Regency ACC40LENG Quick start guide

LISTINGS AND CODE APPROVALS
These gas appliances have been
tested in accordance with AS/NZS
5263.0 & AS/NZS 5263.1.8:2016
and have been certified by IAPMO
for installation and operation as
described in these Installation and
Operating Instructions.
Must be installed as per AS/NZS5601.
Your unit should be serviced
annually by an authorised service
person.
City Series®
Zero Clearance Direct Flue Gas Fireplace
Owners &
Installation Manual
STYLE
Left Corner
Right Corner
MODEL
ACC40LENG / ACC40LELP / ACC40LEULPG
ACC40RENG / ACC40RELP / ACC40REULPG
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Warning
Fire or explosion Hazard
failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
920-124 03.12.20
www.regency-re.com.au
Installer: Please complete the details on the back cover and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
PRIMARILY A DECORATIVE AND NOT A
HEATING APPLIANCE.
DO NOT MODIFY THIS APPLIANCE.

4| City Series ACC40E
data badge
This is a copy of the label that accompanies Direct Flue Gas Fireplace. We have printed a copy of the contents here for your review. The safety label is
located on the front inside base of the unit, visible when the outer front panel is removed.
NOTE: Regency® units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one.
Copy of Data Badge
Part #: 920-216 - Side A Colours: Black on white, except for parts indicated as being Red. Punch out .25" hole top right corner where indicated. Size: 100% W- 6.198" x L- 9.18" Feb. 18/20: Created decal Mar 2/20: Updated lighting plate and serial decal. Material: Printable white polyester 7mm Start serial sequence @ 000001 NOTE: This is a double sided decal
Part #: 920-216 - Side B Colours: Black on white, except for parts indicated as being Red. Punch out .25" hole top right corner where indicated. Size: 100% w- 6.52" h- 11.13" Feb. 18/20: Created decal
Part #: 920-123e
Colour: Black on Grey
Size: 100% 7" W x 2.7" H
June11/19: Created decal
June 13/19: Removed -11 as per Daniela
Jan. 28/20: Added approval number.
Feb. 12/20: Removed first “injector size” value, updated “gas consumption low”
Feb. 19/20: Added label “Primarily a decorative and not a heating appliance”
Mar. 2/20: Changed some consumption and pressure values.
Serial
Number
Regency Gas Fireplace
528
Distributed by:
Western Australia:
Air Group Australia
28 Division St
Welshpool, WA 6106
Eastern Australia
Fireplace Products
Australia Pty. Ltd.
1 Conquest Way
Hallam, VIC 3803
New Zealand
Aber Holdings
17 Main Street Place
Te Rapa, HA 3200
To be installed by an authorised person in
accordance with installation instructions
provided with the appliance.
Electrical: 240V 50/60 Hz
920-123e
Gas Type NG Propane ULPG
Model
ACC40LENG ACC40LELP
ACC40LEULPG
Gas Consumption High 30 MJ/h 30 MJ/h 24 MJ/h
Manifold Pressure High 0.96 kPa 2.60 kPa 2.60 kPa
0.30 kPa 0.70 kPa 0.63 kPa
Injector Size
2.40 mm 1 x #53 1 x #54
1.51 mm 1.39 mm
Approval No. GMK10594
AS/NZS 5263.0 & AS/NZS 5263.1.8
Gas Consumption Low 17.1 MJ/h 16.0 MJ/h 11.7 MJ/h
Manifold Pressure Low
ACC40RENG ACC40RELP
ACC40REULPG
Supply Pressure (Min.) 1.13 kPa 2.75 kPa 2.75 kPa
PRIMARILY A DECORATIVE AND NOT A
HEATING APPLIANCE
920-214
Part #: 920-214 Colours: Black on Grey, except for parts indicated as being Red. Punch out .25" hole top right corner where indicated. Size: 100% w- 6.52" h- 11.13" Feb 18/20: Created decal Mar 2/20: Added: "SUITABLE ONLY FOR INDOOR INSTALLATION", removed French.
DO NOT REMOVE THIS INSTRUCTION PLATE
SUITABLE ONLY FOR INDOOR INSTALLATION
This appliance must be installed in accordance with local codes, if any. If none, follow the current AS/INZS 5601.
CAUTION: Hot while in operation. Do not touch. Severe Burns may result. Due to high surface temperatures keep children, clothing and furniture, gasoline and other liquids having ammable vapors away. Keep burner and control compartment clean. See installation and operating instructions accompanying appliance.
LIGHTING INSTRUCTIONS
FOR YOUR SAFETY READ BEFORE LIGHTING
WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to the owner’s information manual provided with this appliance. For assistance or additional information consult a qualified installer, service agency, or gas supplier.
A) BEFORE LIGHTING smell all around the appliance area for gas. Be sure to smell next to the oor because some gas is
heavier than air and will settle on the oor.
WHAT TO DO IF YOU SMELL GAS - Do not try to light any appliance - Do not touch any electric switch, do not use any phone in your building - Immediately call your gas supplier from a neighbors phone. Follow the gas supplier’s instructions. - If you cannot reach your gas supplier, call the re department. B) Do not use this appliance if any part has been under water. Immediately call a qualied service technician to inspect the
appliance and to replace any part of the control system and any gas control which has been under water.
This appliance needs fresh air for safe operation and must be installed so there are provisions for adequate combustion and ventilation air.
STOP! Read the safety information above on this label.
1) Ensure the Main switch is in the ON position and/or the wall mounted battery holder (if equipped) is in the <REMOTE> position. 2) Press and release the ON/OFF button on the remote handheld transmitter. An audible beep should be heard from the receiver. If not
using the remote, the unit can also be turned on by sliding the battery holder switch to the <ON> position (if equipped).
3) After approximately 4 seconds the spark ignition system will spark for 60 seconds to light the main burner.
4) The unit will turn on. Note: The rst attempt to ignition will last approximately 60 seconds. If there is no ame ignition (rectication) the board will stop spark- ing for approximately 35 seconds. After this wait time, the board will start a second try for ignition by sparking for approximately 60 seconds. If there is still no positive ignition after the second attempt the board will go into lock out. The system will need to be reset as follows (after going into lock out mode): a) Wait 5 minutes - turn the system o󰀨 by pressing the ON/OFF button on the remote. b) After approximately 2 seconds, press the ON/OFF button again. c) Unit will repeat step 2.
TO TURN OFF GAS APPLIANCE
1. Press the ON/OFF button once. 2. Turn o󰀨 all electric power to the unit if service is to be performed.
920-216
920-216
Part #: 908-602c
Colour: Black on White, expect what is indicated in yellow.
Size: printed at 100%
July 18/17: Rev. C - Changed wording on Line 3 as per AGA -
removed Lines 4, 6 and 7 - updated caution
symbol size and font size to 10pt
May 7/14: Changed wording on Line 3 as per AGA
Dec 12/12: Removed redundant ‘do not’ from the last line
Mar. 3/09: Rev. A - added information
Nov. 6/06: no changes to artwork.
DO NOT OPERATE THIS APPLIANCE BEFORE READING THE
INSTRUCTIONS BOOKLET.
DO NOT PLACE ARTICLES ON OR AGAINST THIS
APPLIANCE
DO NOT STORE CHEMICALS OR FLAMMABLE MATERIALS
NEAR THIS APPLIANCE.
DO NOT OPERATE WITH PANELS, COVERS OR GUARDS
REMOVED FROM THIS APPLIANCE.908-602c

City Series ACC40E | 5
dimensions
643mm
842mm
943mm
1089mm
1109mm
261mm
382mm
200mm
375mm
873mm
475mm
449mm
172mm
102mm
1219mm
587mm 616mm
1203mm
Note: Height Dimension may vary depending on the height of the leveling legs.
Dimensions (Left Corner)
Note: These units are non-load bearing.
ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY.
ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS.

6| City Series ACC40E
dimensions
1091mm
643mm
842mm
943mm
1108mm
200mm
382mm
262mm
374mm
873mm
448mm
475mm
172mm
102mm
290mm
184mm
587mm 616mm
1203mm
Dimensions (Right Corner)
Note: Height Dimension may vary depending on the height of the leveling legs.
Note: These units are non-load bearing.

City Series ACC40E | 23
installation
Caution Requirements
The top, back and sides of the fireplace are defined by
standoffs. The metal ends of the standoff may NOT be
recessed into combustible construction.
WARNING
Fire hazard is an extreme risk
if these clearances (air space) to combustible materials are not
adhered to. It is of greatest importance that this fireplace and flue
system be installed only in accordance with these instructions.
Clearances
The clearances listed below are Minimum distances unless otherwise stated:
A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this
fireplace and flue system be installed only in accordance with these instructions.
Note: ACC40LE shown in illustration. Clearances will be the same for the ACC40RE.
Clearance: single sided Dimension Measured From:
A: Mantel Height (min.) ** Top of Fireplace Opening
B: Opening Height 382mm Bottom/Top of Fireplace Opening
C: From Floor Min. 0mm Bottom of Fireplace Opening
D: Sidewall (on one side) Min. 914mm Side of Fireplace Opening
E: Mantel Depth (Max.) ** Front of Fireplace Opening
F: Alcove Depth Min. 914mm Front of Fireplace Opening
G: Convection Air Outlet * Top of Enclosure
H: Convection Air Outlet Opening Offset 0-76mm Max. offset from top of chase enclosure
I: Chase Enclosure (Min.) 1600mm From Base of Unit
K: Clearance to sprinkler head (Min.) 914mm Perpendicular from chase grill
Hearth 0mm No hearth required
** See mantel clearances chart in this manual.
Top View
Alcove
The HeatWave Duct Kit has differ-
ent clearance and framing require-
ments, check the HeatWave manual
for details.
*A minimum of 774 square centimetres of
open area, not lower than 76mm from top
of enclosure, required for all installations
H
I
A
E
B
C
G
D
F
D
F
CC40 UNIT
Side view
L
Chase grill
Sprinkler
K
Flue Clearances to Combustibles
Horizontal - Top 76mm
Horizontal - Side 51mm
Horizontal - Bottom 51mm
Vertical 51mm
Passing through wall/
floor/ceiling - when
firestop is used.
38mm

24 | City Series ACC40E
installation
Clearances
ACC40LE shown
ACC40LE shown
E
G
G
G
H
B
I
L
o
w fr
a
min
g
wi
t
h v
e
n
ts
E
G
B
H
I
Fl
oo
r
to
ce
ilin
g
wi
t
h
top
op
Floor to ceiling with top opening
Low framing with vents in front/sides or top

City Series ACC40E | 25
installation
Clearances
ACC40LE shown
ACC40LE shown
Chase enclosed
H
E
B
I
H
G
G
H
E
B
I
H
G
G
Full framing with vents in front or sides
Full framing with low vents in front or sides

26 | City Series ACC40E
installation
Mantel Clearances
Combustible mantel clearances from top of front facing
are shown in the diagram on the right.
254
0
229mm
383mm
254
508
To p of
Fireplace
Opening
305mm
13mm Plasterboard, timber, timber panel, etc.
To
Bottomof
Fireplace
Opening
130mm
127

City Series ACC40E | 27
installation
Framing Dimensions (Left Corner)
NOTE: Framing may be constructed of combustible material (ie. 51mm x 102mm) and does not require steel studs.
Note: A combined minimum of
774 square centimetres of open
area is required for the convection
air outlet to cool the enclosure.
Ensure clearances for Convection
Air Outlets are met.
See clearances ACC40LE/AC-
C40RE (single sided) in this manual
as there are different methods as to
how this can be achieved.
Note: This appliance must be in-
stalled on a level and solid surface
such as a plywood floor which must
be the full width and depth of the
appliance.
Framing
Dimensions Description ACC40LE
A Framing Height 949mm
B Framing Width 1226mm
C Framing Depth 483mm
D Unit Base to Top Enclosure (Min.) 1600mm
G Flue Centerline Height 1429mm
NOTE: Unit cannot be load-bearing. All finishing materials must be supported by the framing.
Maximum material dimen-
sions 51mm x 102mm for
Header studs (installed
on edge and flat)

28 | City Series ACC40E
installation
Framing Dimensions (Right corner)
NOTE: Framing may be constructed of combustible material (ie. 51mm x 102mm)and does not require steel studs.
Framing
Dimensions Description ACC40RE
A Framing Height 949mm
B Framing Width 1226mm
C Framing Depth 483mm
D Unit Base to Top Enclosure (Min.) 1600mm
G Flue Centerline Height 1429mm
Note: A combined minimum of
774 square centimetres of open
area is required for the convection
air outlet to cool the enclosure.
Ensure clearances for Convection
Air Outlets are met.
See clearances ACC40RE (in this
manual) as there are different meth-
ods as to how this can be achieved.
Note: This appliance must be in-
stalled on a level and solid surface
such as a plywood floor which must
be the full width and depth of the
appliance.
NOTE: Unit cannot be load-bearing. All finishing materials must be supported by the framing.
Maximum material dimen-
sions 51mm x 102mm for
Header studs (installed
on edge and flat)

City Series ACC40E | 35
installation
TV Recessed Into Wall- Typical Installs
Maximum TV Recess TV Flush with Hearth

City Series ACC40E | 41
installation
Venting Introduction
The ACC40LE/ACC40RE uses the "balanced flue" technology Co-Axial system. The inner liner vents products of combustion to the outside while the outer
liner draws outside combustion air into the combustion chamber thereby eliminating the need to use heated room air for combustion and losing warm room
air up the chimney.
Note: These flue pipes must not be connected to any other appliance.
The gas appliance and flue system must be vented directly to the outside of the building, and never be attached to a chimney serving a separate solid fuel or
gas burning appliance. Each direct flue gas appliance must use it's own separate flue system. Common flue systems are prohibited.
Flueing Arrangement for Horizontal Terminations
The diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 90o (two 45o elbows equal one 90o elbow).
Note: Must use optional rigid pipe adapter (Part# 510-994) when using Rigid Pipe Flueing Systems.
• Maintain clearances to combustibles as listed in "Clearances" section
• Horizontal flue must be supported every 0.9m.
• Firestops are required at each floor level and whenever passing through a wall.
• A flue guard should be used whenever the termination is lower than the specified minimum or as per local codes.
• Flex system can only be used up to 3m - otherwise rigid flueing must be used.
Flue RESTRICTOR SETTING:
Flue restrictor factory set at Set 0.
Refer to the "Flue Restrictor Position" section for details on how to change the flue restrictor from the factory setting of Set 0 to Set 2 if required.
Note: For horizontal terminations the Regency Direct Flue Flex System may be used for installations with a maximum continuous flue length of up to 3m.
If longer runs are required, rigid pipe must be used.
1429mm
Metre
1.8
3
4.2
0.9
0.9 1.8 3
5.1
6.1
(Metres)
4.2
3.7
"THIS UNIT MUST ALWAYS
TERMINATE / FLUE
DIRECTLY TO THE OUTDOORS."

40 | City Series ACC40E
installation
Vent Guard - if required*
(Part #946-506/P)
102mm
Horizontal Terminations
Flex Flue 102mm x 175mm
These venting systems, in combination with the ACC40LE/ACC40RE Direct Flue Gas Fireplace, have been tested and listed as a direct flue heater system
by Warnock Hersey/ Intertek. The location of the termination cap must conform to the requirements in the Flue Terminal Locations diagram in "Exterior Flue
Termination Locations" section.
Regency®Direct Flue (Flex) System Termination Kits includes all the parts needed to install the ACC40LE/ACC40RE using a flexible flue.
FPI Kit # Length Contains:
#946-515 1.2m 1. 175mm flexible outer liner (Kit length)
2. 102mm flexible inner liner (Kit length)
3. spring spacers
4. thimble
5. AstroCap termination cap
6. screws
7. tube of Mill Pac
8. plated screws
9. S.S. screws #8 x 38mm drill point
#946-516 3m
Notes:
1. Liner sections should be continuous without any joints
or seams.
2. Only Flex pipe purchased from Regency® may be used
for Flex installations
3. Horizontal vent must be supported every 0.9m.
4. Regency® Direct Vent System (Flex) is only approved for
horizontal terminations.
5. Flex system can only be used up to a maximum continu-
ous vent length of up to 3m. If longer runs are required,
rigid pipe must be used.

42 | City Series ACC40E
installation
Horizontal Terminations
Rigid Pipe 102mm x 175mm
The minimum components required for a basic horizontal
termination are:
1 Horizontal Termination Cap
1 Rigid Pipe Adaptor (510-994)
1 Wall Thimble
1 Length of pipe to suit wall thickness
(see chart)
Wall thickness is measured from the back standoffs to the inside
mounting surface of termination cap. For siding other than vinyl
furring strips may be used instead of the vinyl siding standoff, to
create a level surface to mount the flue terminal. The Terminal
must not be recessed into siding. Measure the wall thickness
including furring strips.
If a Vinyl Siding Standoff is required (it must be used with vinyl
siding), measure to outside surface of wall without siding and
add 51mm.
When using Rigid Flue other than
Simpson Dura-Flue, 3 screws must be
used to secure rigid pipe to adaptor.
This product has been evaluated by Intertek
for using a Rigid Pipe Adaptor in conjunction
with Duravent Direct-Flue, Selkirk Direct-Temp,
Ameri Flue Direct Venting, ICC Excel Direct,
Olympia Chimney and Security Secure Flue
systems. Use of these systems with the Rigid
Pipe adaptor is deemed acceptable and does
not affect the Intertek WHI listing of components.
WARNING:
Do not combine venting components from
different venting systems.
Use of the the AstroCapTM and FPI Riser is
acceptable with all systems.
The FPI AstroCapTM and FPI Riser Flue terminal are certified for installations using FPI venting systems as well as Simpson Dura-Vent® Direct Flue, American
Metal Products Ameri Flue Direct Flue, Security Secure Vent®, ICC Excel, Selkirk Direct-Temp and Olympia Chimney. AstroCapTM is a proprietary trade-
mark of FPI Fireplace Products International Ltd. Dura-Vent® and Direct Flue are registered and/or proprietary trademarks of Simpson Dura-Flue Co. Inc.
Pipe Length
Vertical Terminal
Storm Collar
Flashing
Ceiling Firestop
Adj.Pipe Length
Horizontal
Termination Cap
Wall Thimble
Vinyl Siding
Standoff (Optional)
Rigid Pipe Adapter
o
90 Elbow
Pipe Length
Flat Wall Installation
Wall Thickness
(mm)
Vent Length Required
(mm)
102mm-140mm 152mm
178mm-216mm 229mm
254mm-292mm 305mm
229mm-368mm 279mm-371mm Adj. Pipe
381mm-597mm 432mm-610mm Adj. Pipe

City Series ACC40E | 43
installation
Horizontal Terminations
Rigid Pipe 102mm x 175mm
The diagrams below show examples of horizontal termination arrangements using one, two, or three 90o elbows (two 45o elbows equal one 90o elbow)
1. A maximum of three 90o elbows are permitted.
2. Minimum distance between elbows is 305mm.
• Maintain clearances to combustibles as listed in the "Clearances" section.
• Horizontal flue must be supported every 0.9m.
• Firestops are required at each floor level and whenever passing through a wall.
• Must use optional rigid pipe adaptor (Part# 510-994) when using rigid pipe flue systems.
• A flue guard should be used whenever the termination is lower than the specified minimum or as per local codes.
• Flex system can only be used up to 3m - otherwise rigid flueing must be used.
H
H1
V
Horizontal Venting with Two (2) 90oElbows Horizontal Venting with Three (3) 90oElbows
One 90oelbow = Two 45oelbows.
Option V H + H1
With these options,
maximum total pipe length
is 9.1m with minimum of
1.8m feet total vertical
and maximum 2.4m total
horizontal.
Please note minimum
0.3m between 90oelbows
is required.
Min. Max.
A) 0.3m 0.6m
B) 0.6m 1.2m
C) 0.9m 1.5m
D) 1.2m 1.8m
E) 1.5m 2.1m
F) 1.8m 2.4m
Restrictor Set 0 - Factory Setting
One 90oelbow = Two 45oelbows.
Option V H V + V1 H + H1
With these options,
max. total pipe
length is 9.1m with
min. of 3.6m total
vertical and max.
2.7m total horizon-
tal.
Please note min.
0.3m between 90o
elbows is required.
Min. Max. Min. Max.
A) 0.3m 0.3m 0.6m 0.6m
B) 0.3m 0.6m 0.9m 0.9m
C) 0.6m 0.6m 1.5m 1.2m
D) 0.9m 0.6m 2.1m 1.5m
E) 1.2m 0.9m 2.7m 1.8m
F) 1.5m 1.2m 3m 2.1m
G) 1.8m 1.5m 3.3m 2.4m
H) 2.1m 1.8m 3.6m 2.7m
Restrictor Set 0 - Factory Setting

City Series ACC40E | 45
installation
Flueing Arrangement for Vertical Terminations
Vertical Flueing with Straight Vertical Flueing and or with a max. of two (2) 90oElbows (1 - 90o = 2 - 45o)
The shaded area in the diagram shows all allowable combinations
of straight vertical and offset to vertical terminations, using two
90o elbows, with Rigid Pipe Flueing Systems.
Two 45o elbows equal to one 90o elbow.
• Vent must be supported at offsets.
• Minimum distance between elbows is 305mm.
• Maintain clearances to combustibles as listed in the
"Clearances" section.
• Horizontal vent must be supported every 0.9m.
• Firestops are required at each floor level and whenever
passing through a wall.
• Must use optional rigid pipe adaptor (Part# 510-994) when
using rigid pipe vent systems.
• Refer to the "Vent Restrictor Position" section for details on
how to change the vent restrictor from the factory setting
of Set 0 through to Set 3 if required.
"THIS UNIT MUST ALWAYS
TERMINATE / FLUE
DIRECTLY TO THE OUTDOORS."

44 | City Series ACC40E
installation
Vertical Terminations
Rigid Pipe 102mm x 175mm
The minimum components required for a basic vertical
termination are:
1 Vertical Termination Cap
1 Rigid Pipe Adaptor (510-994)
1 Ceiling Firestop
1 Flashing
1 Storm Collar
1 Length of pipe to suit wall thickness
(see chart)
When using Rigid Flue other than
Simpson Dura-Flue, 3 screws must be
used to secure rigid pipe to adaptor.
This product has been evaluated by Intertek for using a Rigid Pipe Adaptor in conjunction
with Duravent Direct-Flue, Selkirk Direct-Temp, Ameri Flue Direct Venting, ICC Excel
Direct, Olympia Chimney, and Security Secure Flue systems. Use of these systems with
the Rigid Pipe adaptor is deemed acceptable and does not affect the Intertek WHI listing
of components.
WARNING:
Do not combine venting components from different venting systems.
Use of the the AstroCapTM and FPI Riser is acceptable with all systems.
The FPI AstroCapTM and FPI Riser Flue terminal are certified for installations using FPI venting systems as well as Simpson Dura-Vent® Direct Flue, American
Metal Products Ameri Flue Direct Flue, Security Secure Vent®, ICC Excel, Selkirk Direct-Temp and Olympia Chimney. AstroCapTM is a proprietary trade-
mark of FPI Fireplace Products International Ltd. Dura-Vent® and Direct Flue are registered and/or proprietary trademarks of Simpson Dura-Flue Co. Inc.
Galvanized pipe is desirable above the roofline due to its higher
corrosion resistance. Continue to add pipe sections through the
flashing until the height of the flue cap meets the minimum height
requirements specified in diagram 2 or local codes. Note that for
steep roof pitches, the vertical height must be increased. A poor
draft, or down drafting can result from high wind conditions near
big trees or adjoining roof lines, in these cases, increasing the flue
height may solve the problem.
Roof Pitch
Meters
flat to 7/12 0.61
over 7/12 to 8/12 0.61
over 8/12 to 9/12 0.61
over 9/12 to 10/12 0.76
over 10/12 to 11/12 0.99
over 11/12 to 12/12 1.22
over 12/12 to 14/12 1.52
over 14/12 to 16/12 1.83
over 16/12 to 18/12 2.13
over 18/12 to 20/12 2.29
over 20/12 to 21/12 2.44
Diagram 2
Diagram 1

46 | City Series ACC40E
installation
Vertical Terminations
Rigid Pipe 102mm x 175mm
• Two 45o elbows equal to one 90o elbow. Maximum of six 45o elbows allowed.
• Flue must be supported at offsets.
• Minimum distance between elbows is 305mm.
• Maintain clearances to combustibles as listed in the "Clearances" section.
• Horizontal flue must be supported every 0.9m.
• Firestops are required at each floor level and whenever passing through a wall.
• Must use optional rigid pipe adaptor (Part# 510-994 when using rigid pipe flue systems)
Vertical Flueing with Three (3) 90oElbows
One 90oelbow = Two 45oelbows.
V
H1 H
V1
Option V H + H1 V + V1
With these options,
max. total pipe length
is 9.1m with min.
of 3m total vertical
and max. 2.4m total
horizontal.
Please note min.
0.3m between 90o
elbows is required.
Min. Max. Min.
A) 0.3m 0.6m 0.9m
B) 0.6m 0.9m 1.2m
C) 0.9m 1.2m 1.8m
D) 1.2m 1.5m 2.1m
E) 1.5m 1.8m 2.4m
F) 1.8m 2.1m 2.7m
G) 2.1m 2.4m 3.0m
Lengths do not include elbow indicated
