REDRAGON H818 Technical manual

H818 2.4G Wireless gaming headset
Operation Instruction
1. Contents in package
A, Pelops Headset -----------------------------------1PCS
Transmitter -----------------------------------1PCS
C, TYPE-C USB-USB cable -------------------------------1PCS
D、3.5(4P)-3.5(4P) Audio cable ---------------1PCS
2. Headset and transmitter instruction
Transmitter buttons and indicators
① Working indicator
② Mute indicator
③ USB plug
Remark:
Red/Blue LED flashes :Disconnecting；
Blue LED ON：Connected, Microphone is ready；

Red LED ON: Microphone mute；
Red LED flashes: Headset out of power
Pelops headset button instructions
1、Volume +
2、Volume -
3、Stereo, Virtual 7.1 mode switch button
4、Press and hold for 3 seconds to pair/ press and hold for 1 second to microphone mute
or ON switch
5、AUX 3.5mm headset port
6、Charge indicator /working indicator
7、Type-C charging port
8、Power button (Turn OFF when headset in wired connecting)
3. How to charge
Please plug Type- C USB-USB Cable to charging port on headset，then the plug
another port of cable into USB port(DC 5V) for charging，the indicator at charging
port will be light ON in red, the charging time will be 5 hours.

4. How to pair：
1）Turn off the headset and transmitter.
2）Turn on headset, flashes indicator light ON .
3）Press and hold headset pairing button for 3 seconds, flash indicator light ON.
4）Turn on transmitter(plug the transmitter into PC ,PS4)
5）Headset and transmitter pairing automatically, indicators light On in blue.
5.Headset operation：
1）Connect transmitter to PC/PS4 , indicator light ON and flashes.
2）Turn on headset, it will pair to transmitter automatically, indicators on headset and
transmitter lighting steady ON while pairing successful, the indicators flash when failed
to pairing.
3）Press Volume+/- for adjustment.
4）Microphone default ON. To turn off microphone, press pairing/mute button (indicator
light on in Red), then press it again (Indicator light on in blue).
5）Headset is default in stereo sound, press button 3 to switch virtual 7.1sound, headset
has tone of “di “ one time for indication ,press it again to switch back stereo sound,
headset has tone of”di”twice for indication.
6）Low power indicator flash light ON in red when headset power down to 3.5V, headset
and transmitter send alarm , headset indicator flash in blue, transmitter indicator flash in
red, please charge in time.
6. Connecting to PS4 ：
(PS4)
1）Plug transmitter type C into PS4 , and fix it tight to avoid connecting port lose.

2) PS4 output audio settings
6.2.1)Find “settings” on main menu
6.2.2) Find “Device” in settings
6.2.3)Find “Audio devices” in Device
6.2.4)Find “Output to headphones”in Audio devices
6.2.5)Click “All audio” from Output audio

7. Connecting to Xbox ONE
(Xbox ONE)
1）Connect headset to game pad of Xbox ONE by 3.5 audio cable(E) , the headset
now is turn to wired connecting status, power control button will be out of work.
2) X BOX ONE output audio settings：
7.2.1) Click “All settings” in main menu

7.2.2)Click“Display & sound” in settings
7.2.3)Click “Volume”
7.2.4)Click “Chat mixer” for setting

7.2.5)Click “Do nothing”
8.Connecting to PC

1) Plug the USB adaptor to transmitter(B+C), then plug it into computer, make sure no
any mental objects between transmitter and headset
2) Windows OS setting (For example Win 7)
8.2.1) Turn on headset, pair to computer via the transmitter, the indicator will be light on,
play music from PC , if there is no sound, find the desk of PC , click digital output
of the task bar at right down of desk as picture 1, click it by mouse right button, shows
sound device settings as picture 2,
Picture 1 Picture 2
8.2.2)Click “play” by mouse left button as picture 3, choice “2.4G wireless headset” as
picture 4, click it to set the headset as “default devices” at picture 5 .
picture 3 picture 4 picture 5
8.2.3) Click” Record” as picture 6, then choice “2.4G wireless mouse” at microphone
setting as picture 7, click “2.4G wireless mouse” as default device.
picture 6 picture 7 picture 8

9. Specification
Transmitter
Working voltage：5V
Frequency range：2403MHz-2477MHz
Delay time：24mS
Transmitting power：+2 dBm
Wireless working range: 10M
Receiving sensibility ：-85dBm
Headset
Battery working time：≥12h
Charging time： ≈5h
Frequency range：2403MHz-2477MHz
Delay time：24ms
Transmitting power：+2 dBm
Wireless working range: 10m
Receiving sensibility：-85dBm
Drive size：Ф40mm
Drive impedance ：32Ω
Frequency range: 20～20KHz
Microphone size :6*2.7mm
Microphone sensibility: -58dB
Microphone direction:
Microphone frequency response: 100Hz-8KHz
FCC Warning Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This device
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this device does cause harmful interference to radio or television reception, which can be
determined by turning the device off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the device and receiver.
--Connect the device into an outlet on a circuit different from that to which the receiver is

connected.
--Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment
