Redwood Systems RG-2G-1RELAY User manual

Redwood Universal Gateway
Installation Instructions
Model No:
RG-2G-1RELAY
RG-2G-2RELAY
RG-2G-WH
The Redwood Universal Gateway turns on and o any light fixture type (e.g.
fluorescent, CFL, HID, LED, etc.). Installed on or next to each fixture, the Gateway
provides output signals to control one or two external dry contact relays. It
receives low-voltage power from, and communicates with, the Redwood Engine
via low-voltage cable. The Gateway does not require a Redwood Ready fixture
and will work with any fixture. It connects to a Redwood Sensor that transmits
data back to the Redwood Engine.

2
Redwood Universal Gateway Installation Instructions
Specifications
MECHANICAL
•Dimensions: 3” (76.2 mm) W x 1.2”
(30.5 mm) H x 4.2” (106.7 mm) D
•Weight: 0.25lbs (0.11kg)
•For indoor use only
•Operating temperature: 32°F to
122°F; 0°C to 50°C
•Storage temperature: –4°F to 140°F;
–20°C to 60°C
•Operating humidity: 10% to 80% RH
non-condensing
•Storage humidity: 5% to 95% RH
non-condensing
ELECTRICAL/DATA
•Input/output to Redwood Engine:
one channel via either RJ45 or 18
AWG, field terminated, 2 conductor
unshielded cable
•Input/output to Redwood Sensor:
RJ25 connector
•Outputtorelay1andrelay2:
pigtail wires
•InputfromClass2contactclosure*
•Nominalpowerconsumption:
500mW
COMPLIANCE
•Class 2 electrical device
•FCC Part 15 Class A
•UL/cUL listed–File E336145
•CE compliant
•T-Mark compliant–Certificate
No.T72120409
•C-Tickcompliant:AS/NZSCISPR
22:2009
•Environmental: IEC 60950;
Pollution Degree 2
•RoHS compliant
•Designed for California Title
24-2008 compliance
•Made in the U.S.A.
*Thecontactclosureinputcanbeusedforanumberofdierentapplications.PleaseseeyourlocalRedwoodrepresentativeformoreinformation.
Preparation
•Determine location for all fixtures, Redwood Dimmers,
and Redwood Engines
•Lay low-voltage cable from Redwood Engine location
to each fixture location
•Options for connector preparation
º If using 18AWG wiring to connect to the Redwood
Engine, strip wire ends to ¼" (6mm)
º If using the RJ45 connector, it can be wired as T568A
or T568B which are straight through or crossover
arrangements
•Install 3rd party light fixtures according to vendor’s
installation instructions
Wiring Diagrams
Blu
N/C
Yel
Comm
Org
N/O
CONTROL
CIRCUIT
Blk
120 - 277 Vac
Red
Neutral or Other Phase
Wht/Blu
Wht/Red
{
{
Wht/Blu
Wht/Red
REDWOOD UNIVERSAL
GATEWAY WIRING
HARNESS
REDWOOD
UNIVERSAL
GATEWAY
REDWOOD
ENGINE
Connect the
N/O and Comm
relay wires in
series with load
{
AC POWER
DRY CONTACT INPUT
Dry Contact
Relay
Blu
N/C
Yel
Comm
Org
N/O
CONTROL
CIRCUIT
Blk
120 - 277 Vac
Red
Neutral or Other Phase
DRY CONTACT INPUT
Wht/Blu
Wht/Red
{
{
Blu
N/C
Yel
Comm
Org
N/O
CONTROL
CIRCUIT
Blk
120 - 277 Vac
Red
Neutral or Other Phase
DRY CONTACT INPUT
Wht/Blu
Wht/Red
{
{
REDWOOD UNIVERSAL
GATEWAY WIRING
HARNESS
REDWOOD
UNIVERSAL
GATEWAY
Wht/Blu
Wht/Red
Blu/Wht
Red/Wht
DRY CONTACT INPUT
DRY CONTACT INPUT
REDWOOD
ENGINE
AC POWER
Connect the
N/O and Comm
relay wires in
series with load
{
Connect the
N/O and Comm
relay wires in
series with load
{
Dry Contact
Relay
Dry Contact
Relay
Sample Single Dry Contact Relay Sample Dual Dry Contact Relay
[4.2 in]
106.7
mm
[1.2 in]
30.5mm
[3.0 in]
76.2
mm
SPRING LOADED
TERMINAL CONNECTOR
TO ENGINE
RJ45 CONNECTOR
TO ENGINE
RJ25 CONNECTOR
TO SENSOR
REDWOOD UNIVERSAL GATEWAY WIRING
HARNESS CONNECTOR
TO FIXTURE
Redwood Universal Gateway dimensions and connections

3
Redwood Universal Gateway Installation Instructions
• Confirm the correct type of Gateway is being installed
with a Dry Contact Relay. See diagrams below and
confirm correct Gateway is being used for fixture
installation.
• Recommend using an RIB Dry Contact Relay or
equivalent, for example, an RIB 21CDC.
• Please be certain that the fixture you are controlling
can accommodate the type of control you are using;
magnetic metal halide fixtures for instance have
extended hot restart time which could be problematic
in critical areas where the light might not reignite for
an extended period. Instant start ballasts may not be
suitable for frequent switching.
• DoNOTplacetheGatewayinalocationwhereitwill
get hotter than 50°C.
• Check that you used the Redwood supplied RJ25 cable
that came with the Sensor for connecting the Sensor to
the Gateway.
• When the product is installed in air-handling spaces,
such as above some suspended ceilings, the cabling
employedshouldbesuitableunderNEC(2008)Article
800.154 and marked accordingly for use in plenums and
air-handling spaces with regard to smoke propagation,
such as CMP. The products and wiring means should
be installed in accordance with all applicable local
regulations and practices.
• The Redwood Gateways have been tested by UL
to UL2043 which ensures low smoke-emitting
characteristics and suitable fire resistance for equipment
that may be installed in environmental air handling
spaces,asdescribedinArticle300.22(c)oftheNEC
(2008).
Step 2: Connect the Dry Contact Relay to the Universal Gateway using the provided Redwood Universal Gateway
Wiring Harness.
Step 3: Connect the Universal Gateway to the Sensor with the RJ25 connector.
Step 4: The Gateway should be securely mounted to part of the building structure that does not exceed the mechanical
specicationsfortheGateway.NotethattheGatewaymustbewithin6feetoftheSensorandlightxture.
18AWG, 2 CONDUCTOR
CABLES TO
REDWOOD ENGINE
RJ45 TERMINATED
CABLES TO
REDWOOD ENGINE
RJ25 TERMINATED
CABLE TO SENSOR
RJ25
TERMINATED
CABLE TO
SENSOR
REDWOOD UNIVERSAL
GATEWAY WIRING HARNESS
TO RELAYS
REDWOOD UNIVERSAL
GATEWAY WIRING HARNESS
TO RELAYS
Universal Gateway Wiring Harness Wire Assignments
Signal
Color
Relay 1_a
White/blue
Relay 2_a
Blue/white
Sw out
Yellow
Relay 1_b
White/red
Relay 2_b
Red/white
Sw in
Yellow
Universal Gateway Assembly Diagram — Category Cabling Universal Gateway Assembly Diagram — 18AWG Cabling
RG-2G-XXXXX
UNIVERSAL GATEWAY MODELS
RG-2G-2RELAY
2 RELAY FIXTURE
RG-2G-1RELAY
1 RELAY FIXTURE
Redwood Universal Gateway models for fixture installation
Installation Instructions
For Category Cabling
Step 1: Connect the Universal Gateway to the Redwood
Engine with RJ45 connector for category
cabling. Proceed to Step 2.
For 18AWG Wiring
Step 1: Connect the Universal Gateway to the Redwood
Engine using the wire clamp connections to insert
low-voltage 18AWG wiring. Proceed to Step 2.
IMPORTANT NOTE

Redwood Systems |www.redwoodsystems.com |© 2014. Redwood Systems, Inc. All rights reserved.
All other trademarks are the property of their respective owners.
011014 4
Redwood Universal Gateway Installation Instructions
RJ45 CHANNEL
CABLE TO ENGINE
REDWOOD UNIVERSAL
GATEWAY WIRING
HARNESS
REDWOOD
SENSOR CABLE
CEILING
SUSPENSION WIRE
Z-CLIP
CUSTOMER SUPPLIED
TIE WRAPS
REDWOOD SENSOR
CABLE
REDWOOD UNIVERSAL
GATEWAY WIRING
HARNESS
CUSTOMER SUPPLIED —
APPROPRIATE FASTENER
FOR MOUNTING SURFACE
TYPE
RJ45 CHANNEL
CABLE TO ENGINE
ANY TYPE
MOUNTING SURFACE
Mounting Options for Redwood Universal Gateway — Drop Wire and Surface Mount
For drop wire mounting: Recommend using Caddy®multifunctionZ-ClipPart#170650Description4Z34.Supports
#10-24and1/4-20threadedbridleringsandattachesto#12wirethrough¼"rod.
FCC CLASS A REGULATORY STATEMENT—UNITED STATES
Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed toprovide reasonable protec-
tion against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, andcan radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radiocommunications. Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct theinterference at his own expense.
FCC CLASS A REGULATORY STATEMENT—EUROPE AND AUSTRALIA
This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequatemeasures.
LIMITED WARRANTY
Redwood warrants during a warranty period of twelve (12) months from delivery that the products as delivered shall be free of material defects and shall conform in all material respects to Red-
wood’s applicable specifications as set forth in this documentation. As Redwood’s sole and exclusive obligation and Buyer’s sole and exclusive remedy for material breach of the foregoing
warranty, Redwood shall, at its option and in accordance with its standard RMA procedures, refund the purchase price, or repair or replace the nonconforming products, provided proof of pur-
chase and written notice of non-conformance are received by Redwood within the warranty period. This warranty shall not apply to products that Redwood determines have been subjected to
testing for other than specified electrical characteristics or to operating and/or environmental conditions in excess of the maximum values established by Redwood, or have been the subject of
mishandling, misuse, neglect, improper repair, alteration, damage, assembly, or processing that alters physical or electrical properties, or have been damaged in transit. This warranty excludes
all costs of shipping, customs clearance and related charges outside the contiguous 48 United States and Canada. In the event no defect or breach of warranty is discovered by Redwood upon
receipt of returned products, the products will be returned at Buyer’s expense. Any repair or replacement provided to Buyer will not extend the warranty period for the products in question.
Excluded from the foregoing warranty are parts defined by Redwood as “consumable.”
DISCLAIMEROFWARRANTY.THISWARRANTYEXTENDSTOBUYERONLYANDNOTTOBUYER’SCUSTOMERSORUSERSOFBUYER’SPRODUCTSANDISINLIEUOF,ANDREDWOODEX-
PRESSLYDISCLAIMS,ALLOTHERWARRANTIES,WHETHEREXPRESS,IMPLIEDORSTATUTORY,INCLUDING,BUTNOTLIMITEDTO,ANYWARRANTIESOFMERCHANTABILITY,FITNESSFOR
APARTICULARPURPOSE,TITLEANDNON-INFRINGEMENT.Thiswarrantyshallnotbeenlarged,andnoobligationorliabilityshallariseoutofRedwood’srenderingoftechnicaladvice,facilities
or services in connection with the delivery of the products. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Some states do not
allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
Relays
Redwood recommends RIB Dry Contact Input Relays
from Functional Devices
Ordering Information
PhoneNumber:(510)270-5360(SelectOption1)
SKU Number Description
RG-2G-1RELAY Redwood Universal Gateway for 1 relay
RG-2G-2RELAY Redwood Universal Gateway for 2 relays
RG-2G-WH Redwood Universal Gateway Wiring Harness
Contact Information
Redwood Systems
3839 Spinnaker Court
Fremont, CA, 94538
1-800-840-0709 (USA)
1-510-270-5360 (International)
www.redwoodsystems.com
www.commscope.com
support@redwoodsystems.com
For RoHS Inquiries:
CommScope Inc.
Corke Abbey, Bray
Co. Dublin, Ireland
Attn: Legal Department
