Reflex Variomat Operating instructions

Master/Slave Operation
24.09.2015
Variomat / Variomat Giga / Reflexomat
GB Service Instructions

Contents
Master/Slave Operation — 24.09.2015 English — 3
English
Master/Slave Operatio n
24.09.2015
Contents
1Notes regarding the service instructions......................................................................................................................................4
2Models..............................................................................................................................................................................................4
3Overview..........................................................................................................................................................................................4
3.1Function ................................................................................................................................................................................................. 5
4Connection ......................................................................................................................................................................................6
4.1Connecting the RS-485 with the Control Basic controller .............................................................................................................. 7
4.2Connecting the RS-485 with the Control Touch controller ............................................................................................................ 8
5Controller.........................................................................................................................................................................................9
5.1Operator panel ...................................................................................................................................................................................... 9
5.1.1Control Basic....................................................................................................................................................................... 9
5.1.2Control Touch...................................................................................................................................................................10
5.2Setting the controller parameters....................................................................................................................................................11
5.2.1Control Basic.....................................................................................................................................................................11
5.2.2Control Touch...................................................................................................................................................................13
6Commissioning .............................................................................................................................................................................20
7Operation.......................................................................................................................................................................................20
8Controller messages .....................................................................................................................................................................21
8.1Control Basic........................................................................................................................................................................................21
8.2Control Touch ......................................................................................................................................................................................22
9Annex .............................................................................................................................................................................................24
9.1Reflex Customer Service ....................................................................................................................................................................24


Notes regarding the service instructions
4 — English Master/Slave Operation — 24.09.2015
1Notes regarding the service instructions
The electric wiring of the devices must be completed by a specialist in accordance with all applicable national and local regulations. The
Master/Slave operation must be installed by authorised personnel of Reflex Winkelmann GmbH.
Note!
Thoroughly read these instructions and follow them during installation.
2Models
The Master/Slave operation is a software expansion of these device controllers:
• Control Basic
• Control Touch
These devices can be expanded with Master/Slave operation:
• Variomat
• Variomat Giga
• Reflexomat
3Overview
Exemplary representation of two devices in Master/Slave operation.
1 Device 4 RS-485 signal line
2 Solenoid valve with ball valve M Motor ball valve in overflow line
3 Make-up system
One unit assumes the function of the master. The other unit becomes the slave. Unit level values are transmitted via the RS-485 signal
line. The master unit controls pressure maintenance in both units.

Overview
Master/Slave Operation — 24.09.2015 English — 5
3.1 Function
In a multiple-unit network, the water levels in the expansion tanks are monitored and maintained. The master controls the pressure in
the slaves. The master transmits via RS-485 signal line its current level value to the slaves. The water level in the slave is regulated if the
difference in water levels between master and slaves exceeds a specific value.
The slave supports the master in maintaining the pressure:
• Increasing water level.
– The slave's compressor or pump is started.
– The optional second compressor or second pump are switched on when the water level does not reach the master level within
the defined time.
– The compressors or pumps are shut down when the water level is the same as in the master.
– The slave is switched to individual mode when the pressure exceeds the maximum pressure.
– The slave is switched to master/slave mode when the pressure drops below the maximum pressure.
• Decreasing water level.
– The overflow valve is opened.
– The optional second overflow valve is opened when the water level does not reach the master device level within the defined
time.
– The overflow valves are closed when the water level is the same as in the master.
– The slave is switched to individual mode when the pressure drops below the minimum pressure.
– The slave is switched to master/slave mode when the pressure drops below the minimum pressure.
Note!
The parameters for the level values in the controller are pre-set at the factory. If necessary, adjust the factory settings to
the system-specific conditions.
– For adjusting factory settings, see chapter 5.2 "Setting the controller parameters" on page 11 .

Connection
6 — English Master/Slave Operation — 24.09.2015
4Connection
Connect the RS-485 signal line for master/slave operation on the controllers' circuit boards. Only a specialist (qualified electrician) is
authorised to complete the connection which must be realised in accordance with national and location regulations.
Proceed as follows:
1. Isolate the devices from the power supply.
2. Secure the devices against unintentional reactivation.
3. Verify the de-energised state.
For connecting the RS-485 network, use only the following screened cables:
• Y(ST)Y 2x2x0,6; alternative Y(ST)Y 2x2x0,8.
• Maximum conductor length 1000 metres.
Connect as follows:
• Connect the screened cable at the circuit board plug connection of the operating unit.
• Use the DIP switch to activate the terminal resistance.

Connection
Master/Slave Operation — 24.09.2015 English — 7
4.1 Connecting the RS-485 with the Control Basic controller
Danger – electric shock!
• Risk of serious injury or death due to electric shock. Some parts of the device's circuit board may still carry 230 V
voltage even with the device physically isolated from the power supply.
– Before you remove the covers, completely isolate the device controller from the power supply.
– Verify that the main circuit board is voltage-free.
Circuit board of the Control Basic controller.
000248_001_R001
12
ON
2
1
1 DIP switches 1 and 2 2 Connection terminals for RS-485 connection
Proceed as follows:
1. Open the housing cover of the Control Basic controller.
2. Use a screened cable to connect the RS-485 interface to the main circuit board.
• Slot 7, terminals 29, 30, 31.
3. Connect the cable screen at one side.
• At terminal 22.
4. Activate the terminators on the main circuit board.
• Use DIP switch 1.
Note!
Activate the terminator when the device is at the beginning or the end of an RS-485 network.

Connection
8 — English Master/Slave Operation — 24.09.2015
4.2 Connecting the RS-485 with the Control Touch controller
Danger – electric shock!
• Risk of serious injury or death due to electric shock. Some parts of the device's circuit board may still carry 230 V
voltage even with the device physically isolated from the power supply.
– Before you remove the covers, completely isolate the device controller from the power supply.
– Verify that the main circuit board is voltage-free.
Main circuit board of the Control Touch controller.
1 Connection terminals for RS-485 connection 2 DIP switches 1 and 2
Proceed as follows:
1. Use a screened cable to connect the RS-485 interface to the main circuit board.
• S 1, terminals 1 (A+), 2 (B-), 3 (GND).
2. Connect the cable screen at one side.
• At terminal 18.
3. Activate the terminator on the main circuit board.
• Use DIP switch 1.
Note!
Activate the terminator when the device is at the beginning or the end of the RS-485 network.

Controller
Master/Slave Operation — 24.09.2015 English — 9
5Controller
5.1 Operator panel
5.1.1 Control Basic
Operator panel of the Control Basic controller.
000088_001_R001
Error Auto
Quit
Menu Auto Manual Stop
Ok
11
10
98 765
4
1
3
2
1 Error LED
• The Error LED illuminates in the event of a fault
7 "Back" to the previous menu
2 Display 8 Auto
• For continuous operation
3 Auto LED
• The Auto LED illuminates green in Automatic mode
• The Auto LED flashes green in Manual mode
• The Auto LED is not illuminated when the system is
stopped
9 "Forward" to the next menu
4 Stop
• For commissioning and entry of new values in the
controller
10 Menu
• Call up the Customer menu
5 OK
• Confirm actions
11 Quit
• Acknowledge messages
6 Manual
• For tests and maintenance tasks
Selecting and changing parameters
1. Use "OK" (5) to select the parameter.
2. Use the "▼" (7) or "▲" (9) arrow keys to change the parameter.
3. Use "OK" (5) to confirm the parameter.
4. Use the "▼" (7) or "▲" (9) arrow keys to switch to a different menu option.
5. Use "Quit" (11) to switch to a different menu level.

Controller
10 — English Master/Slave Operation — 24.09.2015
5.1.2 Control Touch
Operator panel of the Control Touch controller.
000039_001_R001
OK
AUT O
ST OP
AUT O
ST OP
213
5
4
76
10
8
9
12
11
13
1 Message line 8 Display value
2 "▼"/ "▲" buttons
• Set digits.
9 "Manual mode" button
• For function tests.
3 ""/"" buttons
• Select digits.
10 "Stop mode" button
• For commissioning.
4 "OK" button
• Confirm/acknowledge input.
• Browse in the menu.
11 "Automatic mode" button
• For continuous operation.
5 "Up" and "Down" scroll bar
• "Scroll" in the menu.
12 "Set-up menu" button
• For setting parameters.
• Fault memory.
• Parameter memory.
• Display settings.
• Primary tank information.
• Software version information.
6 "Scroll back" button
• Cancel.
• Move backward up to the main menu.
13 "Info menu" button
• Displays general information.
7 "Display help texts" button
• Opens help texts.

Controller
Master/Slave Operation — 24.09.2015 English — 11
5.2 Setting the controller parameters
5.2.1 Control Basic
Example representation of the Control Basic controller
Enter the parameters as follows:
1. Press "Manual" to switch to manual operation. 1% 0 bar
XXX XXX XXX XXX
2. Press "Menu" to switch to the Service menu. Service menu˃
3. Use the "▼▲" arrow keys to enter the code for accessing the Service menu.
– Code: ▲▼▲▲▼
Service menu˃
4. Switch to the "Master/Slave" sub-menu.
– Press to "OK" to select the sub-menu.
– Use the "▼▲" arrow keys to enter the code for accessing the Service menu.
– Code: ▼▼▼▲▲
Master/Slave˃
Note!
You have opened the Master/Slave menu. Adjust the factory settings of the parameters to the device-specific conditions.
5. Switch to the next list item, "Unit address".
– Use the arrow keys to enter the address number.
– Press "OK" to confirm.
Device address:
01
Note!
Address selection for an example network of five devices. Any address number must be assigned only once.
– Select address number 1 for the master.
– Select address numbers 2, 3, 4, 5 for the four slaves.
6. Switch to the next list item, "Master/Slave".
– Use the arrow keys to enter the specific function.
Master/Slave:
NO:
YES:
The device assumes the Master function.
The device assumes the Slave function.
No
– Press "OK" to confirm.
7. Switch to the next list item, "Number Slaves".
– Use the arrow keys at the master to enter the number of slaves.
– You can have a maximum of 10 slaves.
– Do not enter a number in the slaves (Number = 0).
– Press "OK" to confirm.
Master/Slave:
4

Controller
12 — English Master/Slave Operation — 24.09.2015
8. Switch to the next list item, "Max. pressure deviation".
– This parameter is meaningless in the master and can be ignored.
– Define the parameter in the slaves.
– Setting range 0.1 – 5.0 bar.
– Use the arrow keys to enter the parameter value.
– Press "OK" to confirm.
Max. pressure deviation:
dPmaxSL = 1.0 bar
9. Switch to the next list item, "Activation delay".
– The activation delay sets the activation behaviour of the optional second pump,
compressor or overflow valve.
– This parameter is meaningless in the master and can be ignored.
– Define the parameter in the slaves.
– Setting range 0–240 seconds.
– Use the arrow keys to enter the parameter value.
Activation delay:
LK/MK = 5 s
– Press "OK" to confirm.
10. Switch to the next list item, "Max. level deviation".
– This parameter is meaningless in the master and can be ignored.
– Define the parameter in the slaves.
– Setting range 0 – 20 %.
– Use the arrow keys to enter the parameter value.
Max. level deviation:
dNiv = 5 %
– Press "OK" to confirm.
11. Switch to the next list item, "Block message 29 PFK".
– Use the arrow keys to select each function.
Message 29 PFK
NO: Select this function for the master.
The "29 Communication fault" message is output to the floating contact.
Block? NO
YES: Select this function for the slaves.
The "29 Communication fault" message is not output to the floating
contact.
– Press "OK" to confirm.
Note!
You have completed the settings in the controllers when all parameters for the master and the slaves are entered.
– Ensure that all devices are set to Master/Slave operation.

Controller
Master/Slave Operation — 24.09.2015 English — 13
LIS
M
COK
5.2.2 Control Touch
Representation of a Control Touch controller using the example of a Variomat with one pump.
Enter the parameters as follows:
1. Switch on the main switch of the operating unit to activate
the controller.
2. Press "Setup Menu".
Variomat VS 2.1
800l
25% 2.9 bar
NSP
System
Continuous degassing
3. Press "Service >".
– The controller opens the Service menu.
Settings
Customer >
Service >
2.9 bar 0 %
4. Use the "▲" and "▼" keys to enter the code for accessing
the Service menu.
– Code: ▲▼▲▲▼
– The controller opens the Service menu.
Settings
Code input
Please enter
the code for
the Service menu
2.9 bar 0 %
AUTO
STOP
AUTO
STOP
OK

Controller
14 — English Master/Slave Operation — 24.09.2015
COK
5. Use the scroll bar to navigate to the "Master/Slave" function.
6. Press "Master/Slave".
– The controller switches to the selected area.
Settings > Service
Master/ Slave >
Master controller >
SD card >
2.9 bar 0 %
Note!
You are within the Master/Slave menu. Adjust the factory settings of the parameters to the device-specific conditions.
8. Press "Address“.
– The controller switches to the address administration.
Settings>Service>Master/Slave
(240) Address 1
(241) Master/Slave No
(242) Number of Slaves 0
(243) Max. pressure deviation 1 bar
2.9 bar 0 %
7. Use the "▲" and "▼" keys to enter the code for accessing
the Master/Slave menu.
– Code: ▼▼▼▲▲
– The controller opens the Master/Slave menu.
Master/ Slave >
Code input
Please enter
the code for
the Master/Slave
2.9 bar 0 %

Controller
Master/Slave Operation — 24.09.2015 English — 15
9. Set the appropriate address for each Master or Slave
function.
– Use the buttons to enter the address number.
– Press "OK" to confirm.
Settings>Service>Master/Slave
(240) Address
1
2.9 bar 0 %
Note!
Address selection for an example network of five devices. Any address number must be assigned only once.
– Select address number 1 for the master.
– Select address numbers 2, 3, 4, 5 for the four slaves.
10. Press "Master/Slave".
– The controller switches to the Master/Slave function
selection.
Settings>Service>Master/Slave
(240) Address 1
(241) Master/Slave No
(242) Number of Slaves 0
(243) Max. pressure deviation 1 bar
2.9 bar 0 %
11. Select the desired function:
• "No"
– The device assumes the Master function.
• "Yes"
– The device assumes the Slave function.
• Confirm your selection with "OK".
The function for the respective device is selected.
Settings>Service>Master/Slave
(241) Master/Slave
No
Yes
2.9 bar 0 %
OK
OK

Controller
16 — English Master/Slave Operation — 24.09.2015
12. Press "Number of Slaves".
Settings>Service>Master/Slave
(240) Address 1
(241) Master/Slave No
(242) Number of Slaves 0
(243) Max. pressure deviation 1 bar
2.9 bar 0 %
13. Specify the number of slaves.
– In the master, specify the number of slaves.
– You can specify a maximum of 10 slaves.
– Do not enter a number in the slaves (Number = 0).
– Use the buttons to enter the number.
– Press "OK" to confirm.
Settings>Service>Master/Slave
(242) Number of Slaves
4
2.9 bar 0 %
14. Press "Max. pressure deviation".
Settings>Service>Master/Slave
(240) Address 1
(241) Master/Slave No
(242) Number of Slaves 4
(243) Max. pressure deviation 1 bar
2.9 bar 0 %
OK

Controller
Master/Slave Operation — 24.09.2015 English — 17
15. Specify the value for the maximum pressure deviation for the
device.
– This parameter is meaningless in the master and can be
ignored.
– Define the parameter in the slaves.
– Setting range 0.1 – 5.0 bar.
– Use the buttons to enter the parameter value.
– Press "OK" to confirm.
Settings>Service>Master/Slave
(243) Max. pressure deviation
1.0
2.9 bar 0 %
16. Press "Activation delay“.
– The activation delay determines the activation
behaviour of the optional second pump, compressor or
overflow valve.
Settings>Service>Master/Slave
(244) Activation delay 5s
(245) Max. level deviation 5%
(246) Block message 29 PFK? No
2.9 bar 0 %
17. Specify the value for the activation delay for the device.
– This parameter is meaningless in the master and can be
ignored.
– Define the parameter in the slaves.
– Setting range 0 – 240 seconds.
– Use the buttons to enter the parameter value.
– Press "OK" to confirm.
Settings>Service>Master/Slave
(244) Activation delay
_5s
2.9 bar 0 %
OK
OK

Controller
18 — English Master/Slave Operation — 24.09.2015
18. Press "Max. level deviation". Settings>Service>Master/Slave
(244) Activation delay 5s
(245) Max. level deviation 5%
(246) Block message 29 PFK? No
2.9 bar 0 %
19. Specify the value for the maximum level deviation for the
device tanks.
– This parameter is meaningless in the master and can be
ignored.
– Define the parameter in the slaves.
– Setting range 0–20 %.
– Use the buttons to enter the parameter value.
– Press "OK" to confirm.
Settings>Service>Master/Slave
(245) Max. level deviation
_5%
2.9 bar 0 %
20. Press "Block message 29 PFK". Settings>Service>Master/Slave
(244) Activation delay 5s
(245) Max. level deviation 5%
(246) Block message 29 PFK? No
2.9 bar 0 %
OK

Controller
Master/Slave Operation — 24.09.2015 English — 19
21. Select the desired function:
• "No"
– Select this function for the master.
– The "29 Communication fault" message is output to
the floating contact.
• "Yes"
– Select this function for the slaves.
– The "29 Communication fault" message is not
output to the floating contact.
• Press "OK" to confirm.
The function for the respective device is selected.
Settings>Service>Master/Slave
(246) Block message 29 PFK?
No
Yes
2.9 bar 0 %
Note!
You have completed the settings in the controllers when all parameters for the master and the slaves are entered.
– Ensure that all devices are set to Master/Slave operation.
OK

Commissioning
20 — English Master/Slave Operation — 24.09.2015
6Commissioning
The following prerequisites must be met for commissioning the Master/Slave operation of the system:
1. All parameter settings are completed for all devices.
2. The master is defined.
3. The slaves are defined.
For setting the parameters, see chapter 5.2 "Setting the controller parameters" on page 11 .
After all parameters are set, switch the master and the slaves to Automatic mode:
• "Control Basic" controller:
– Press "Auto" on the controller's operator panel.
• "Control Touch" controller:
– Touch "Auto" on the controller's operator panel.
7Operation
Subsequently to starting the Master/Slave operation of the system, the master sends its current level value to the slaves. The pressure
maintenance of the slaves is assumed by the master.
Note!
Variomats are active in slave function only when pressure maintenance is operating. If a Variomat executes the degassing
task, the slave function is blocked for the duration of the degassing cycle.
