red lion PAX2D User manual

PAX2D
1/8 DIN Digital Input Panel Meter
Installation Guide
See the Red Lion website or the enclosed USB thumbdrive
for a complete user manual
SPECIFICATIONS
POWER:
AC Power: 40 to 250 VAC, 50/60 Hz, 20 VA
DC Power: 21.6 to 250 VDC, 8 W
Isolation: 2300 Vrms for 1 min. to all inputs and outputs.
INPUTS A and B:
DIP switch selectable to accept pulses from a variety of sources including
switch contacts, TTL outputs, magnetic pickups and all standard RLC
sensors.
LOGIC: Input trigger levels VIL = 1.5 V max.; VIH = 3.75 V min.
Current sinking: Internal 7.8 KΩpull-up to +5 VDC, IMAX = 0.7 mA.
Current sourcing: Internal 3.9 KΩpull-down, 7.3 mA max. @ 28 VDC,
VMAX = 30 VDC.
Filter: Damping capacitor provided for switch contact bounce. Limits
input frequency to 50 Hz and input pulse widths to 10 msec. minimum.
MAGNETIC PICKUP:
Sensitivity: 200 mV peak
Hysteresis: 100 mV
Input impedance: 3.9 KΩ@ 60 Hz; Must also have SRC switch ON. (Not
recommended with counting applications.)
Maximum input voltage: ±40 V peak, 28 Vrms
DUAL COUNT MODES:
When any dual count mode is used, then User Inputs 1 and/or 2 will accept
the second signal of each signal pair. The user inputs do not have the
Logic/Mag, HI/LO Freq, and Sink/Source input setup switches. The user
inputs are inherently a logic input with no low frequency filtering. Any
mechanical contacts used for these inputs in a dual count mode must be
debounced externally. The user input may only be selected for sink/source
by the User Jumper placement.
SENSOR POWER:
+18 VDC, ± 5% @ 60 mA max.; short circuit protected
USER INPUTS: Three programmable user inputs
Max. Continuous Input: 30 VDC
Isolation To Sensor Input Common: Not isolated.
PRESCALER OUTPUT:
NPN Open Collector: ISNK = 100 mA max. @ VOL = 1 VDC max. VOH = 30
VDC max. Duty cycle 25% min. and 50 % max.
ENVIRONMENTAL CONDITIONS:
Operating Temperature Range: 0 to 50 °C
Storage Temperature Range: -40 to 60 °C
Vibration to IEC 68-2-6: Operational 5-150 Hz, 2 g
Shock to IEC 68-2-27: Operational 25 g (10 g relay)
Operating and Storage Humidity: 0 to 85% max. RH non-condensing
Altitude: Up to 2000 meters
CERTIFICATIONS AND COMPLIANCES:
CE Approved
EN 61326-1 Immunity to Industrial Locations
Emission CISPR 11 Class A
IEC/EN 61010-1
RoHS Compliant
UL Listed: File #E179259
Type 4X Indoor Enclosure rating (Face only)
IP65 Enclosure rating (Face only)
IP20 Enclosure rating (Rear of unit)
CONNECTIONS: High compression cage-clamp terminal block
Wire Strip Length: 0.3" (7.5 mm)
Wire Gauge Capacity: One 14 AWG (2.55 mm) solid,
two 18 AWG (1.02 mm) or four 20 AWG (0.61 mm)
CONSTRUCTION: This unit is rated NEMA 4X/IP65 for indoor use only.
IP20 Touch safe. Installation Category II, Pollution Degree 2. One piece
bezel/ case. Flame resistant. Synthetic rubber keypad. Panel gasket and
mounting clip included.
WEIGHT: 8 oz. (226.8 g)
Drawing No. LP0901A
Effective 04/13
CUS LISTED
UL
R
3RSD
PROCESS CONTROL EQUIPMENT
3.80 (96.52)
(49.53)
(2.54)
(44.45)
3.60 (91.44)
4.14 (105)
1.95
0.10
1.75
1
32
4
DIMENSIONS In inches (mm) Note: Recommended minimum clearance (behind the panel) for mounting clip
installation is 2.1" (53.4) H x 5.5" (140) W.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

SAFETY SUMMARY
All safety related regulations, local codes and instructions that appear in this
literature or on equipment must be observed to ensure personal safety and to
prevent damage to either the instrument or equipment connected to it. If
equipment is used in a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired. Do not use this unit to directly
command motors, valves, or other actuators not equipped with safeguards. To do
so can be potentially harmful to persons or equipment in the event of a fault to
the unit.
METER INSTALLATION
The PAX2D meets NEMA 4X/IP65 requirements when properly installed.
The unit is intended to be mounted into an enclosed panel. Prepare the panel
cutout to the dimensions shown. Remove the panel latch from the unit. Slide the
panel gasket over the rear of the unit to the back of the bezel. The unit should
be installed fully assembled. Insert the unit into the panel cutout.
While holding the unit in place, push the panel latch over the rear of the unit
so that the tabs of the panel latch engage in the slots on the case. The panel latch
should be engaged in the farthest forward slot possible. To achieve a proper seal,
tighten the latch screws evenly until the unit is snug in the panel (Torque to
approximately 7 in-lbs [79N-cm]). Do not over-tighten the screws.
Installation Environment
The unit should be installed in a location that does not exceed the operating
temperature and provides good air circulation. Placing the unit near devices that
generate excessive heat should be avoided.
SETTING THE DIP SWITCHES
To access the switches, remove the meter base from the case by firmly
squeezing and pulling back on the side rear finger tabs. This should lower the
latch below the case slot (which is located just in front of the finger tabs). It is
recommended to release the latch on one side, then start the other side latch.
Warning: Exposed line voltage exists on the circuit boards. Remove all
power to the meter and load circuits before accessing inside of the
meter.
SETTING THE INPUT DIP SWITCHES
The meter has six DIP switches for Input A and Input B terminal set-up that must
be set before applying power.
SWITCHES 1 and 4
LOGIC: Input trigger levels VIL = 1.5 V max.; VIH = 3.75 V min.
MAG: 200 mV peak input sensitivity; 100 mV hysteresis; maximum voltage:
± 40 V peak (28 Vrms); Input impedance: 3.9 KΩ @ 60 Hz; Must also have SRC
switch ON. (Not recommended with counting applications.)
SWITCHES 2 and 5
SNK.: Adds internal 7.8 KΩpull-up resistor to +5 VDC, IMAX = 0.7 mA.
SRC.: Adds internal 3.9 KΩpull-down resistor, 7.3 mA max. @ 28 VDC, VMAX
= 30 VDC.
SWITCHES 3 and 6
HI Frequency: Removes damping capacitor and allows max. frequency.
LO Frequency: Adds a damping capacitor for switch contact bounce. Also
limits input frequency to maximum 50 Hz and input pulse widths to minimum
10 msec.
CAUTION: Risk of Danger.
Read complete instructions prior to
installation and operation of the unit.
CAUTION:
Risk of electric shock.
PANEL
LATCHING
SLOTS
BEZEL
PANEL
GASKET
PANEL
LATCH
LATCHING
TABS
PANEL
MOUNTING
SCREWS
-.00
(92 )
-.0
+.8
3.62 +.03
(45 )
1.77
-.0
+.5
-.00
+.02
PANEL CUT-OUT
Main
Circuit
Board
REAR TERMINALS
FRONT DISPLAY
INPUT SET-UP
DIP SWITCHES USER
INPUT
JUMPER
123456
SRC
SNK
Finger
TabFinger
Tab
USB
Connector
6
5
4
3
2
1
ON
Input B SRC.
Input B LO Freq.
Input B MAG.
Input A LO Freq.
Input A SRC.
Input A MAG.
SNK.
HI Freq.
Logic
HI Freq.
SNK.
Logic
Factory Setting
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

POWER WIRING
The power supplied to the meter shall employ a 15 Amp UL
approved circuit breaker for AC input and a 1 Amp, 250 V UL
approved fuse for DC input. It shall be easily accessible and
marked as a disconnecting device to the installed unit. This device
is not directly intended for connection to the mains without a
reliable means to reduce transient over-voltages to 1500 V.
1
2
AC/DC
AC/DC
1
2
AC/DC
AC/DC
+
-
1
2
AC/DC
AC/DC
+
-OR
AC Power DC Power
INPUT SIGNAL WIRING
CAUTION: Sensor input common is NOT isolated from user input common. In order to preserve the safety of the meter application, the sensor input
common must be suitably isolated from hazardous live earth referenced voltage; or input common must be at protective earth ground potential. If not,
hazardous voltage may be present at the User Inputs and User Input Common terminals. Appropriate considerations must then be given to the potential
of the user input common with respect to earth ground; and the common of the isolated plug-in cards with respect to input common.
345
MAGNETIC PICKUP
6
+18VOUT COMM INPUT A INPUT B
3
1
2
ON
63 4 5
to 2.5 mA MAX.
Resistor to limit current AC
+18VOUT COMM INPUT A INPUT B
3
2
1
ON
43 5 6
2.2KΩ
COMM +18VOUT INPUT B INPUT A
2
1
3
ON
NPN O.C.
3 4 5 6
COMM +18VOUT INPUT A INPUT B
1
2
3
ON
PNP O.C.
3 4 5 6
+18VOUT COMM INPUT A INPUT B
2
1
3
ON ON
4
2
3
1
3 5 6
+5V
COMM
DIODE
+18VOUT COMM INPUT B INPUT A
3 4 5 6
INPUT A INPUT B COMM +18VOUT
2
1
3
ON
63 4 5
INPUT A INPUT B +18VOUT COMM
1
2
3
ON
3 4 5 6
INPUT A INPUT B +18VOUT COMM
2
1
3
ON
AC Inputs From Tach Generators, Etc.
Input A
Two Wire Proximity, Current Source
Input A
Magnetic Pickup
Input A
Current Sourcing Output
Input A
Interfacing With TTL
Input A
Current Sinking Output
Input A
Switch or Isolated Transistor; Current Sink
Input A
Switch or Isolated Transistor; Current Source
Input A
Emitter Follower; Current Source
Input A
63 4 5
NPN O.C.
+18VOUT COMM INPUT A INPUT B
4
1
2
3
6
5
ON
3 4 5 6
NPN O.C.
Count A
8 9
NPN O.C.
Count B
+18VOUT COMM INPUT A INPUT B
3
2
1
ON
4
5
6
USER 1 USER 2
Quad; Current Sink Output
Single
Counter A
Counter A &
Counter B
Dual Quad/Quad; Current Sink Output
If you are wiring Input B, connect signal to Terminal 6 instead of 5, and set DIP switches 4, 5, and 6 to the positions shown for 1, 2, and 3.
Shaded areas not recommended for counting applications.
63 4 5
NPN O.C.
NPN O.C.
8
Rate
Count
+18VOUT COMM USER 1 INPUT A INPUT B
4
1
2
3
6
5
ON
Dual Quad/Count; Current Sink Output
Counter A
& Rate B
If using single Counter B, then wire signal to 6,
and Quad/Direction to 9. Set switches as shown.
USER INPUT WIRING
If User Input 1 and/or 2 are wired for quadrature or directional counting, an additional switching device should not be
connected to that User Input terminal. User Input terminal does not need to be wired in order to remain in inactive state.
Sourcing Logic (USrACt HI)
When the USrACt parameter is programmed to HI,
the user inputs of the meter are internally pulled
down to 0 V with 20 KΩresistance. The input
is active when a voltage greater than 2.2 VDC
is applied.
USER INPUTS
USER 3 USER 2 USER 1 COMM.
7 8 9 10
Sinking Logic (USrACt LO)
When the USrACt parameter is programmed to
LO, the user inputs of the meter are internally
pulled up to +3.3 V with 20 KΩresistance. The
input is active when it is pulled low (<1.1 V).
+
(30V max.)
SUPPLY
V
USER 3 USER 2 USER 1 COMM.
87
-
109
USER INPUTS
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

LIMITED WARRANTY
The Company warrants the products it manufactures against defects in materials and workmanship for a
period limited to two years from the date of shipment, provided the products have been stored, handled,
installed, and used under proper conditions. The Company’s liability under this limited warranty shall
extend only to the repair or replacement of a defective product, at The Company’s option. The Company
disclaims all liability for any afrmation, promise or representation with respect to the products.
The customer agrees to hold Red Lion Controls harmless from, defend, and indemnify RLC against
damages, claims, and expenses arising out of subsequent sales of RLC products or products containing
components manufactured by RLC and based upon personal injuries, deaths, property damage, lost prots,
and other matters which Buyer, its employees, or sub-contractors are or may be to any extent liable,
including without limitation penalties imposed by the Consumer Product Safety Act (P.L. 92-573) and
liability imposed upon any person pursuant to the Magnuson-Moss Warranty Act (P.L. 93-637), as now in
effect or as amended hereafter.
No warranties expressed or implied are created with respect to The Company’s products except those
expressly contained herein. The Customer acknowledges the disclaimers and limitations contained herein
and relies on no other warranties or afrmations.
PS OUT COMM
711
-+
PRESCALER OUTPUT WIRING (NPN O.C.)
SETPOINT (ALARMS) WIRING
SERIAL COMMUNICATION WIRING
ANALOG OUTPUT WIRING



See appropriate plug-in card
bulletin for wiring details.
ORDERING INFORMATION
DESCRIPTION PART NUMBER
Digital Input Panel Meter PAX2D000
Dual Setpoint Relay Output Card PAXCDS10
Quad Setpoint Relay Output Card PAXCDS20
Quad Setpoint Sinking Open Collector Output Card PAXCDS30
Quad Setpoint Sourcing Open Collector Output Card PAXCDS40
RS485 Serial Communications Card with Terminal Block PAXCDC10
Extended RS485 Serial Communications Card with Dual RJ11 Connector PAXCDC1C
RS232 Serial Communications Card with Terminal Block PAXCDC20
Extended RS232 Serial Communications Card with 9 Pin D Connector PAXCDC2C
DeviceNet Communications Card PAXCDC30
Profibus-DP Communications Card PAXCDC50
Analog Output Card PAXCDL10
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]
