Redliro JK1608E-2 Operating manual

MODEL
JK1608E-2
REDLIRO TREADMILL
PRODUCT USE GUIDE

Service
Safety Information
Technical Parameters
Package List
Product Structure
Assembly and Folding
Operating Instruction
Console Command Description
Remote Control Instructions
Battery Replacement
Instructions for Using the Treadmill
Preparation before use
Instructions for Use
Product Maintenance
Daily Cleaning
Routine Maintenance
Troubleshooting and Handling
Workout Guide
Warranty
SERVICE
Thank you for purchasing this Redliro product. Questions, problems,
missing parts? Before returning to your retailer, contact our Customer
Service Department to receive more complete service, please email
your order number to: [e-mail]
Response
Time
URL : www.redliro.com
FOR INFORMATION REGARDING WARRANTY, REPLACEMENT PARTS, AND REFUNDS,
PLEASE CONTACT OUR CUSTOMER SUPPORT.
Emailing us with the information above will be the best
method to receive a response during peak business hours.
CONTENT
2
4
5
6
7
8
10
11
13
15
16
16
16
20
20
21
23
27
28

[email protected] [email protected]
45
SAFETY INFORMATION
TO REDUCE THE RISK OF INJURY, PLEASE READ INSTRUCTIONS IN FULL BEFORE USE.
• Intended for at-home use only. Please only use in an area with 3 - 6 feet of free space around your device.
Do not operate your device on a carpet more than 0.5 inches thick or near water.
• Treadmill is not intended for use by children or those with physical, sensory, or cognitive impairments.
• To avoid injury, do not disassemble this machine without guidance of manufacturer.
• This product only works with electrical outlets with a voltage between 100 and 120VAC. If your product’s
plug does not t your home’s outlets, do not attempt to use.
• Check all parts before use to ensure the screws and nuts are not loose.
• Keep ngers away from moving parts. Don’t put your hands or feet in the space under the running belt.
Keep children or pets away from the treadmill.
• Wear appropriate exercise clothes and athletic shoes while using the treadmill. Loose tting or oversized
clothing can get caught in machine. Always wear the clip with the safety key fasten to the panel while using
the treadmill.
• Unstable power supply may overload the circuit. Do not plug high-power devices such as a computer into
an outlet on the same circuit.
• This product can only be used by one person at a time.
• Do not place any objects on the machine. Do not stand directly on the belt when the machine is turned on.
• Keep children, pets, and household objects clear of the machine when folding and unfolding. Do not start
the machine when it is folded.
• Always unplug the power cord after use before cleaning and performing maintenance.
• Only use manufacturer’s accessories. Never exceed product’s maximum weight capacity of 220 lbs. (100kg)
• Moisture and overheating will a󰀨ect the use of the product. Please keep the machine, motor, power cord
and plug away from water and high temperatures.
• If the treadmill overheats, emits smoke or a burning smell during use, please stop using it immediately and
contact customer service for replacement
• The company is not responsible for any harm caused by improper use
TECHNICAL PARAMETERS
Product configuration Technical parameter
lnput voltage 110 V
Speed range 0.5-7.5 mph
Maximun load bearing 220 lbs
Packaging size 57.72 x 27.4 x 6.69 inches
Folding size 53.7 x 24.8 x 5.5 inches
Assembly size 51.9 x 24.8 x 42.1 inches
Operating area 41 x 15 inches
Rated power 2.25 hp
Net / Gross weight 50.7/57.3 lb

[email protected] [email protected]
67
PRODUCT STRUCTURE
Instrument & Buttons
Column Tube
Display Panel
Motor Lower Cover
Locking Switch
Rear Shield (Left)
Power Switch
Safety Key
Motor Upper Cover
Running Belt
Foot Edge Strip
Rear Shield (Right)
SERIAL NO. DESCRIPTION QUANTITY UNIT
1 TREADMILL 1 PC
2 REMOTE CONTROL 1 PC
3 POWER CORD (THREE-PINPLUG) 1 PC
4 SILICONE LUBRICANT 1 PC
5 L STYLE WRENCH 1 PC
6 SAFETY KEY 1 PC
PACKAGE LIST
TREADMILL × 1 REMOTE CONTROL × 1
SILICONE LUBRICANT × 1POWER CORD
(THREE-PINPLUG) × 1
L STYLE WRENCH × 1 SAFETY KEY × 1

[email protected] [email protected]
89
ASSEMBLY AND FOLDING
ASSEMBLY STEPS
NOTE: THE RUNNING BELT IS MADE OF HEAD AND TAIL SPLICING, THERE ARE
SEAM MARKS, IT IS NORMAL PROCESS PHENOMENON, AND DOES NOT AFFECT THE
NORMAL USE OF THE TREADMILL.
STEP 1
Unpack your package, take out the related
accessories and the machine. Put the
machine on level ground.
STEP 2
Unscrew the adjustment knobs on both
sides of the frame (3 turns recommended),
push up the column tube, keep the hinge of
the main unit corresponding to the slot, and
then tighten the adjustment knobs on both
sides.
STEP 3
Install the safety key to complete the
assembly.
FOLDING STEPS
STEP 1
Hold the column tube with one hand, and
unscrew the adjustment knobs on both
sides of the frame respectively (3 turns
recommended)
STEP 2
Hold the column firmly and lower it until it
lays at. Then screw in the knobs.
STEP 3
The folding of the machine is complete.

[email protected] [email protected]
10 11
OPERATING INSTRUCTION
THE TREADMILL HAS A MAXIMUM SPEED OF 4 MPH WHEN THE HANDRAILS FOLD DOWN.
1. The “TIME” window has two display modes.
• Standard mode counts from 00:00 ~ 99:00 and resets to 0 when it reaches 99:00.
• The preset/custom mode allows user to set a time for length of use. Select from 5 minutes to 99 minutes.
Once countdown has reached 0, your device will slowly stop and enter standby mode.
2. The "CALORIES" window has two display modes.
• Standard mode counts from 0 to 999.9, and resets to 0 when it reaches 999.9.
• The preset/custom mode allows user to set calorie value. Select from20 to 990. Once countdown has
reached 0, your device will slowly stop and enter standby mode.
3. The “STEP” window displays the number of steps taken. The count is 0~9999 steps. When the step count
reaches 9999, it will reset to 0.
4. The "SPEED" window displays the current running speed, and the speed range is 0.5mph~7.5mph.
In preset mode, 12 preset schemes (P1 ~ P12) are displayed.
5. The "Distance" window has two display modes.
• In standard mode, the distance will increase from 0.0 to 99 miles, and the count will reset to 0 when it
reaches 99
• In preset/custom mode, the distance will be reduced from the inputted data (setting range: 1~99 miles) to 0.
When the display is 0, your device will slowly stop and enter the standby state.
12 43 5
CONSOLE COMMAND DESCRIPTION
Safety key:
One end of the safety key is attached to the treadmill by magnet while the other end must be clamped to your
clothing. In an emergency, you can pull the magnetic key from the treadmill to stop running immediately.
Start button:
In standby mode, pressing the Start button will start the treadmill after 3 seconds. The default speed is 0.5mph.
In preset/custom mode, press the Start button and the running belt will begin moving at its preset speed. The
treadmill will begin to accumulate dat.
In the pause mode, press Start button and the running belt will begin moving at the previous selected
program.
Stop button:
Press the Stop button while in use for the treadmill to slow down and return to the standby mode.
In the pause mode, press Stop button and the running belt will slowly return to standby mode.
+/- button:
Used for speed adjustment while your device is in use. The adjustment range is 0.1 mph each time you
press. Hold for more than 0.5 seconds, the speed will continue to increase or decrease. Can also be used to
adjust settings in preset/custom mode.
Programs
Mode
Start
P
M
Safety Key Phone/Pad Holder
stop
Increase speed
Reduce speed

[email protected] [email protected]
12 13
M button:
Press the M button while in standby mode to switch to custom mode. Select between time setting (setting
range 5:00 ~ 99:00), distance setting (setting range1 ~ 99miles ) and calorie setting( setting range 20 ~ 990 ).
Press M button to change the cyclic display or xed display mode when in use.
Cyclic display mode: The default mode when in use. The left screen displays Time, Step and Calorie in a
loop. The right screen displays Speed and Distance in a loop. The display between each option in 5 second
intervals.
Fixed display mode: When in cyclic display mode, press the M button to xed the option on the left or right
screen.
P button:
In standby mode, it is used to select 12 preset automatic programs (P01 ~ P12)
The 12 preset programs have the following speeds:
REMOTE CONTROL INSTRUCTIONS
HOW TO ESTABLISH A NEW CONNECTION
1. Ensure the treadmill is connected to the power source but keep it powered on.
2. Hold the Mute button and Reset buttons on the remote control simultaneously for 5 seconds. The light on
the remote control will ash as it enters pairing mode.
3. The remote control will pair with treadmill automatically after a few seconds.
Increase Speed
Mode
ResetMute
Start / Stop Reduce Speed
Programs
NOTE: TO USE THE REMOTE CONTROL, YOU MUST FIRST ESTABLISH A NEW CONNECTION
SET TIME/20=RUNNING TIME FOR EACH SECTION
P1 SPEED 2.0 2.0 3.0 4.0 5.0 3.0 4.0 5.0 5.0 3.0 4.0 5.0 4.0 4.0 4.0 2.0 3.0 5.0 3.0 2.0
P2 SPEED 2.0 3.0 4.0 5.0 6.0 4.0 6.0 6.0 6.0 4.0 5.0 6.0 4.0 4.0 4.0 2.0 4.0 5.0 3.0 2.0
P3 SPEED 2.0 4.0 4.0 6.0 6.0 4.0 7.0 7.0 7.0 4.0 7.0 7.0 4.0 4.0 4.0 2.0 5.0 3.0 3.0 2.0
P4 SPEED 2.0 5.0 5.0 6.0 6.0 6.0 6.0 4.0 4.0 2.0 2.0 4.0 7.0 6.0 6.0 6.0 6.0 6.0 4.0 2.0
P5 SPEED 3.0 3.0 5.0 7.0 6.0 6.0 7.5 5.0 5.0 7.5 7.5 5.0 6.0 5.0 7.5 5.0 7.0 5.0 4.0 3.0
P6 SPEED 3.0 7.5 7.5 7.0 7.5 6.0 7.5 6.0 4.0 2.0 5.0 4.0 7.0 6.0 6.0 6.0 7.5 6.0 4.0 3.0
P7 SPEED 3.0 4.0 6.0 6.0 7.5 6.0 7.5 7.0 5.0 6.0 6.0 6.0 6.0 7.0 7.5 7.0 6.0 6.0 5.0 3.0
P8 SPEED 3.0 5.0 6.0 7.0 7.5 7.5 7.0 7.5 4.0 7.0 7.0 4.0 7.0 7.0 7.5 7.0 7.5 7.0 5.0 3.0
P9 SPEED 4.0 7.0 3.0 1.0 7.0 7.0 7.5 7.5 5.0 7.5 6.0 7.0 6.0 7.0 7.5 7.5 7.0 7.0 5.0 3.0
P10 SPEED 4.0 5.0 3.0 7.5 7.5 7.5 7.5 7.5 4.0 7.5 5.0 4.0 7.0 7.5 7.0 7.0 7.5 7.0 6.0 4.0
P11 SPEED 4.0 7.5 6.0 7.5 7.0 6.0 6.0 7.5 5.0 7.5 7.5 6.0 6.0 6.0 6.0 6.0 7.0 7.5 7.5 2.0
P12 SPEED 4.0 4.0 7.0 7.5 2.0 7.5 7.5 7.5 7.5 7.5 7.5 7.5 7.0 7.5 7.5 2.0 7.5 7.5 7.5 2.0

[email protected] [email protected]
14 15
Start/Stop button:
Press Start/Stop button in standby mode and the treadmill will start after 3 seconds. The default speed is 0.5
mph.
Press Start/Stop button in preset/custom mode and the treadmill will start immediately, running at preset
values. It will immediately begin accumulating data.
Press Stop button while running belt is in motion and the treadmill will slow down slowly and return to pause
mode.
In the pause mode, press Start button and the running belt will begin moving at the previous selected
program.
+/- button:
Used for speed adjustment while your device is in use. Speed will be adjusted 0.1 mph each time you press.
Hold for more than 0.5 seconds and the speed will continue to increase or decrease. Can also be used to
adjust settings in preset/custom mode.
M button:
Press the M button while in standby mode to switch to custom mode. Select between time setting (setting
range 5:00 ~ 99:00), distance setting (setting range1 ~ 99miles ) and calorie setting( setting range 20 ~ 990 ).
Press M button to change the cyclic display or xed display mode when in use.
Mute button:
Press the "Mute" button once to mute noise. Press it twice to cancel the operation.
Reset button:
In the pause mode, press Reset button and the running belt will slowly return to standby mode
P button:
In standby mode, the P button is used to select 12 preset automatic programs (P01 ~ P12)
FUNCTION OF THE REMOTE CONTROL
Step 1: Push back to remove the cover and install the battery.
BATTERY REPLACEMENT
Step 2: Remove button cell of remote control:
After long-term use, the remote control will have reduced sensitivity or become inoperable due to insu󰀩cient
power, and the battery needs to be replaced. Remove battery cover and take dead batteries out of your
remote control.
Step 3: Install button cell of remote control:
Ensure you have purchased new batteries that are the right type for the remote control by comparing with the
dead ones. Insert your new batteries into the remote and replace cover. Dispose of old batteries responsibly.
1
1
2
2
3
3
123

[email protected] [email protected]
16 17
INSTRUCTIONS FOR USING THE TREADMILL
PREPARATION BEFORE USE:
INSTRUCTIONS FOR USE
1. Plug in the power cord
2. Establish the connection between the treadmill and the remote control
3. Press the power switch on the treadmill and wait for the indicator light to turn on
4. Connect the safety key
Note: All modes of the treadmill must be started while the machine is in standby. Keep treadmill in standby
before switching to a di󰀨erent mode.
Note: In order to extend the life of treadmill, the maximum time for one workout has been set to 99 minutes.
The treadmill will stop running should you hit this time and the display screen will read END.
HOW TO USE THE TREADMILL IN STANDARD MODE
1. How to turn on the treadmill
In standby mode, press the Start button on the console or the Start/Stop button on the remote control and the
running belt will begin moving at 0.5mph in 3 seconds
2. How to adjust the treadmill speed
To change the speed of the running belt, press the +/- buttons on the console or remote control; the speed
will be adjusted by 0.1mph when you press the button. Hold for 0.5 seconds or longer and the speed will
increase or decrease continuously.
3. How to select the desired display mode
The left screen displays three modes: Time, Step and Calorie. The right screen displays two modes: Speed
and Distance. When the treadmill is running, you can select xed display or cyclic display mode by pressing
the M button on the remote control. In cyclic display mode, the display between each option in 5 second
intervals.
4.How to pause/restart the treadmill
Press Stop button on the console or the Start/Stop button on the remote control while running belt is in
motion and the treadmill will slow down slowly and return to pause mode.
In the pause mode, press Start button on the console or the Start/Stop button on the remote control and the
running belt will begin moving at the previous selected program.
5. How to turn o󰀨 the treadmill
When the treadmill is suspended, press the Stop button on the console (or the reset button on the remote
control) and the treadmill will slowly return to standby mode.
HOW TO USE THE TREADMILL IN PRESET MODE
1. How to choose a program
In standby mode, you can select from 12 preset automatic programs (P1-P12) by pressing the P button on
the console or remote control
2. How to adjust the time of the preset program
After you have selected a preset program, press the +/- buttons on the console or remote control to adjust its
duration in 1 minute increments. Hold for over 0.5 seconds for timer to roll quickly. The selectable time range
is 5-99 minutes.
3. How to turn on the treadmill
When you have selected the desired automatic program and duration, press the Start button on the console
(or the Start/Stop button on the remote control), and the running belt will begin moving at the preset program
speed in 3 seconds
4.How to pause/restart the treadmill
Press Stop button on the console or the Start/Stop button on the remote control while running belt is in
motion and the treadmill will slow down slowly and return to pause mode.
In the pause mode, press Start button on the console or the Start/Stop button on the remote control and the
running belt will begin moving at the previous selected program.
5. How to turn o󰀨 the treadmill
When the treadmill is suspended, press the Stop button on the console (or the reset button on the remote
control) to slow and return to standby mode.
Note: The speed can’t be adjusted when running in preset mode
HOW TO USE THE TREADMILL IN CUSTOM MODE
1. How to choose a program
In standby mode, you can press the M button on the console or remote control to select a mode from time,
distance and calorie
2. How to set the value of the program
Note: Only one of the three modes can be selected.

[email protected] [email protected]
18 19
Time setting:
In standby mode, press the M button on the console or remote control and adjust time by pressing the +/-
buttons to adjust its duration in 1 minute increments. Hold for over 0.5 seconds for timer to roll quickly. The
selectable time range is 5-99 minutes.
Distance setting:
In standby mode, press the M button on the console or the remote control twice and then adjust the distance
by pressing the +/- buttons on the console or remote control. Hold for more than 0.5 seconds for counter to
roll quickly. The selectable distance range is 1-99 miles.
Calorie setting:
In standby mode, press the M button on the console or remote control 3 times, and then adjust the number
of calories you wish to burn by pressing the +/- buttons. Adjustments made in units of 10 calories. Hold for
more than 0.5 seconds for the value to increase or decrease continuously. The selectable calorie burn range
is 20-990 calories.
3. How to turn on the treadmill
Once you've set up your desired program, press the Start button on the console (or the Start/Stop button on
the remote control) and the running belt will begin moving at 0.5mph in 3 seconds
4. How to adjust the treadmill speed
To change the speed of the running belt, you can press the +/- buttons on the console or remote control.
Pressing the button once will adjust speed by 0.1 mph; holding the button will allow counter to roll quickly.
5.How to pause/restart the treadmill
Press Stop button on the console or the Start/Stop button on the remote control while running belt is in
motion and the treadmill will slow down slowly and return to pause mode.
In the pause mode, press Start button on the console or the Start/Stop button on the remote control and the
running belt will begin moving at the previous selected program.
6. How to turn o󰀨 the treadmill
When the treadmill is suspended, press the Stop button on the console or the reset button on the remote
control, the treadmill will slowly stop and return to the standby mode.
