Recom RCM-4-TP-D User manual

1
Grid-connected PV Inverter
Three Phase Dual MPPT
RCM-4-TP-D/RCM-5-TP-D/RCM-6-TP-D/RCM-8-TP-D/
RCM-10-TP-D/
RCM-12-TP -D /RCM-15-TP -D / RCM-17-TP -D /
RCM-20-TP/ RCM-25-TP
-D
User Manual
RECOM TECHNOLOGIES

2

3
CONTENTS
1. Preface ......................................................................................................................5
1.1 Overview ....................................................................................................... 5
1.2 Target Groups ............................................................................................... 5
2. Safety Instructions ............................................................................................5
2.1 Safety Notes .................................................................................................5
2.2 Statement .....................................................................................................5
2.3 Important Safety Matters ............................................................................6
2.4 Symbols Explanation ...................................................................................7
3. Product Introduction .......................................................................................9
3.1 Basic Features ..............................................................................................9
3.2 Appearance Introduction ..........................................................................10
3.3 Display Interface ........................................................................................12
3.4 Packing List .................................................................................................13
4. Product Installation .......................................................................................13
4.1 Selection of Installation Location .............................................................13
4.2 Mounting the Inverter ................................................................................15
4.3 Electrical Connection ................................................................................17
4.4 Monitoring Device Installation ..................................................................22
4.5 RS485/DRED Connection ...........................................................................23
4.6 System Layout of Units without Integrated DC Switch ...........................26
5. Start and Stop ....................................................................................................27
5.1 Start Inverter ..............................................................................................27
5.2 Stop Inverter ..............................................................................................27
6. General Operation ...........................................................................................28
6.1 Display Operation .....................................................................................28
6.2 Auto-Test ....................................................................................................29
7. Troubleshooting ...............................................................................................30
7.1 Fault Messages ..........................................................................................30
7.2 Maintenance ..............................................................................................31
8. Technical Parameters ....................................................................................32

4
Attention
The products, services or features you purchase are subject to the commercial
contracts and terms of RECOM TECHNOLOGIES. All or part of the products, services or
features described in this document may not be within your purchasing or using scope.
Unless otherwise agreed in the contract, the Company shall not make any express or
implied declaration or guarantee of the contents of this document.
Due to product version upgrades or other reasons, the contents of this document will
be updated periodically. Unless otherwise agreed, this document serves only as a
guide to use, and all statements, information and recommendations in this document
do not constitute any express or implied guarantee.
RECOM SILLIA SAS
Address: 4 Avenue Pierre Marzin, Lannion, 22300, France
Website: www.recom-solar.com
Service Mail: [e-mail]
Hotline: [phone]

5
1. Preface
1.1 Overview
This manual is an integral part of RECOM RCM 4~25-TP series three-phase inverters (hereinafter
referred to as the inverters). It mainly introduces the assembly, installation, electrical
connection, debugging, maintenance and troubleshooting of the products. Before installing
and using inverters, please read this manual carefully, understand the safety information and
be familiar with the functions and characteristics of inverters.
1.2 Target Groups
This manual is applicable to the electrical installers with professional qualifications and
the people who bought this inverter. If there are any problems in the installation process,
please call RECOM TECHNOLOGIES service telephone at [phone] or email RECOM
TECHNOLOGIES at [e-mail] for consultation.
2. Safety Instructions
2.1 Safety Notes
2.1.1 Before installation, you should read this manual carefully and follow the instructions in
this manual strictly.
2.1.2 Installation operators need to undergo professional training or obtain electrical related
professional quali󽗉cation certi󽗉cates.
2.1.3 When installing, do not touch any part of the inner part of the inverter except the
terminals.
2.1.4 All electrical installations must conform to local electrical safety standards.
2.1.5 If the inverter needs maintenance, please contact the local designated personnel for
system installation and maintenance.
2.1.6 To use this grid-connected inverter for power generation needs the permission of the
local power supply authority.
2.1.7 During the operation of the inverter, the surface temperature may be higher and there is
a risk of burns. Do not touch.
2.1.8 When installing photovoltaic panels in the daytime, the photovoltaic panels should be
covered with opaque materials to avoid the risks and danger of high voltage at the panel end
in sunlight.
2.2 Statement
RECOM TECHNOLOGIES has the right not to undertake quality assurance in any of the
following circumstances:
2.2.1 Damages caused by irregular transportation.

6
2.2.2 Damages caused by incorrect storage, installation or use.
2.2.3 Damages caused by installation and use of equipment by non-professionals or untrained
personnel.
2.2.4 Damages caused by failure to comply with the instructions and safety warnings in the
products and documents.
2.2.5 Damages caused by running in an environment that doesn't meet the requirements
which stated in the documents.
2.2.6 Damages caused by operation beyond the parameters speci󽗉ed in applicable technical
speci󽗉cations.
2.2.7 Damages caused by unauthorized disassembly, alteration of products or modi󽗉cation of
software codes.
2.2.8 Damages caused by abnormal natural environment (force majeure, such as lightning,
earthquake, 󽗉re, storm, etc.).
2.2.9 Any damages caused by the process of installation and operation which don’t follow the
local standards and regulations.
2.2.10 Products beyond the warranty period.
2.3 Important Safety Matters
The following symbols may appear in this manual, which represent the following meanings:
Danger
Warning
Caution
Used to warn of urgent dangerous situations, if not avoided, it
could result in death or serious personal injury.
DescriptionSymbol
Used to warn of potentially dangerous situations, if not avoided, it
may result in death or serious personal injury.
Used to warn of potentially dangerous situations, if not avoided, it
may result in moderate or minor personal injury.
Attention
Used to transmit the safety warning information about equipment
or environment, if not avoided, it may cause equipment damage,
data loss, equipment performance degradation or other
unpredictable results. "Attention" does not involve personal
injury.
Note Used to highlight important information, best practices and
tips, etc. it's not warning, doesn't involve personal injury and
equipment damage information.

7
2.4 Symbols Explanation
This chapter mainly elaborates the symbols displayed on the inverter, nameplate and packing
box.
2.4.1 Symbols on the Inverter
DescriptionSymbol
Inverter running indicator.
Grounding symbol, the inverter casing needs to be properly
grounded.
2.4.2 Symbol on the Inverter nameplate
The inverter cannot be disposed of with household waste.
DescriptionSymbol
Please read the instructions carefully before installation.
Do not touch any internal parts of the inverter until 5 min after
being disconnected from the mains and PV input.
CE mark, the inverter complies with the requirements of the
applicable CE guidelines.
Danger. Risk of electric shock!
TUV certi󽗉cation.
The surface is hot during operation and no touch is allowed.
Electric shock hazard, it is strictly forbidden to use the person to
disassemble the inverter casing.
Inverter status indicator.

8
Handle with care.
DescriptionSymbol
This side up.
Keep dry.
Stacked layers.
2.4.3 Symbol on the Packing box

9
RECOM
RCM Series
RECOM
RCM Series
RECOM
RCM Series
RECOM
RCM Series
RECOM
RCM Series
IT
TT
TN-C-S
TN-S TN-C
3. Product Introduction
3.1 Basic Features
3.1.1 Function
The RECOM RCM 4~25-TP-D series is a three-phase grid-connected PV inverter which used to
e󽗋ciently convert the DC power generated by the PV string into AC power and feed it into the
grid.
3.1.2 The RCM 4~25-TP-D series inverter contains 10 models which are listed below:
RCM-4-TP-D, RCM-5-TP-D, RCM-6-TP-D, RCM-8-TP-D, RCM-10-TP-D, RCM-12-TP-D,
RCM-15-TP-D, RCM-17-TP-D, RCM-20-TP-D, RCM-25-TP-D
3.1.3 Applicable grid type
The applicable grid types for the RECOM RCM 4~25-TP-D series are TN-S, TN-C, TN-C-S, IT and
TT. When applied to the TT grid, the voltage of N to PE should be less than 30V. See Figure 3-1
for details:
3.1.4 Storage conditions
1) Inverter must be stored in its original packaging.
2) The storage temperature should be in the range of -30 ° C and + 60 ° C , and the relative
humidity stored is less than 90%.
3) If a batch of inverters needs to be stored, the height of each pile should be no more
than 6 levels.
Transformer Transformer Transformer
Transformer Transformer
Figure 3-1 Applicable grid type

10
Figure 3-2 Front view
Figure 3-3 Side view
3.2 Appearance Introduction
3.2.1 Inverter front view, as shown in Figure 3-2:
3.2.2 Inverter side view, as shown in Figure 3-3:
410mm
175mm
Name
Plate
Logo
Display
550mm
410mm

11
Figure 3-4 Bottom view
Figure 3-5 Inverter back view
3.2.3 Inverter bottom view, as shown in Figure 3-4:
3.2.4 Inverter back view, as shown in Figure 3-5:
175mm
DC Switch (Optional) Com2 Port
(Optional)
DC Input Terminal
Back Rail
Com1 Port
AC Output Terminal
Back Rail
Vent Valve

12
Item Indicator Status Description
1Power
Indicator
O󽗈 No input voltage detected or input voltage is too low.
Slow 󽗊ashing Inverter powered on, waiting for the grid connection.
Quick 󽗊ashing Inverter detected grid power and entered self-test status.
Always on Normal, grid-connected and power generated.
2Alarm
Indicator
Always on An alarm or fault is detected, and the display can view the speci󽗉c
fault information.
O󽗈 The inverter is running normally.
Slow 󽗊ashing The monitoring device is not connected to the router or is not
connected to the base station.
Quick 󽗊ashing The monitoring device is connected to the router or connected to
the base station but not connected to the server.
3OLED
Display
On Display the inverter operating information.
O󽗈 If the button pressed without any response, the screen is faulty or
not well connected.
4Button Physical
button Switch OLED display information and set parameters by short
press and long press.
3.3 Display Interface
Figure 3-6 Display interface

13
Anti-reverse version 2pcs / RS485 and DRED version 1pcs (This connector already
pre-installed inside the inverter).
② RCM 4~12-TP-D 2pcs / RCM-15-TP-D 3pcs / RCM 17~25-TP-D 4pcs.
③ DRED version only (This connector already pre-installed inside the inverter).
Inverter × 1 Wall Bracket × 1 Expansion Bolt × 5 3Pin Terminal × 1
①PV Terminal × 2 ②
Figure 3-7 Packing list
3.4 Packing List
The package of the inverter includes the following accessories. Please check whether the
accessories in the packing box are complete at the 󽗉rst time when receiving the goods. See
Figure 3-7 for the packing list:
4. Product Installation
4.1 Selection of Installation Location
The RECOM RCM 4~25-TP-D series is designed with IP65 protection for indoor and outdoor
installations. When selecting an inverter installation location, the following factors should be
considered:
1) The wall on which the inverter is mounted must be strong and can withstand the weight of the
inverter for a long time.
2) The inverter needs to be installed in a well-ventilated environment.
3) Do not expose the inverter directly to strong sunlight to prevent the power derating due to
excessive temperature.
4) The inverter should be installed in a place with shelter to prevent direct exposure to sunlight
and rain.
5) Install the inverter at the eye level for easy inspection of screen data and further maintenance.
6) The ambient temperature of the inverter installation location should be between -30 ° C and
60 ° C.
7) The surface temperature of the inverter may reach up to 75 ° C. To avoid risk of burns, do not
touch the inverter while it’s operating and inverter must be installed out of reaching of children.
4.1.1 Recommended installation location of the inverter, as shown in Figure 4-1:
WiFi/GPRS(Optional) AC Terminal × 1 Ground Terminal × 1 6Pin Terminal × 1
③
Note
Inspection
Report
User
Manual
Quick
Guide
User Manual× 1
Quick Guide × 1
Inspection Report × 1
①

14
4.1.2 The requirements for inverter installation spacing are shown in Figure 4-2:
Figure 4-1 Recommended installation
Figure 4-2 Recommended installation space
Figure 4-3 Recommended installation angle
Do not put 󽗊ammable and explosive articles around the inverter.
Warning
500mm 500mm
500mm
500mm
300mm
300mm 300mm
4.1.3 The installation angle of the inverter is recommended as shown in Figure 4-3:
Max 30°
√ √×

15
4.2 Mounting the Inverter
4.2.1 Wall bracket installation
Dimensions of wall bracket, see Figure 4-4:
1) Use the wall bracket as the template to mark the position of 5 holes on the wall. See Figure
4-5 for details:
Figure 4-4 Dimensions of wall bracket
Figure 4-5 Mark the hole position
150mm
300mm
150mm
150mm150mm

16
Figure 4-6 Fix the wall bracket
Figure 4-7 Mounting the inverter
Before drilling, make sure to avoid the buried water tube and electric wires
in the wall to avoid danger.
2) Use an electrical driller with 10mm diameter bit to drill 5 holes on the wall and make sure
hole depth is 80mm.
3) Insert the expansion tubes into the holes and tighten them, then 󽗉x the bracket onto the
wall with expansion screws by using a cross screwdriver, as shown in Figure 4-6:
4.2.2 Mounting the inverter
Lift up the inverter with both hands, hang the back rail on the 󽗉xed wall bracket carefully, see
Figure 4-7 for details:
Warning

17
4.3 Electrical Connection
Danger hint
4.3.1 Inverter PV string connection
4.3.1.1 The following principles must be considered when making electrical connections to the
inverter:
1) Disconnect the AC breaker on the grid side.
2) The DC switch of the inverter must be turned to the "OFF" position.
3) The number and type of the PV panels connected in the two strings of one MPPT must be
same.
4) Make sure the maximum output voltage of each PV string does not exceed 1100V.
4.3.1.2 DC connector assembly procedures
1) Select the appropriate photovoltaic cable:
2) Peel o󽗈 the DC cable insulation sleeve for 7 mm, as shown in Figure 4-8:
Cable type Conductor cross-setional area (mm²)
General photovoltaic cable
Scope (mm²) Recommended value (mm²)
2.5-4.0 4.0
A high voltage in the conductive part of the inverter may cause an electric
shock. When performing any installation on the inverter, make sure that the AC
and DC sides of the inverter are completely de-energized.
Do not ground the positive or negative pole of the PV string, otherwise it will
cause serious damage to the inverter.
Static may cause damage to the electronic components of the inverter. Anti-
static measures should be taken during the repairing or installation.
Do not use other brands or other types of PV terminals other than the PV
terminal in the accessory package. RECOM TECHNOLOGIES has the right to
refuse all damages caused by the mixed-use of terminals.
Moisture and dust can damage the inverter, ensure the cable gland is securely
tightened during installation. The warranty claim will be invalided if the inverter
damaged by the cable connector not well installed.
Figure 4-8
Wire cross-setional area 2.5-4mm27mm
Danger
Warning
Attention
Attention
Warning

18
Figure 4-9
+
-
Crimping Plier
Figure 4-10
Figure 4-11
3) Disassemble the connector in the accessory bag, as shown in Figure 4-9:
4) Insert the DC cable through the DC connector nut into the metal terminal and press the
terminal with a professional crimping plier (pull back the cable with some power to check if
it’s tight enough), as shown in Figure 4-10:
5) Insert the positive and negative cables into the corresponding positive and negative
connectors, pull back the cable to ensure that the terminal is tightly attached in the connector.
6) Use an open-end wrench to screw the nut to the end to ensure that the terminal is well
sealed, as shown in Figure 4-11:
1.Before assembling the DC connector, make sure that the cable polarity is
correct.
2.Use a multimeter to measure the voltage of the DC input string, verify the
polarity of the DC input cable, and ensure that each string voltage is within
1000V.
Warning
Open-end Wrench

19
An AC breaker must be connected on the AC side of the inverter.
Any loads cannot be directly connected to the inverter.
Warning
Figure 4-12
Figure 4-13
Model RCM-4-
TP-D
RCM-5-
TP-D
RCM-6-
TP-D
RCM-8-
TP-D
RCM-10-
TP-D
RCM-12-
TP-D
RCM-15-
TP-D
RCM-17-
TP-D
RCM-20-
TP-D
RCM-25-
TP-D
Copper
Cable
2.5
-10mm2
2.5
-10mm2
2.5
-10mm2
3.2
-10mm24-10mm26-10mm26-10mm28-10mm28-10mm28-10mm2
Breaker 20A 20A 20A 20A 32A 32A 32A 40A 40A 50A
7) Insert the positive and negative connectors into the inverter DC input terminals respectively,
and a "click" sound represents the assembly in place, as shown in Figure 4-12:
4.3.2 Connection of AC output
The RECOM RCM 4~25-TP-D series three phase inverter applies to the three-phase power grid
with a voltage of 230/400V and a frequency of 50/60Hz.
The recommended cable and AC breaker for the RECOM RCM 4-25TP-D series three phase
inverter are shown in the following table:
4.3.2.1 AC connector connection steps
1) Take the AC connector out of the accessory bag and disassemble it, as shown in Figure 4-13:
Cable Gland Threaded Sleeve AC Terminal Head

20
Figure 4-15
Allen Key
Figure 4-16
2) According to the table above, select an appropriate copper cable, peel the insulation sleeve
of AC cable o󽗈 for 50mm, and peel o󽗈 the end of 3L /PE / N wires for 8mm, as shown in Figure
4-14:
3) Insert the stripped end of the 󽗉ve wires into the appropriate hole of the terminal head by
following the rules: yellow green wire to PE port, red or brown 󽗉re wires to L ports (no requests
for the sequence of three 󽗉re wires), and blue or black wire to the N port. Please try to pull out
the cable to make sure it’s well connected. As shown in Figure 4-15:
4) According to the arrow direction to push the threaded sleeve to make it connected with the
AC terminal head and then rotate the cable gland clockwise to lock it. As shown in 󽗉gure 4-16:
Figure 4-14
Strip Length:8mm
50mm
Wire Diameter:13-18mm
