Redback A 2073B User manual

A 2073B
Alert/Evac Module
®
A 2073B Alert Evac Option
Proudly Assembled in Australia
OPERATING INSTRUCTIONS
Distributed by Altronic Distributors Pty. Ltd. Perth. Western Australia.
Phone: [phone] Fax: [phone] Internet: www.altronics.com.au
Generates pre announcement chime, alert and evacuation tones for Redback amplifiers and mixers.
Installation
1. Switch off and remove power from unit.
2. Remove lid from case.
3. Unscrew the small protector plate on the rear panel to reveal the mounting holes for the A 2073B.
4. Line up the A 2073B with the relevant holes in the rear panel, ensure the trimpots on the board are accessible.
5. Using the screws provided attach the A 2073B module to the rear panel via the green connector.
6. Plug the 10 way IDC cable into the 10 way header situated inside the amplifier or mixer. (Refer to instructions
supplied with your amplifier/mixer for header location)
7. Plug the plastic bushes supplied into the holes on the rear panel through which you can see the trimpots.
8. The A 2073B is now ready for operation
9. The unit is triggered by closing the contacts in the 5 way pluggable header. There are four different trigger inputs:
Alert tone - triggered by a closed contact between AL (alert tone) and GND (ground).
Evac tone - triggered by a closed contact between EV (evac tone) and GND (ground).
Chime - triggered by a closed contact between CH and GND (ground).
Cancel - triggered by a closed contact between CAN (cancel) and GND (ground).
IMPORTANT NOTE:
The evacuation tone for this device conforms to fire evacuation standards AS1670.4. 2004.
The evacuation tone (tempural pattern) conforms to international standards.

REDBACK A 2073B Alert Evac Option
Page 2
AL
EV CH CAN GND
Fig 1: Remote trigger contacts.
Voice over
level Remote contacts
10 Way IDC
Cable (To amplifier)
Chime
level
Alert/Evac
level
Switch 1
DIP Switch 2
Microphone
+-
Red Blk
Fig 2: Board layout of the A 2073B alert/evac module
10. The A 2073B has a voice over option which is enabled by DIP switch 2. When this DIP switch is set to “ON” the
recorded message will play twice after 4 cycles of the evac tone. Note: this voice over will only operate when the A
2073B is in evac mode. To record a message, connect the supplied microphone to the 2 way euro block as shown in
figure 2. To start recording, set DIP switch 4 to “ON”. When finished recording, set the DIP switch back to “OFF”.
11. Output level trimpots are available for the chime, alert/evac tones and voice over.
12. The A 2073B is equipped with a “switch over” option. This switches the Alert tone to the Evacuation tone automati-
cally. Switch 1 turns ON the “switch over” option as well as adjusting the time that the Alert tone will sound for
before switching to the Evacuation tone. See table 1 for selection details.
13. The alert and evac triggers can be set to be momentary or alternate action by DIP switch 1. In momentary operation
the alert or evac tones will operate only while the trigger is activated. In alternate operation the tones will operate con-
tinuously after they have been triggered.
Table 1: Switch 1 Settings
SW1 Position Switch Over Option
0 Disabled
1 Alert swtiches to Evac after 30 seconds
2 Alert swtiches to Evac after 60 seconds
3 Alert swtiches to Evac after 90 seconds
4 Alert swtiches to Evac after 120 seconds
5 Alert swtiches to Evac after 150 seconds
6 Alert swtiches to Evac after 180 seconds
7 Alert swtiches to Evac after 210 seconds
8 Alert swtiches to Evac after 240 seconds
9 Alert swtiches to Evac after 270 seconds
Table 2: DIP Switch Settings
SWITCH ON OFF
1 Momentary Alert Alternate Alert
& Evac Operation. & Evac Operation.
2 Voiceover ON. Voiceover OFF.
3 Not Used. Not Used.
4 Mic Recording Mic Recording
ON. OFF.
