Redrock J130913 User manual

PART NUMBER J130913
FITS Jeep Wrangler JK
07-17
Hi-Lift Jack Hood Mount Bracket
Installation Instruct ions
KEY TO COMPONETS
A. 2 ea. Mounting bracket
B. 2 ea. U brackets
C. 2 ea. Wing nuts
D. 1 ea. Velcro strap
E. 2 ea. M10x1.0x40mm button head bolt
F. 4 ea. M8x1.25x30mm button head bolt
G. 4 ea. M8 flat washer
H. 4 ea. M8 split washer
I. 2 ea. M10 flat washer
J. 2 ea. M10 split washer
TOOLS NEEDED
10mm socket
#2Philip’s head
screw driver
A
Page 1
Please take a few minutes to read and thoroughly familiarize yourself with the installation procedures outlined
in this manual. Following the steps as outlined will save you time and help reduce mistakes. Once the
instructions are reviewed, if you feel that you are not capable of safely installing the parts seek the help of a
qualified installation expert to help you complete the job. The manufacture is in no way responsible for any
personal injury or vehicle damage that may occur during the installation.
.
California Propos
ition
65
Warning!
This product may contain lead a chemical known to the State of California to
cause cancer and birth defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov.
B C
E F G
H
D
I J

NOTE: Only applicable for 4 door Jeep.
Step 3.
Place a supplied M8x1.25x30mm button head bolt with
supplied M8 flat washer (G) and supplied M8 split washer
(H) through the hole in the bracket through the hole in the
hood hinge onto factory hood. Repeat step for remaining
bolt. Once all hardware is installed tighten down all
hardware. Repeat step 1-3 for remaining bracket.
Page 2
Step 1.
Using a T-50 torx bit locate and remove two factory bolts
on the hood. Discard factory hardware.
INSTALLING BRACKET ON HOOD HINGE
Step 1.
Using a T-50 torx bit locate and remove two factory bolts
on the door hinge. Discard factory hardware.
Step 2.
Place supplied mounting bracket (A) onto Jeep. Line up
the bracket holes with the holes in the hood hinge holes.
INSTALLING BRACKET ON REAR DOOR HINGE

Page 3
INSTALLING BRACKET ON REAR DOOR HINGE continued
Step 1.
Place supplied mounting bracket (A) onto Jeep. Line up
the bracket holes with the holes in the door hinge holes.
Step 2.
Place a supplied M8x1.25x30mm button head bolt with
supplied M8 flat washer (G) and supplied M8 split washer
(H) through the hole in the bracket through the hole in the
door hinge onto factory hood. Repeat step for remaining
bolt. Once all hardware is installed tighten down all
hardware. Repeat step 1-3 for remaining bracket.
This completes the installation.
