Redarc 50A MIDI Fuse Kit User manual

50A MIDI Fuse Kit
FK50

50A MIDI FUSE KIT
The FK50 is designed to provide for a simple, neat fuse installation
for dual battery systems. The FK50 is perfect for the TVMS Rogue
(TVMS1240) powering wiring loom installation and the Manager30
(BMS1230S3) DC input installation.
spare
12mm
16mm²
40mm
6mm
KIT CONTENTS
No. Part Quantity
150 A MIDI Fuse 2
2Fuse Holder 1
3Nut and Spring Washer to suit Fuse Holder 2
4Lug 2
5Heatshrink 2
*The Lugs provided are intended for a 16mm² cable. If using a smaller cable gauge, insert with
conductor foldback; if using larger cable gauge, source a larger lug.
1
2
4
3
5

LIMITED WARRANTY
For full warranty terms and conditions, visit the
Warranty page of the REDARC website. Refer to
the web address and contact details applicable to
your region.
Australia, New Zealand & Europe
www.redarc.com.au/warranty
REDARC Electronics Pty Ltd
23 Brodie Road (North),
Lonsdale SA 5160
Australia
Australia [phone]
New Zealand [phone]
UK & Europe [phone]
North America
www.redarcelectronics.com/warranty
REDARC Corporation
c/o Shallco, Inc.
308 Component Dr.
Smitheld, NC 27577
USA
USA [phone]
Canada [phone]
Mexico [phone]
Design and specications are subject to change without notice.
Copyright © 2022 REDARC Electronics Pty Ltd. All rights reserved.
REDARC® and THEPOWEROFREDARC® are trademarks of REDARC
Electronics Pty Ltd.

Start
Battery
DC Input
50 A Fuse
(and holder)
50 A Fuse
(and holder)
Extend cables as required
Auxiliary
Battery
Do not plug-in to Main Unit until
wiring of C,D and E is complete < 150 mm (6")
< 150 mm (6")
Make DC Input
connection before
mounting Output
Connector to the
Manager30
Start
Battery
DC Input
50 A Fuse
(and holder)
50 A Fuse
(and holder)
Extend cables as required
Auxiliary
Battery
Do not plug-in to Main Unit until
wiring of C,D and E is complete < 150 mm (6")
< 150 mm (6")
Make DC Input
connection before
mounting Output
Connector to the
Manager30
FUSE KIT ASSEMBLY
Order of installing Bolt in the Fuse Holder:
1. MIDI Fuse
2. Lug with Heatshrink and cable
3. Spring Washer
4. Nut
LUG AND HEATSHRINK ASSEMBLY
Strip the end of the cable back
enough to ensure the insulation
does not enter the barrel of the
Lug when fully inserted.
Slide the Heatshrink over the
cable.
Insert the stripped wires into the
barrel of the Lug.
Crimp the Lug using the correct
crimping tool.
Slide the Heatshrink to partially
cover the Lug, leaving the Lug
tongue exposed.
Shrink the heat shrink.
TVMS ROGUE INSTALLATION
Power Wiring Loom Wiring
MANAGER30 INSTALLATION
DC Input Wiring Connection

INST210-3 EN
