Realtek Semiconductor RTL8192EEBT User manual

RTL8192EEBT
user manual
1
RTL8192EEBT
RTL8192EE+RTL8761AU
Combo Module User’s Manual
Rev. 0.1
12 .03. 2013
:
Realtek Semiconductor Corp.
No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan
Tel.: [phone]. Fax: [phone]
www.realtek.com

RTL8192EEBT
user manual
2
COPYRIGHT
©2012 Realtek Semiconductor Corp. All rights reserved. No part of this document may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means without the written permission of Realtek Semiconductor Corp.
DISCLAIMER
Realtek provides this document “as is”, without warranty of any kind. Realtek may make improvements and/or
changes in this document or in the product described in this document at any time. This document could include
technical inaccuracies or typographical errors.
TRADEMARKS
Realtek is a trademark of Realtek Semiconductor Corporation. Other names mentioned in this document are
trademarks/registered trademarks of their respective owners.
USING THIS DOCUMENT
This document is intended for the software engineer’s reference and provides detailed programming
information.
Though every effort has been made to ensure that this document is current and accurate, more information may
have become available subsequent to the production of this guide.

RTL8192EEBT
user manual
3
Table of Contents
1. GENERAL DESCRIPTION ...............................................................................................................................................4
2. FUNCTIONAL SPECIFICATIONS .................................................................................................................................................. 5
4. WARNING ................................................................................................................................................................................ 6
4.5.1 Federal Communication Commission Interference Statement......................................................................................6
4.5.2 Industry Canada Statement..........................................................................................................................................7
4.5.3 NCC 警語 ....................................................................................................................................................................10

RTL8192EEBT
user manual
4
1. General Description
The Realtek RTL8192EE is a highly integrated single-chip MIMO (Multiple In, Multiple Out) Wireless LAN
(WLAN) solution for the wireless high throughput 802.11n specification. It combines a MAC, a 2T2R capable
baseband, and RF in a single chip. The RTL8192EE provides a complete solution for a high throughput
performance wireless client.
The RTL8192EE baseband implements Multiple Input, Multiple Output (MIMO) Orthogonal Frequency
Division Multiplexing (OFDM) with 2 transmit and 2 receive paths (2T2R) and is compatible with the IEEE
802.11n specification. Features include two spatial streams transmission, short Guard Interval (GI) of 400ns,
spatial spreading, and transmission over 20MHz and 40MHz bandwidth. The RTL8192EE provides a spatial
stream Space-Time Block Code (STBC) and Low Density Parity Check (LDPC) encoding and decoding to
extend the range of transmission. At the receiver, extended range and good minimum sensitivity is achieved by
having receiver diversity up to two antennas. As the recipient, the RTL8192EE also supports explicit sounding
packet feedback that helps senders with beamforming capability. With two independent RF blocks, the
RTL8192EE can perform fast roaming without link interruption.
For legacy compatibility, Direct Sequence Spread Spectrum (DSSS), Complementary Code Keying (CCK) and
OFDM baseband processing are included to support all IEEE 802.11b and 802.11g data rates. Differential
phase shift keying modulation schemes, DBPSK and DQPSK with data scrambling capability, are available
along with complementary code keying to provide data rates of 1, 2, 5.5 and 11Mbps with long or short
preamble. The high-speed FFT/IFFT paths, combined with BPSK, QPSK, 16QAM, and 64QAM modulation
of the individual subcarriers and rate compatible punctured convolutional coding with coding rate of 1/2, 2/3,
3/4, and 5/6, provides the maximum data rate of 54Mbps and 300Mbps for IEEE 802.11g and 802.11n MIMO
OFDM respectively.
The RTL8192EE builds in an enhanced signal detector, an adaptive frequency domain equalizer, and a
soft-decision Viterbi decoder to alleviate severe multi-path effects and mutual interference in the reception of
multiple streams. For better detection quality, receive diversity with maximal-ratio-combine (MRC) applying
up to 2 receive paths are implemented. Robust interference detection and suppression are provided to protect
against Bluetooth, cordless phone, and microwave oven interference. Receive vector diversity for multi-stream
application is implemented for efficient utilization of MIMO channels. Efficient IQ-imbalance, DC offset,
phase noise, frequency offset, and timing offset compensations are provided for radio frequency front-end
impairments. Selectable digital transmit and receive FIR filters are provided to meet transmit spectrum mask
requirements and to reject adjacent channel interference, respectively.
The RTL8192EE supports fast receiver Automatic Gain Control (AGC) with synchronous and asynchronous
control loops among antennas, antenna diversity functions, and adaptive transmit power control functions to
obtain the better performance in the analog portions of the transceiver.
The RTL8192EE MAC supports 802.11e for multimedia applications, 802.11i for security, and 802.11n for
enhanced MAC protocol efficiency. Using packet aggregation techniques such as A-MPDU with BA and
A-MSDU, protocol efficiency is significantly improved. Power saving mechanisms such as Legacy Power Save,
U-APSD, and MIMO power saving reduce the power wasted during idle time, and compensate for the extra
power required to transmit MIMO OFDM. The RTL8192EE provides simple legacy and 20MHz/40MHz
co-existence mechanisms to ensure backward and network compatibility.

RTL8192EEBT
user manual
5
The Realtek RTL8761AU is a highly integrated single-chip Bluetooth 2.1/3.0/4.0 controller, USB interface. It
combines BT Protocol Stack (LM, LL, and LE), BT Baseband, modem, and BT RF in a single chip.
The RTL8761AU Bluetooth controller complies with Bluetooth core specification v4.0, and supports dual
mode (BR/EDR + AMP + Low Energy Controllers). It is compatible with previous versions, including v2.1 +
EDR and v3.0 + HS. For BR/EDR, it supports scatternet topology and allows four active links in slave mode,
and seven active links in master mode. For Low Energy, it supports multiple states and allows eight active links
in master mode. The links in BR/EDR and LE can be active simultaneously.
2. Functional Specifications
Standards
WiFi:
IEEE 802.11b, IEEE 802.11g, Draft IEEE 802.11n, IEEE 802.11d,
IEEE 802.11e, IEEE 802.11h, IEEE 802.11i
BT:
V2.1+EDR/BT v3.0/BT v3.0+HS/BT v4.0
Bus Interface
WiFi: PCI Express BT: USB
Form Factor
NGFF 、minicard
Data Rate
802.11b:
11, 5.5, 2, 1 Mbps;
802.11g:
54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n:
MCS 0 to 15 for HT20MHz;
MCS 0 to 15 for HT40MHz
BT:
1 Mbps for Basic Rate
2,3 Mbps for Enhanced Data Rate
,6,9,12,18,24,36,48,54 Mbps for High Speed
Media Access Control
WiFi:
CSMA/CA with ACK
BT:
AFH, Time Division
Modulation Techniques
802.11b:
CCK, DQPSK, DBPSK
802.11g:
64 QAM, 16 QAM, QPSK, BPSK
802.11n:
64 QAM, 16 QAM, QPSK, BPSK
BT:
8DPSK, /4 DQPSK, GFSK
Network Architecture
WiFi:
Ad-hoc mode (Peer-to-Peer )
Infrastructure mode
BT:
Pico Net
Scatter Net

RTL8192EEBT
user manual
6
Operating Channel
WiFi 2.4GHz:
11: (Ch. 1-11) – United States
13: (Ch. 1-13) – Europe
14: (Ch. 1-14) – Japan
BT 2.4GHz:
Ch. 0 ~78
Frequency Range
2.400GHz ~ 2.4835 GHz
Security
WiFi :
WPA, WPA-PSK, WPA2, WPA2-PSK, WEP 64bit & 128bit, IEEE
802.11x, IEEE 802.11i
BT:
Simple Paring
Operating Voltage
3.3 V ±9% I/O supply voltage
4. Warning
4.5.1 Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through 11.

RTL8192EEBT
user manual
7
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users
) For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band by supplied
firmware programming tool. OEM shall not supply any tool or info to the end-user regarding to Regulatory Domain
change.
As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM
integrator is still responsible for testing their end-product for any additional compliance requirements required
with this module installed (for example, digital device emissions, PC peripheral requirements, etc.).
IMPORTANT NOTE: 7KLVGHYLFHDQGLWVDQWHQQDVPXVWQRWEHFRORFDWHGZLWKDQ\RWKHUWUDQVPLWWHUVH[FHSW
LQDFFRUGDQFHZLWK)&&PXOWLWUDQVPLWWHUSURGXFWSURFHGXUHV5HIHULQJWRWKHPXOWLWUDQVPLWWHUSROLF\
PXOWLSOHWUDQVPLWWHUVDQGPRGXOHVFDQEHRSHUDWHGVLPXOWDQHRXVO\ZLWKRXW&3
.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm
may be maintained between the antenna and users. The final end product must be labeled in a visible area with
the following: “Contains FCC ID: TX2RTL8192EEBT”.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
4.5.2 Industry Canada Statement
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following
two conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference that may cause undesired operation of the
device
French translation:
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de
licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de
brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage
susceptible de provoquer un fonctionnement indésirable.
This device has been designed to operate with an antenna having a maximum gain of 3.5dBi.
Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required
antenna impedance is 50 ohms.

RTL8192EEBT
user manual
8
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the
EIRP is not more than required for successful communication.
French translation:
Ce dispositif a été conçu pour fonctionner avec une antenne ayant un gain maximum de 3.5 dBi. Une antenne à
gain plus élevé est strictement interdite par les règlements d'Industrie Canada. L'impédance d'antenne requise
est de 50 ohms.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peutfonctionner avec une
antenne d'un type et d'un gain maximal (ou inférieur) approuvé pourl'émetteur par Industrie Canada. Dans le
but de réduire les risques de brouillage radioélectriqueà l'intention des autres utilisateurs, il faut choisir le type
d'antenne et son gain de sorte que lapuissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité
nécessaire àl'établissement d'une communication satisfaisante.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
French translation:
NOTE IMPORTANTE: (Pour l'utilisation de dispositifs mobiles)
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement non
contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de
rayonnement et votre corps.
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and
) For all products market in Canada, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band
by supplied firmware programming tool. OEM shall not supply any tool or info to the end-user regarding to
Regulatory Domain change.
As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM
integrator is still responsible for testing their end-product for any additional compliance requirements required
with this module installed.
French translation :
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions suivantes: (Pour utilisation de
dispositif module)
1) L'antenne doit être installée de telle sorte qu'une distance de 20 cm est respectée entre l'antenne et les
utilisateurs, et
CAN ICES-3 (B)/NMB-3(B)

RTL8192EEBT
user manual
9
) Pour tous les produits vendus au Canada, OEM doit limiter les fréquences de fonctionnement CH1 à CH11
pour bandes de fréquences 2.4G grâce aux outils de microprogrammation fournis. OEM ne doit pas fournir
d'outil ou d'informations à l'utilisateur final en ce qui concerne le changement de réglementation de domaine.
Tant que les 3 conditions ci-dessus sont remplies, des essais supplémentaires sur l'émetteur ne seront pas
nécessaires. Toutefois, l'intégrateur OEM est toujours responsable des essais sur son produit final pour toutes
exigences de conformité supplémentaires requis pour ce module installé.
IMPORTANT NOTE: 7KLVGHYLFHDQGLWVDQWHQQDVPXVWQRWEHFRORFDWHGZLWKDQ\RWKHUWUDQVPLWWHUV
H[FHSWLQDFFRUGDQFHZLWK,&PXOWLWUDQVPLWWHUSURGXFWSURFHGXUHV5HIHULQJWRWKHPXOWLWUDQVPLWWHUSROLF\
PXOWLSOHWUDQVPLWWHUVDQGPRGXOHVFDQEHRSHUDWHGVLPXOWDQHRXVO\ZLWKRXWUHDVVHVVPHQWSHUPLVVLYHFKDQJH
French translation:
NOTE IMPORTANTE: &HWDSSDUHLOHWVRQDQWHQQHVQHGRLWSDVrWUHFRORFDOLVpVRXIRQFWLRQQHPHQWHQ
DVVRFLDWLRQDYHFXQHDXWUHDQWHQQHRXWUDQVPHWWHXU
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm
may be maintained between the antenna and users. The final end product must be labeled in a visible area with
the following: “Contains IC: 6317A-RTL8192EEBT”.
French translation:
Plaque signalétique du produit final
Ce module émetteur est autorisé uniquement pour une utilisation dans un dispositif où l'antenne peut être
installée de telle sorte qu'une distance de 20cm peut être maintenue entre l'antenne et les utilisateurs. Le produit
final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC:
6317A-RTL8192EEBT ".
Manual Information To The End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
French translation:

RTL8192EEBT
user manual
10
Manuel d'information à l'utilisateur final
L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final quant à la façon
d'installer ou de supprimer ce module RF dans le manuel de l'utilisateur du produit final qui intègre ce module.
Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et avertissements
comme indiqué dans ce manuel.
4.5.3 NCC 警語
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功
率或變更原設計之特性及功能。
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並
改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電
機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
本模組於取得認證後將依規定於模組本體標示審合格籤。
系統廠商應於平台上標示「本產品內含射頻模組： XXXyyyLPDzzzz-x (NCC ID) 」字樣。
Realtek Semiconductor Corp.
Headquarters
No. 2, Innovation Road II, Hsinchu Science Park,
Hsinchu, 300, Taiwan, R.O.C.
Tel: [phone] Fax: [phone]
www.realtek.com.tw
4.5.4 Japan Statement
Host system must be labeled with "Contains MIC ID:xxxxxx“, MIC ID displayed on label.

Tota l AntennaList
No. Brand Ant.
Type Con. Type Peak Gain (dBi) Model No.
1 LYNwave PIFA
IPEX
MHF4 TX1: 3.5 TX1: ALA110-222050-300011
2 LYNwave PIFA IPEX TX1: 3.5 TX1: ALA110-222050-300010
3 JOYMAX DIPOLE
IPEX TX1: 3.0 TX1: TWF-614XMPXX-500
4 Well Green PIFA IPEX TX1: 0.85
TX2: 0.44
TX1: SKW10WMPB01+A
TX2: SKW10WMPB02+A
5 Well Green PIFA IPEX TX1: 0.42
TX2: -0.13
TX1: SK65EWMPB01+A
TX2: SK650WMPB02+A
6 JESS-LINK PIFA IPEX
TX1: 2.72
TX2: 0.07
TX1: DC33001AD00
TX2: DC33001AD00
7 HIGH-TEK PIFA IPEX
TX1: -0.93
TX2: 0.87
TX1: DC33001AC00
TX2: DC33001AC00
8 Luxshared PIFA IPEX
TX1: -0.28
TX2: 0.59
TX1: L01RF023-YT-R (WLAN Main)
TX2: L01RF029-YT-R (WLAN Aux)
9 Luxshared PIFA IPEX
TX1: 2.08
TX2: 0.14
TX1: L01RF019-DT-R (31-502717)
TX2: L01RF021-DT-R (31-502716)
10 Well Green PIFA IPEX TX1: 0.55
TX2: 1.36
TX1: SKAEUWMPB01+B
TX2: SKAEUWMPB01+B
11 Well Green PIFA IPEX TX1: 0.82
TX2: -2.23
TX1: SKA91WMPB02+A
TX2: SKA91WMPB01+A
12 Wgt PIFA IPEX
TX1: 2.14
TX2: 1.92
TX1: W550EU WM-1
TX2: W550EU WM-2
13 Acon PIFA IPEX
TX1: -0.63
TX2: -3.39
TX1: APP6P-700781
TX2: APP6P-700782
14 Acon PIFA IPEX
TX1: -0.13
TX2: -0.23
TX1: ATM6P-70100
TX2: ATM6P-70200
15 WNC PIFA IPEX
TX1: -0.58
TX2: -1.48
TX1: DQ6G15G5800
TX2: DQ6G15G5700
16 Zhan Yun PIFA IPEX
TX1: -0.70
TX2: -1.20
TX1: DQ60QTLI200
TX2: DQ60QTLI201
17 WNC PIFA IPEX
TX1: 1.15
TX2: 0.59
TX1: 81.EKG15.G30
TX2: 81.EKG15.G29
18 YAGEO PIFA IPEX
TX1: 0.59
TX2: 0.90
TX1: CAN4313LC0613WLA3
TX2: CAN4313LC0613WLA4
19 WNC PIFA IPEX
TX1: 0.18
TX2: 0.60
TX1: 81.EKG15.G38
TX2: 81.EKG15.G37
20 JESS-LINK PIFA IPEX
TX1: 1.89
TX2: 1.56
TX1: PANT11A00008‐1
TX2: PANT11A00009‐1


No. Brand Ant.
Type Con. Type Peak Gain (dBi) Model No.
21 Foxconn PIFA IPEX
TX1: 0.21
TX2: 0.60
TX1: WDAN-T1RH1
TX2: WDAN-T1RH2
22 Well Green PIFA IPEX
TX1: 0.21
TX2: -0.75
TX1: SKX71WMPB01+B
TX2: SK370WMPB01+B
23 Luxshared PIFA IPEX
TX1: -0.6
TX2: -0.29
TX1: L01RF008-R
TX2: L01RF009-R
24 Well Green PIFA IPEX
TX1: 0.72
TX2: 0.49
TX1: SKW25WMPB01+A
TX2: SKW25WMPB01+A
25 Well Green PIFA IPEX
TX1: -0.17
TX2: -2.24
TX1: SK549WMPB01+A
TX2: SK549WMPB02+A
26 Wgt PIFA IPEX
TX1: 1.7
TX2: 2.53
TX1: W350ETQ WM-1
TX2: W350ETQ WM-2
27 Well Green PIFA IPEX
TX1: -1.93
TX2: -1.28
TX1: SKW54WMPB01+C
TX2: SKW34WMPB02+A
28 Joinsoon PIFA IPEX
TX1: 2.6
TX2: 0.53
TX1: IA-120266
TX2: IA-120267
29 WNC PIFA IPEX
TX1: 0.24
TX2: -0.58
TX1: 25.90AH8.001
TX2: 25.90AH7.001
30 Wieson PIFA IPEX
TX1: 1.28
TX2: 0.34
TX1: 25.90AH8.011
TX2: 25.90AH7.011
31 Yageo PIFA IPEX
TX1: -0.27
TX2: -0.88
TX1: 25.90AH8.021
TX2: 25.90AH7.021
32 Yageo PIFA IPEX
TX1: -0.11
TX2: -0.68
TX1: 25.90AJB.001
TX2: 25.90AJC.001
33 Yageo PIFA IPEX
TX1: -1.32
TX2: -1.14
TX1: 25.90AJB.001
TX2: 25.90AJC.001
34 Yageo PIFA IPEX
TX1: 2.74
TX2: 0.63
TX1: 25.90ALR.001
TX2: 25.90ALQ.001
35 WNC PIFA IPEX
TX1: -0.61
TX2: 1.91
TX1: 25.90AAL.001
TX2: 25.90AAK.001
36 TE Connectivity PIFA IPEX TX1: 1.29
TX2: 0.04
TX1: 25.90AAL.011
TX2: 25.90AAK.011
37 Amphenol PIFA
IPEX
MHF4
TX1: -1.73
TX2: -1.65
TX1: 0C50890
TX2: 0C50888
38 Amphenol PIFA
IPEX
MHF4
TX1: -1.54
TX2: -0.53
TX1: C-3942-16-000-48
TX2: C-3941-16-000-48


No. Brand Ant.
Type Con. Type Peak Gain (dBi) Model No.
39 Luxshare PIFA
IPEX
MHF4
TX1: -0.47
TX2: -0.25
TX1: LA22LN718-1N-3F
TX2: LA22LN719-1N-3F
40 YAGEO PIFA
IPEX
MHF4
TX1: 1.80
TX2: 1.19
TX1: CAN4313LL0727WLA1
TX2: CAN4313LL0727WLA2
41 Amphenol PIFA
IPEX
MHF4
TX1: -1.69
TX2: 0.41
TX1: LX3965-16-000-C
TX2: LX3964-16-000-C
42 Luxshare-ICT PIFA
IPEX
MHF4
TX1: -0.61
TX2: 1.82
TX1: DC330016W00
TX2: DC330016W10
43 HIGH-TEK PIFA IPEX
TX1: -2.20
TX2: -2.20 TX1: 25.90ALR.011 TX2: 25.90ALQ.011
44 HIGH-TEK PIFA IPEX
TX1: -0.70
TX2: -0.60 TX1: 25.90AJB.011 TX2: 25.90AJC.011
45 HIGH-TEK PIFA IPEX
TX1: -0.42
TX2: 1.59 TX1: 25.90AJB.011 TX2: 25.90AJC.011
