3
7. Use of an attachment not recommended or sold by REDARC may result in a risk of fire, electric shock, or injury
to persons.
8. Cable and fuse sizes are specified by various codes and standards which depend on the type of vehicle the
system is installed into. Selecting the wrong cable or fuse size could result in harm to the installer or user and/ or
damage to the TVMS or other equipment installed in the system. For this reason, do not replace fuses with ones
of higher amperage ratings. The installer is responsible for ensuring that the correct cable and fuse sizes are
used when installing this system.
9. Do not drop metal tools onto a vehicle battery. Doing so might cause the battery to spark or might short-circuit
the battery or other electrical parts that may cause an explosion.
10. Remove personal metal items such as rings, bracelets, necklaces, and watches before working with a vehicle
battery. A vehicle battery can produce a short-circuit current high enough to weld a ring or the like to metal,
causing a severe burn.
11. NEVER SMOKE OR ALLOW A SPARK OR FLAME NEAR A BATTERY AS THESE MAY CAUSE THE
BATTERY TO EXPLODE. TO REDUCE THE RISK OF A SPARK NEAR A BATTERY WHEN CONNECTING
THE BATTERY INSTALLED IN A VEHICLE TO THE TVMS, ALWAYS DO THE FOLLOWING:
Wire the Output Connector before connecting it to the Distribution Box. During connection of the unit, the
Battery Output (positive) must be connected first, followed by the Ground (chassis) terminal. The chassis
connection should be made away from the battery and fuel lines. Once all connections are wired to the Output
Connector, plug the connector into the Distribution Box.
12. Do not use this product to control safety critical devices or those that could cause harm if operated remotely
(for example fume exhaust fans or lifters). Only operate devices with moving parts when you have a clear line of
sight to the moving parts.
13. Ensure that the Display is not mounted in vehicle head-impact zones. Doing so may result in injury to the driver
and/or passenger in the event of an accident.
14. Ensure the Display is not mounted where it may distract the driver of the vehicle. Distracting the driver may
result in an accident.
15. Risk of damage to the system. Do NOT connect a load negative (−) to the chassis AND to the applicable
negative (−) output channel as this may cause damage to the Distribution Box under some circumstances.
Connect to the applicable negative (−) output channel OR a suitable chassis grounding point to avoid damage.
16. Risk of damage to the system. When using REDARC RS/RS2 Series inverters, do NOT connect to the 'TRC'
socket at the front (mains end) of the inverter as this will cause damage to the RedVision Distribution Box.
Connect to the 'REMOTE' socket to avoid damage.
NOTICE
1. Do NOT connect computers or IT equipment to the RJ45 ports on the RedVision Distribution Box or Display.
Damage may occur.
2. It is recommended to leave the Display connected at all times to the base unit.
3. The Distribution Box may be mounted in any orientation but must be mounted onto a flat, solid surface using 4 x
M6 screws or bolts. Failure to adequately mount the unit, such as using adhesives to mount the unit will result in
unreliable operation of the Distribution Box.
4. It is the installer's responsibility to ensure their installation complies with any applicable legal and regulatory
requirements. Within Australia, installers may wish to consult AS/NZS 3001 as one potentially relevant standard.
5. Ensure that the channel and master override dip-switches are turned off after use to prevent accidental
operation of the channel / flattening of either the Starter or Auxiliary battery.
6. The RedVision App and its interactions with RedVision has not been tested on all smartphones available on
the market so is not guaranteed to work on all devices. However, the app should work on most phones with
Bluetooth® 4.0 (or later) running IOS 11. 1 (or later) or Android 7.0 (or later).
7. Ensure all wiring is firmly secured to the vehicle and not suspended from the water level sensor inputs or other
connectors. Excessive loading on these pins may result in damage to the Distribution Box.
8. Specifications subject to change without notice.
