Redliro JK105C-1 Operating manual

Index
Warnings & Safety Precautions
Precautions During Use
Instructions For Setting Up The Machine
Console
Folding And Unfolding
Using Silicone Oil
Adjusting The Belt
Daily Maintenance
Trouble Shooting
Technical Date
2
3
5
7
7
8
8
10
1
9

▲Warnings & Safety Precautions
◆For safety reasons, do not turn the treadmill on before you are completely on it.
◆If the treadmill is moving and you are not on it, please stop the device and then get on it.
◆Do not attempt to get on it while it is moving.
◆If you feel nauseous or if the treadmill is not running properly while you are using it, stop
using it immediately.
◆Never try to manipulate the belt of the treadmill directly while it is in operation.
◆When you want to increase the speed, do so progressively. We recommend you wear
sneakers and sportswear when using the treadmill.
◆Children, the elderly and pregnant women should not use the machine. People suffering
from any type of ailment should consult with their doctor before using the machine.
◆Attach the safety dip to your clothing when using the machine. Keep a firm hold on the
handles when using the machine.
◆Install the treadmill on a flat, level surface. Do not install the machine in the following
locations:
◆Outdoors. (The machine has been designed exclusively for indoor use.)
◆Inclined surfaces or on terraces.
◆Places exposed to bright sunlight or near heating appliances.
◆Do not connect the machine to the same socket as other electrical appliances
(computers, air conditioning, etc.) to avoid voltage spikes since these can trigger treadmill
errors.
◆Be careful when folding or unfolding the machine next to children or objects.
◆Keep the machine away from wet objects. Water could cause a malfunction.
Before starting to use the treadmill, verify
that you have hooked the clip of the Security
key in the indicated place on the main panel.
If it is not connected, the item will not work.

▲Precautions During Use
◆If you don't feel well before getting on the treadmill, consult with your doctor or trainer.
◆Our company is exempt from any liability for bodily injury caused by improper use.
◆Unplug the machine after use.
◆Always unplug the machine when moving it or when changing parts.
◆Place the machine on a smooth, flat surface. Do not place objects within 2 meters of the
machine.
◆Do not turn on the machine when it is folded up.
◆Never put water in the machine, especially in the motor, power cord and electrical outlet.
◆Do not wear loose or unsuitable clothing when using the machine as this can be
dangerous.
◆Do not use the machine in small, non-ventilated or flammable areas.
◆Do not place objects on the treadmill.
◆Keep the machine's electrical plug well away from sources of heat or fire.
◆Always turn off all the functions and unplug the machine after use.
◆Do not disassemble the machine without instructions from a professional.
◆Make sure the belt is securely fastened before using the machine.

▲Instructions For Setting Up The Machine
1.Main Structure
2.Security key
3.Wrench
4.Silicone Oil
5.Flat washer (x2) + Curved washer (x4)
6.M 6 knob (x2)
7.M16 knob + M12 knob
8.Screw M8*45 (x2) + Screw M8*30(x4)
9.Handrail cover (x2)
3.Remove the screws pre-assembled on the console.
With the assistance of another person, lift the frame
and while one person holds the handrail, the other
shall fix the handrail to the frame with the set of
screws provided, using the proper wrench. Connect
the cables, making sure that they are connected in the
right direction.
2.Remove the pre-assembled screws, then assemble.
1.Take out 4 short screws and pads from spare bag,
fix left and right upright tubes with base frame by
the screws. Please do not fasten the screws before
finish assembling.

5.First, please demount the M6 knob at the back
of panel and take out another M6 knob from
accessory bag. Then rotate panel to proper
position. Fix the two knobs to back of panel. Put
safety key.
on panel after finished assembling.
on panel afterfinished assembling.
6.Fix M16 knob to left upright tube, fix running
frame with base tube by M12 knob.
4.Take out 2 long screws and pads, fix panel with
upright tubes with the screws. Then fasten the
screws of above point 2 mentioned. Then put the
cover to armrest. Before fasten screws, please
make sure the cables in the upright tube will not
pressed by screws.
★ Note: You can search “REDLIRO JK105C-1” in YouTube
to see the video for how to assembly.

▲Console
DISTANCE:
Measures the distance travelled
in each workout

1. Press the "START" button and after 3 seconds the machine will switch on at a speed of
0.5 MPH.
2. Press the " ➕" button to increase the speed and the" ━" button to decrease it.The
maximum speed is 6 MPH; the minimum is 0.5 MPH.
3. Press the "MODE" button to display the speed, time and calories on the console.
◆SCAN: It shows 1 in 1 every 30 seconds the different registers:
SPEED|TIME| CALORIE
◆SPEED: Displays the speed during workout
◆TIME: Measures the time of each workout.
◆CALORIE: Calculates calories burnt during workout.
4. The treadmill has 12 programs that can be activated by pressing "PROG". To select a
programme, press "PROG" when the machine is in standby mode. Then press "START" to
start the treadmill.
*Note: When using the treadmill with an "automatic" programme, the "➕" "－" button is disabled.
5. For emergency stop，please pull out safety key.The machine will stop very slowly. Pull
out safety key the screen will show “Err”，put on it will show “OFF”
6. Press "STOP" to switch the machine off after use.

▲Folding And Unfolding
▲Using Silicone Oil
Pull up the running belt slightly, apply silicone oil to the backside of the belt and the top
surface of the running deck. Start the machine and keep it running for 3 minutes, let the oil
spread and even out. It is recommended to maintain the treadmill every 30 days to achieve
the best performance, which also helps to extend the life of the running belt.
Folding:
Turn on the fixed knob then lift the running board
to assemble the machine. Pull out the tension knob,
aimed at the platform then release the knob to fix
the machine. Move the machine
Unfolding:
Pull out the tension knob then fall down the running
board and fix the machine with the fixed knob then
use the machine after electrify.

▲Adjusting The Belt
▲Daily Maintenance
◆Make sure the machine is unplugged before carrying out any maintenance or cleaning.
◆Clean the belt and console at least once a week after use.
◆Check that the screws are tightened properly.
◆Do not hang clothes or other objects on the machine.
The belt deflects to the left...
Start the machine at a speed of 2 - 3 MPH without load and use
the wrench to turn the treadmill adjustment screw a quarter turn .
Keep the machine running unloaded for 1 to 2 minutes. Perform
this process until the belt moves in an aligned and straight line.
The belt deflects to the right...
Start the machine at a speed of 2 - 3 MPH without load and use
the wrench to turn the treadmill adjustment screw a quarter turn.
Keep the machine running unloaded for 1 to 2 minutes. Perform
this process until the belt moves in an aligned and straight line.
The belt is locked...
Use wrench to rotate the adjustment screws on both sides of the
tape and turn them around clockwise until they are unlocked. If
it's still locked, turn the two screws around until it works
properly.

▲Trouble Shooting
ERROR
CODE
REASON
SOLUTION
Err(or E00)
No safety key on panel
1. Put safety key in the yellow area of panel
2. Err(or E00) still shows or there is no function, change
the computer screen/display monitor.
E2 / E6
Down control panel or motor
is broken
First replace the down control, and then replace the motor
Motor carbon brush cover is
off
Replace the cover/replace the motor directly
The motor wire is off
Reinsert
E4
Overload protection
Add silicone oil to the running belt, restart, and run at low
speed for a period of time.
Replace the down control
E5
Overcurrent protection
(protection setting is low)
Increase the protection value, take down the safety key,
long press speed "-" to enter the parameter setting, press
the mode key to select d8, and increase the value by 0.5
Down control panel is broken
Replace the down control
the motor torque is too large
Take down the safety key, long press speed "-" to enter
the parameter setting, press the mode key to select d1,
decrease value gradually
Long-term use lacks
lubricating oil, increasing
running resistance
Add lubricating oil, restart, run at low speed for a period
of time in use
E7
There is a problem with the
upper control panel, the down
control panel, and the
connection line
First check whether the connection line & connector is
connected, see whether it is plugged, whether the
appearance is damaged or broken, it is best to replace the
vertical rod first
If there is no problem with the connection line, consider
replacing the down control
If there is no problem with the down control, consider
replacing the upper control
E8
The motor is stuck
A person stands on the treadmill and pushes the running
belt backwards. Whether the running belt rotates and
whether there is a friction sound. If it cannot be turned or
there is a sound when it is turned, find out the reason and
replace it.
The drum is stuck
Down control panel is broken

▲Technical Data
TECHNICAL DATA
VOLTAGE 110 V 丨50-60 Hz
SPEED 0.5-6 MPH
MAX W. SUPP.
NET WEIGHT
GROSS WEIGHT
DIMENSIONS
66 LBS
57 LBS
200 LBS
57×20.5×50 INCHES
