Reecom Electronics R-200 User manual

FCC Information
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
In accordance with FCC requirements, changes or
modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to
operate this product.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
1. Reorient or relocate the receiving antenna;
2. Increase the separation between the equipment and receiver;
3. Connect the equipment into an outlet on a circuit different
from that to which the receiver is needed;
4. Consult the dealer or an experienced radio/TV technician
for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the condition that this device does not
cause harmful interference.
- 1 -
Model: R-200
User's Manual
Please read before using the Alert Radio
Weather / All Hazards Alert Radio
Reecom Electronics Inc.
S.A.M.E (Specific Area Message Encoding) Technology
http://www.reecominc.com

- 2 -
Table Of Contents
Installing the Back-Up Batteries -------------------
Powering up the Radio ------------------------------
Setting Time / Date ---------------------------------
1.1 Access to program Menu -------------------------
1.2 LCD Back Light ----------------------------------
1.3 Turn On the Radio --------------------------------
Turn Off the Radio -------------------------------
1.4 Review Stored County Codes ------------------
1.5 Review / Edit Event Blocking -------------------
1.6 Review Alert Message ---------------------------
1.7 Auto Key Lock -----------------------------------
1.8 Review Watched Channels ----------------------
1.9 Nap Timer ----------------------------------------
1.10 Alarm Clock -------------------------------------
1.11 Deactivate Alarm Clocks -----------------------
1.12 Turn Off the Radio ------------------------------
1.13 Receiving Alert Message -----------------------
National Weather Service (NWS) Test Signals
1.14 AUDIO OUT Socket ----------------------------
5
5
5
6
6
6
6
7
7
7
7
7
8
8
9
9
11
12
13
Event Message Table 1 ---------------------------------
Event Message Table 2 ---------------------------------
Non-Alert Message Table ------------------------------
10
10
10
Section 1: Operation
Getting Started ----------------------------------------- 5
Features ------------------------------------------------- 42.1 Setting Date / Time --------------------------------
2.2 Setting Channel / County --------------------------
2.3 Setting Alert Mode ---------------------------------
2.4 Setting Siren Volume ------------------------------
2.5 Setting Voice Volume ------------------------------
2.6 Setting Event Blocking ----------------------------
2.7 Setting Multi-Channel Watch ---------------------
2.8 Setting ALARM OUT Socket ---------------------
2.9 Siren Test -------------------------------------------
2.10 Setting LCD Back Light ---------------------------
2.11 Setting Auto Key Lock -----------------------------
2.12 Setting Key Tone On / Off -------------------------
15
16
18
19
19
20
21
22
22
23
23
23
24
Trouble Shooting ----------------------------------------
ONE YEAR LIMITED WARRANTY --------------------
Specification ---------------------------------------------- 25
26
Section 2: Setting Up the Radio
- 3 -

Features:
- S.A.M.E (Specific Area Message Encoding) Alert Technology
- Multi-Channel (WX) Watch in Standby Mode
- LED Indicators For Warning, Watch or Advisory / Statement
- Display Alert Message and Effective Time At a Glance
- Effective Time Auto-Count-Down Display
- Display the Number of Active Event
- LCD Back Light Display
- E.O.M (End Of Message) Detection
- Alert Mode: Voice EOM, Voice Timer, Siren or Alert Disable
- Defeat Siren Option
- Programmable Siren / Voice Volume Independently
- Digital Radio Volume
- 51 Event Memories for Alert Messages with Date/Time Log
- 26 County Memories for County Codes / SAME# Storage
- Display Real Time Clock / Calendar Date / Auto-Calendar
- Dual Alarm Clocks With Snooze Function
- Nap Timer - from 1 Minute to 2 Hours
- Alarm Out Socket For External Alarm System Such As X-10
- Audio Out Socket (Mono) For External Speaker System
- External Antenna RCA Jack For External Antenna
- Back-up Battery (4AA Size, Alkaline) For Emergency Power
(Battery Not Included)
- Battery Low Detection / Indication
- 4 -
Powering Up the Radio
Plug the supplied A/C adapter jack to the radio DC JACK.
Then, plug the A/C adapter to a standard 120V A/C wall outlet.
Setting Time and Date
The date/time must be set correctly as it will be the alert
time for the event message saved to the memory.
Note
3. Press key to save time and start to set date.
1. Press or key to set time, hold the key to change faster.
4. Press or key to set the Month, Day or Year.
6. Press key to save and exit.
2. Press or key to select hour / minute digits.
5. Press or key to select Month, Day or Year digits.
If it is desired to set time/date later, press MENU key to exit.
Otherwise; follow steps below to set time and date.
Getting Started
Installing the Back-up Batteries
1. Press down the battery base cover and slide it out to remove.
2. Insert batteries in correct polarity shown in the compartment.
3. Place the battery cover back and slide it in to click into place.
The radio requires four (4) AA size alkaline batteries (such as
Energizer or DuraCell Brand) for back-up power in case A/C
power fails or temporarily disconnected.
1. icon on display indicates low battery.
2. It is recommended to power up the radio with the
supplied A/C adapter to prevent battery drain.
3. Do not leave weak or dead batteries in the battery
compartment.
For better reception, the radio should be placed nearing a
window facing to the direction of the NWS (National Weather
Service) transmitter. The radio is not weather resistant, care
must be taken.
Note
- 5 -

1.6 Review Alert Message (in Standby Mode)
'NO EVENT MESSAGES'indicates no test / alert
messages received.
- Press key to enter event memory mode.
- Press or key to view alert messages in the memory.
Info
- Press key to view the alert channel and date / time.
- Press key again to revert to event message display.
Tips Press LIGHT key to turn the LED on / off if desired.
The LED is turned off initially.
1.8 Review Watch Channels
Press key in Standby mode to see the watched WX
channel(s). CH stands for Channel.
1.4 Review Stored County Codes (in Standby Mode)
- Press key to view the stored county code / SAME#.
- Press MENU key to exit.
- Press or key to view other stored county codes, if any.
- 7 -
1.5 Review/Edit Event Blocking (in Standby Mode)
1. Press key, then key to enter View/Edit Alerts mode.
2. Follow steps 3 to 8 in section 2.6 to view/edit event message.
Info - Events in Event Message Table 2 are read only, no edit.
- Press LIGHT key to turn the LED light off if desired.
Press LIGHT key again to turn on the LED.
Refer to Section 2.11 Setting Auto Key Lock to set
key lock / unlock.
1.7 Auto Key Lock (in Standby Mode)
Info
When the 'KEY LOCK' is set On in program Menu page P11,
in Standby Mode, keys will be auto-locked after a preset
time delay to prevent accidental key presses. To unlock the
key pad temporarily, press MENU, then STOP key shortly.
1.3 Turn On the Radio
- Press RADIO key to turn on the radio.
Press RADIO key to display the channel frequency
briefly.
Tips
- Press or key to adjust the volume, long press the key
will change the volume continuously.
Pull out and orient the telescopic antenna to have the
best reception.
Note
- Press STOP key to turn off the radio and the radio will be
in Standby mode.
Turn Off the Radio
- To set your local channel, refer to Section 2.2.
If Multiple Channel Watch has been selected (in Section 2.7),
press , , or key to switch the channels.
Section 1 Operation
If the radio is powered by batteries, pressing a key
(except STOP key when turning off the radio) will
illuminate the back light for 10 seconds. In program
menu mode, the back light is always on. Please refer
Section 2.10 to set the back light.
1.2 LCD Back Light
Info
In Standby mode, press and hold MENU key for 2 seconds to
enter program menu. Then, refer Section 2 to set up the radio.
1.1 Access to Program Menu
- 6 -
In the web site below, on-line manual is available for
manual update or error correction, if any.
Http://www.reecominc.com
Note
Info Standby Mode: the radio is powered up, no radio voice.

The icon or indicates Alarm 1 or 2.
1.10 Alarm Clocks (in Standby Mode)
Two (2) alarm clocks are available.
Info
Press key to enter the sub-menu. Then, press or key
to select ON/OFF, or key to set snooze time or alarm
volume.
Press ALM 1 or ALM 2 key to set alarm 1 or 2. If the alarm
time, day, snooze time and alarm volume are set as desired,
press MENU key to activate the alarm clock; or press key
to edit. Press , , or key to set alarm time.
Each digit in the first line is for sub-menu entry.
The digits 1 to 7 denote Sunday to Saturday respectively;
Z sign denote Snooze time;
sign denote BUZZ alarm.
1.9 Nap Timer (in Standby Mode)
Note Nap cycle will be terminated upon alert receiving with
audible response.
- Press and hold SNOOZE key for 2 seconds to enter Nap mode.
- Press or key to set nap time, 1 minute up to 2 hours.
- Press key to save.
- Press or key to set snooze time.
When nap time is up, Buzz alarm starts out loud gradually.
Press STOP or MENU key to stop the alarm or press SNOOZE
key start snooze cycle.
- Press key to confirm and start nap cycle with a beep tone
and timer count down shown on the display.
Note
a). individual day alarm On or OFF.
b). Zsign, SNOOZE time in minutes.
c). sign, alarm volume.
At least one alarm day has to be set before setting
snooze time, alarm volume or activating alarm clock.
Press or key to select the sub-menu and you will see:
- 8 -
- If uninterrupted, the alarm will stop in 1 hour.
Press ALM 1 or ALM 2 key once to deactivate the alarm clock.
1.11 De-activat Alarms
As all set, press MENU key to exit and activate the alarm clock.
In the second line display: indicates clock alarm
has been set for the week day above.
Info
When the time is up, the radio will alarm out loud gradually
to the preset alarm volume (gradual wake).
- Press STOP or MENU key to stop alarm completely.
- Press SNOOZE key to stop alarm and start snooze cycle
with snooze timer count down shown on the display.
- 9 -
1.12 Turn Off the Radio
Info
- Long press STOP key for 2 seconds to turn off the radio
and the LCD displays RADIO OFF, no alert receiving.
- To turn on the radio, long press MENU key for 2 seconds
or power-up the radio with A/C adapter. Then, the radio
will be in alert standby mode.
When the radio is powered by back-up batteries, the
radio can be turned off not
used temporarily (a day or two). When the radio is
turned off, no alerts will be received but clock alarm
and nap timer can still be functioning. If the radio is
not going to use for longer time, remove the batteries.
to extend battery life if
The radio cannot be turned off if powered by A/C
adapter or there is active event under Effective Time
count down.
Note

Event Message Table 1 (events with defeat siren option)
REQUIRED WEEKLYTEST
REQUIRED MONTHLYTEST
ADMINISTRATIVE MESSAGE
AVALANCHE WATCH
AVALANCHE WARNING
NATIONAL SILENT TEST
NETWORK NOTIFICATION MESSAGE
PRACTICE / DEMO
POWER OUTAGE ADVISORY
HURRICANE WATCH
ICEBERG WARNING
NATIONAL INFORMATION CENTER
NATIONAL PERIODIC TEST
NATIONALAUDIBLE TEST
FLASH FREEZE WARNING
FREEZE WARNING
HIGH WIND WATCH
HIGH WIND WARNING
HURRICANE STATEMENT
FLASH FLOOD WARNING
FLOOD STATEMENT
FLOOD WATCH
FLOOD WARNING
FIRE WARNING
DAM WATCH
DUST STORM WARNING
EVACUATION WATCH
FLASH FLOOD STATEMENT
FLASH FLOOD WATCH
BOIL WATER WARNING
BLIZZARD WARNING
CHILD ABDUCTION EMERGENCY
COASTAL FLOOD WATCH
COASTAL FLOOD WARNING
Beep (Initially Disabled)
Beep (Initially Disabled)
Beep (Initially Disabled)
Watch Siren
Warning Siren
Audible Response
Warning Siren
Warning Siren
Advisory Siren
Watch Siren
Warning Siren
Watch Siren
Warning Siren
Watch Siren
Advisory Siren
Watch Siren
Warning Siren
Advisory Siren
Watch Siren
Warning Siren
Warning Siren
Warning Siren
Warning Siren
Watch Siren
Warning Siren
Advisory Siren
Watch Siren
Warning Siren
Beep (Initially Disabled)
Beep (Initially Disabled)
Beep (Initially Disabled)
Beep (Initially Disabled)
Beep (Initially Disabled)
Beep (Initially Disabled)
Advisory Siren
Event Message on Display
- 11 -
National Weather Service (NWS) Test Signals
If no alert / test signals has been received for 10 days,
the radio will display: RE-CHECK SET UP. Please
check the channel / county
settings.
the radio reception and
1.13 Receiving Alert Message
Upon receiving alert, will generate siren (if events
unblocked) with display the event message and
the radio
flashing LED,
Effective Time, unlock keypad if locked previously. The event
message, the receiving channel and current date / time will be
saved into the event memory. The oldest message will be
cleared if the memory is full. The alarm out socket functions
per Alert Option Table in Section 2.3. Press any key to stop
siren. As siren stops, the number of active event, Effective
Time, real time clock and receiving channel will be displayed
alternatively.
Info
Note
1.14 AUDIO OUT Socket
Upon receiving alert, the radio will
the audio out socket(Mono)
The output level can be
adjusted in program menu page P4 and P5.
output siren / voice signal
via to the external device, such as
external speaker. Connect a 3.5mm (1/8 inch) phone jack to the
socket with center positive polarity.
Test messages (e.g. Required Weekly Test) are used to
test if the radio can properly respond to alerts. Set your
local channel and county code (SAME#) correctly
(refer to Section2.2) to confirm the Weekly Test.
Although est messages are initially set to blocked
(defeat siren), the test message is still displayed on the
LCD and saved to the event memory historically for
review. T
the t
o set audio response for test messages, please
refer to Section 2.6.
To stop event message scrolling on the LCD screen,
press and hold the STOP key and the LED light will be
turned off. Release the key to resume.
Tips
- 10 -

- 13 -
Audible Response
Non-Alert Messages
TRANSMITTER BACKUP ON
TRANSMITTER CARRIER OFF
TRANSMITTER CARRIER ON
TRANSMITTER PRIMARY ON
None
The radio will not give audible / visual response
to the Non-Alert messages which will be saved
to the event memory for review.
Audible Response
Alert Message on Display
VOLCANO WARNING
WILD FIRE WARNING
UNRECOGNIZED WARNING
Warning Siren
Warning Siren
Warning Siren
Event Message Table 2 (continue)
Note
SHELTER IN-PLACE WARNING
TORNADO WARNING
TROPICAL STORM WARNING
TSUNAMI WATCH
TSUNAMI WARNING
Warning Siren
Warning Siren
Watch Siren
Warning Siren
Warning Siren
Non - Alert Message Table
LOCALAREA EMERGENCY
LAWENFORCEMENT WARNING
LAND SLIDE WARNING
NUCLEAR POWER PLANT WARNING
RADIOLOGICAL HAZARD WARNING
Advisory Siren
Warning Siren
Warning Siren
Warning Siren
Warning Siren
IMMEDIATE EVACUATION
FOOD CONTAMINATION WARNING
HAZARDOUS MATERIALS WARNING
HURRICANE WARNING
INDUSTRIAL FIRE WARNING
Warning Siren
Warning Siren
Warning Siren
Warning Siren
Warning Siren
Audible Response
Warning Siren
Warning Siren
Warning Siren
Warning Siren
Warning Siren
BIOLOGICAL HAZARD WARNING
CIVIL DANGER WARNING
CIVIL EMERGENCY MESSAGE
CHEMICAL HAZARD WARNING
CONTAMINATED WATER WARNING
DAM BREAK WARNING
CONTAGIOUS DISEASE WARNING
EMERGENCYACTION NOTIFICATION
EMERGENCYACTION TERMINATION
EARTHQUAKE WARNING
911 TELEPHONE OUTAGE EMERGENCY
TROPICAL STORM WATCH
WINTER STORM WATCH
WINTER STORM WARNING
WILD FIRE WATCH
Advisory Siren
Watch Siren
Watch Siren
Warning Siren
Watch Siren
Warning Siren
Warning Siren
Warning
Siren
Warning Siren
Siren
Advisory
Advisory Siren
Watch Siren
Advisory Siren
UNRECOGNIZED STATEMENT
UNRECOGNIZED WATCH
UNRECOGNIZED EMERGENCY
Event Message on Display
Event Message Table 1 (continue)
SPECIAL MARINE WARNING
SPECIAL WEATHER STATEMENT
SEVERE WEATHER STATEMENT
SEVERE THUNDERSTORM WATCH
SEVERE THUNDERSTORM WARNING
TORNADO WATCH
Warning Siren
Advisory Siren
Advisory Siren
Watch Siren
Warning Siren
Watch Siren
Event Message Table 2 (events without defeat siren option)
Audible Response
Event Message on Display
- 12 -
STORM SURGE WATCH
STORM SURGE WARNING
EXTREME WIND WARNING
SNOW SQUALL WARNING
Watch Siren
Warning Siren
Warning Siren
Warning Siren

Section 2 Setting Up the Radio
Variety features and functions are available for use
and configured in Program Mode with Menu Pages
listed below:
Info
Info
Two-beep tone indicates wrong key pressed. To exit program
mode, keep pressing MENU key. If no keys is pressed for 5
minutes, program mode will be automatically exited.
SET DATE TIME
CHANNEL COUNTY
ALERT MODE
SIREN VOLUME
SET EVENT BLOCKING
P1
P2
P3
P4
P5
P7
Menu
Page Description
MULTI-CH WATCH
P6
ALARM SOCKET
P9
SIREN TEST
P10
BACK LIGHT
P11
VOICE VOLUME
P8
KEY TONE
AUTO KEY LOCK
P12
Menu
Page Description
2.1 Setting Date / Time (Menu Page P1)
The date / time must be set correctly as they will be
the time reference for the receiving alert message
saved into the event memory.
Note
1. Long press MENU key for 2 seconds to enter program mode.
2. Press key to enter menu page P1.
5. Press key to save time and start to set date.
3. Press or key to set time, hold the key to change faster.
6. Press or key to set the Month, Day or Year.
8. Press key to save and exit.
4. Press or key to select hour / minute digits.
7. Press or key to select Month, Day or Year digits.
Press and hold the MENU key for 2 seconds to enter
Program Mode. The LCD icons next to the MENU key
and key will be helpful in programming the radio.
- 15 -
Blank
- 14 -

Three county options are available:
1. Press or key to select county option.
3. Press or key to browse the stored county codes or
go to the empty memory to add county code.
2.2.2 ADD / Edit / Delete County
4. Press key to edit, delete or add county code.
(d). Press or key to set the county code digit.
(e). Press or key to move to the next / previous digit.
(g). Press key to save.
5.
or
(f). Repeat (d) and (e) above to set all six digits.
1. ALL COUNTY,2. MULTIPLE COUNTY,3. SINGLE COUNTY.
(c). Press key to edit county code.
-with ALL COUNTY option, the radio will respond all alerts
from the receiving channel, regardless of the areas.
- with MULTIPLE COUNTY option, the radio will only
respond the alerts for the counties of your interest.
2. Press key. If ALL COUNTY option is selected, it will
exit to the main menu. If SINGLE COUNTY option is
selected, then, go through steps 5(c) to (g) below.
If there is no county codes stored, 'ALL COUNTY'
option will be set automatically.
Note
(h). Repeat from step 3 for the next county edit, if any.
(a). To add county code, follow steps in section 2.2.1.
or
(b).To delete county code, press key, then key.
(i). Press MENU key to exit.
- with SINGLE COUNTY option, the county code is stored in
the first memory location, COUNTY 01. The radio will
respond alerts related to the location in County 01.
To delete county code at SINGLE COUNTY option,
change the option to MULTIPLE COUNTY to delete there.
- 17 -
2.2 Setting Channel / County (Menu Page P2)
1. Long press MENU key for 2 seconds to enter program mode.
2. Press key to menu page P2.
4. Press key to set Home channel for your area.
Press or key to adjust voice volume.
Tips
5. Press key to save.
3. Press key and the radio is turned on with channel shown.
2. Press key to move to the next digit.
3. Repeat step 1 and 2 to set all six digits.
4. (a). Press MENU key to exit if no other county codes entry.
1. Press or key to set county code digit.
(b). Press key to save and continue to add next county
code, repeat step 1 to 3 above.
6. Press key to Add / Edit county code and continue on in
the Section 2.2.1 below.
or
If there is no county codes ever stored in the memory, follow
steps below. Otherwise; go to next Section 2.2.2
2.2.1 Add County Code
Before setting Channel / County, please call NWS toll free No.:
1-888-NWS-SAME (1-888-697-7263) or visit NWS web site:
https://www.weather.gov/nwr/counties to obtain:
1. NOAA Station Frequency for your home area, or Channel No.
2. SAME# for your home county, or County Code
In the web site, select the state, then search your county and jot
down the SAME# (County Code) and Frequency, as your
Home Channel for your area.
Note Both Channel and County Code are inter-related for
alert receiving. Either one of them set incorrectly will
result in no alert response and finally display
RE-CHECK SET UP on the LCD after every 10 days.
- 16 -

- Press key to save and exit.
- Press or key to set the timer in minutes, up to 1 hour.
3. Press key to select.
4. Press or key to select alert option.
5. Press key to set alert option.
If VOICE Timer (option 2) or SIREN (option 3) is selected,
continue to set Voice Timer or Siren Timer respectively.
2. Keep pressing key to menu page P3.
2.3 Setting Alert Mode (Menu Page P3)
Alert Responses:
Alert Option:
1. VOICE EOM
4. Alert Disable
Activate the Alarm Out Socket,
EOM signal received, or press STOP
key to deactivate the Alarm Out Socket and
the radio will
8 seconds
siren, then, voice broadcast (max.15 minutes)
until
return to previous state
immediately before alert receiving.
Activate the Alarm Out Socket, generate
Siren Timer expired, or press any
key to deactivate the Alarm Out Socket and
the radio will return to Standby mode.
siren until
No audible / visual responses.
.Alarm Out Socket not activate
3. SIREN
1. Long press MENU key for 2 seconds to enter program mode.
2. VOICE Timer
Activate the Alarm Out Socket,
key deactivate the
Alarm Out Socket and the radio will return to
previous state immediately before alert
receiving.
8 seconds
siren, then, voice broadcast until Voice Timer
expired, or press STOP to
(End of Message)
Alert Option Table
HR - MIN stands for Hour : Minute.
Info
- 18 -
2.4 Setting Siren Volume (Menu Page P4)
1. Long press MENU key for 2 seconds to enter program mode.
The siren volume can be set to your desired loudness.
Siren mute option is also available for the events in
Event Message Table 1.
Info
3. Press key to select.
4. Press or key to set siren volume. During siren, the
ALARM OUT socket is activated for testing the external
device if connected.
5. Press key to save and exit.
1. Long press MENU key for 2 seconds to enter program mode.
2. Keep pressing key to menu page P5.
Voice volume is used when the radio broadcasts voice
message after siren tone. Voice volume can be set to
your desired loudness for VOICE EOM or VOICE Timer.
alert mode.
3. Press key to turn on the radio broadcast.
2.5 Setting Voice Volume (Menu Page P5)
Info
4. Press or key to set voice volume as desired.
5. Press key to save and exit.
Note If siren volume is set to 00 or SIREN MUTE, siren will
not be generated for the events in Event Message Table 1.
However, siren will be generated at the VOICE VOLUME
level for the events in Event Message Table 2.
2. Keep pressing key to menu page P4.
- 19 -
