outputs with the same common that can be used to send various
messages.
There is the option to connect a detection device to detect persons/objects under the door. This
could be a detection device operated by air pressure contact (in combination with 1.2KΩ), an
8.2KΩsafety edge or opto sensors. If you choose automatic closing in normal mode, the door will
stop and open fully or simply stop if the detection device is triggered.
The detection device can remain enabled or be turned off in the event of a fire. The delay time
until the door continues descending after the detection device is triggered can be specified in the
menu. For the event that there is still a power supply, you can also specify that the door should
open fully and then close again when the detection device is triggered in a fire or when the
battery capacity is low.

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 3
For the event that the safety mechanism is triggered when the closed pre-limit switch is reached,
you can choose in the menu whether it should then simply stop there, or the detection device
should be turned off and the movement continued until the "closed" limit switch is reached.
Photocell safety devices only work in normal mode and will cause the door to stop if the beam is
broken. If you release the "close" button and then press it again, the door will continue closing.
The photocell will be turned off in the event of a fire.
The service cycle counter can be enabled in the menu. When it is enabled and the set number of
cycles is reached, the LED will light up red and green alternately. A message will appear on the
display.
If the emergency/fire alarm contact is interrupted or if the batteries are nearly flat (and
the close option has been selected for this event), the door will close automatically and
the safety device may not be enabled!
The required mains supply is: 1N~230V AC +/- 10% (phase + neutral + earth)

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 4
2 Safety guidelines
Read this manual carefully before starting any work on the control unit. Check the
screw connections before switching the control unit on for the first time.
NOTE: Before starting work on the control unit, disconnect the
mains power supply and disconnect the battery terminals.
Working on this control unit when it is live poses a risk to life and could result in serious
injury!
Only qualified personnel with the right skills and expertise are permitted to work on
the control unit. Qualified personnel means: persons who are familiar with the
installation, configuration, commissioning & operation of electrically driven door and
gate systems. They must be able to evaluate the system as a whole, to identify
potential hazards and to install the required safety devices.
Safety-related guidelines
Safe use of this control unit can only be assured if it is used for its intended purpose. The
manufacturer shall not be held liable for any damage or losses caused by external components
or not following these instructions.
Modifications are only permitted by agreement with the manufacturer. If modifications are
applied without the manufacturer's consent, the manufacturer's declaration shall be invalid.
When installing, commissioning, maintaining and inspecting the control unit, the
safety and accident prevention guidelines for the specific application must be taken
into account.
Only use safety products (such as detection devices and photocells) that fulfil the applicable
standards.

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 5
3 Installation
For reliable, professional installation of this control unit, check and implement the points below:
üThe control unit must be installed in a robust housing that fulfils the requirements with
respect to the location in which it will be sited.
üThe cable grommets may need to be replaced to meet the required IP value. Additional
seals may be required.
üPVC insulated cabling may only be used in indoor spaces.
üThe power supply phase (1N~230V AC-50Hz, +/-10%) must have a fuse to prevent short
circuiting and overload.
üIf using a power supply cable with a 3-pin 16A CEE plug (phase, neutral & earth), a 16A
wall socket should be installed in the immediate vicinity of the control unit with a fuse
that meets the applicable standards/guidelines. After installing the control unit and
supply cable plus the wall socket, check that the screw connections have been properly
tightened and that everything has been correctly connected.
üIf a supply cable is connected to the system, the following applies: Connect up the control
unit using a fixed supply cable and fit a fuse as indicated earlier. A multi-pin switch must
be fitted in the immediate vicinity of the control unit to interrupt the power supply, all
pins of which should be interrupted when it is switched off. Note: the switch used should
have a contact opening that meets overvoltage category III for total isolation.
üAn on-site risk assessment must be carried out on the entire system by the installer.
Check as part of this process that the door or gate is properly secured and does not pose
an entrapment risk for persons or objects.
üThe system must, as a minimum, fulfil the requirements of European and locally
applicable legislation and standards. Under European legislation, automatic doors or
gates must satisfy the requirements of the Machinery Directive 2006/42/EC and in
particular the following standards: EN 12445; EN 12453; EN 12635 and EN 13241-1, that
permit a declaration of conformity.
üMeasures must be put in place to prevent the door or gate limit switch being passed, e.g.
safety limit switches, mechanical stops or other safety systems.
üCheck the technical specifications of any external components used, such as: photocells,
traffic lights or induction loop detectors. These may not exceed the max. permissible load
on the control unit.

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 6
4 Connections
Connect the mains supply (1N~230V AC) to terminal strip X1 (see Figure 1). The incoming supply
for emergency power is also connected to X1. Connect the outgoing supply for emergency power
to terminal strip X2 (see Figure 2). If an emergency power supply is not being used, connect the
mains power supply to X2 (L and N) as well.
Connect the earth to X16!
Figure 1 Connecting the mains supply
Figure 2 Connecting an emergency power supply (left), without an emergency power supply (right)
Mainssupply
230VAC
OUT

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 7
Connect the power supply for the frequency control (1N~230V AC) to X15 (see Figure 3).
Connect the earth to X16!
Figure 3 Connecting the power supply for the frequency control
Connect the 3 phases (3~230V AC) of the motor directly to the frequency control (U-V-W), and
connect the motor electric brake to terminal strip X14 using a rectifier (see Figure 4).
Connect the earth to X16!
Note! Make sure the motor is in a delta configuration. The output of the frequency
control is 3~230V AC.
Figure 4 Connecting the motor
Frequency
control
Brake
GooDrive10frequency
controller

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 8
Connect the frequency control actuator to terminal strip X13 (see Figure 5).
Figure 5 Connecting the frequency control actuator
Connect the digital limit switch (DES) to terminal strip X5 (see Figure 6).
Note! Two types of encoders may be connected: Kostal or GFA. Before replacing these,
the control unit must first be reset to the factory settings using parameter 9.5 setting 1!
Isolate the system and only replace the encoder with an encoder of a different type!
Figure 6 Connecting the digital limit switch
GooDrive10frequency
controller
Brake actuator
Direction of rotation "opening"
Speed selection "opening"
Speed selection "opening"
Direction of rotation "closing"
+24Vsafetychain
Safetychain

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 9
An external up-stop-down control can be connected to terminal strip X7 (see Figure 7). The cover
control including control LED can be inserted in X8.
If X7 is not being used, connections 1 and 2 for the stop function must be connected
together by a bridging wire.
Figure 7 Connecting the up-stop-down control
A photocell can be connected to terminal strip X3 (see Figure 8). Terminal strip X3 also has a
connection for a 24V DC power supply for a photocell or any other accessories, such as a
receiver.
This can take a load of up to 500mA. If a photocell is not connected, the terminals must
be connected together by a bridging wire.
Figure 8 Connecting a photocell
Photocell
Externalcontrol Covercontrol
Closed
Closed

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 10
A key switch can be connected to terminals 7 and 8 on terminal strip X9 (see Figure 9). This is
installed in the cover and is used to switch the control unit on and off.
If a key switch is not being used, the terminals for this input must be connected
together by a bridging wire for the control unit to work.
A potential-free N.C./breaker contact for the fire alarm or smoke alarm control centre, which is
interrupted in the event of a fire/emergency, can be connected to terminals 5 and 6.
If this input is not being used, the terminals must be connected together by a bridging
wire.
An escape pushbutton can be connected to terminals 3 and 4 that can be used to open the door
in the event of a fire/emergency.
An impulse sender can be connected to terminals 1 and 2, e.g.: a pull switch can be connected
that can be used to open or close the door.
Figure 9 Connecting terminal X9
Figure 9.2 Connecting terminal X9 for smoke/fire alarms (power supply: X3)
Impulse input
Escape pushbutton
Fire alarm contact
Control uniton/off

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 11
A detection device can be connected to terminal strip X4 (see Figure 10). This could be a
detection device triggered by air pressure (pressure wave contact) in combination with a 1.2KΩ
resistor, or an electrical safety edge with an 8.2KΩresistor (electrical anti-entrapment bar).
Optical sensors may also be connected as a safety device.
Figure 10 Connecting a detection device
Electricalsafety
edge
Pressurewave
contact
Brown
Green
White

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 12
There are two outputs designed as potential-free make-and-break contacts on terminal strip X11
(see Figure 11). One of these is the siren that is switched when the door is moving. The other is
the alarm that switches if the fire alarm contact input is active or if the battery for the emergency
power supply is nearly flat.
Figure 11 Alarm and siren outputs
On terminal strip X10, there are 8 outputs designed as a potential-free N.O./make-contact with
the same common/joint connection (see Figure 12). These outputs transmit 8 messages, i.e.:
2. "Open" limit switch reached (door/shutter open)
3. "Closed" limit switch reached (door/shutter closed)
4. "Overclose" limit switch reached
5. Motor safety chain broken (thermo contact interrupted or emergency control active)
6. Test function active
7. Detection device activated fault (can be changed to photocell or both in the menu)
8. Battery for emergency power supply low
9. No mains power supply, emergency power supply activated (only switches if an emergency
power supply is available and is active)
Figure 12 Message on terminal X10
"Open" li
mit switch
"Closed" limit switch
Overclose
Safety chain
Test function
Detection device
Detection device
No mains power

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 13
The emergency power supply RS232 connection (if present) is connected to terminal X12 (see
Figure 13). Connection 5 is the common/-. Connection 8 is low battery voltage and connection
9 is power failure/no mains power supply.
Figure 13 UPS RS232 connection

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 14
5 Commissioning
After switching on the mains power supply, the door can be operated in deadman mode* using
the pushbutton on the PC board. The direction of rotation should coincide with the buttons. If
this is not the case, disconnect the mains power supply and swap the two phases (U and V) on
the frequency control output. After you have checked the direction of rotation, the end positions
can be set. To do so, the control first needs to set its direction. For this purpose, run the control
in any direction for around 4 seconds.
After setting the end positions, the control can be configured as required in the menu. The door
mode (0.1) is an important parameter for configuration. Set the parameter to 1 for deadman
operation in both directions or set it to 2 for impulse-controlled opening and deadman closing or
to 3 for impulse-controlled opening and closing.
DISPLAY:
Movement
"open"
End position
"open"
Movement
"closed"
End position
"closed"
No end positions Pre-limit switch
Setting the open and closed end positions
1. Send the door or gate to the required "open" position using the arrow keys "˄" and "˅" on
the control PC board. The top vertical segments will then flash (Fig. 1).
2. Press and hold the STOP/OK key on the control PC board for around 3 seconds until the top
vertical segments go out and the bottom vertical segments light up (Fig. 2).
3. Send the door or gate to the required "closed" position using the arrow keys "˄" and "˅" on
the control PC board. The bottom vertical segments will start flashing (Fig. 3).
4. Press and hold the STOP/OK key on the control PC board for around 3 seconds until the
display changes as shown above (Fig. 4).
Display
flashes
Display Display
flashes
Display

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 15
The door or gate can now be operated in deadman mode*. You can make fine adjustments and it
is easy to change the end position settings later using the menu (1.1 to 1.9).
* Deadman operation: The door or gate will move for as long as the arrow button is held down
Automatic or deadman mode
When the control unit is set to the factory settings, the door will open and close in deadman
mode.
If required, you can set the door to open automatically by setting parameter 0.1 to 2 in the
menu. To specify automatic opening and closing, set parameter 0.1 to 3.
Safety devices
There is the option to connect a detection device to the control unit. This could take the form of
opto sensors, an air pressure contact (in combination with 1.2KΩ) or an 8.2KΩelectrical safety
edge. The detection device is connected to X4. Use parameter 0.2 to choose whether it should be
detected automatically or whether to set up the connected safety device permanently. If you
choose "automatic detection", the safety device must be present when the control unit is started
up, and must not be interrupted or activated. The safety device will then only be detected on
starting up.
If no safety device is detected when starting up, fault message 2.0 will appear on the
display. If deadman closing has been chosen in normal mode, fault message 2.0 will
appear once. If automatic closing has been chosen, it will be shown repeatedly.
Parameter 0.3 is used to specify the function of the detection device in normal mode. In the case
of the factory settings, the door will stop and then open fully. Option 2 allows you to choose just
to stop the door if the detection device is triggered. A new command then has to be given for the
door to continue moving.
Parameter 0.4 allows you to specify the function of the detection device when closing in a fire, if
you have chosen to close when the emergency power supply battery voltage is low (parameter
3.7 set to 2). In the factory setting, the detection device is disabled. With option 2, the door stops
lowering and waits for the time set in parameter 0.5 and then continues closing. With option 3,
the door will open fully, if there is still mains power, wait for the time set in parameter 0.5 and
then close again. If there is no mains power supply, the door will just stop and continue closing
after the time set in parameter 0.5.
Parameter 3.6 allows you to choose to disable the detection device in the event of a fire if it is
not present or is interrupted when the fire alarm contact input becomes active.
Parameter 3.5 allows you to choose to restrict the number of times the detection device stops
the door. If you opt for this, you can choose using parameter 1.9 whether the detection device is
to be ignored if the maximum number of attempts has been reached (i.e. continue closing
without the detection device), or that the door should re-open after two seconds and then stop.
As well as the detection device, there is also the option to connect a photocell. This only works in
normal mode if you have chosen automatic closing. In this case, the door will stop if the
detection device is activated and then open fully.
The photocell is turned off in the event of a fire.

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 16
Impulse function
The control unit has an impulse input. If one direction is deadman, the impulse should be
retained in that direction. If it is released the drive will stop. If it is then pressed again, the other
direction will become active.
If automatic opening has been chosen, the door will continue to run according to the factory
settings until it reaches the open limit switch and can only then be lowered back down by the
impulse input. By changing parameter 2.2 to setting 2, the door can also be stopped during
opening by activating the impulse input once again. And, if the impulse input is activated again,
the door will descend in deadman mode for as long as the impulse input remains active.
Fire alarm function
If the fire alarm contact is activated, the door will close. In the standard factory setting, the door
lowers until it reaches the closed limit switch. If the door needs to descend further than the
closed limit switch, the optional "overclose" limit switch can be used. For this purpose, parameter
3.1 should be set to 2.
The normal open button can be turned on or off using parameter 3.3 if the fire alarm function is
enabled. If it is active, the door will open when the deadman is pressed and immediately close
again when it is released.
The fire alarm function can be extended after the fire alarm contact input has closed again. This
can be set from 0 to 240 seconds using parameter 3.4.
An input is also available to connect an escape pushbutton. When this button is pressed, the door
will open. Once the delay time –which can be set from 1 to 240 seconds using parameter 3.2 –
has expired, it will then close again. The button can be pressed again during the delay time to
close the door immediately.
NOTE: The door cannot be opened if there is no mains power!
You can choose, for the event of opening the door using the escape pushbutton or normal open
button in a fire, whether it should open fully or to a set mid-position. This position can be set in
parameter 1.7 and activated using parameter 1.6. It can only be activated if a position has been
set for parameter 1.7.
Test function and power failure
If the test function is active, a message will appear on the display and the red LED will light up. In
the event of a power failure, the red LED will also light up if there is an emergency power supply.
The power supply will switch over to emergency power and it will only be possible to close and
not open the door.
The test function is intended to check whether the door still closes on the emergency power
supply.
Battery for emergency power supply low
If the battery for the emergency power supply is too low, this will be communicated to the
control unit by the UPS RS232 connection. A message will then appear on the display and the red
LED on the control unit will light up. In the case of the standard factory settings, the door will
then close. If this is not desirable, it can be disabled using parameter 3.7.

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 17
Messages
There is a potential-free make-and-break contact on the control unit to which a siren or warning
light can be connected. This contact will switch when the door is moving.
There is another potential-free make-and-break contact, alarm, that switches when the fire alarm
input is active or if you have set the door to close when the emergency power supply battery
voltage is low.
There are 8 messages that have the same common, all designed as potential-free N.O./make
contacts. The messages are as follows:
-"Open" limit switch reached
-"Closed" limit switch reached
-"Overclose" limit switch reached
-Motor safety chain interrupted
-Test function active
-Detection device activated/faulty, can be set using parameter 2.3 or message output only
from the detection device or only from the photocell or both.
-Emergency power supply battery low
-No mains power (only works if there is an emergency power supply)
Service cycle counter
The service cycle counter can be activated in the menu using parameter 8.7. Parameter 8.5
allows you to set the number of door openings (per 1,000) before a service alert is output. When
the counter reaches zero, the LED on the cover flashes red and green alternately (if no fault
message is active) and the message C.S. will appear on the display.

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 18
6 Menu
Settings can be entered in the menu. There are three pushbuttons on the PC board to the right of
the display: ˅, ˄and stop/ok (see figure). In normal mode, these work as an up-stop-down
control.
To open the menu, hold the "stop/ok" button down for around 3 seconds. You can cycle through
the parameters using the "˅" and "˄" buttons. Once you have got to the right parameter, you can
open it by pressing "stop/ok". You can then make changes to the parameter using "˅" and "˄".
To return to the menu and confirm the change, press "stop/ok" briefly. To exit the menu, go to
parameter 0.0 and press "stop/ok" briefly.
Parameter
Description
Settings
0.0
Exit menu
Exit the menu by pressing
"stop/ok"
0.1
Select deadman or automatic
movement (default setting: .1)
.1 Deadman opening, deadman
closing
.2 Automatic opening,
deadman closing
.3 Automatic opening,
automatic closing
0.2
Select type of detection
(default setting: .1)
.1 Automatic detection
.2 Select opto sensors
.3 Select 1K2 pressure
wave/air pressure contact
.4 Select 8K2 electrical safety
edge
.5 No detection
0.3
Select function of anti
-
entrapment device in normal
mode (default setting: .1)
.1 Stop and return the
door/shutter to the fully open
position
.2 Stop if the anti-entrapment
device is activated and only
continue if the close button is
pressed again
0.4
Select function of anti
-
entrapment device in a fire
(default setting: .1)
.1 Disable anti
-
entrapment
device
.2 Stop if anti-entrapment
device is activated and
continue closing after a set

DOOR CONTROL
FireSafe
Manual
Keep this manual together with the appendices in a safe place! 19
time (parameter 0.5).
.3 If there is still power, open
fully, and if there is no power,
stop and close again after a set
time (parameter 0.5)
0.5
Time to close again after
activating the detection device
in a fire (default setting: 3 s.)
2 to 60 seconds
0.6
Select function of "closed" pre
-
limit switch (default setting: .1)
.1 Stop when detection device
is triggered
.2 Disable/ignore detection
device
0.7
Return time for anti
-
entrapment device closing
direction (default setting: .0)
.0 Faster
.1
.2
.3 Slower
