RegalVue
Owner’s Manual

Table of Contents
Product Information....................................................................................................................3
Care and Maintenance..................................................................................................3
Basic Navigation Features.........................................................................................................4
Touch Screen Navigation...........................................................................................................6
Quick Access Key Features ......................................................................................................8
Stereo Feature..............................................................................................................8
Video Feature..............................................................................................................12
Diagnostic Message Feature.......................................................................................14
Main Menu ..................................................................................................................15
GPS Feature...............................................................................................................24
Profiles Feature...........................................................................................................26
Engine Statistics..........................................................................................................30
Troubleshooting........................................................................................................................31
We continually strive to bring you the highest quality, full-featured products. As a result, you may find
that your actual display screens may be slightly different than what was represented in this manual at the
time of printing.

2015-03-05 3 1511647
Product Information
RegalVue is a touch screen display solution. It is designed for instrumentation on electronically
controlled engines communicating via SAE J1939 and NMEA 2000. The display is a multi-
functional tool that provides GPS tracking, multimedia display, speed control and rider profiles.
In addition, the display enables equipment operators to view many different engine parameters
and service codes.
Care and Maintenance
General maintenance is not required; however, a soft cloth can be used for cleaning the units.
Window cleaner or alcohol can also be used to clean the glass portion of the display. Do not
use harsh or abrasive cleaners on the unit.

2015-03-05 4 1511647
Basic Navigation Features
All product features are easily accessed through Quick Access Keys, Touch Menus and Touch
Screen commands.
Quick Access Keys
These controls are accessed via the Quick Access Keys: stereo, video, diagnostic messages,
settings, maps, speed control, engine statistics and Home.

2015-03-05 5 1511647
Touch Point Commands
Touch key commands provide additional features and navigation shortcuts. Depending on the
current screen being displayed, they may appear as icons or a vertical control bar. Touch key
commands are used throughout the RegalVue display to:
•Access features
•Edit settings
•Navigate to deeper levels
•Navigate the screen
NOTE: Touch points are defined by words or graphics that are highlighted with
a soft glow.

2015-03-05 6 1511647
Touch Screen Navigation
Widget
Description
DATA BAR ON – Touch this to display the engine status at the bottom of
the screen. The data bar provides the following information:
•Fuel Level
•Oil Pressure
•RPM
•Speed
•Engine Temperature
•Voltage
NOTE: To change the selection of each pane, touch
and hold that pane until a list appears with the available
choices. Select the alternate setting.
DATA BAR OFF – Touch this to remove the data bar from the bottom of
screen.
DECREASES VALUE – Touch this to decrease the value in the selected
field.
INCREASES VALUE – Touch this to increase the value in the selected field.
DONE – Touch this to save updated settings and exit the screen.
CANCEL – Touch this to leave the screen without accepting any changes.
CONTINUE – Touch this to move to the next page of settings if applicable.

2015-03-05 7 1511647
Widget
Description
BACK – Touch this to move to the previous screen. The changes will be
saved.
ZERO OFF – Touch this to turn ZERO OFF on or off. This function is found
in the upper middle of every page of the display (except the Main Menu).
NOTE: When cruise is turned OFF,the driver must pull
the throttle back slightly. This shows throttle authority. It
must be done in order for the system to release the
cruise set point and return to speeds not governed by
the Zero Off commanded speed.
SCREEN IMAGE EDITOR – Touch this area of the screen to change the
screen image. The following screen will appear:
Model Image – can be changed per the boat that is selected in Dealer
Settings.
User Image – Touch User Image and then the download button. The
following screen will appear:
Follow the instructions to upload a saved image from a USB drive.

2015-03-05 8 1511647
Quick Access Key Features
This section describes the features accessed through the Quick Access Keys located to the
left and right of the display.
Stereo Feature
Stereo Display can be accessed by pressing the Quick Access Key
This feature provides universal control to the stereo mimicking all the controls of a standard
remote control. This includes iPod and Thumb Drive music.
Stereo - Touch Commands
Touch Command
Description
SOURCE – Touch this to select a connected source. RegalVue supports
the following devices:
•FM radio
•AM radio
•Sat
•iPod
•DVD
•VHF
Touching and holding [SOURCE] will turn the device On or Off.

2015-03-05 9 1511647
Touch Command
Description
iPod MENU – Touch this button to display the iPod menu, as shown
below:
Utilize the Up and Down arrows, then touch Select when the appropriate
choice is displayed.
VOLUME – Touch this button to lower the volume.
VOLUME – Touch this button to raise the volume.
VOLUME – Touch this button to mute the volume.
PREV TRACK – Plays the previous track current CD.
NEXT TRACK – Plays the next track of the current CD.
PLAY/PAUSE – Toggles between Play and Pause modes when a CD is
playing.

2015-03-05 10 1511647
Touch Command
Description
REWIND - Touch this button to rewind the current selection.
FAST FORWARD - Touch this button to fast forward the current selection.
Regal F700 Stereo AUX Home Screen
To access the Regal F700 Stereo Settings, press
Utilize the + and – keys to adjust the appropriate settings.
