Redliro JK1608L Operating manual

MODEL
JK1608L
REDLIRO TREADMILL
PRODUCT USE GUIDE

SERVICE
Thank you for purchasing this Redliro product. Questions, problems,
missing parts? Before returning to your retailer, contact our Customer
Service Department to receive more complete service, please email
your order number to: [e-mail]
Response
Time
URL : www.redliro.com
FOR INFORMATION REGARDING WARRANTY, REPLACEMENT PARTS, AND REFUNDS,
PLEASE CONTACT OUR CUSTOMER SUPPORT.
Emailing us with the information above will be the best
method to receive a response during peak business hours.
CONTENT
Service
Safety Information
Technical Parameters
Package List
Product Structure
Assembly
Console Command Description
Instructions for Using the Treadmill
Preparation before use
Instructions for Use
Product Maintenance
Daily Cleaning
Routine Maintenance
Troubleshooting and Handling
Workout Guide
Warranty
2
4
5
6
7
8
12
14
14
14
17
17
18
20
23
24

[email protected] [email protected]
45
SAFETY INFORMATION
TO REDUCE THE RISK OF INJURY, PLEASE READ INSTRUCTIONS IN FULL BEFORE USE.
• Intended for at-home use only. Please only use in an area with 3 - 6 feet of free space around your device.
Do not operate your device on a carpet more than 0.5 inches thick or near water.
• Treadmill is not intended for use by children or those with physical, sensory, or cognitive impairments.
• To avoid injury, do not disassemble this machine without guidance of manufacturer.
• This product only works with electrical outlets with a voltage between 100 and 120VAC. If your product’s
plug does not t your home’s outlets, do not attempt to use.
• Check all parts before use to ensure the screws and nuts are not loose.
• Keep ngers away from moving parts. Don’t put your hands or feet in the space under the running belt.
Keep children or pets away from the treadmill.
• Wear appropriate exercise clothes and athletic shoes while using the treadmill. Loose tting or oversized
clothing can get caught in machine. Always wear the clip with the safety key fasten to the panel while using
the treadmill.
• Unstable power supply may overload the circuit. Do not plug high-power devices such as a computer into
an outlet on the same circuit.
• Do not place any objects on the machine. Do not stand directly on the belt when the machine is turned on.
• This product can only be used by one person at a time.
• Keep children, pets, and household objects clear of the machine when folding and unfolding. Do not start
the machine when it is folded.
• Always unplug the power cord after use before cleaning and performing maintenance.
• Only use manufacturer’s accessories. Never exceed product’s maximum weight capacity of 300 lbs. (136kg)
• Moisture and overheating will a󰀨ect the use of the product. Please keep the machine, motor, power cord
and plug away from water and high temperatures.
• This product is intended for home use only. Any medical information (i.e. heart rate, pulse) cannot be used
as a replacement for the consultation of a medical professional.
• Please hold the handrail when using the treadmill
• If the treadmill overheats, emits smoke or a burning smell during use, please stop using it immediately and
contact customer service for replacement
• The company is not responsible for any harm caused by improper use
TECHNICAL PARAMETERS
Product configuration Technical parameters
Input voltage 110 v
Speed range 0.5-5.5 mph
Maximum load bearing 300 lbs
Package size 51.2x27.4x8.7 inches
Assembly size 51x25x46 inches
Operating area 41x16 inches
Rated power 2.25 hp
Net/gross weight 66/77 lb
Net / Gross weight 50.7/57.3 lb

[email protected] [email protected]
67
PACKAGE LIST
SERIAL NO. DESCRIPTION QUANTITY UNIT
1 CONSOLE 1 PC
2 TREADMILL 1 PC
3 ARMREST BAR BASE 1 PC
4 ARMREST 2 PCS
5 M8 CURVED WASHER 4 PCS
6 M8*16 SCREW 6 PCS
7 M8 FLAT WASHER 2 PCS
8 M12 KNOB 1 PC
9 M16 KNOB 1 PC
10 SAFETY KEY 1 PC
11 SILICONE LUBRICANT 1 PC
12 L STYLE WRENCH 1 PC
13 OPEN END WRENCH 1 PC
4
3
2
1
6 75 8 9 10 11 12 13
Instrument & Buttons
Folding Lock Button
Column Tube
Display Panel
Motor Lower Cover
Locking Switch
Rear Shield (Left)
Safety Key
Handrail Button
Armrest
Motor Upper Cover
Running Belt
Foot Edge Strip
Rear Shield (Right)
PRODUCT STRUCTURE
Power Switch

[email protected] [email protected]
89
ASSEMBLY
ASSEMBLY STEPS
NOTE: THE RUNNING BELT IS MADE OF HEAD AND TAIL SPLICING, THERE ARE
SEAM MARKS, IT IS NORMAL PROCESS PHENOMENON, AND DOES NOT AFFECT THE
NORMAL USE OF THE TREADMILL.
Carefully open the box and remove the treadmill and accessories package placing the treadmill on the
ground.
STEP 1
Remove the pre-locking screw as shown in the expanded view. Connect the communication cable between
the right support bar and control console. Then reinstall the control console and support bar using the pre-
locking screw previously removed.
STEP 2
STEP 3
2
Raise the treadmills support bar (No.2) to the vertical position. Then secure it by using two M8×16mm screws
(No.6), one M8 at washer (No.7), and one M8 curved washer (No.5).
Rotate the control console (No.1) to the vertical position and attach to the support bar using the M8×16
screws (No.6) and M8 curved washers (No.5).
6
6
7
5
6
6
5
5
1

[email protected] [email protected]
10 11
Remove the pre-installed M5x25 screws on the armrest bar base (No.3). Then insert the armrest (No.4) bars
into the armrest bar base (No.3), and reinstall the M5x25 screws.
[email protected]
4
4
3
8
9
10
Tighten the M12 knob (No.8). Fold the treadmill and secure it with the M12 knob (No.8). Attach the handrail
assembly to the control console using the M5 × 25 screws.
Tighten the M16 knob (No.9). Secure the safety key (No.10).
After assembly,connect the power and turn on the power switch to start enjoying your new treadmill.
STEP 4
STEP 5
STEP 6

[email protected] [email protected]
12 13
CONSOLE COMMAND DESCRIPTION
DISTANCE:
The “Distance” window has two display modes.
(1) In standard mode, the distance will be counted from 0 to 99.9 miles, and it will reset to 0 when it reaches
99.9.
(2) The preset/custom mode allows user to set a distance. Select from 0.4 miles to 99 miles. Once
countdown has reached 0, your device will slowly stop and enter standby mode.
SCAN:
Displayed data changes every 5 seconds, cycling between SPEED, TIME, and DISTANCE.
SPEED:
Current machine speed.
TIME:
The “Time” window has two display modes.
(1) Standard mode counts from 00:00 ~ 99:00 and resets to 0 when it reaches 99:00.
(2) The preset/custom mode allows user to set a time for length of use. Select from 5 minutes to 99 minutes.
Once countdown has reached 0, your device will slowly stop and enter standby mode.
CAL:
The “Calories” window has two display modes.
Standard mode counts from 0~ 999.9 and resets to 0 when it reaches 999.9.
The preset/custom mode allows user to set calorie value. Select from10 to 99 0. Once countdown has
reached 0, your device will slowly stop and enter standby mode.
Heart rate display:
Hold sensors on left and right handrails at the same time to see your current heart rate. Heart rate data
cannot be displayed at the same time as speed, time, and calorie data.
START button:
In standby mode, pressing the START button will start the treadmill after 3 seconds. The default speed is
0.5mph.
TIME
PROGRAMA
SET TIME/20=RUNNING TIME FOR EACH SECTION
P1 SPEED 1.1 1.1 2.2 2.2 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 2.2 2.2 1.1 1.1
P2 SPEED 1.1 2.2 3.3 4.4 4.4 4.4 4.4 3.3 2.2 1.1 1.1 2.2 3.3 4.4 4.4 4.4 4.4 3.3 2.2 1.1
P3 SPEED 1.1 1.1 1.1 2.2 2.2 2.2 3.3 3.3 3.3 4.4 4.4 4.4 5.5 5.5 5.5 5.5 4.4 3.3 2.2 1.1
P4 SPEED 1.1 3.3 4.4 5.5 4.4 3.3 1.1 1.1 3.3 4.4 5.5 4.4 3.3 1.1 1.1 3.3 4.4 5.5 4.4 3.3
P5 SPEED 1.1 2.2 3.3 4.4 5.5 3.3 3.3 4.4 5.5 3.3 3.3 4.4 5.5 3.3 3.3 4.4 5.5 3.9 2.2 1.1
P6 SPEED 1.1 1.1 2.2 3.3 4.4 5.5 5.5 5.5 5.5 5.5 5.5 4.4 4.4 3.3 2.2 2.2 2.2 1.1 1.1 1.1
P7 SPEED 1.1 3.3 4.4 3.3 5.5 4.4 5.5 5.5 3.3 5.5 5.5 5.5 5.5 3.3 5.5 4.4 5.5 5.5 3.3 1.1
P8 SPEED 1.1 2.2 3.3 4.4 3.3 5.5 3.3 5.5 3.3 5.5 5.5 3.3 5.5 3.3 5.5 3.3 4.4 3.3 2.2 1.1
P9 SPEED 1.1 4.4 2.2 5.5 3.3 5.5 3.3 5.5 4.4 5.5 5.5 4.4 5.5 3.3 5.5 3.3 5.5 2.2 3.3 1.1
P10 SPEED 1.1 3.3 2.2 5.5 5.5 3.3 5.5 5.5 5.5 3.3 5.5 5.5 5.5 5.5 4.4 3.3 4.4 2.2 3.3 1.1
P11 SPEED 1.1 2.2 5.5 5.5 5.5 5.5 3.3 5.5 5.5 5.5 5.5 5.5 5.5 3.3 5.5 5.5 5.5 5.5 2.2 1.1
P12 SPEED 2.2 2.2 3.3 5.5 2.2 3.3 5.5 2.2 5.5 3.3 5.5 4.4 5.5 5.5 5.5 3.3 4.4 2.2 3.3 1.1
In preset/custom mode, press the button and the treadmill will start, run at preset values and accumulate
data.
When the machine is paused, pressing the START button will continue the program set before pause.
The START button on the handrail has the same function.
STOP button:
Press the STOP button while using your device to pause activity.
While paused, pressing the STOP button will put your device in standby mode.
The STOP button on the handrail has the same function.
+/- button:
Used for speed adjustment while your device is in use. The adjustment range is 0.1 mph /once. Hold for
more than 0.5 seconds, the speed will continue to increase or decrease. Can also be used to adjust settings
in preset/custom mode.
MODE button:
Press the Mode button while in standby mode to switch between time setting (setting range 5:00 ~ 99:00),
distance setting (setting range0.4 ~ 99miles ) and calorie setting( setting range 10 ~ 990 ).
When device is in use, press the “M” button to switch between four display modes: Scan, Time, Speed, and
Calorie.
Security key:
One end of security key is xed on the treadmill by magnet, and the other end is clamped to the clothes. In
an emergency, you can pull the magnetic key from the treadmill to stop running immediately.
PROG button:
While in standby mode, used to select 12 preset automatic programs P01 ~ P12
The 12 preset programs have the following speeds:

[email protected] [email protected]
14 15
INSTRUCTIONS FOR USING THE TREADMILL
PREPARATION BEFORE USE:
INSTRUCTIONS FOR USE
1. Plug in the power cord
2. Press the power switch on the treadmill and wait for the indicator light to turn on
3. Connect the safety key
Note: All modes of the treadmill must be started while the machine is in standby. Keep treadmill in standby
before switching to a di󰀨erent mode.
Note: In order to extend the life of treadmill, the maximum time for one workout has been set to 99 minutes.
The treadmill will stop running should you hit this time and the display screen will read END.
HOW TO USE THE TREADMILL IN STANDARD MODE
1. How to turn on the treadmill
In standby mode, press the Start button on the console or the Start button on the handrail and the running
belt will begin moving at 0.5mph in 3 seconds
2.How to adjust the treadmill speed
Use the +/- buttons on the console or handrail for speed adjustment while your device is in use. The
adjustment range is 0.1 mph /once. Hold for more than 0.5 seconds, the speed will continue to increase or
decrease. Can also be used to adjust settings in custom mode.
3. How to select the desired display mode
The display provides four modes: Scan, Time, Distance, and Calorie. When the treadmill is running, you
can select mode by pressing the M button on the console. The display cycles between the four options in 5
second intervals.
4.How to Pause/Turn o󰀨 the treadmill
When the treadmill is running, press the STOP button on the console or handrail, the treadmill will temporarily
out of service.
(1) Press the START button on the console or handrail, the treadmill will continue to run.
(2) Press the STOP button on the console or handrail, the treadmill will return to the standby state.
HOW TO USE THE TREADMILL IN PRESET MODE
1. How to choose a program
In standby mode, you can select from 12 preset automatic programs (P1-P12) by pressing the PROG button
on the console.
2. How to adjust the time of the preset program
After you have selected a preset program, press the +/- buttons on the console or handrail to adjust its
duration in 1 minute increments. Hold for over 0.5 seconds for timer to roll quickly. The selectable time range
is 5-99 minutes.
3. How to turn on the treadmill
When you have selected the desired automatic program and duration, press the Start button on the console
or handrail, and the running belt will begin moving at the preset program speed in 3 seconds
4. How to turn o󰀨 the treadmill
When the treadmill is running, press the Stop button on the console or handrail to slow and return to standby
mode.
Note: The speed can’t be adjusted when running in preset mode
HOW TO USE THE TREADMILL IN CUSTOM MODE
1. How to choose a program
In standby mode, you can press the MODE button on the console to select a mode from time, distance and
calorie
2. How to set the value of the program
Note: Only one of the three modes can be selected
Time setting:
In standby mode, press the MODE button on the console and adjust time by pressing the +/- buttons on the
console or handrail to adjust its duration in 1 minute increments. Hold for over 0.5 seconds for timer to roll
quickly. The selectable time range is 5-99 minutes.

[email protected] [email protected]
16 17
Distance setting:
In standby mode, press the MODE button on the console twice and then adjust the distance by pressing
the +/- buttons on the console or handrail. Hold for more than 0.5 seconds for counter to roll quickly. The
selectable distance range is 0.5-99 miles.
Calorie setting:
In standby mode, press the MODE button on the console 3 times, and then adjust the number of calories
you wish to burn by pressing the +/- buttons on the console or handrail. Adjustments made in units of 10
calories. Hold for more than 0.5 seconds for the value to increase or decrease continuously. The selectable
calorie burn range is 10-990 calories.
3. How to turn on the treadmill
Once you've set up your desired program, press the Start button on the console or handrail and the running
belt will begin moving at 0.5mph in 3 seconds
4. How to adjust the treadmill speed
Use the +/- buttons on the console or handrail for speed adjustment while your device is in use. The
adjustment range is 0.1 mph /once. Hold for more than 0.5 seconds, the speed will continue to increase or
decrease. Can also be used to adjust settings in standard mode.
5.How to turn o󰀨 the treadmill
When the treadmill is running, press the Stop button on the console or handrail, the treadmill will slowly stop
and return to the standby mode.
PRODUCT MAINTENANCE
REGULAR MAINTENANCE IS IMPORTANT FOR YOUR SAFETY AND TO EXTEND THE LIFE OF
YOUR PRODUCT. PLEASE CHECK AND TIGHTEN ALL PARTS BEFORE YOUR FIRST USE AND
REPLACE WORN PARTS OVER TIME AS NEEDED.
DAILY CLEANING
Clean your treadmill regularly. The running belt and console must be clean and dry for long term safe use.
Power o󰀨 and unplug your treadmill. Wipe the exterior with a damp cloth and a small amount of mild soap.
The display console must be kept dry, however; wipe it with a dry, soft towel.
Dry the treadmill thoroughly with a soft towel.
Note: Do not spray liquid directly on the treadmill. To avoid damaging the console, keep it dry at all
times.

[email protected] [email protected]
18 19
USE OF SILICONE LUBRICANT
The treadmill has been lubricated prior to shipment. Friction between the running belt and the
running board will greatly affect the service life and performance of the product, so be sure to
lubricate every 3 months or 100 miles of use.
Gently lift the running belt 2-3 inches to give yourself enough room to apply silicone lubricant to
the surface of the running board. Apply the lubricant in 4 - 6 inch strips on both sides of the board,
ensuring that none gets into the motor shaft, which can cause the belt to slip.
Start the treadmill and let it run for 3 minutes to distribute the silicone lubricant evenly.
ROUTINE MAINTENANCE
RUNNING BELT ADJUSTMENT
All treadmills are shipped with the running belt adjusted in place of immediate use.
The running belt may deviate from its ideal position over time, which can be caused by the following.
1. The main body is not in kept in a stable position.
2. The user's feet are not in the center of the running belt.
3. The user's feet exert uneven force.
If the deviation is due to issues 2 and 3 above, the treadmill can be returned to normal after 3 minutes of
rotation with no weight on the running belt .
If the above does not solve the problem, adjust the running belt with the L-Wrench.
RUNNING BELT IS OFF CENTER
Note: Please remove the safety key and unplug the power cord.
Running belt shifted to the left
Use the L-Wrench wrench to turn the left rear roller bolt clockwise 1/4 of a turn to tighten the running belt.
Running belt shifted to the right
Use the L-Wrench to turn the right rear roller bolt clockwise 1/4 of a turn to tighten the running belt.
Then plug in the power cord, connect the safety key, and run the treadmill for 3 minutes. Repeat until the
running belt is centered.
Note: use of your treadmill with the running belt out of place can cause preventable wear with the
potential for injury.
Running belt is loose
Note: Please remove the safety key and unplug the power cord.
The running belt will loosen over time. A loose running belt will not function properly.
Use the L-Wrench turn both rear idler bolts clockwise 1/4 of a turn to tighten the running belt.
Then plug in the power cord, connect the safety key, run the treadmill for 3 minutes. Repeat until the running
belt is centered.
Note: A running belt that is too tight can cause damage to the belt itself and its rollers. Strange
noises are an indication your belt is too tight and must be loosened for a safe experience.
Note: Search “REDLIRO” on YouTube to nd videos on how to adjust the running belt.
