Record Power CX2000 User guide

Original Instruction Manual
CX2000 Compact Dust &
Chip Extractor
Always wear safety glasses when
using woodworking equipment.
Always read the instructions
provided before using
woodworking equipment.
i
Kg
Version 3.0
August 2013
To register this product please visit
www.recordpower.info
It is important to register your product as soon as possible in order to receive efficient after sales
support and be entitled to the full 5 year guarantee. Your statutory rights are not affected.
Please see back cover for contact details.
Important
For your safety read instructions carefully
before assembling or using this product.
Save this manual for future reference.
i
Kg
CX2000 Manual 3.0.indd 1 19/08/2013 09:47

2
Contents
1. Explanation of Symbols
2. General Health & Safety Guidance
3. Additional Health & Safety for Chip Extractors
4. Record Power Guarantee
5. Getting to Know your Chip Collector
6. Specifications
7. Contents of the Package
8. Assembly
9. Operation
10. Maintenance
11. Troubleshooting
12. Electrical Connection & Wiring Diagram
13. Parts Diagram & Parts List
CX2000 Manual 3.0.indd 2 19/08/2013 09:47

3
THE SYMBOLS AND THEIR MEANINGS SHOWN BELOW MAY BE USED THROUGHOUT THIS MANUAL.
PLEASE ENSURE THAT YOU TAKE THE APPROPRIATE ACTION WHEREVER THE WARNINGS ARE USED.
1. Explanation of Symbols
i
Kg
i
Kg
i
Kg
i
Kg
i
Kg
i
Kg
i
Kg
i
Kg
Mandatory
Instructions
Warning
Read and fully understand the instruction manual
before attempting to use the machine.
Indicates an instruction that requires particular attention
Wear protective eyewear
Use respiratory protective equipment
Use suitable protective footwear
Use hearing protection
Use protective work gloves
Indicates a risk of severe personal injury or
damage to the machine
Indicates a risk of severe personal injury
from electrical shock
Risk of personal injury from lifting of heavy items
Indicates a risk of severe personal injury from
airborne objects
Risk of fire
i
Kg
i
Kg
i
Kg
i
Kg
CX2000 Manual 3.0.indd 3 19/08/2013 09:47

4
2. General Health & Safety Guidance
Ensure that you carefully read and fully understand the
instructions in this manual before assembly, installation and
use of this product. Keep these instructions in a safe place for
future reference.
WARNING: for your own safety, do not attempt to operate this machine
until it is completely assembled and installed according to
these instructions.
WARNING: When using any machine, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and
personal injury.
Safe Operation
1. Use Personal Protective Equipment (PPE)
• The operation of any machine can result in foreign objects being thrown
into your eyes, which can result in severe eye damage. Protective
eyewear or other suitable eye protection or face shield should be used at
all times. Everyday spectacles only have impact resistant lenses. They are
not protective eyewear and do not give additional lateral protection.
• Use respiratory protective equipment (dust mask etc.) if the machining
operation creates dust. Exposure to high levels of dust created by
machining hardwoods, softwoods and man made composite boards can
result in serious health problems. Some imported hardwoods give off
highly irritating dust, which can cause a burning sensation. The use of
respiratory protective equipment should not be seen as an alternative to
controlling the risk of exposure at source by using adequate dust
extraction equipment.
• The use of ear plugs or ear defenders is recommended when the machine
is in use, particularly if the noise level exceeds 85 dB.
• Wear suitable protective gloves when handling cutting tools or blades.
Gloves should NOT be worn when using the machine as they can be
caught in moving parts of the machine.
• Non-slip safety footwear is recommended when using the machine and
handling large work pieces.
2. Dress appropriately
• Do not wear loose clothing, neckties or jewellery; they can be caught in
moving parts of the machine.
• Roll up long sleeves above the elbow.
• Wear protective hair covering to contain long hair.
3. Safety warnings
• Find and read any warning labels on the machine.
• It is important that any labels bearing health and safety warnings are
not removed, defaced or covered. Replacement labels can be obtained by
contacting our Customer Service Department.
4. Familiarise yourself with the machine
• If you are not thoroughly familiar with the operation of this machine,
obtain advice from your supervisor, instructor, or other qualified person or
contact your retailer for information on training courses. Do not use this
machine until adequate training has been undertaken.
5. Take care when moving or positioning the machine
• Some machines can be very heavy. Ensure the floor of the area in which
the machine is to be used is capable of supporting the machine.
• The machine and its various components can be heavy.
Always adopt a safe lifting technique and seek assistance when lifting
heavy components. In some cases it may be necessary to use mechanical
handling equipment to position the machine within the work area.
• Some machines have optional wheel kits available to allow them to be
manoeuvred around the workshop as required. Care should be taken to
install these according to the instructions provided.
• Due to the nature of the design of some machines the centre of gravity
will be high making them unstable when moved. Extreme care should be
taken when moving any machine.
6. The machine should be level and stable at all times
• When using a leg stand or cabinet base that is designed to be fitted to
the machine, always ensure that it is securely fastened to the machine
using the fixings provided.
• If the machine is suitable to be used on a workbench, ensure that the
workbench is well constructed and capable of withstanding the weight
of the machine. The machine should always be securely fastened to the
workbench with appropriate fixings.
• Where possible, floor standing machines should always be secured to the
floor with fixings appropriate to the structure of the floor.
• The floor surface should be sound and level. All of the feet of the
machine should make contact with the floor surface. If they do not, either
re-locate the machine to a more suitable position or use packing shims
between the feet and the floor surface to ensure the machine is stable.
7. Remove adjusting keys and wrenches
• Ensure that all adjusting wrenches and keys are removed before
switching the machine ‘ON’. There is a risk of severe personal injury or
damage to the machine from airborne objects.
8. Before switching the machine ‘ON’
• Clear the machine table of all objects (tools, scrap pieces etc.)
• Make sure there is no debris between the work piece and the
table / work support.
• Ensure that the work piece is not pressed against, or touching the saw
blade or cutting tool.
• Check all clamps, work holding devices and fences to ensure that they
are secure and cannot move during machining operations.
• Plan the way that you will hold and feed the work piece for the entire
machining operation.
9. Whilst machining
• Before starting work, watch the machine while it runs. If it makes
an unfamiliar noise or vibrates excessively, switch the machine ‘OFF’
immediately and disconnect it from the power supply. Do not restart until
finding and correcting the source of the problem.
10. Keep the work area clear
• Working clearances can be thought of as the distances between
machines and obstacles that allow safe operation of every machine
without limitation. Consider existing and anticipated machine needs,
size of material to be processed through each machine and space for
auxiliary stands and/or work tables. Also consider the relative position of
each machine to one another for efficient material handling. Be sure to
allow yourself sufficient room to safely operate your machines in any
foreseeable operation.
• Cluttered work areas and benches create the risk of accidents. Keep
benches clear and tidy away tools that are not in use.
• Ensure that the floor area is kept clean and clear of any dust and debris
that may create trip or slip hazards.
11. Consider the work area environment
• Do not expose the machine to rain or damp conditions.
• Keep the work area well lit and ensure that there is artificial lighting
available when there is insufficient natural light to effectively light the
work area. Lighting should be bright enough to eliminate shadow and
prevent eye strain.
• Do not use the machine in explosive environments eg. in the presence of
flammable liquids, gases or dust.
• The presence of high levels of dust created by machining wood can
present a risk of fire or explosion. Always use dust extraction equipment
to minimise the risk.
12. Keep other persons away (and pets)
• The machine is designed to be used by one person only.
• Do not let persons, especially children, touch the machine or extension
cable (if used) and keep visitors away from the work area.
• Never leave the machine running unattended. Turn the power supply off
and do not leave the machine unattended until it comes to a
complete stop.
• If the work area is to be left unattended, all machinery should be
switched ‘OFF’ and isolated from the mains power supply.
13. Store machines safely when not in use
• When not in use, machines should be stored in a dry place, out of reach
CX2000 Manual 3.0.indd 4 19/08/2013 09:47

5
2. General Health & Safety Guidance - cont.
of children. Do not allow persons unfamiliar with these instructions or
with the machine to operate it.
14. Do not overreach
• Choose a working position that allows your body to remain balanced
and feed the work piece in to the machine without overreaching.
• Keep proper footing and balance at all times.
15. Electrical supply
• Electrical circuits should be dedicated to each machine or large enough
to handle combined motor amp loads. Power outlets should be located
near each machine so that power or extension cables are not obstructing
high-traffic areas. Observe local electrical guidelines for proper
installation of new lighting, power outlets, or circuits.
• The machine must be connected to an earthed power supply.
• The power supply must be equipped with a circuit breaker that provides
short circuit, overload and earth leakage protection.
• The voltage of the machine must correspond to the voltage of the mains
power supply.
• The mains plug fitted to the machine should always match the power
outlet. Do not modify the plug in any way. If a replacement plug is
required it should be fitted by a competent person and of the correct
type and rating for the machine.
• If you are unsure about any electrical connections always consult a
qualified electrician.
16. Avoid unintentional starting of the machine
• Most machines are fitted with a no-volt release (NVR) switch to prevent
unintentional starting. If in doubt always ensure the machine switch
is in the ‘OFF’ position before connecting it to the power supply. This
means the machine will not automatically start up after a power cut or
switching on of the power supply, unless you first reset the start switch.
17. Outdoor use
• Your machine should not be used outdoors.
18. Extension cables
• Whenever possible, the use of extension cables is not recommended.
If the use of an extension cable is unavoidable, then it should have
a minimum core cross section of 2.5 mm² and limited to a maximum
length of 3 metres.
• Extension cables should be routed away from the direct working area to
prevent a trip hazard.
19. Guard against electric shock
• Avoid body contact with earthed or grounded surfaces such as pipes
and radiators. There is an increased risk of electric shock if your body is
earthed or grounded.
20. Always work within the machine’s intended capacities
• Operator safety and machine performance are seriously adversely
affected if attempts to make the machine perform beyond its limits
are made.
21. Do not abuse the power cable
• Never pull the power cable to disconnect it from the power socket.
Always use the plug.
• Keep the power cable away from heat, oil and sharp edges.
• Do not use the power cable for carrying or moving the machine.
22. Secure the work piece
• Ensure that the work piece is securely held before starting to machine it.
• When working within 300 mm of the machining area, always use a push
stick to feed the work piece in to the blade or cutting tool. The push stick
should have a minimum length of 400 mm. If the push stick becomes
damaged, replace it immediately.
• Use extra supports (roller support stands etc.) for any work pieces large
enough to tip when not held down to the table top.
• Do not use another person as a substitute for a table extension, or as
additional support for a work piece that is longer or wider than the basic
table, or to help feed, support, or pull the work piece.
• Do not attempt to machine more than one work piece at a time.
• When feeding the work piece towards the blade or cutting tool never
position your hands in direct line of the cutting path. Avoid awkward
operations and hand positions where a sudden slip could cause your
hand or fingers to move into the machining area.
23. Stay alert
• Safety is a combination of operator common sense and alertness at all
times when the machine is being used.
• Use all machines with extreme care and do not use the machine when
you are tired or under the influence of drugs, alcohol or medication.
24. Use the correct tool for the job
• Do not use the machine for any purpose other than which it
was designed.
• When selecting replacement cutting tools and blades, always ensure that
they are designed to cut the material that you intend to use them for. If
in any doubt seek further advice from the manufacturer.
25. Connect dust extraction equipment
• Always use dust extraction equipment. The dust extractor should be of
suitable size and capacity for the machine that it is connected to and
have a filtration level appropriate to the type of waste being collected.
Refer to the relevant section of the manual for details of the specific dust
extraction requirements for this machine.
• The dust extractor should be switched ‘ON’ before starting the machine
that it is connected to. The dust extractor should be left running for 30
seconds after the last machining operation is complete in order to clear
any residual waste from the machine.
26. Ensure that the machine is correctly guarded
• Never use the machine if any of the standard safety guards and
equipment are removed or damaged.
• Some machines incorporate safety interlocks to prevent the machine
from being used without the guards in place. Never attempt to bypass
or modify the interlocks to allow the machine to be used without the
guards in place.
27. Maintain your machine with care
• This manual gives clear instructions on installation, set up and
operation of the machine and also details any routine and preventative
maintenance that should be performed periodically by the user.
• Remember always to switch off and unplug the machine from the power
supply before carrying out any setting up or maintenance operations.
• Follow any instructions for the maintenance of accessories
and consumables.
• Do not use compressed air to clean the machine. Always use a brush to
dislodge dust in places that are awkward to reach and a dust extractor
to collect the waste.
• Inspect electric cables periodically and, if damaged, have them replaced
by an authorised service facility or qualified electrician.
• Inspect extension cables (if used) periodically and replace if damaged.
28. Keep cutting tools sharp and clean
• Correctly maintained cutting tools are easier to control and less likely
to bind.
• Cutting tools and blades can become hot during use. Take extreme care
when handling them and always allow them to cool before changing,
adjusting or sharpening them.
29. Disconnect the machine from the power supply
• When not in use, before servicing, changing blades etc. always
disconnect the machine from the power supply.
30. Check for damaged parts
• Before each use of the machine, it should be carefully checked to
determine that it will operate properly and perform its
intended function.
• Check for alignment of moving parts, binding of moving parts, breakage
of parts and any other conditions that may affect the operation of
the machine.
CX2000 Manual 3.0.indd 5 19/08/2013 09:47

6
2. General Health & Safety Guidance - cont.
• A guard or other part that is damaged should be properly repaired
or replaced by a qualified person unless otherwise indicated in this
instruction manual.
• Do not use the machine if the switch does not turn the machine ‘ON’
and ‘OFF’.
• Have defective switches replaced by a qualified person.
31. Warning!
• The use of any accessory or attachment, other than those recommended
in this instruction manual, or recommended by our Company may present
a risk of personal injury or damage to the machine and invalidation of
the warranty.
32. Have your machine repaired by a qualified person
• This machine complies with the relevant safety rules and standards
appropriate to its type when used in accordance with these instructions
and with all of the standard safety guards and equipment in place. Only
qualified persons using original spare parts should carry out repairs.
Failure to do this may result in considerable danger to the user and
invalidation of warranty.
33. Caution! Motor may become hot during use
• It is normal for motors on some machines to become hot to the touch
during use. Avoid touching the motor directly when in use.
1. Safe Operation
• The chip extractor should be level and stable at all times
• Never attempt use the machine unless it is attached to the floor stand.
• Ensure that there is no debris between the base of the extractor and the
floor.
• Never place the dust extractor on a raised surface or workbench.
• In all cases, position the dust extractor as close as possible to the
application it is to be used for.
• Never over stretch the hose to make it reach.
2. Familiarise yourself with the machine
• If you are not thoroughly familiar with chip extractors, be aware of the
inherent risks due to the way in which these machines work. There are
moving parts inside the machine that can cause serious injury. Always
strictly follow any safety instructions detailed in the manual when using,
emptying or servicing the machine.
3. Before switching the machine ‘ON’:
• Ensure that the switch of the machine is in the ‘OFF’ position before
connecting or disconnecting the power supply.
• Ensure that the extraction hose is securely fitted to the outlet of the dust
extractor.
• Always ensure that the filter bag (or optional filter cartridge) and the
collection bag are securely and correctly positioned and not damaged.
Replace any damaged bags or filters immediately. Always ensure a good
seal between the filter and body of the machine.
4. Whilst using the chip extractor:
• Do not completely cover the end of the extraction hose as the machine
will not function correctly.
• Do not reduce the diameter of the extraction hose as this will affect the
performance of the machine.
• Do not attempt to remove the filter or collection bag whilst the machine
is running.
• Do not attempt to use the chip extractor without the extraction hose
fitted to the inlet on the body of the machine.
• This product is for dry use only and should not be used or stored outdoors
or in wet conditions.
• All Record Power chip extractors are designed solely for use with
wood dust and chippings. Do not use the machine to remove vapours,
fumes, gases or other materials such as plaster dust, as there is a risk
of combustion. Doing so will invalidate the warranty and may result in
damage to the machine or serious injury to the user.
• Do not use the machine to pick up hazardous dust.
• Do not pick up liquids and scrap metal (such as nails and filings) or any
combustible substance.
• If the hose becomes blocked, switch the machine ‘OFF’ immediately to
prevent any damage to the machine and disconnect from the power
supply before removing the blockage. Note that the impeller fan will
continue to rotate for several seconds after the machine has been
switched ‘OFF’.
• Never attempt to place your hand inside the hose or inlet of the dust
extractor whilst it is running.
• Ensure that the machine is used in a well ventilated area.
5. Avoiding fires:
• Wood dust is combustible and when suspended in the air, it may form a
cloud which can explode if the air concentration is higher than 40g/m_.
• Sparks can smolder in dust for a long time before fire or flame is
detected. If metal contacts metal during operation, immediately switch
the machine ‘OFF’, disconnect the power cable from the mains supply and
wait for the motor to come to a complete stop. Empty the dust into an
approved air tight metal container in case of spark. Remedy the metal to
metal contact problem before resuming operation.
• Do not operate the dust extractor in environments containing explosive
risks, such as pilot lights, open flames, vapours, gases or high levels of
airborne dust.
6. Maintenance:
• Always switch the machine ‘OFF’, disconnect from the power supply and
wait until the motor has completely stopped before carrying out any
routine maintenance such as emptying waste or replacing filters.
• When carrying out any routine maintenance, keep your hands away from
the fan blade within the body of the machine.
7. The elimination or control of risks from wood dust is required by the
‘Health & Safety at Work etc. Act 1974’, the ‘Provision & Use of Work
Equipment Regulations 1998’ and the ‘Control of Substances Hazardous
to Health (COSHH) Regulations 2002’. We recommend that you study and
follow these regulations.
Further guidance can be obtained from The Health & Safety Executive and
their website www.hse.gov.uk.
3. Additional Health & Safety Guidance for Chip Extractors
CX2000 Manual 3.0.indd 6 19/08/2013 09:47

7
4. Record Power Guarantee
“Products” means the Products sold by Record Power subject to these
terms and conditions;
“Record Power” is Record Power Limited, whose company registration
number is 4804158 and registered office address is Centenary House,
11 Midland Way, Barlborough Links, Chesterfield, Derbyshire, S43 4XA
and sells through a network of Authorised Dealers;
“Authorised Distributor” is the nominated importer for your region
who will generally sell through a network of Authorised Dealers. Details of
Authorised Distributors for specific countries can be found in the Product
manual or at www.recordpower.info;
“Authorised Dealer” is a retailer or business authorised to sell Record
Power Products to end users.
1 Guarantee
1.1 Record Power guarantees that for a period of 5 years from the date
of purchase the components of qualifying Products (see clauses 1.2.1
to 1.2.9) will be free from defects caused by faulty construction
or manufacture.
1.2 During this period Record Power, its Authorised Distributor or
Authorised Dealer will repair or replace free of charge any parts
which are proved to be faulty in accordance with paragraphs 1.1
above provided that:
1.2.1 you follow the claims procedure set out in clause 2 below;
1.2.2 Record Power, our Authorised Distributor or Authorised Dealer are
given a reasonable opportunity after receiving notice of the claim to
examine the Product;
1.2.3 if asked to do so by Record Power, its Authorised Distributor or
Authorised Dealer, you return the Product, at your own cost, to
Record Power's premises or other approved premises such as those
of the Authorised Distributor or supplying Authorised Dealer, for the
examination to take place;
1.2.4 the fault in question is not caused by industrial use, accidental
damage, fair wear and tear, wilful damage, neglect, incorrect
electrical connection, abnormal working conditions, failure to follow
our instructions, misuse, or alteration or repair of the Product without
our approval;
1.2.5 the Product has been used in a domestic environment only;
1.2.6 the fault does not relate to consumable Products such as blades,
bearings, drive belts or other wearing parts which can reasonably
be expected to wear at different rates depending on usage (for full
details contact Record Power or your local Authorised Distributor);
1.2.7 the Product has not been used for hire purposes, by you or by a
previous owner;
1.2.8 the Product has been purchased by you as the guarantee is not
transferable from a private sale.
1.2.9 where the Product has been purchased from a retailer, the 5 year
guarantee is transferable and begins on the date of the first purchase
of the Product and in the event of a claim under this guarantee
proof of the original purchase date will be required to validate the
warranty period.
2 Claims Procedure
2.1 In the first instance please contact the Authorised Dealer who
supplied the Product to you. In our experience many initial problems
with machines that are thought to be due to faulty parts are actually
solved by correct setting up or adjustment of the machines. A good
Authorised Dealer should be able to resolve the majority of these
issues much more quickly than processing a claim under
the guarantee.
2.2 Any damage to the Product resulting in a potential claim under the
guarantee must be reported to the Authorised Dealer from which it
was purchased within 48 hours of receipt.
2.3 If the Authorised Dealer who supplied the Product to you has been
unable to satisfy your query, any claim made under this Guarantee
should be made directly to Record Power or its Authorised Distributor
(for details of the Authorised Distributor in your country please see
your Product manual or check www.recordpower.info for details).
The claim itself should be made in a letter setting out the date and
place of purchase, and giving a brief explanation of the problem
which has led to the claim. This letter should then be sent with
proof of the purchase date (preferably a receipt) to Record Power or
its Authorised Distributor. If you include a phone number or email
address this will help to speed up your claim.
2.4 Please note that it is essential that the letter of claim reaches Record
Power or its Authorised Distributor on the last day of this Guarantee
at the latest. Late claims will not be considered.
3 Limitation of Liability
3.1 We only supply Products for domestic and private use. You agree not
to use the Product for any commercial, business or re-sale purposes
and we have no liability to you for any loss of profit, loss of business,
business interruption or loss of business opportunity.
3.2 This Guarantee does not confer any rights other than those expressly
set out above and does not cover any claims for consequential loss
or damage. This Guarantee is offered as an extra benefit and does
not affect your statutory rights as a consumer.
4 Notice
This Guarantee applies to all Products purchased from an Authorised
Dealer of Record Power within the United Kingdom of Great
Britain and Northern Ireland. Terms of Guarantee may vary in other
countries – please check with the Authorised Distributor in your
country (details of the Authorised Distributor for your country can be
found in the manual or at www.recordpower.info).
CX2000 Manual 3.0.indd 7 19/08/2013 09:47

8
6. Machine Specification
5. Getting to Know your Chip Collector
Capacity: 54 litres
Size: H1520 x W370 x D670 mm
Motor: 230 V / 50 Hz / 550 W / 3/4 hp
Full load current: 2.4 A
Weight: 15 kg
Filtration: 30 micron
Air flow: 500 CFM
A Filter bag
B Collection bag
C Inspection window
D Motor
E On / off switch
F Bag support arm
G Wheels
H Handle
A
B
C
D
E
F
G
H
CX2000 Manual 3.0.indd 8 19/08/2013 09:47

9
7. Contents of the Package
On unpacking please check that all contents shown below are present.
A Motor and Housing
B Frame Base
C Extraction hose
D Left Frame
E Right Frame
F Bag support arm
H Filter bag
I Collection Bag
J Washer
K Butterfly Nut
M Spring Washer
N Flat Washer
O Support Plate
P Knob 4pcs
Q Socket head cap screw 4pcs
R Flat washer 4pcs
S Nylon locking nut 4pcs
T hose pipe clip
A
B
D
C
E
F
H
I
J
K
M
N
O P
Q
R
S
T
CX2000 Manual 3.0.indd 9 19/08/2013 09:47

10
8. Assembly
Fig.8.1
1. Fully unscrew the tube joint covers on the left
side of the frame base, leaving them in place on
the tube joint base.
2. Place the left frame (D) through the tube joints
into the base (B), ensuring the longest section is
towards the front of the base, Fig 8.1.
Fig.8.2
Fig.8.3
3. Repeat as above to fit the right frame (E) to
the base (B), Fig 8.2.
4. Position the support plate (O) as fig 5 and
lock in place with socket head cap screws (Q),
washers (R) and nylon locking nuts (S). Ensure
the frame is assembled correctly, then tighten.
Fig 8.3.
D
B
E
O
QRS
CX2000 Manual 3.0.indd 10 19/08/2013 09:47

11
8. Assembly - cont.
Fig.8.4
Fig.8.5
5. Position the motor and housing (A) on top of
the frame with the four threaded studs passing
through the corresponding holes on top of the
frame. Secure in position using the knobs (P) and
washers (J). See fIg 8.4.
6. Thread the butterfly nut (K) onto the bag
support arm. Place the spring washer (M) and
washer (N) on the bag support arm and screw
the bag support arm to the motor and housing,
Fig 8.5. Lock the arm in position using the
butterfly nut.
A
J
P
K
M
N
CX2000 Manual 3.0.indd 11 19/08/2013 09:48

12
8. Assembly - cont.
7. Take the filter bag and insert it through the
hole in the motor and housing, ensuring the
closed end is uppermost. The supporting collar
which is sewn into the open end of the filter
bag should fit snugly inside the upper rim of
the motor and housing, holding the filter bag in
place, see Fig 8.6. Now attach the loop on the
closed end of the filter bag through the loop on
the bag support arm.
8. Fit the collection bag into the motor and
housing, ensuring the supporting collar is fitted
into the lower rim and the inspection window
faces outwards to give good visibility.
9. Finally, attach the 100 mm diameter extraction
hose to the inlet on the underside of the motor
and housing (directly beneath the motor) using
the hose clip.
Fig.8.6
H
I
CX2000 Manual 3.0.indd 12 19/08/2013 09:48

13
9. Operation
PLEASE NOTE: This chip collector is intended for use with
woodworking machinery only to collect wood chippings and
dust. If used to collect other kinds of waste, the warranty will
not be valid.
PLEASE NOTE: The use of reducers to limit the diameter of the
collection hose will severely reduce the suction of this type of
machine.
Ensure the extraction hose is securely connected to the chip extractor and to
the machine from which waste is to be collected.
Always leave the chip extractor running for a short while after use of the
machinery. This will ensure all waste is extracted from the machinery and the
extraction hose.
Empty the contents of the collection bag when it is within 100 mm (4') one
the top of the bag.
i
Kg
i
Kg
CX2000 Manual 3.0.indd 13 19/08/2013 09:48

14
i
Kg
10. Maintenance
WARNING: Unplug the machine from the power source before
carrying out any maintenance.
To ensure maximum efficiency, regularly clean the filter bag by shaking it to
remove any dust which has collected on its surface.
Large chippings and shavings can block the inlet. With the machine turned
off and unplugged from the power source, regularly check the inlet for
blockages and remove. Never place hands into the inlet.
11. Trouble Shooting
WARNING: Unplug the machine from the power source before carrying out any maintenance.
Symptom Possible Causes Solutions
Machine will not start. 1. No power supply.
2. Defective switch.
3. Faulty fuse.
1. Check the power cable and fuse.
2.Replace the switch.
3. Replace the fuse.
Machine loses suction. 1. Blocked hose.
2. Blocked inlet.
3. Hose diameter reducer being used.
1. Remove the hose from the machine and unblock.
2. Remove the collection bag and carefully unblock the inlet
using a suitable tool.
3. Remove the reducer.
i
Kg
CX2000 Manual 3.0.indd 14 19/08/2013 09:48

15
12. Electrical Connection & Wiring Diagram
Machines supplied for use in the UK are fitted with a 3 pin plug conforming
to BS1363, fitted with a fuse conforming to BS1362 and appropriate to the
current rating of the machine.
Machines supplied for use in other countries within the European Union are
fitted with a 2 pin Schuko plug conforming to CEE 7/7.
Machines supplied for use in Australia & New Zealand are fitted with a 3 pin
plug conforming to AS/NZS3112.
In all cases, if the original plug or connector has to be replaced for any
reason, the wires within the mains power cable are colour coded as follows:
230 V (Single Phase)
Brown: Live (L)
Blue: Neutral (N)
Green and Yellow: Earth (E)
The wire coloured brown must always be connected to the terminal marked
‘L’ or coloured red.
The wire coloured blue must always be connected to the terminal marked ‘N’
or coloured black.
The wire coloured green and yellow must always be connected to the
terminal marked ‘E’ or with the earth symbol:
or coloured green / green and yellow.
It is important that the machine is effectively earthed. Some machines will be
clearly marked with the double insulated logo:
In this case there will not be an earth wire within the circuit.
In the case of the BS1363 plug for use in the UK, always ensure that it is
fitted with a fuse conforming to BS1362 appropriate to the rating of the
machine. If replacing the original fuse, always fit a fuse of equivalent rating
to the original. Never fit a fuse of a higher rating than the original. Never
modify the fuse or fuse holder to accept fuses of a different type or size.
Where the current rating of the machine exceeds 13 A at 230 V, or if the
machine is designated for use on a 400 V 3 phase supply a connector
conforming to BS4343 (CEE17 / IEC60309) will be used.
230 V machines will be fitted with a blue 3 pin connector. The wiring for this
type of this connector will be the same as shown above.
400 V, 3 phase machines will be fitted with a red 4 or 5 pin connector. The
wiring for this type of connector is as shown below:
400 V (3 phase)
Brown: Live (L1)
Black: Live (L2)
Grey: Live (L 3)
Blue: Neutral (N)
Green and Yellow: Earth (E)
The wire coloured brown must always be connected to the terminal
marked ‘L1’.
The wire coloured black must always be fitted to the terminal
marked ‘L2’.
The wire coloured grey must always be connected to the terminal
marked ‘L3’.
The wire coloured blue must always be connected to the terminal
marked ‘N’ or coloured black.
The wire coloured green and yellow must always be connected to the
terminal marked ‘E’ or with the earth symbol
If in doubt about the connection of the electrical supply, always consult a
qualified electrician.
CX2000 Manual 3.0.indd 15 19/08/2013 09:48

16
13. Parts Diagrams
CX2000 Manual 3.0.indd 16 19/08/2013 09:48

17
14. Parts List
Ref No. Description Ref No. Description
1 Switch Box Cover
2 Tapping Screw
3 Wire nut
4 Power Switch
5 Washer
6 Spring Washer
7 Pan Head Screw
8 Strain Relief
9 Power Cord
10 Switch Box
11 tooth washer
12 Motor
13 Bag Support Arm
14 Washer
15 Spring Washer
16 Butterfly Nut
17 Filter Bag
18 Motor and Housing
19 Impeller
20 Capacitor
21 Washer
22 Bolt-L
23 100mm Hose clip
24 100mm Hose
25 Pan Head Screw
26 Lower Housing
27 Collection Bag
29 Right Frame
30 Washer
31 Knob
32 Left Frame
33 Socket Head Cap Screws
34 Washer
35 Nylock Nut
36 Support Plate
37 Tube Joint Cover
38 Tube Joint Base
39 Spring Pin
40 Washer
41 Wheel
42 Pin
43 Frame Base
44 L Joint Tube Base
43 L Joint Tube Cover
46 Tube Pad
CX2000 Manual 3.0.indd 17 19/08/2013 09:48

18
EU Declaration of Conformity
Cert No: EU / CX2000 / 1
RECORD POWER LIMITED,
Centenary House, 11 Midland Way,
Barlborough Links, Chesterfield,
Derbyshire, S43 4XA
declares that the machinery described:-
1. Type: Dust Collector
2. Model No: CX2000
3. Serial No .........................................................................
Conforms with the following directives:-
MACHINERY DIRECTIVE 2006/42/EC
(repealing / replacing Directives
LOW VOLTAGE DIRECTIVE 2006/95/EC
and its subsequent amendment
ELECTROMAGNETIC 2004/108/EC
COMPATIBILITY DIRECTIVE
and its subsequent amendments
and complies with the relevant essential health and safety requirements.
Signed................................................Dated: 01/08/2013
Andrew Greensted
Managing Director
CX2000 Manual 3.0.indd 18 19/08/2013 09:48

19
CX2000 Manual 3.0.indd 19 19/08/2013 09:48

Woodworking Machinery & Accessories
United Kingdom
Record Power Ltd
Centenary House, 11 Midland Way,
Barlborough Links, Chesterfield,
Derbyshire, S43 4XA
Tel: [phone]
www.recordpower.co.uk
Eire
Record Power Ltd
Centenary House, 11 Midland Way,
Barlborough Links, Chesterfield,
Derbyshire, S43 4XA
Tel: [phone]
www.recordpower.co.uk
Australia
Tools 4 Industry
Po Box 3844
Parramatta 2124
Tel: [phone]
Fax: [phone]
www.recordpower.com.au
New Zealand
Tools 4 Industry
Po Box 276079
Manukau City 2241
Tel: [phone]
Fax: [phone]
www.recordpower.co.nz
Made in China
CX2000 Manual 3.0.indd 20 19/08/2013 09:48
