Reebok One Series User manual

ONE SERIES
GB40s BIKE
ASSEMBLY GUIDE / CONSOLE GUIDE
ΣΥΝΑΡΜΟΛΟΓΗΣΗ / ΟΔΗΓΙΕΣ ΧΡΗΣΗΣ

GB40s
BIKE ASSEMBLY GUIDE
2

REEBOKFITNESSEQUIPMENT.COM
B580
Screwdriver (1)
Box Spanner(1)
Allen Key(1)
Acorn Nut forM8 Bolt (2) M-2
CurvedWasher φ8*φ19 *2T (2) M-3
Allen Bolt M8*16L (4) M-4
Carriage Bolt M8*75L(2) M-1 Manual
Washerφ12*φ19*1T (4) M-5

GB40s
BIKE ASSEMBLY GUIDE
4
1
Allen Bolt M8*16L (4) M-4
Washerφ12*φ19*1T (4) M-5
2
3 4

REEBOKFITNESSEQUIPMENT.COM
Box Spanner(1)
Acorn Nut for M8 Bolt (2) M-2
Curved Washer
φ8*φ19
*
2T
(2) M-3
Carriage Bolt M8*75L(2) M-1
5
Box Spanner(1)
6
Box Spanner(1)
7

GB40s
BIKE ASSEMBLY GUIDE
6
Exploded view

REEBOKFITNESSEQUIPMENT.COM
ITEM DESCRIPTION Q'TY ITEM DESCRIPTION Q'TY
A GB40s Console SM2705-67 1 F-3 Sin
g
le wheel 1
A-1 Screw M5*P0.8*10L 4 F-4 Pulle
y
1
B Handlebar set 1 F-5 Bearin
g
6900RS 1
B-1 Foam grip 2 F-6 Bearin
g
6003RS 1
B-2 Hand
p
ulse set 2 F-7 Bearin
g
6203 1
B-3 Hand
p
ulse wire 1 F-8 Bearin
g
6300RS 1
B-4 Screw M4*20L 2 F-9 Flat washer 1
B-5 End ca
p
2 F-10 Star washer 2
B-6 Handlebar 1 F-11 Bushin
g
of fl
y
wheel 1
C Handlebar post set 1
F-12 Bushin
g
of fl
y
wheel 1
C-1 Sensor wire (Upper) 1
F-13 Flywheel 1
C-2 Screw M5*P0.8*20L 2
G Idler set 1
C-3 Handlebar
po
st
1
G-1 Idler wheel 1
D Main frame set 1
G-2 Nut M8 1
D-1 Nylon M8*P1.0*20L 2
G-3 Flat washer 1
D-2 Knob 1
G-4 Hex
ag
onal screw M8*P1.25*18L 1
D-3 Sensor wire 1
G-5 Wave washer 2
D-4 DC wire 1
G-6 Flat washer 1
D-5 Screw M4*10L 1
G-7 Hexa
g
onal screw M6*P1.0*12L 1
D-6 Sensor fixed bracket 1
G-8 Idler
sp
rin
g
1
D-7 Flat washer 1
G-9 Idler 1
D-8 Wave washer 1
H Ma
g
net set 1
D-9 Flat washer 1
H-1 Flat washer 2
D-10 C cli
p
1
H-2 Hex
ag
onal screw M6*P1.0*16L 2
D-11 Bearin
g
6203 2
H-3 S
p
rin
g
washer 2
D-12 Sleeve for seat
po
st 1
H-4 Ma
g
net 1
D-13 Left crank with ca
p
1
I Front stabilizer set 1
D-14 Ri
g
ht crank with ca
p
1
I-1 Front stabilizer
p
ad 1
D-15 Belt 1
I-2 Front stabilizer
p
ad 1
D-16 Left chain cover
(
u
pp
er
)
1
I-3 Screw 3/16' 2
D-17 Ri
g
ht chain cover
(
lower
)
1
I-4 Front stabilizer 1
D-18 Crank ca
p
2
J Rear stabilizer set 1
D-19 Screw M5*16 4
J-1 Ad
j
ust small
p
ad 2
D-20 Screw M4*50L 6
J-2 End ca
p
of stabilizer 2
D-21 Washer of handlebar
po
st 2
J-3 Screw 3/16' 4
D-22 Servo motor set 1
J-4 Rear stabilizer 1
D-23 Motor wire 1
K Seat
p
ost set 1
D-24 Screw M8*P1.25*20L 4
L Seat slider set 1
D-25 Semi washer 4
L-1 Fixin
g
screw bracket 1
D-26 Axle 1
L-2 Knob of seat 1
D-27 Hex
ag
onal screw M8*P1.25*1
2L
3
L-3 Flat washer 1
D-28 Pulle
y
1
L-4 End ca
p
2
D-29 Bushin
g
1
L-5 Seat slider 1
D-30 Pedal set 1
M Hardware kit set 1
D-31 Ca
p
of handlebar
po
st 1
M-1 Screw M8*P1.25*75L 2
D-32 Main frame 1
M-2 Nut M8 2
E Water bottle cage 1
M-3 Semi washer 2
F Flywheel set 1
M-4 Screw M8*16 4
F-1 Nut 3/8' 5
M-5 Flat washer 4
F-2 Flywheel ax
Semi washer
le 1
N Switching power adapter 1
O Seat set 1
B-7 2

ONE SERIES GB40s
CONSOLE GUIDE
8
RECOVERY
RECOVERY
RESET
ENTER
DOWN
UP
STOP / START
A
B
C
D
E
F
A
B
C
D
E
F
Enter / Mode Up
Recovery Down
Reset Start / Stop
COMPUTER FUNCTIONS
BUTTON FUNCTIONS
ENTER / MODE
When in a program used as a enter button to confirm
settings
RECOVERY
To test heart rate recivery
RESET
Used to reset the functions at any time.
Please note STOP must be pressesd before RESET
UP
To select training mode and adjust funtion value up
DOWN
To select training mode and adjust function value
down
START / STOP
To start or stop exercise

REEBOKFITNESSEQUIPMENT.COM
OPERATION PROCEDURE
When the power supply is connected to the machine the computer will powe on with a long beep sound.
All segments of the lcd display will light ip for 2 seconds and the wheel diameter 78” will be dosplayed as
below.
The Main menu will be displayed. The user can press START to begin immediately in the manual mode.
All values (SPEED, DISTANCE, TIME) will count up from zero. Resistance level can be changed at any time
during exercise by pressing UP or DOWN,
1
2
