Redsbaby Jive User manual

1
Redsbaby Jive
Instruction Manual
®

2
Contents
General instructions 3
Warranty information 4
Warnings and safety precautions 6
Features and components 8
Assembly instructions 9
Frame 9
Brake component 9
Rear wheels 9
Front swivel wheels 10
Bassinet 10
Seat and bumper 11
Basket 11
Using your Redsbaby Jive 12
Folding and unfolding 12
Engaging and releasing the brake 13
Locking the front swivel wheels 13
Adjusting the handle 13
Using the 5-point safety harness 14
Reversing and reclining the seat 15
Using the tether strap 15
Lifting and carrying your Redsbaby Jive safely 15
Product Care 16

3
General Instructions
This document contains important information and must be kept for
future reference.
Please read thoroughly before commencing assembly and use of your
Redsbaby Jive. Incorrect assembly and use can be dangerous and result
in serious injury or even death.
There may be slight variations in the design of your product to that shown
in the images of this instruction manual.

4
Warranty information
12 Month Warranty
The Redsbaby Jive and its accessories come with a 12 Month Warranty
to cover against faults in materials and workmanship when your products
are used under normal conditions, according to our user manuals and
technical specications.
Our goods come with guarantees that cannot be excluded under
the Australian Consumer Law. You are entitled to a replacement or
refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and
the failure does not amount to a major failure.
The 12 Month Warranty period starts from the date your product(s)
are dispatched from our warehouse. This includes products that are
purchased via pre-sale (for example items that are out of stock or newly
launching products). Please remember that for a claim to be valid, it must
be made within the claims period.
There are a few circumstances under which the warranty is not valid
including:
- defects resulting from improper care or use;
- normal wear and tear, including scratches to the pram frame;
- products that are purchased second hand or from an unauthorised
distributor;
- faulty or incorrect assembly;
- using a part or accessory that is not compatible with the product and/or
not manufactured by Redsbaby;
- tyre punctures; and
- damage to handlebar grips or fabrics as a result of normal handling and
daily use.
For a full list of what is covered and what is excluded from the warranty,

5
please read our Terms and Conditions at www.redsbaby.com.au. Please
ensure you follow the assembly instructions, which can be found in this
instruction manual.
How To Make A Warranty Claim
Send an email to [e-mail] to notify us of your warranty
claim. To validate your warranty claim we will require you to include in
your email:
- a description of the warranty defect including photographs;
- your contact details;
- attached invoice with order number; and
- product batch number (the batch number is printed on a sticker that
is located at the bottom of your pram frame, near the brake).
We will respond to your warranty claim within 7 business days and
depending on the nature of the warranty claim, arrange collection of
the product from your nominated address. Collection will take place on
a business day (i.e. not a public holiday or weekend within your state
or territory) between 7am and 5.30pm. Please take care to repack the
product in secure and stable packaging to avoid any damage occurring
in the returns transit. We do not take responsibility for any damage that
occurs in transit to and from our pram repairer.
Once our pram repairer has received the product they will inspect
and conrm the reported defect. We will then contact you with further
information surrounding the repair such as the estimated turn around
time.
If you have any questions, you can contact us at [e-mail].

6
Warnings and safety precautions
Please read the following warnings and safety precautions thoroughly
before using your Redsbaby Jive. Incorrect assembly and use can result
in serious injury or death.
Always follow safety instructions for assembly, folding and use.
Always ensure that your Redsbaby Jive is correctly assembled and locks
are engaged before use.
After unpacking, immediately discard any plastic wrapping and
packaging materials, as these can lead to a choking hazard.
Always use the safety features that come with your Redsbaby Jive, such
as the tether strap, brakes and harness.
GENERAL WARNINGS:
• To avoid injury or death: Always apply the brakes whenever the
Redsbaby Jive is stationary.
• Do not leave children unattended.
• Secure the child in the harness at all times.
• Do not carry extra children or bags on the Redsbaby Jive.
• Make sure children are clear of any moving parts if you adjust the
Redsbaby Jive, otherwise they may be injured.
• Follow the manufacturer’s instructions.
• Put on all the brakes whenever you park the Redsbaby Jive.
• Use the harness at all times.
• When not in use disconnect shoulder straps from the waist strap and/or
buckle.
• The harness can form loops which may cause a strangulation hazard.
Never leave a harness connected when not tted to a child in the
Redsbaby Jive.
• Use the tether strap to stop the Redsbaby Jive rolling away.
• Do not use the seat or bassinet with any other models of stroller.
• Do not use bassinet once the child can sit up unaided.
• Only use the bassinet in the at position. Do not recline.
• Do not use any accessories that are not designed for or compatible with
the Redsbaby Jive.

7
• Take care when used on stairs or escalators.
• Do not use or leave the Redsbaby Jive near open re or exposed ame.
• Brakes must always be applied when the Redsbaby Jive is not moving.
GENERAL SAFETY
PRECAUTIONS:
• When the vehicle is being folded and unfolded, there is potential
for ngers or parts of the body to be injured and due care should be
exercised.
• Overloading, incorrect folding or the use of non-approved accessories
may cause injury or damage your Redsbaby Jive.
• Ensure you follow the regular maintenance and care instructions
included in this manual. Pay special attention to maintenance and care of
the brakes.
• The Redsbaby Jive must only be used for one (1) child.
• Do not hang bags on the Redsbaby Jive handles, as this can cause it to
become unstable.
• Do not lift or carry the Redsbaby Jive when a child is in it.
• Do not lift or carry the Redsbaby Jive when fully assembled. Only lift and
carry when folded.
• The Redsbaby Jive is designed for use on at or gentle sloping surfaces
and may be unstable on higher sloping and uneven surfaces. The vehicle
may tip over when used incorrectly on steep inclines/declines.
• Do not leave the rain cover on without the ventilation window on the
front of the rain cover open.
• When using your Redsbaby Jive on stairs or escalators, take care.
MAXIMUM WEIGHT LIMITS:
• Maximum weight for a child in the bassinet is 9kg (19.8 lbs).
• Maximum weight for a child in the seat is 20kg (44.1 lbs).
• Maximum weight for items in the basket is 5kg (11 lbs).

8
Features and components
1
2
3
4
5
6
7
8
9
10
11
14
1. Adjustable
handle
2. Canopy
3. Frame fold
latches
4. Bumper bar
5. Frame
6. Fold lock
7. Seat unit
8. Circular frame
9. Adjustable foot
rest
10. Brake
11. Front swivel
wheels
12. Basket
13. Rear wheels
14. Bassinet
13
12

9
Assembly instructions
Frame
To release the frame from the folded position:
1. Place frame on the ground and position yourself behind the handle bar.
2. Release the automatic frame lock located on the left hand side of the
frame.
3. Holding the frame on both sides, gently lift the frame continuing until
the frame locks into place. When the frame has been fully opened, you
will hear and feel a rm ‘click’.
Brake component
The brake will come permanently assembled on your pram frame and
is located at the bottom of the frame in the right hand side and is red in
colour.
Rear wheels
Fit the rear wheels by clicking them into rear wheel housing located at
the back of the pram frame. You will hear and feel a rm ‘click’ when the
wheels are locked in place.
IMPORTANT: Ensure you check that the wheels are clicked in correctly
by tugging them outwards. Failure to attach the wheels correctly will
result in them falling o the pram while in use.
To remove, simply press the button in the middle of the wheel to release.
1
2

10
Front swivel wheels
Fit the front swivel wheels by inserting them into the front wheel housing
located at the front of the frame. You will hear and feel a rm ‘click’ when
the wheels are locked in place.
Assembling the bassinet
Note: The Jive Bassient will come in a separate carton to your Jive pram.
1. Pull the three support rods located in the bottom of the bassinet into
place by following step 1A, 2A and 3A below. Once assembled correctly,
your bassinet will sit rigid and upright.
2. Assemble the bassinet lining on the bassinet frame.
3. Insert your bassinet mattress into the bottom of the bassinet snugly.
4. Secure your bassinet apron by using the press studs located on the
bassinet canopy.
TIP! You can open the apron using the zippers rather than unbuttoning
the apron from the canopy each time.
5. Secure the bassinet adaptors in the pram frame.
6. Click the bassinet into the adaptors. Check the bassinet is secured by
lifting it upwards when in the pram frame.
7. To remove, lift and release the locks on either side of the bassinet.
WARNING:
• Do not use bassinet once the child can sit up unaided.
• This bassinet is only approved for use with model Redsbaby Jive.
• The maximum weight of a child that can be carried in this bassinet: 9kgs.
1A 1B 1C

11
Assembling the seat and bumper
1. Take the seat unit fabric and stretch the head rest section over the top
of the circular frame and secure the Velcro tab located at the back.
2. Pull the rest of the seat unit fabric tightly towards the bottom of the
frame. Secure the seat unit fabric to the frame using the press studs
provided down the left and right hand sides of the circle frame.
3. Pull the foot rest upwards and secure the bottom of the seat unit fabric
over the foot rest and attach the Velcro tab located under the foot rest.
4. Attach the bumper by aligning the ends of the bumper with the two
openings on the circular frame. Gently push down into place until you
hear and feel a rm ‘click’ on both sides.
5. If desired, attach the canopy.
6. To place the seat on the frame, push down gently until you feel and
hear a rm ‘click’.
Basket
1. Secure the basket to the frame using the press studs provided.
2. Loop the webbing located at the rear of the basket around the frame,
and fasten using the press studs provided. Repeat using the webbing
located on the left and right sides of the basket by securing to the side of
the pram frame.
To remove, release all press studs.
WARNING:
• The weight limit of items in the shopping basket is 5kg.
• Do not exceed the weight limit. Overloading the shopping basket may
result in damage to the basket and your stroller.
WARNING:
• Do not use this seat with any other models of stroller.
• This seat is only approved for use with model: Redsbaby Jive.
• The maximum weight of a child that can be carried in this seat: 20kgs.

12
Using your Redsbaby Jive
Folding and unfolding the Redsbaby Jive frame
To release the frame from the folded position:
1. Release the the frame fold lock on the left hand side of the frame.
2. Holding the frame on either side, gently lift the top half of the frame and
place on the ground.
3. Continue to lift the handle until the frame fold locks engage.
IMPORTANT: When the frame fold locks have been engaged correctly
and the frame has been fully opened, you will hear and feel a rm ‘click’.
To fold the frame
1. Remove the bassinet or seat unit if attached to the frame.
2. Simultaneously pull back on the frame fold locks on the left and right
hand side of the frame.
3. Gently fold the frame forwards and downwards until the frame fold
latches automatically engage.
Note: The frame fold latch will engage automatically.
4. Turn the handle bar inwards by pressing the buttons located on either
side simultaneously.
Tip: You can also fold the Redsbaby Jive with the seat connected in the
fully upright and forward-facing position.
Safe lifting and carrying of the Redsbaby Jive frame when folded
IMPORTANT: Do not lift or carry the Redsbaby Jive when a child is in it.
IMPORTANT: Do not lift or carry the Redsbaby Jive when fully assembled.
Only lift and carry when folded.
1. Always lift and carry the frame using two hands.
2. Ensure the frame fold locks are engaged.
WARNING:
• Make sure children are clear of any moving parts when you adjust the
Redsbaby Jive, otherwise they may be injured.
• Ensure the frame fold locks are engaged correctly before placing a child in
the Redsbaby Jive.

13
Engaging and releasing the brake
The brake is located next to the right rear wheel of the Redsbaby Jive.
The brake is identied by its red colour.
1. To engage the brake, press downwards and backwards on the brake
until you feel and hear a ‘click’.
2. To release the brake, press your foot forwards on the brake in the
opposite direction until the brake lock disengages.
IMPORTANT: Ensure you have disengaged the brake completely before
pushing your pram. If you hear a clicking sound, double check the brake
lock isn’t clicking on the rear wheel. It can be helpful to push your heel
downwards on the brake in the released position rmly to ensure the
brake lock is not touching the rear wheel.
Locking the front swivel wheels
1. Press downwards on the buttons located on top for the front wheel
housing until you hear and feel a ‘click’.
2. Push the Redsbaby Jive forwards until you hear a second click in both
front wheels.
2. To unlock, simply press the buttons again. When released successfully,
you will hear and feel a ‘click’.
Adjusting the handle
Simultaneously press the buttons located on either side of the handle and
move the handle to the desired height.

14
Using the 5-point safety harness
WARNING:
• Use the harness at all times.
• When not in use disconnect shoulder straps from the waist strap and/
or buckle. The harness can form loops which may cause a strangulation
hazard. Never leave a harness connected when not tted to a child in the
Redsbaby Jive.
IMPORTANT: For the safety of your
child the 5-point safety harness must
be properly tted and adjusted. Follow
the instructions and Figure 1 below.
1. Ensure the seat is assembled correctly
by following steps on page 11.
2. Slide the shoulder strap clip (A1) onto
the waist strap clip (B1) and clip into the
center buckle (C).
3. Slide the shoulder strap clip (A2) onto
the waist strap clip (B2) and clip into the
center buckle (C)
Note: The shoulder heights can be
adjusted according to your child’s height
by feeding the shoulder straps through
the seat back. The shoulder straps
should sit just above the shoulders of
your child.
4. Adjust the shoulder strap (A1) and (A2), waist straps (B1) and (B2) and crotch
strap (D) to the desired t.
5. To unlock the 5-point safety harness, simply press the button in the middle of
the centre buckle (C) to release all straps at once.
Note: Padding has been provided for the shoulder straps (A1) and (A2) and
crotch strap (D) for the comfort of your child. The use of this padding is optional.
Figure 1
A1 A2
B1 B2
C
D

15
Reversing and reclining the seat
IMPORTANT: Do not reverse or recline the seat when a child is in the
seat.
1. To recline, press and hold both round buttons on the inside of the seat
and move into the desired position. When in place, you will hear and feel
a rm ‘click’.
2. To reverse, remove the seat unit by pulling the tabs located on either
side of the seat unit inwards and lift upwards. The seat unit can be tted
either rear or forward facing.
Using the tether strap
Attach the tether strap to your wrist at all times when using the Redsbaby
Jive.
Lifting and carrying the Redsbaby Jive safely
IMPORTANT: Do not lift or carry the Redsbaby Jive when a child is in it.
IMPORTANT: Do not lift or carry the Redsbaby Jive when fully
assembled. Only lift and carry when folded. For folding instructions, refer
to page 12.
WARNING:
• Use the tether strap to stop the Redsbaby Jive rolling away.

16
Product care
IMPORTANT: Ensure you follow the regular maintenance and care
instructions. Pay special attention to maintenance and care of the brakes.
General Maintenance
• Regularly inspect the locking devices, brakes, harness assembly, catches,
seat adjusters, joints and xings to ensure they are secure and in full
working order.
• Do not store your Redsbaby Jive in your car boot for prolonged
periods of time, especially when it is hot and this can lead to warping
some of the plastics parts and reduce the life of your product.
• The brakes and wheels are subject to wear and should be replaced as and
when necessary. Brakes are available through contacting our customer care
team at [e-mail].
• Should any parts of the Redsbaby Jive become stiff or difcult to operate,
ensure that dirt is not the cause. Use a light application of a silicone spray
lubricant, ensuring the lubricant penetrates between the components. Use
sparingly, as excessive application may encourage the accumulation of dirt.
Regular light lubrication of moving parts will extend the life of your Redsbaby
Jive and make operating, opening and folding much easier.
• Do not leave the Redsbaby Jive in sunlight for prolonged periods of time,
as the colour of some fabrics may fade.
• Store the Redsbaby Jive in a dry, well-ventilated and safe place.
• Do not use your Redsbaby Jive if any screws are loose or missing or if any
component is damaged.
Cleaning
Plastic and metal parts
• Sponge clean with warm water and a mild detergent and then air dry.
• Do not use any abrasive or corrosive cleaning products on your Redsbaby
Jive.
Fabrics
• May be cleaned by sponging lightly with warm water and a mild soap
(ensure your child is not allergic to the soap you use). Then air dry.
• For more instructions, follow the care labels on each fabric item.
IMPORTANT: Do not place any fabric or other component of your Redsbaby
Jive in the dryer. Allow all parts to dry thoroughly before storing.

17

18
YOUR REDSBABY JIVE
©Copyright 2013-2015 Redsbaby
‘Redsbaby’ is a registered Trademark of Redsbaby Pty Ltd.
ABN 31 167 364 178.
