ReadyNet WRT300N-DD User manual

WRT300N-DD
User Manual

Contents
Features.............................................................................................................................................3
Configuring the Router.....................................................................................................................3
1 Operation Mode .............................................................................................................................8
2 Internet Settings.............................................................................................................................8
2.1 WAN....................................................................................................................................9
2.2 LAN ..................................................................................................................................13
2.3 DHCP clients.....................................................................................................................15
2.4 Advanced Routing.............................................................................................................15
2.5 QoS ...................................................................................................................................16
3 Wireless Settings..........................................................................................................................17
3.1 Wireless Network..............................................................................................................17
3.2 Advanced...........................................................................................................................19
3.3 Security .............................................................................................................................19
3.4 WPS ..................................................................................................................................20
3.5 Station List........................................................................................................................21
4 Firewall........................................................................................................................................22
4.1 MAC/IP/Port Filtering ......................................................................................................22
4.2 Port Forwarding ................................................................................................................23
4.3 DMZ..................................................................................................................................23
4.4 System Security.................................................................................................................24
4.5 Content Filtering ...............................................................................................................24
5 Administration..............................................................................................................................25
5.1 Management......................................................................................................................26
5.2 Upload Firmware ..............................................................................................................27
5.3 Setting Management .........................................................................................................27
5.4 Status.................................................................................................................................28
5.5 Statistics............................................................................................................................29
5.6 System Command .............................................................................................................29
5.7 System Log .......................................................................................................................30
5.8 SDK History......................................................................................................................31
Appendix: Glossary.....................................................................................................................32

Features
► Complies with IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u standards.
► 1 10/100M Auto-Negotiation RJ45 WAN port, 4 10/100M Auto-Negotiation RJ45
LAN ports, supporting Auto MDI/MDIX.
► Adopts 2x to 3x eXtended Range wireless LAN transmission technology.
► Supports 54/48/36/24/18/12/9/6Mbps or 11/5.5/3/2/1Mbps data transfer rates.
Up to 300Mbps
► Provides WEP,WPA,WPA2,WPA2 Mixed authentication, TKIP/AES encryption
security.
► Shares data and Internet access for users, supporting PPPoE, Dynamic IP, Static IP,
PPTP Internet access.
► Supports Virtual Server, Special Application and DMZ host.
► Supports UPnP, Dynamic DNS, Static Routing.
► Connecting Internet on demand and disconnecting from the Internet when idle for
PPPoE.
► Built-in NAT and DHCP server supporting static IP address distributing.
► Built-in firewall supporting IP address filtering, Port filtering, and MAC address
filtering.
► Provides 64/128/152-bit WEP encryption security and wireless LAN ACL (Access
Control List).
► Supports Flow Statistics.
► Supports ICMP-FLOOD, UDP-FLOOD, and TCP-SYN-FLOOD filter
► Ignores Ping packets from WAN or LAN ports.
► Supports firmware upgrade.
► Supports Web management.
Configuring the Router
In the IE browser, type "10.10.10.254" into the login screen.
Enter you username and password, the default username is "admin", and the default
password is "admin".
After your successful login, you can see the interface as follows:

You can configure and manage the router. There are six main menus on the left of the
web pages. Submenus will be available after you click one of the main menus. The six
main menus are: Operation Mode, Internet Settings, Wireless Settings, Firewall,
Storage, Administration. To apply any settings you have altered on the page, please
click the Apply button.
There are three buttons at the top of the menus, "open all" ,"close all" and "Ralink".
Open all: open all the sub-menu.
Close all: close all the sub-menu.
Ralink: return to the login page.
On the right of the web page, you can see four setting button: Select Language, Status,
Statistic, Management
Select Language
You can choose three languages: English, Traditional Chinese and Simple Chinese.
Status
Click the "Status" button, the page will displays the status of Ralink SoC Platform,
including System Info, Internet Configurations and Local Network. As follows:

Statistic:
Click the "Statistic" button, the page will display the Ralink SoC statistics. You can see
the information of send and receive packets in all ports.

System Management:
Click the "Management" button, enter into the system management setting page.
You can set the account to access the web server of Access Point, NTP settings and
DDNS settings here.
Click the "Apply" button to enable configuration to take effect.
Click the "Cancel" button to cancel the setting.

DDNS:
The router offers a Dynamic Domain Name System (DDNS) feature. DDNS lets you
assign a fixed host and domain name to a dynamic Internet IP Address. It is useful
when you are hosting your own website, FTP server, or other server behind the router.
Before using this feature, you need to sign up for DDNS service providers such as
www.zoneedit.com or www.no-ip.com. The Dynamic DNS client service provider will
give you a password or key.
To set up for DDNS, follow these instructions:
1. Type the domain names your dynamic DNS service provider gave.
2. Type the Account for your DDNS account.
3. Type the Password for your DDNS account.

4. Click the Apply button to apply to the DDNS service.
1 Operation Mode
You can setup different modes to LAN and WLAN interface for NAT and bridging
function.
Click "Apply" button to enable configuration to take effect.
Click "Cancel" button to cancel the settings.
2 Internet Settings
There are five submenus under the Internet Settings menus: WAN, LAN, DHCP clients,
Advanced Routing, QoS.

2.1 WAN
You can configure the parameters for Internet network which connects to the WAN port
of your Access Point. Here you may change the access method to static IP, DHCP,
PPPoE , L2TP, PPTP or 3G by click the item value of WAN Connection type.
a. If you choose Static IP, you should have fixed IP Parameters specified by your ISP.

You should type the following parameters into the spaces provided:
IP Address - Enter the IP address in dotted-decimal notation provided by your
ISP.
Subnet Mask - Enter the subnet Mask in dotted-decimal notation provided by your
ISP, usually is 255.255.255.0.
Default Gateway - (Optional) Enter the gateway IP address in dotted-decimal
notation provided by your ISP.
Primary DNS Server - (Optional) Enter the DNS address in dotted-decimal
notation provided by your ISP.
Secondary DNS Server - (Optional) Type another DNS address in dotted-decimal
notation provided by your ISP if provided.
Click the "Apply" button to enable configuration to take effect.
Click the "Cancel" button to cancel the setting.
b. The router is set up by default as a DHCP (Dynamic Host Configuration Protocol)
server, which provides the TCP/IP configuration for all the PC(s) that are connected to
the router on the LAN.
c. If you choose PPPoE, you should enter the following parameters.
