REED SD-3007 User manual

Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Model
Instruction
Manual
Humidity/Temperature
Datalogger
SD-3007
reedinstruments
www com

reedinstruments
www com
2
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Table of Contents
Features............................................................................................ 3
Specications................................................................................3-5
Instrument Description ..................................................................... 6
Operating Instructions.................................................................7-11
Function selection.......................................................................... 7
Humidity/Temperature measurement ............................................. 7
Dew Point measurment.................................................................. 7
Wet Bulb measurement ................................................................. 7
Data Hold ...................................................................................... 8
Data Record (Max., Min. reading)................................................... 8
Backlight ON/OFF.......................................................................... 9
Datalogger..................................................................................... 9
Auto Datalogger........................................................................9-10
Manual Datalogger....................................................................... 10
Checking the Time....................................................................... 10
Check Sampling Time Information................................................ 10
SD Card Data Structure............................................................... 11
Data Transfer from SD card to Computer..................................... 11
Advanced Settings ....................................................................12-14
Set Clock Time ............................................................................ 12
Setting the Decimal point on the SD Card....................................13
Auto power OFF management..................................................... 13
Set Beeper Sound ON/OFF ......................................................... 13
Select the Thermometer to Type K or Type J................................ 13
Select the Temperature unit to °C or °F........................................ 14
Set sampling time ........................................................................ 14
SD memory card Format ............................................................. 14
PC Serial Interface.......................................................................... 15
System Reset ................................................................................. 16
Battery Replacement...................................................................... 16

reedinstruments
www com
3
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Features
• Dew point and Wet bulb humidity measurements
• Type K, Type J thermocouple thermometer
• Fast humidity measuring response time
• Real time SD memory card datalogger with a built-in clock and
calendar
• No extra software needed, just plug the SD card into the computer
and it downloads directly to EXCEL
• SD card capacity: 1 GB to 16 GB
• Easy to read LCD with backlight
• Auto power off or manual power off
• Data hold, record max. and min. reading
• High accuracy microcomputer circuit
• Power by UM3/AA (1.5 V) x 6 batteries
• USB/RS232 Computer interface
• Separated probe for easy measurements of multiple environments
• Automatic temperature compensation for the anemometer and type
K/J thermometer
Specifications
Circuit: Custom microprocessor LSI circuit
Display: 52mm x 38mm LCD with backlight
Humidity Temp. units: %RH / °C or °F
Dew Point/Wet Bulb units: (°C, °F)
Temperature units: (°C, °F)
Auto Sampling Time: 1, 2, 5, 10, 30, 60, 120, 300, 600, 1800,
3600 seconds
Memory Card: SD memory card, 1 GB to 16 GB
Sampling Time of Display: Approx. 1 second

reedinstruments
www com
4
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Data Output: USB/RS232 PC computer interface
Temperature Range: 0-50°C (0-122°F)
Résolution: 0.1°C/0.1°F
Accuracy: ± 0.8°C/1.5°F
Operating Temperature: 0-50°C (0-122°F)
Operating Humidity: Less than 85% R.H.
Power Supply: UM3/AA (1.5 V) x 6 batteries
Weight: 515g/1.13lb
Dimensions: 177 x 68 x 45mm (7.0 x 2.7 x 1.9”)
Includes: Humidity/Temp. probe
Optional accessories: 2G SD Card (SD-2GB)
Type K thermocouple probe (TP-01)
Soft carrying case (CA-05A)
USB cable (USB-01)
RS232 cable (UPCB-01)
Power adapter (AP-9VA-110V)
Data Acquisition Software (SW-U801-WIN)
Tripod (BS-6)
Visit us at www.reedinstruments.com for more information on our Optional
Accessories, or e-mail us at [e-mail]
Humidity
Range: 5% to 95% RH
Résolution: 0.1% RH
Accuracy: ≥70% RH: ± (3% reading + 1% RH)
< 70% RH: ± 3% RH
Temperature
Range: 0 - 50°C, 32 - 122°F
Résolution: 0.1°
Accuracy: ±0.8°C, ±1.5°F continued...

reedinstruments
www com
5
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Dew Point
Range: -25.3°C - 48.9°C, -13.5°F - 120.1°F
Résolution: 0.1°
Wet Bulb
Range: -21.6°C - 50.0°C, -6.9°F - 122.0°F
Résolution: 0.1°
Type K/J thermometer
Sensor Type Résolution Range Accuracy
Type K
0.1°C -50.0 to 1300.0°C ± (0.4% + 0.5°C)
-50.1 to -100.0°C ± (0.4% + 1°C)
0.1°F -58.0 to 2372.0°F ± (0.4% + 1°F)
-58.1 to -148.0°F ± (0.4% + 1.8°F)
Type J
0.1°C -50.0 to 1200.0°C ± (0.4% + 0.5°C)
-50.1 to -100.0°C ± (0.4% + 1°C)
0.1°F -58.0 to 2192.0°F ± (0.4% + 1°F)
-58.1 to -148.0°F ± (0.4 % + 1.8°F)
Above specication tests under the environment RF Field Strength
less than 3 V/M & frequency less than 30 MHz only
For service on this or any other REED product or information on other
REED products, contact REED Instruments at [email protected]

reedinstruments
www com
6
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Instrument Description
1. Display
2. Power, ESC, & Backlight Button
3. Hold Button, Function Button,
& Next Button
4. REC Button, Enter Button
5. SET Button, Up Button, & Time
Check Button
6. Logger Button, Down Button,
& Sampling Time Check Button
7. Probe input socket
8. Type K/J thermometer socket
9. SD card slot
10. RS232 Output
11. Reset Button
12. AC/DC 9V Power Adapter
Input Socket
13. Battery Compartment/Cover
14. Battery Cover Screws
15. Stand
16. Tripod Fix Nut
17. Probe Plug
18. Probe Handle
19. Probe Head

reedinstruments
www com
7
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Operating Instructions
Function selection
1) Turn on the meter by pressing the Power Button. To turn the meter
off, hold the Power Button for over 2 seconds.
2) The meter has 4 measuring functions to choose from: Humidity/
Temp, Dew Point, Wet Bulb, or Type K/J Thermometer. When the
meter is on, press and hold the Function Button. The display will
ash “rH”, for Humidity/Temperature measurement, “dP” for Dew
Point measurement, “_Et” for Wet Bulb measurement, and “tP” for
Type K/J Thermometer measurement. Release the Function Button
to choose the displayed function.
Humidity/Temperature measurement
1) 1) When the meter is off, plug the Probe into the Probe Input
Socket, then power on the meter by pressing the Power Button.
2) Select the “rH” function (see Function Select).
3) Hold the Probe Handle and face the Probe Head against the mea-
suring source. The top part of the Display will show the Humidity
value, and the lower part of the Display will show the Temperature
value.
Dew Point measurment
1) Select the “dP” function (see Function Select).
2) Hold the Probe Handle and face the Probe Head against the mea-
suring source. The top part of the Display will show the Dew Point
value, and the lower part of the Display will show “dP”.
Wet Bulb measurement
1) Select the “_Et” function (see Function Select).
2) Hold the Probe Handle and face the Probe Head against the mea-
suring source. The top part of the Display will show the Wet Bulb
value, and the lower part of the Display will show “_Et”.

reedinstruments
www com
8
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Type K/J Thermometer measurement
1) Select the “tP” function (see Function Select).
2) Plug the optional Type K or J Thermocouple Probe into the Type
K/J Probe Input Socket. Be sure the Probe is not plugged in.
3) The screen will display a “K”, meaning it is congured for a Type
K thermometer probe. The measured temperature will now be dis-
played on the display screen. To change the meter to accept a Type
J Probe, please see the Advanced Settings section.
Data Hold
While taking a measurement, press the Hold Button once and the mea-
sured value will hold on the screen, and a HOLD symbol will appear.
Press the Hold Button once again will release the data hold function.
Data Record (Max., Min. reading)
The data record function records the maximum and minimum readings.
Press the REC Button once to start the Data Record function and a “REC”
symbol will appear on the display. With the “REC” symbol on the display:
1) Press the REC Button once, and a ”REC. MAX.” symbol along with
the maximum value will appear on the display. To delete the maxi-
mum value, press the Hold Button once and the display will show
a “REC.” symbol only and execute the memory function continu-
ously.
2) Press the REC Button again, and a “REC. MIN.” symbol along
with the minimum value will appear on the display. To delete the
minimum value, press the Hold Button once, and the display will
show a “REC.” symbol only and execute the memory function
continuously.
3) To exit the memory record function, press the REC button for 2
seconds. The display will revert to the current reading.

reedinstruments
www com
9
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Backlight ON/OFF
After powering the meter ON, the LCD Backlight will turn on automati-
cally. While taking measurements, press the Backlight Button and the LCD
Backlight will turn off. Press the Backlight Button once again to turn the
LCD Backlight back ON.
Datalogger
Preparation Before Executing the Datalogger Function:
1) Insert the optional SD card into the SD card socket.
2) Before you use an SD card with this meter for the rst time, it is
recommend to format the SD card. See Advanced Settings section
of this manual for instructions.
3) If this is the rst time the meter is used you need to adjust the
clock. See Advanced Settings section of this manual for instruc-
tions.
4) Now you need to set the decimal format. The numerical data struc-
ture downloaded to the SD card is defaulted used the “.” as the
decimal, for example “20.6” “1000.53”. But in certain countries the
“,” is used as the decimal point, for example “20,6” “1000,53”. See
Advanced Settings section of this manual for instructions on how
to change the Decimal Character.
Auto Datalogger (Set sampling time ≥1 second)
1) Start Datalogging; press the REC Button, and the “REC” symbol
will appear on the LCD screen, then press the Logger Button, the
“REC” symbol will ash while the measuring data and time informa-
tion is being saved in memory. To set the sampling time, and to
toggle the beeper sound on or off, refer to the Advanced Settings
section of this manual.
2) Pause the Datalogging; while Datalogging, if press the Logger But-
ton once. While paused, the “REC” symbol will stop ashing. Press
the Logger Button again to resume Datalogging, and the “REC”
symbol will begin to ash again.
continued...

reedinstruments
www com
10
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
3) Stop Datalogging; while the Datalogger function is paused, press
the REC Button for 2 seconds. The “REC” symbol will disappear
indicating the Datalogging function has stopped.
Manual Datalogger (Set sampling time = 0 seconds)
1) Set sampling time is to 0 second; Press the REC Button, and the
“REC” symbol will appear on the LCD screen. Press the Logger
Button, and the “REC” symbol will ash once and one Beep will
sound, at the same time the measuring data along the time infor-
mation will be saved in memory. The lower Display will show the
Position (record) number, which is saved as well.
2) To Change the Position Number; press the Down Button and the
lower position number will ash on the display. Press the Up or
Down Buttons to set the Position Number (1 to 99) to help identify
the measurement location. The lower Display will show P x (x = 1 to
99). After the position number is selected, press the Enter Button to
conrm.
3) Stop Datalogging; press the REC Button for 2 seconds, and the
“REC” symbol will disappear indicating the Datalogging function
has stopped.
Checking the Time
During normal functions (not Datalogging), press the Time Check Button
and the lower LCD display will show the Year, Month/Date, Hour/Minute.
Check Sampling Time Information
During normal functions (not Datalogging), press the Sampling Button and
the lower LCD display will show the Sampling Time Information.

reedinstruments
www com
11
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
SD Card Data Structure
1) The rst time the SD card is used in the meter, the SD card will
generate a folder: HTA01
2) The rst time you use the Datalogger, in the folder HTA01, a new
le name HTA01001.XLS will be created. The Datalogger will use
this le until the Data has reached to 30,000 rows. The meter will
then will generate a new le with a subsequent number, for ex-
ample HTA01002.XLS.
3) The folder HTA01 can hold 99.XLS les. When that number has
been reached, the meter will then will generate a new folder with
a subsequent number, for example HTA02. Max number of HTA--
folders is 10.
Data Transfer from SD card to Computer (EXCEL Software)
1) After Datalogging, remove the SD card from the SD card slot.
2) Plug in the SD card into the Computer’s SD card slot or insert the
SD card into the optional SD card adapter and connect to your
Computer. Turn your computer on and a folder will appear on your
desktop representing you SD card.
3) Open “Microsoft EXCEL”. Download the EXCEL les from the SD
Card to the computer by opening up the SD folder and selecting
the desired EXCEL les, and drag-and-drop them onto your Com-
puter. Open the les with EXCEL (File – Open).
4) The EXCEL le will have the following column headers in this order:
Place (Position Number), Date (Year/Month/Day), Time (in 24h
clock), Value, and Unit.

reedinstruments
www com
12
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Advanced Settings
During normal functions (not Datalogging), press and hold the SET Button
for 2 seconds to enter the “Advanced Setting” mode. Press the Next But-
ton scroll through eight main functions, shown on the lower display:
dAtE Set clock time (Year/Month/Date, Hour/Minute/Second)
dEC Set SD card Decimal character
PoFF Auto power OFF management
bEEP Set beeper sound ON/OFF
tYPE Select the Thermometer to Type K or Type J
t-CF Select the temperature unit to °C or °F
SP-t Set sampling time (Hour/Minute/Second)
Sd F SD memory card Format
While in the “Advanced Setting” function, press the Esc Button to exit and
to return to normal functioning.
Set Clock Time
1) When the lower display shows “dAtE”, press the Enter Button.
Use the Up and Down Buttons to adjust the Year. After the desired
value is set, press the Enter Button to adjust the Month, Date, Hour,
Minute, and Second values.
2) After all the time values have been set the screen will jump to “SD
card Decimal character” setting screen. To exit “Advanced Set-
tings”, press the Esc Button.
Note: After the time value is set, the internal clock will run even when
the power is off, if the battery is under normal conditions.

reedinstruments
www com
13
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Setting the Decimal point on the SD Card
1) When the lower display shows “dEC”, use the Up or Down Buttons
to toggle between “bASIC” (“.” Decimal Point) or “Euro” (“,” Deci-
mal Point).
2) After the Decimal point character has been selected, press the
Enter Button to save the setting as the default. To exit “Advanced
Settings”, press the Esc Button.
Auto power OFF management
1) When the lower display shows “PoFF”, use the Up or Down But-
tons to select the value “yES” (Enable Auto Power Off) or “no”
(Disable Auto Power Off.
2) After selecting “yES” or “no”, press the Enter Button to save the
setting as the default. To exit “Advanced Settings”, press the Esc
Button.
Set Beeper Sound ON/OFF
1) When the lower display shows “bEEP”, use the Up or Down But-
tons to select “yES” (Beeper Sound is ON) or “no” (Beeper Sound
is OFF).
2) After selecting “yES” or “no”, press the Enter Button to save the
setting as the default. To exit “Advanced Settings”, press the Esc
Button.
Select the Thermometer to Type K or Type J
1) When the lower display shows “tYPE”, use the Up or Down Buttons
to select “K” (for Type K Thermometer) or “J” (for Type J Thermom-
eter).
2) After selecting “K” or “J”, press the Enter Button to save the setting
as the default. To exit “Advanced Settings”, press the Esc Button.

reedinstruments
www com
14
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Select the Temperature unit to °C or °F
1) When the lower display shows “t-CF”, use the Up or Down Buttons
to select “C” (for °C) or “F” (for °F).
2) After selecting “C” or “F”, press the Enter Button to save the set-
ting as the default. To exit “Advanced Settings”, press the Esc
Button.
Set sampling time
1) When the lower display shows “SP-t”, use the Up or Down Buttons
to adjust the value to either 0, 1, 2, 5, 10, 30,60, 120, 300, 600,
1800, or 3600 seconds.
2) After the Sampling value is selected, press the press the Enter But-
ton to save the setting as the default. To exit “Advanced Settings”,
press the Esc Button.
SD memory card Format
Please Note: Formatting the SD card erases all data from that SD card.
1) When the lower display shows “Sd F”, use the Up or Down Buttons
to select “yES” (format the SD card) or “no” (do not format the SD
card).
2) To format your SD card, select “yES” and press the Enter Button.
The Display will show “yES Enter”, to conrm. Press the Enter But-
ton to conrm.

reedinstruments
www com
15
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
PC Serial Interface
The instrument features an PC output via 3.5 mm terminal. The connector
output is a 16 digit data stream which can be utilized to the user’s specic
application. An USB RS232 lead with the following connection will be
required to link the instrument with the PC serial input.
Meter (3.5mm Jack Plug) PC (9W “D” Connector)
Center Pin Pin 2
Ground/Shield Pin 5
The 16 digit data stream will be displayed in the following format:
D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
D0 End Word
D1 to D4 Upper Display reading, D1= LSD, D4= MSB
D5 to D8 D5=? D6=? D7=? D8=?
D9 Decimal Point ( DP) for display
0 = No DP, 1 = 1 DP, 2 = 2 DP, 3 = 3 DP
D10 D10 = 0
D11 D11 = 0
D12 D12 = 0
D13 D13 = 0
D14 D14 = 0
D15 Start Word

reedinstruments
www com
16
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
System Reset
If an error occurs, press the Reset Button with a Pin. If the Reset Button
does not x the error, please send in the unit to our Calibration Lab for
repair. E-mail [email protected] for more information.
Battery Replacement
1) When the left corner of LCD display shows , it is necessary to
replace the battery
2) Loosen the screws of the Battery Cover and remove
3) Remove the batteries and replace with Six DC 1.5 V batteries
(UM3, AA, Alkaline/heavy duty)
4) Make sure the battery cover is properly secured after changing the
battery
For service on this or any other REED product or information on other
REED products, contact REED Instruments at [email protected]

reedinstruments
www com
17
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Notes _________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________

reedinstruments
www com
18
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Notes _________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________

reedinstruments
www com
19
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Notes _________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________

reedinstruments
www com
20
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Notes _________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
