ReadyRefresh Allure Series User manual

Rev. A - 060220
Allure Sparkling Water Dispenser
User Manual
Warnings:
1. Misuse of the water dispenser or failure to follow directions may result in serious
personal injury.
2. DO NOT use the water dispenser if it is not in its upright position.
3. DO NOT use the water dispenser for anything other than carbonating water. Use of the
water dispenser for any unintended purposes may result in serious personal injury.
4. Use the water dispenser on a flat, stable surface away from heat sources and do not
leave in direct sunlight.
5. DO NOT place the water dispenser on a hot surface (e.g. kitchen oven/stove/ hob) and
never use it close to a flame.
6. DO NOT move the water dispenser during the carbonation process.
7. To reduce the risk of personal injury or property damage, any servicing or repair
should be performed by a ReadyRefresh authorized service representative.
8. ONLY dispense sparkling water into vessels approved for carbonated beverages.
Sealed containers may burst if not rated for pressurized use.
9. Close adult supervision is necessary when the water dispenser is used by children and
it is not recommended for use by children under 5 years of age.
I. Operating Conditions:
1. Working Voltage: AC115V±10%, 60Hz;
2. PCB Storage Temperature: -10℃～55℃; Operating Temperature: 0℃～35℃.
II. Display and Buttons:

Rev. A - 060220
III. Buttons and Indicators Function:
1. Sparkling Water Dispense/Reset Button: After selecting the desired sparkling level on
the display, press and hold the large green button to dispense sparkling water. If the
green light is flashing, a reset is required. Follow the instructions in the
Troubleshooting section.
2. Sparkling Level Decrease Button: Press the button once and the sparkling level will
decrease one level as represented by the bars on the display
3. Sparkling Level Increase Button: Press the button once and the sparkling level will
increase one level as represented by the bars on the display
4. Cooling Status Indicator: When the dispenser is in the process of cooling water, the
indicator will flash repeatedly. When it has finished cooling, the image will remain
steady, indicating that the water is at its coldest temperature
5. Replace CO2: When the pressure inside CO2 cylinder drops due to low gas, an orange
light will flash, indicating that it is time to replace the cylinder
6. Time to Clean: When the dispenser is due to be cleaned, the button will illuminate.
After cleaning, press and hold the button to reset the cleaning schedule. The light
will turn off until the dispenser is due again for cleaning.
7. Child Safety and Hot Water Dispense Button: To dispense hot water, press and hold
the child safety button and hot water button at the same time. To stop dispensing,
release the buttons.
8. Cold Water Dispense Button: To dispense cold water, press and hold the cold water
button. To stop dispensing, release the button.
IV.. Setup Procedure:
1. DO NOT PLUG THE DISPENSER IN. Invert a 3 or 5 gallon bottle water onto the
no-spill adapter. Bubbles will form in the bottle indicating that water is flowing into the
reservoirs.
2. Verify that the red HOT SWITCH on the back of the dispenser is in the off position.
Once the formation of bubbles stops, plug the power cord into an electrical outlet to
supply power.
3. Place a large cup under the spigot. Press and hold the SPARKLING WATER button until
water flows out. This indicates that the sparkling reservoir is filled. (NOTE: This
water will not be carbonated)
4. Press and hold both the CHILD SAFETY and HOT WATER buttons at the same time until
water flows out. This indicates that the hot reservoir is filled.
5. You may now turn on the red HOT SWITCH on the back of the dispenser to begin heating
the water.
6. Install a CO2 cylinder:
a) Remove the drip tray. Then lift and pull out the lower panel.
b) Turn the funnel upward for easier access. Insert the cylinder into the funnel, and
rotate clockwise to install. An audible beep will be heard, indicating that gas is
entering the dispenser. Continue to turn the cylinder firmly until fully tight.
c) Turn the funnel downward until the cylinder rests against the back wall
d) Replace the lower panel and drip tray
7. Press and hold the sparkling water button until sparkling water continuously dispenses.

Rev. A - 060220
This will be known by an increase in dispense pressure.
8. While the cooling status indicator flashes, the dispenser is chilling the still and
sparkling water. When the cooling status indicator stops flashing and remains steady,
the cold water has reached its ideal temperature setting. (Note: This may take 1-2 hours
depending on ambient conditions)
9. The dispenser is ready to dispense hot, cold, and cold sparkling water.
V.CO2 Cylinder Change
NOTE: the CO2 cylinder can be removed and installed at any time due to the self-sealing
needle valve. The cylinder does not need to be fully depleted before removing.
1. When the REPLACE CO2 indicator light is illuminated on the front panel, the cylinder is
due to be replaced. Remove the drip tray. Then lift and pull out the lower panel.
2. Turn the funnel and cylinder upward for easier access. Support the cylinder with one hand,
and rotate it counter-clockwise until loose. (NOTE: a small amount of gas may be heard
escaping. This is normal.)
3. Remove the empty cylinder.
4. Insert the new, full cylinder into the funnel, and rotate clockwise to install. An audible
beep will be heard, indicating that gas is entering the dispenser. Continue to turn the
cylinder firmly until fully tight. Turn the funnel downward until the cylinder rests
against the back wall. Then replace the panel and drip tray.
VI. Cleaning Instructions
It is recommended to clean your dispenser every 3 to 6 months using the following items:
Clean pair of rubber gloves
A new sponge or non-abrasive cleaning pad
Lint-free paper towels
Bucket or large bottle
Boiling water
New, unopened 3 or 5 gallon water bottle
Phillips head screw driver
Cleaning the Cold Tank
1. Remove the 3 or 5 gallon water bottle from the dispenser.
2. Drain the cold tank water by holding the blue cold water dispense button until water stops
flowing.
3. After draining the cold tank, unplug the dispenser from the power outlet.
4. Remove the no-spill adapter on top of the dispenser by pulling upward. Then remove the
plastic baffle inside of the tank by pulling upward.
5. Carefully fill the cold tank with clean, boiling water. Always use caution around hot
water!
6. Let boiled water sit for 3 minutes to partially cool.
7. Put on protective rubber gloves, and once safe to do so, use a new sponge or cleaning pad
to gently clean the cold tank by scrubbing the entire surface. Never use soap, cleaning
fluid, steel wool or other abrasive material to clean the cooling unit.

Rev. A - 060220
8. Fill the cold tank with clean bottled water
9. Plug the dispenser back into a power outlet, and drain the cold tank again completely.
10. Clean the no-spill adapter and baffle (previously removed) by washing both with warm
soapy water. Rinse thoroughly to remove any soap residue.
11. Replace the baffle by inserting it into the connections at the bottom of the cold tank.
Then replace the non-spill adaptor by pushing the assembly into the cold tank opening.
Draining the Hot Water and Carbonation Tanks
12. To drain water from the hot tank:
a) Remove the 3 or 5 gallon bottle from the dispenser, if installed.
b) Unplug the power cord, and rotate the dispenser to access the back surface
CAUTION: Water will be VERY hot! Wear protective gloves and use extreme caution.
c) Locate the hot drain port at the rear, and place a large bucket under the drain to catch
the hot water.
d) While pulling the knob on the hot tank drain plug outward, turn the drain plug
counter clockwise and pull out the plug.
e) After all hot water has drained into the bucket, close the hot tank drain by pushing in
the plug, and turning the plug clockwise until fully locked.
13. To drain sparkling water from the carbonation tank:
a) Remove the 3 or 5 gallon bottle from the dispenser, if installed, and unplug the
dispenser’s power cord, if powered.
b) Locate the carbonation tank drain tube located at the rear of the dispenser
c) Remove the drain tube from the drain tube dock by pulling the tube downward

Rev. A - 060220
d) Place a large bucket under the drain tube to catch the drained carbonation tank water
e) Using a screwdriver, turn the drain valve counter-clockwise until water begins to
flow.
f) After all water has drained from the carbonation tank, close the drain valve by
turning it clockwise with screwdriver until tight.
g) Place the carbonation drain tube back into the drain dock
h) Place a new, un opened 3 or 5 gallon bottled water on the dispenser
i) Place a cup under the dispense nozzle, reconnect power, and then press and hold the
hot unlock & hot dispense buttons together until water begins to flow
j) Press and hold the cold water button until water begins to flow
k) Press and hold the carbonation button to dispense a small amount of (8 to 12 ounces)
sparkling water in to a cup
The cleaning process is complete.
Contact Customer Service at [phone] to learn more about the ReadyRefresh™
Professional Cleaning Service. Our dedicated ReadyRefresh™ Technicians use
professional-grade cleaners and equipment to employ a unique process that thoroughly
cleans water dispensers. Contact ReadyRefresh to schedule service today.
VI. Troubleshooting:
No water dispensing
or poor flow rate
No or slow sparkling
water only
If the SPARKLING WATER button is flashing
and will not dispense water, a reset is required.
Place a cup larger than 33oz under the spout.
Then press and hold the SPARKLING WATER
dispense button until a beep is heard (5 seconds).
Release the button. The dispenser will dispense
water for 10-15 seconds until the reset is

Rev. A - 060220
complete.
CO2 pressure is used to force sparkling water out
of the spigot. If the CO2 cylinder is empty,
water will not flow properly. If the “Replace
CO2” light is flashing, replace the CO2 cylinder
with a new one.
No water from any
button
Ensure there is water in the 5-gallon bottle. If
the bottle is empty, replace the bottle with a new
one.
The dispenser requires power to dispense water.
Ensure the dispenser is plugged into a functional
wall outlet or power supply. LED lights will
illuminate if there is power.
Water is Leaking
From the spigot
A few drops after each dispense is normal
If water is seen continuously leaking, there may
be an issue with the dispenser. Contact your
ReadyRefresh Service Center
From elsewhere
Ensure the no-spill cover on top of the dispenser
is pushed fully down and sitting flat.
Remove the 5-gallon bottle and inspect it for
holes or damage. Place a new bottle onto the
dispenser and monitor for leaks
If leaks continue, contact your ReadyRefresh
Service Center
Water is Not
Hot/Cold/Sparkling
No Sparkling
If the CO2 cylinder is empty, water will not be
sparkling. If the “Replace CO2” light is
flashing, replace the CO2 cylinder with a new
one. If the cylinder is not empty, the cylinder
may have loosened from the cooler, causing the
gas flow to stop. Remove the cylinder and
reinstall until it is fully tight.
Water needs to be cold to properly absorb the
CO2 and provide the sparkling sensation. If the
icon is flashing, allow the dispenser to finish
chilling the water. After the icon remains
steady, the water should be fully saturated with
CO2.
Not Cold
The dispenser has two cold reservoirs to chill:
still & sparkling. Because of the large capacity,
it can take up to 2 hours to fully chill the water
after initial setup
After dispensing more than 1 liter of still or
sparkling water, the dispenser may take up to 1
hour to fully chill the water.
The dispenser needs at least 4-6” of clearance on

Rev. A - 060220
each side to allow proper cooling of the
condenser coils. Ensure adequate spacing.
Dirty or dusty condenser coils may impact
performance. Inspect the condenser coils on the
back of the dispenser, and ensure they are clean.
Wipe them with a clean, dry cloth if necessary.
Not Hot
The dispenser has a red HOT SWITCH on the
back of the dispenser to manually turn the heater
on and off. Ensure the switch is illuminated and
in the ON position
The dispenser may take up to 20-30 minutes to
fully heat the water after initial setup, or after
dispensing more than 1 liter of hot water.
Dispenser is Noisy
Loud humming
The dispenser has a compressor that chills the
water when the temperature rises, and a booster
pump that allows sparkling water to overcome
the high pressure of CO2 gas when dispensing.
The “humming” heard during either of these
actions is normal.
Hissing is heard
If hissing is heard, CO2 gas may be leaking.
Ensure the CO2 cylinder is fully tightened into
the dispenser funnel until a hard stop is felt.
The CO2 cylinder valve may be damaged.
Install a new cylinder and monitor for additional
hissing.
If hissing is still heard, contact your
ReadyRefresh Service Center.
TECHNICALAPPENDIX
VII. Temperature Control:
1. The hot water temperature is controlled by mechanical thermostats, keeping the water
temperaturebetween178 ⁰ Fand195 ⁰ F;
2. The cold water temperature is controlled by a mechanical thermostat, keeping the water
temperaturebetween41 ⁰ Fand50 ⁰ F;
3. The sparkling water temperature is controlled by an electrical temperature control circuit,
keeping the water temperature between 38 ⁰ F and 43 ⁰ F.
VIII. Carbonator Tank Water Level Inspection and Control:
The sparkling water level is measured by a float switch.
1. When the float switch is disengaged for more than one second, the sparkling water level is
low and the booster pump will engage to refill chamber;
2. When the float switch is engaged for more than one second, it means the sparkling water
level is acceptable and the booster pump disengages.

Rev. A - 060220
IX. Airlock Release Program:
1. If the booster pump is running for more than two minutes, but the float switch does not
become engaged, the sparkling water reservoir will become airlocked with CO2. This is
caused by continuously pressing the dispense button with no water available, or if the
dispenser is improperly setup. The dispenser will recognize this and activate the Airlock
Release Program.
2. When activated, the green dispense button will continuously flash, indicating that the
dispense function is disabled. Pressing and holding the button for 5 seconds will start the
correction sequence.
3. The high pressure gas solenoid will close, preventing CO2 from entering the reservoir.
The dispense solenoid will then open, releasing the high pressure airlock. The booster
pump will engage and water will continue to flow until the reservoir is completely filled
with water.
4. When the float switch is engaged, the program will terminate and the dispenser will return
to normal operating conditions.
