Regency CV40E-NG Quick start guide

Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
City Series®
Zero Clearance Direct Vent Gas Fireplace
Owners &
Installation Manual
STYLE MODEL
Single sided CV40E-NG / CV40E-LP
Three sided CB40E-NG / CB40E-LP
Tested by:

- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach you gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Warning
FIre or explosion Hazard
failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
919-648 FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4 10.24.16

2| City Series
This appliance may be installed in an aftermarket, permanently lo-
cated, manufactured home (USA only) or mobile home, where not
prohibited by local codes.
This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible fore use with other
gases, unless a certified kit is used.
To the New Owner:
Congratulations!
You are the owner of a state-of-the-art Gas Fireplace by REGENCY®. The City Series are hand crafted appliances and
have been designed to provide you with all the warmth and charm of a wood fireplace at the flick of a switch. The CV40E/
CB40E City Series have been approved by Intertek for both safety and efficiency. As it also bears our own mark, it promises
to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now to
acquaint yourself with these instructions and the many features of your Regency® Fireplace.

City Series | 3
MANUFACTURED MOBILE HOME REQUIREMENTS
INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE
This Regency® product has been tested and listed by Intertek as a Direct Vent Wall Furnace to the following standards: VENTED GAS
DECORATIVE FIREPLACE CAN/CGA-2.17-M91, and ANSI Z21.50-2014 • CSA 2.22-2014. and GAS-FIRED APPLIANCES FOR USE AT
HIGH ALTITUDES CAN/CGA 2.17-M91.
This Direct Vent System Appliance must be installed in accordance with the manufacturer's installation instructions and the Manufactured
Home Construction and Safety Standard, Title 24 CFR, Part 3280, or the current Standard of Fire Safety Criteria for Manufactured Home
Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240-MH Mobile Home Standard in Canada.
This appliance installation must comply with the manufacturer's installation instructions and local codes, if any. In the absence of local codes
follow the current National Fuel Gas Code, ANSI Z223.1 and the current National Electrical Code ANSI/NFPA 70 in the U.S.A., and the
current CAN/CGA B149 Gas Installation Code and the current Canadian Electrical Code CSA C22.1 in Canada.
This Regency® mobile/manufactured home listed appliance comes factory equipped with four 1/4" diameter holes located near each corner
of the base. Fasten the fireplace in place using screw, inserted through the holes.
This appliance comes equipped with a dedicated #8 Ground Lug for attachment of the ground wire to the steel chassis as applicable to local
codes. See the "Wiring Diagram" section.
The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the
National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1.
This appliance may only be installed in an aftermarket permanently located, manufactured home (U.S.A only) or mobile home, where not
prohibited by local codes.
This appliance can only be used with the type of gas indicated on the rating plate. This appliance is not convertible for use with other cases,
unless a certified kit is used.
Ensure that structural members are not cut or weakened during installation.

4| City Series
table of contents
Unit Installation with Horizontal Termination ...............55
Dura-Vent Horizontal terminations ...............................56
Dura-Vent Vertical Termination ....................................57
4" x 6-5/8" venting .......................................................57
Vertical Termination 4" x 6-5/8" venting ......................58
Vertical flue extension kit (part #946-756) ...................59
Ceiling Firestop / firestop spacer (part #946-757) .......59
High Elevation ..............................................................60
Gas Line Installation ....................................................60
Pilot Adjustment ...........................................................60
Gas Pipe Pressure Testing ..........................................60
885 S.I.T. Valve Description .........................................60
Wiring Diagrams ..........................................................61
Inner glass panel (firebox glass) Installation/removal . . 62
Outer safety glass panel (barrier glass) Installation /
removal ........................................................................64
Outer safety glass panel Installation / removal ............65
LP conversion instructions ...........................................66
Accessories
CV40E Painted panel installation ................................68
Inner Panels-CV40E ....................................................68
Outer Panels-CV40E ...................................................68
CV40E glass panel installation ....................................69
CV40E enamel panel installation .................................70
CB40E Painted panel installation ................................71
Inner Panels - CB40E ..................................................71
Outer Panels - CB40E .................................................71
CB40E glass panel installation ....................................72
CB40E enamel panel installation .................................73
Burner and Firebox media options ..............................74
Optional driftwood Log set Installation .........................75
CV40E (single sided) - Optional finishing trim .............77
First Fire ......................................................................78
Normal Operating Sounds Of Gas Appliances ............78
Aeration Adjustment ....................................................78
Lighting Procedure ......................................................79
Shutdown Procedure ...................................................79
Copy of the Lighting Plate Instructions ........................80
Maintenance
Maintenance Instructions ............................................81
Log Replacement ........................................................81
Glass Gasket ...............................................................81
Glass ...........................................................................81
Glass replacement .......................................................81
Bulb Replacement .......................................................82
Valve Replacement ......................................................83
Parts
CV40E main assembly ................................................84
CB40E main assembly ................................................87
Warranty .....................................................................91
Copy of Safety Decal .....................................................5
Important Message ......................................................9
Before You Start .............................................................9
Installation
General Safety Information ..........................................10
Installation Checklist ....................................................10
Heatwave Duct System ...............................................10
Locating Your Gas Fireplace ........................................11
Unit Assembly Prior to Installation ...............................11
Clearances CV40E (single sided) ................................13
Clearances CB40E (3 sided) .......................................14
Clearances CB40E (3 sided) .......................................15
Mantel Clearances CV40E/CB40E 3 sided .................16
Mantel Leg Clearances ................................................16
Framing Dimensions CV40E (single sided) .................17
Framing Dimensions CB40E (3 sided) ........................18
Optional framing kit Installation CB40E .......................19
Optional compact wood panel kit Installation CB40E . . 25
Optional compact wood panel kit Installation CB40E . . 27
Optional extended wood panel kit Installation CB40E . 28
Optional extended wood panel and TV bracket kit Instal-
lation CB40E ................................................................30
Optional extended hearth kit Installation CB40E .........33
Optional compact & extended hearth panel kit
Installation CB40E .......................................................35
Optional Front Grill Installation ....................................36
Optional Side Grill Installation .....................................37
Wall Board/Drywall Installation CV40E/CB40E ...........38
Framing and Finishing Inset Installations CV40E ........39
Framing and Finishing Inset Installations CB40E ........40
Extended Finish CB40E (walls closed off at either end) . .
40
Guidelines for installing a TV above the unit ...............41
Exterior Vent Termination Locations ............................42
4” x 6-5/8” Rigid Pipe Cross Reference Chart .............43
Wall mount On / Off Switch and battery holder ...........45
Vent Restrictor Position ...............................................46
Venting
Horizontal Terminations ...............................................47
Flex Vent 4" x 6-7/8" ....................................................47
Venting Introduction .....................................................48
Venting Arrangement for Horizontal Terminations .......48
Horizontal Terminations ...............................................49
Rigid Pipe 4" x 6-5/8" ...................................................49
Horizontal Terminations ...............................................50
Rigid Pipe 4" x 6-5/8" ...................................................50
Horizontal Venting with Two (2) 90o Elbows .................50
Horizontal Venting with Three (3) 90o Elbows ..............50
Vertical terminations Rigid Pipe 4" x 6-5/8" .................51
Venting Arrangement for Vertical Terminations ............52
Vertical Terminations Rigid Pipe 4" x 6-5/8" ...............53
Installation with Horizontal Termination ......................54
4" x 6-5/8" venting .......................................................54

City Series | 5
safety decal
This is a copy of the label that accompanies Direct Vent Gas
Fireplace. We have printed a copy of the contents here for your
review. The safety label is located on the front inside base of
the unit, visible when the outer front panel is removed.
NOTE: Regency® units are constantly being improved. Check
the label on the unit and if there is a difference, the label on
the unit is the correct one.
Copy of Safety Decal
For the State of Massachusetts, installation
and repair must be done by a plumber or
gasfitter licensed in the Commonwealth of
Massachusetts.
For the State of Massachusetts, flexible con-
nectors shall not exceed 36 inches in length.
For the State of Massachusetts, the appli-
ances individual manual shut-off must be a
t-handle type valve.
The State of Massachusetts requires the
installation of a carbon monoxide alarm in
accordance with NFPA 720 and a CO alarm
with battery back up in the same room where
the gas appliance is installed.
Part #: 919-649 - Side AColour: Black on grey except what is indicated as being printed red.Size: (File at 100%) 9.3"w x 5.9"hMaterial: Mar. 21/16: Created draftAug. 10/16: Updated decalAug. 15/16: Updated decal as per Matt C
DO NOT REMOVE THIS LABEL / NE PAS ENLEVER CETTE ÉTIQUETTE 445445DOOR SEAL: Please check that the door is properly sealed
FPI Fireplace Products International Ltd. Delta, BC, Canada
Minimum Clearances to Combustibles /Dégagement minimum des matériaux combustiblesSerial No./ No de Série919-649
MAY BE INSTALLED IN MANUFACTURED (MOBILE) HOMES AFTER FIRST SALE.
Listed/Nom: VENTED GAS FIREPLACE / FOYER AU GAZ À ÉVACUATIONCertified for/Certifie pour: CANADA and U.S.A.éTested to: CAN/CGA-2.17-M91(R2009)ANSI Z21.50-2014Conforms to:CSA 2.22-2014Certified to:
Electrical supply / Alimentation électrique 115VAC, 1.5 A, 60Hz. Made in Canada/ Fabriqué au CanadaDuplicate S/N(See Instruction Manual for detailed instructions)(Voir Manuel pour plus de détails)
APPAREIL FONCTIONNANT AU GAZ PROPANECONÇU POUR FOYER :Modèle
CV40E-LP/CB40E-LP
PROPANE GAS: Model: CV40E-LP/CB40E-LP
NATURAL GAS: Model: CV40E-NG/CB40E-NGMinimum supply pressureManifold pressure - HighManifold pressure - LowOrifice sizeMaximum inputMinimum inputAltitudeAPPAREIL FONCTIONNANT AU GAZ NATUREL CONÇU POUR FOYER :Modèle CV40E-NG/CB40E-NG
5.0" WC/C.E. (1.25 kPa)3.8" WC/C.E. (0.94 kPa)1.1" WC/C.E. (0.27 kPa)# 42 DMS 28,500 Btu/h (8.33 kW)15,500 Btu/h (4.54 kW)0-4500 ft/pi (0-1372 m)11" WC/C.E. (2.73 kPa)10.5" WC/C.E. (2.62 kPa)2.9" WC/C.E. (0.72 kPa)# 53 DMS 28,500 Btu/h (8.35kW)15,500 Btu/h (4.54 kW)0-4500 ft/pi (0-1372 m)
Minimum supply pressureManifold pressure - HighManifold pressure - LowOrifice sizeMaximum inputMinimum inputAltitude
DEFA
B
C
Side Walls / Murs latérauxA 8.5” (216 mm)Ceiling / PlafondB 37-1/2” (953 mm)Min. Mantel Height /Hteur Min ManteauC 9" (229 mm) with 12” mantelMax. Mantel Depth/Profondeur Max ManteauD 12” (305 mm) Alcove Width/Largeur AlcôveE 84" (1524 mm)Alcove Depth/Profondeur AlcôveF 36" (2134 mm)This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1, or Natural Gas and Propane Installation Code, CSA B149.1.This appliance must be installed in accordance with the Standard CAN/CSA Z240 MH, Mobile Housing, in Canada, or with the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, in the United States, or when such a standard is not applicable, ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home Installations Standard or ANSI A119.2 ou NFPA 501C Standard for Recreational VehiclesThis appliance is only for use with the type(s) of gas indicated on the rating plate and may be installed in an aftermarket, permanently located, manufactured home (USA only) or mobile home, where not prohibited by local codes. See owner's manual for details. This appliance is supplied with a conversion kit.L'appareil doit être installé conformément aux codes et règlements locaux, ou, en l'absence de tels règlements, selon les codes d'installation National Fuel Gas Code ANSI Z223.1, ou CSA-B149.1 Natural Gas and Propane Installation Code en vigueur.L'appareil doit être installé conformément à la norme CAN/CSA-Z240, Série MM, Maisons mobiles ou CAN/CSA-Z240 VC, Véhicules de camping, ou la norme 24 CFR Part 3280, Manufactured Home Construction and Safety Standard. Si ces normes ne sont pas applicables, veuillez vous référer à la norme ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home Installations Standard, ou ANSI A119.2 ou NFPA 501C Standard for Recreational Vehicles.Cet appareil doit être utilisé uniquement avec les types de gaz indiqués sur la plaque signalétique et peut être installé dans une maison préfabriquée (É.-U. seulement) ou mobile installée à demeure si les règlements 4001172
For Use Only with Barrier CV40E - 1 sided (Part # 940-435/P) & CB40E 3 sided (Part # 940-438/P,940-439/P,940-440/P) Follow installation instructions. Utiliser uniquement avec l’écran CV40E -1 face (n°940-435/P) & CB40E - 3 faces (n°940-438/P,940-439/P,940-440/P) . Suivre les instructions d'installation.
Pression d'allimentation minimumPression de sortie (manifold) - HautePression de sortie (manifold) -
Basse
Taille de l’orificeDbit Calorifique maximum éDbit Calorifique minimuméAltitude
Pression d'allimentation minimumPression de sortie (manifold) - HautePression de sortie (manifold) - BasseTaille de l’orificeDbit Calorifique maximuméDbit Calorifique minimuméAltitude
VENTED GAS FIREPLACE - NOT FOR USE WITH SOLID FUELS. NE PAS UTILISER AVEC UN COMBUSTIBLE SOLIDE. FOYER AU GAZ À ÉVACUATION -
Part No. 946-556 Heatwave Kit may be used. La trousse Heatwave (pièce n°946-556) peut être utilisée.Model/Modele: CV40E-NG CV40E-LP CB40E-NG CB40E-LP FOR USE WITH GLASS DOORS CERTIFIED WITH THE APPLIANCE ONLY DOITÊTRE UTILISÉ UNIQUEMENT AVEC LES PORTES VITRÉES CERTIFIÉES AVEC Downloaded from www.Manualslib.com manuals search engine

6| City Series
requirements
5.08: Modifications to NFPA-54, Chapter 10
(2) Revise 10.8.3 by adding the following additional requirements:
(a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for
residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than
seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall
be satisfied:
1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the time of installation of the side wall horizontal vented gas fueled
equipment, the installing plumber or gasfitter shall observe that a hard wired carbon monoxide detector with an alarm and battery back-up is
installed on the floor level where the gas equipment is to be installed. In addition, the installing plumber or gasfitter shallobserve that a battery
operated or hard wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure
served by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the services of
qualified licensed professionals for the installation of hard wired carbon monoxide detectors
a. In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired carbon
monoxide detector with alarm and battery back-up may be installed on the next adjacent floor level.
b. In the event that the requirements of this subdivision can not be met at the time of completion of installation, the owner shall have a period of
thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day period, a batteryoperated carbon
monoxide detector with an alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance with the above provisions
shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certified.
3. SIGNAGE. A metal or plastic identification plate shall be permanently mounted to the exterior of the building at a minimum height of eight
(8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment. The
sign shall read, in print size no less than one-half (1/2) inch in size, "GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL
OBSTRUCTIONS".
4. INSPECTION. The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation
unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the provisions of 248 CMR
5.08(2)(a)1 through 4.
(b) EXEMPTIONS: The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:
1. The equipment listed in Chapter 10 entitled "Equipment Not Required To Be Vented" in the most current edition of NFPA 54 as adopted by
the Board; and
2. Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the dwelling, building or
structure used in whole or in part for residential purposes.
(c) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM PROVIDED. When the manufacturer of Product
Approved side wall horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the
instructions provided by the manufacturer for installation of the equipment and the venting system shall include:
1. Detailed instructions for the installation of the venting system design or the venting system components; and
2. A complete parts list for the venting system design or venting system.
(d) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM NOT PROVIDED. When the manufacturer of a
Product Approved side wall horizontally vented gas fueled equipment does not provide the parts for venting the flue gases, butidentifies
"special venting systems", the following requirements shall be satisfied by the manufacturer:
1. The referenced "special venting system" instructions shall be included with the appliance or equipment installation instructions; and
2. The "special venting systems" shall be Product Approved by the Board, and the instructions for that system shall include a parts list and
detailed installation instructions.
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions,
all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipmentat the completion of
the installation.
MA Code - CO Detector
(for the State of Massachusetts only)

City Series | 7
dimensions
33716"849mm
381316"986mm43"1091mm
25916"648mm
4614"1175mm
714"183mm
43916"1107mmØ634"171mmØ4"102mm
11716"291mm
2178"556mm181116"475mm171116"449mm
15116"382mm778"200mm3738"949mm3458"879mm1012"267mm
CV40E (single sided) dimensions
Dimensions will appear as (inches)" / (metric)mm
throughout this manual. The inches are rounded to the
nearest 1/16" when converted, when greater accuracy
is required, use the metric dimensions.

8| City Series
dimensions
48716"1231mm
25
9
16"648mm3738"949mm
43"1091mm47"1194mm
33716"849mm714"183mm
Ø4"102mmØ634"171mm
11716"291mm
48716"1231mm2414"616mm4958"1261mm181116"475mm171116"449mm
3458"879mm1012"267mm15116"382mm3958"1007mm778"200mm
CB40E (3 sided) dimensions
Dimensions will appear as (inches)" / (metric)mm
throughout this manual. The inches are rounded to the
nearest 1/16" when converted, when greater accuracy
is required, use the metric dimensions.

City Series | 9
installation
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED
ON OR NEAR THE APPLIANCE.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACE TEMPERATURES, ESPE-
CIALLY THE FIREPLACE GLASS, AND
SHOULD STAY AWAYTO AVOID BURNS
OR CLOTHING IGNITION.
INSTALLATION AND REPAIR SHOULD
BE DONE BY AN AUTHORIZED
SERVICE PERSON. THE APPLIANCE
SHOULD BE INSPECTED BEFORE
USE AND AT LEAST ANNUALLY BY A
PROFESSIONAL SERVICE PERSON.
MORE FREQUENT CLEANING MAY
BE REQUIRED DUE TO EXCESSIVE
LINT FROM CARPETING, BEDDING
MATERIAL,ETC.IT IS IMPERATIVETHAT
CONTROLCOMPARTMENTS,BURNERS
AND CIRCULATING AIR PASSAGEWAYS
OF THE APPLIANCE BE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED
OUT OF TRAFFIC AND AWAY FROM
FURNITURE AND DRAPERIES.
WARNING: FAILURE TO INSTALL THIS
APPLIANCE CORRECTLY WILL VOID
YOUR WARRANTY AND MAY CAUSE A
SERIOUS HOUSE FIRE.
YOUNG CHILDREN SHOULD BE CARE-
FULLY SUPERVISED WHEN THEY ARE
IN THE SAME AREA AS THE APPLI-
ANCE. TODDLERS,YOUNG CHILDREN
AND OTHERS MAY BE SUSCEPTIBLE
TO ACCIDENTAL CONTACT BURNS. A
PHYSICAL BARRIERS IS RECOMMEND-
ED IFTHERE ARE AT RISK INDIVIDUAL
INTHE HOUSE. TO RESTRICT ACCESS
TO A FIREPLACE OR STOVE, INSTALL
AN ADJUSTABLE SAFETY GATE TO
KEEP TODDLERS, YOUNG CHILDREN
AND OTHER AT RISK INDIVIDUALS OUT
OF THE ROOM AND AWAY FROM HOT
SURFACES.
Important Message
SAVE THESE INSTRUCTIONS
City Line Direct Vent Fireplaces must be installed
in accordance with these instructions. Carefully
read all the instructions in this manual first. Consult
the "authority having jurisdiction" to determine the
need for a permit prior to starting the installation.
It is the responsibility of the installer to ensure
this fireplace is installed in compliance with
manufacturer's instructions and all applicable codes.
Before You Start
Safe installation and operation of this appliance
requires common sense, however, we are required
by the Canadian Safety Standards and ANSI
Standards to make you aware of the following:
ANY SAFETY SCREEN, GUARD, OR
BARRIER REMOVED FOR SERVICING
THE APPLIANCE,MUST BE REPLACED
PRIORTOOPERATINGTHEAPPLIANCE.
IFTHE BARRIER BECOMES DAMAGED,
THE BARRIER SHALL BE REPLACED
WITH THE MANUFACTURER'S
BARRIER FOR THIS APPLIANCE.
A BARRIER DESIGNED TO REDUCE
THE RISK OF BURNS FROM THE HOT
VIEWING GLASS IS PROVIDED WITH
THIS APPLIANCE AND SHALL BE
INSTALLED FOR THE PROTECTION
OF CHILDREN AND OTHER AT-RISK
INDIVIDUALS
WE RECOMMEND REMOVING THE
GLASS WITH THE GLASS VACUUM
HOLDERS SUPPLIED BY THE MANU-
FACTURER. LOWER THE GLASS TO
REST IN A SAFE PLACE. THIS IS TO
PREVENT DAMAGE TO THE GLASS
EDGES.EXTRA CARE MUST BETAKEN
WHEN REMOVING/INSTALLING THE
GLASS. BREAKAGE OR DAMAGE TO
THE EDGE OF THE GLASS WHICH
OCCURS AS A RESULT OF CARELESS
HANDLING WILL NOT BE COVERED
UNDER WARRANTY.

10 | City Series
installation
Installation Checklist
1. Locate appliance. Refer to the following sections:
a) Locating Your Fireplace
b) Clearances
c) Combustible Mantel Clearances
d) Framing & Finishing
e) Venting. See the "Venting Introduction" to
"Venting Arrangements" sections.
2. Assemble Standoffs. Refer to the "Unit Assem-
bly Prior to Installation" section. (NOTE: must
be done before installing unit into fireplace.)
3. Install vent. See the "Horizontal Installations"
to "Installation Procedures" sections.
4. Install 4 AA batteries into receiver battery
box. Hook receiver to wiring marked receiver,
this will enable operation of the appliance
manually when position in "ON" position.
Note: The wire harness (marked receiver) is
located near the gas valve and will need to be
routed to the exterior of the fireplace from either
the left or right hand side of the appliance prior
finishing.
5. Bring 120 volt power to appliance. Required
to operate lights and highly recommended to
operate gas valve. AA Batteries serve as back
up only if 120 volt power is lost.
6. Make gas connections. Test the pilot. Must be as
per diagram. Refer to the "Gas Line Installation"
& "Pilot Adjustment" sections.
7. Install standard and optional features. Refer
to the following sections where applicable:
a. Safety Glass
b. Firebox (inner) glass
c. Log Set
d. Fireglass
e. Ceramic stones or other approved media
f. Painted, enamel or glass panels (panels
required)
g. Optional Framing Kit
h. Heatwave Kit
8. Plug 3 prong plug for the lights into the
receptacle. The 3 prong plug will be located
near the gas valve on the appliance.
9. Final check.
Before leaving this unit with the customer, the
installer must ensure that the appliance is firing
correctly and operation fully explained to customer.
General Safety Information
1. The appliance installation must conform with
local codes or, in the absence of local codes,
with the current Canadian or National Gas
Codes, CAN1-B149 or ANSI Z223.1 Installation
Codes.
2. See general construction and assembly
instructions. The appliance and vent should be
enclosed.
3. This appliance must be connected to the
specified vent and termination cap to the outside
of the building envelope. Never vent to another
room or inside a building. Make sure that the
vent is fitted as per Venting instructions.
4. Inspect the venting system annually for blockage
and any signs of deterioration.
5. Venting terminals shall not be recessed into a
wall or siding.
6. Any safety glass removed for servicing must
be replaced prior to operating the appliance.
7. To prevent injury, do not allow anyone who is
unfamiliar with the operation to use the fireplace.
8. Wear gloves and safety glasses for protection
while doing required maintenance.
9. Be aware of electrical wiring locations in walls
and ceilings when cutting holes for termination.
10. Under no circumstances should this appliance
be modified. Parts that have to be removed for
servicing should be replaced prior to operating
this appliance.
11. Installation and any repairs to this appliance
should be done by a qualified service person.
A professional service person should be called
to inspect this appliance annually. Make it a
practice to have all of your gas appliances
checked annually.
12. Do not slam shut or strike the glass door.
13. Under no circumstances should any solid fuels
(wood, paper, cardboard, coal, etc.) be used in
this appliance.
14. The appliance area must be kept clear and
free of combustible materials, (gases and other
flammable vapours and liquids).
Emissions from burning wood or gas could
contain chemicals known to the State of
California to cause cancer, birth defects or
other reproductive harm.
Heatwave
Duct System
Optional kit
The HeatWave Air Duct Kit increases the
effectiveness of your fireplace by dispersing warm
air from the fireplace to remote locations in the same
room or other rooms in your home.
Up to two kits may be installed on the fireplace.
Please Note: One adaptor kit #656-995 must be
used with each 946-556.
The HeatWave Duct Kit has different clearance
and framing requirements, check the HeatWave
manual for details.
This includes:
1. Clocking the appliance to ensure the correct
firing rate (rate noted on label 28,500 Btu/h NG/
LP) after burning appliance for 15 minutes.
2. If required, adjusting the primary air to ensure
that the flame does not carbon. First allow the
unit to burn for 15-20 min. to stabilize.
CAUTION:Any alterationtothe product thatcauses
sooting or carboning that results in damage
is not the responsibility of the manufacturer.

City Series | 11
installation
Locating Your
Gas Fireplace
1. When selecting a location for your fireplace,
ensure that the clearances are met.
2. The appliance must be installed on a flat, solid,
continuous surface For example a wood, metal
or concrete floor or in a raised (on the wall) ap-
plication. The appliance must be installed on
a metal or wood panel extending the full width
and depth of the appliance.
3. The CV40E/CV40B Direct Vent Gas Fireplace
can be installed in a recessed position or framed
out into the room as in A, B, C, D and E.
See Diagram 1. EDiagram 1
CV40E
CB40E
A) Flat on Wall-CV40E
B) Flat on Wall Corner-CV40E
C) Recessed into Wall/Alcove-CV40E
D) Corner-CV40E
E) 3 sided-CB40E
4. For bedroom installations, check with local
codes before installation. This appliance is
offered with a remote control.
5. The CV40E/CB40E Direct Vent Gas Fireplace
is approved for alcove installations, see "Clear-
ances" section for details.
6. We recommend that you plan your installa-
tion on paper using exact measurements for
clearances and floor protection before actually
installing this appliance. Have an authorized
inspector, dealer, or installer review your plans
before installation.
Note: For vent terminations refer to "Exterior
Vent Termination Locations" section.
Unit Assembly Prior to Installation
Before you start
The CV40E has 6 standoffs, 2 on each side and 2 at the back that need assembly before installation.
The CB40E has only 2 standoffs at the back that need assembly before installation.
WARNING! Risk of Fire! Comply with all minimum clearances.
tooltip
Side and back standoff assembly CV40E
The standoffs are shipped in a flat position and must be folded into shape and attached.
Take each standoff off the unit by removing one screw and bend into the correct shape. Slot the 2 tabs
of the stand off into the slots in the unit and attach the other end with one screw.
Standoff locationsBack standoff assembly CB40E
Take each standoff off the unit by removing one
screw. Bend into the correct shape (see above). Slot
the 2 tabs of the stand off into the slots in the unit
and attach the other end with one screw.

12 | City Series
installation
Levelling bolts
Nailing strips CV40E
Nailing strips are shipped folded flat against the unit.
Fold nailing strips out 90º before installing unit.
Secure nailing strips to framing using wood or
metal screws.
Levelling bolts
There are four levelling bolts - two on each side
that can be adjusted if required.
Access panel removal
The front access panel may be removed for ease
of hooking up gas and electrical. Once complete
ensure that the access panel is reinstalled prior to
any finishing.
The CV40E has 4 screws to remove access cover
and the CB40E has 8 screws to remove access
cover. See locations in diagrams to the right.
Nailingstrips
4 screws
Nailing strips
8 screws
tooltip
Nailing strips CB40E
Nailing strips are shipped with the appliance and will
need to be attached. Note that the nailing strips are
not required if using the optional chase or extended
framing kit and may be recycled.
1. Secure nailing strip to appliance with 2 screws
per side.
2. Secure nailing strips to framing using wood or
metal screws.

City Series | 13
installation
Caution Requirements
The top, back and sides of the fireplace are defined by
standoffs. The metal ends of the standoff may NOT be
recessed into combustible construction.
WARNING
Fire hazard is an extreme risk
if these clearances (air space) to combustible materials are not
adhered to. It is of greatest importance that this fireplace and vent
system be installed only in accordance with these instructions.
Clearances CV40E (single sided)
The clearances listed below are Minimum distances unless otherwise stated:
A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this
fireplace and vent system be installed only in accordance with these instructions.
Note: CV40E (single sided unit) clearances listed on this page - for CB40E (3 sided) see next page.
Clearance: single sided  
 ** Top of Fireplace Opening
 25-9/16" (649mm) Top of Fireplace Opening
B2: Opening Height 15-1/16" (383mm) Bottom/Top of Fireplace Opening
 8-1/2" (216mm) Side of Fireplace Opening
 **
 84" (2134mm) Sidewall to Sidewall (Minimum)
 36" (914mm) Front to Unit (Maximum)
G: Ceiling
(in front of fireplace) 37-1/2" (953mm) Top of Fireplace Opening
 * Top of Enclosure
󰀨 0-3" (76mm) 󰀨
 63" (1600mm) 
Hearth 0" No hearth required
** See mantel clearances chart in this manual.

Horizontal - Top 3"
Horiztonal - Side 2"
Horiztonal - Bottom 2"
Vertical 2"
Passing through wall/
floor/ceiling - when

1-1/2"
Alcove
E
F
D
ACB1GB2JHK
The HeatWave Duct Kit has differ-
ent clearance and framing require-
ments, check the HeatWave manual
for details.
CV40E- Single sided
*A minimum of 120 square
inches of open area, not
lower than 3" from top of
enclosure, required for all
installations

14 | City Series
installation
Caution Requirements
The top, back and sides of the fireplace are defined by
standoffs. The metal ends of the standoff may NOT be
recessed into combustible construction.
WARNING
Fire hazard is an extreme risk
if these clearances (air space) to combustible materials are not
adhered to. It is of greatest importance that this fireplace and vent
system be installed only in accordance with these instructions.
Clearances CB40E (3 sided)
Clearance: 3 sided  
 25-9/16" (649mm) Top of Fireplace Opening
 ** Top of Fireplace Opening
 8-1/2" (216mm) Side of Fireplace Opening
 48-7/16" (1230mm) Minimum inside dimensions
 **
 84" (2134mm) Side wall to side wall (min.)
 36" (914mm) Front of Unit
 0-3" (76mm) From top of enclosure
 120 sq. inches (min) * Top/front or side of enclosure
 19" (483mm) Minimum inside dimensions
J: Opening Height 15-1/16" (383mm) Bottom/Top of Fireplace Opening
 1-1/2" To Top of Ceiling
 63" (1600mm) 
Hearth 0" No hearth required
** See mantel clearances chart in this manual

Horizontal - Top 3"
Horiztonal - Side 2"
Horiztonal - Bottom 2"
Vertical 2"
Passing through wall/
floor/ceiling - when

1-1/2"
* A minimum of 120 square inches of open area, not lower than 3" from top of enclosure, required for all
installations — this can be achieved by having an open area in front, each side, and/or above as shown
in the four diagrams on the next page.
The HeatWave Duct Kit has differ-
ent clearance and framing require-
ments, check the HeatWave manual
for details.
EFAlcove

City Series | 15
installation
Clearances CB40E (3 sided)
Floor to ceiling with top opening Low framing with vents in front/sides or top
Full framing with low vents in front or sides Full framing with vents in front or sides
KCIA1ADLJHBLICDA1AJGGHHHBICGAA1GDJLHHBIBADCJGGLHHDownloaded from www.Manualslib.com manuals search engine

16 | City Series
installation
Mantel Clearances CV40E Single sided / CB40E 3 sided
Combustible mantel clearances from top of front facing
are shown in the diagram on the right.
Mantel Leg Clearances
Combustible mantel leg clearances as per diagram: CombustibleMaterial21264810StandoffWood Stud(OnEdge)014ToUnitBase9”25-9/16”10
20
26TopofFireplaceOpening12" (305mm)Drywall, wood, wood panel, etc.2”
12"4"
AllowablemantelMANTELLEGleg projection
7"
8-1/2"
2"12"
MANTELLEG8-1/2"CV40E (single sided) CB40E (3 sided)

City Series | 17
installation
Framing Dimensions CV40E (single sided)
NOTE: Framing may be constructed of combustible material (ie. 2 x 4)and does not require steel studs.

  CV40E
A Framing Height 37-3/8” (949mm)
B Framing Width 46-3/4" (1187mm)
C Framing Depth 19" (483mm)
D Minimum Height to Combustibles 63"(1600mm)
E Corner Wall Depth 55" (1396mm)
F Corner Facing Wall Width 77-3/4" (1974mm)
G Vent Centerline Height 56-1/4" (1429mm)
I Gas Connection Opening Height 2" (51mm)
J Gas Connection Height 4 " (106mm)
K Gas Connection Inset 13" (330mm)
L Gas Connection Opening Width 3-1/2" (89mm)
Note: A combined minimum of
120 square inches of open area
is required for the convection air
outlet to cool the enclosure. En-
sure clearances for Convection Air
Outlets are met.
See clearances CV40E (single
sided) in this manual as there are
different methods as to how this
can be achieved.
Note: This appliance must be in-
stalled on a solid surface such as
a plywood floor which must be the
full width and depth of the appliance.

18 | City Series
installation
Framing Dimensions CB40E (3 sided)
NOTE: Framing may be constructed of combustible material (ie. 2x4) and does not require steel studs. Two (2) optional steel stud kits may also be purchased.
These kits may be used in place of the conventional wood framing as shown below. It comes as a compact kit (flush to the appliance on all sides)or
an extended kit. The extended kit protrudes beyond each side of the appliance as shown on the front cover of this manual. There is also an optional
hearth kit which may be purchased as shown on the front cover of this manual. These kits are highly recommended as it was designed specifically for
the product to facilitate ease of installation. See instructions in this manual for details.

  CB40E
A Framing Height 37-3/8” (949mm)
B Framing Width 48-1/2" (1232mm)
C Framing Depth 19" (483mm)
D Minimum Height to Combustibles 63"(1600mm)
G Vent Centerline Height 56-1/4" (1429mm)
I Gas Connection Opening Height 2" (51mm)
J Gas Connection Height 4 " (106mm)
K Gas Connection Inset 13" (330mm)
L Gas Connection Opening Width 3-1/2" (89mm)
Note: A combined minimum of 120 square inches of open area is required for the convection air outlet to cool the enclosure. Ensure clearances for Convection
Air Outlets are met. See clearances CB40E (3 sided) in this manual as there are different methods as to how this can be achieved.
Note: Only basic framing dimensions are shown. The framing may also extend beyond the appliance on either side and also extend out front if a hearth is
desired. See clearance/finishing requirements for details
Note: This appliance must be installed on
a solid surface such as a plywood floor
which must be the full width and depth of
the appliance.

City Series | 19
installation
optional framing kit Installation CB40E
Optional Extended and Compact Framing Kits
43210/,+$/()76,'(5,*+76,'(/()75,*+7[[[[[[[[[[[%-[/()75,*+7/()76,'(5,*+76,'($[%[+[,[/[0[1[2[3[4[-[Extended framing kit parts layout
Note: Wood/self tapping screws not provided
Compact framing kit parts layout
Note: Wood/self tapping screws not provided
The following procedure shows the assembly of the extended framing kit—the
installation of the compact framing kit is identical except part 656-224 (Step
24) is not required. Note: Nailing strips not required with framing kit.
1. Start with the unit away from the wall, install Part A (x2) to the back of the
unit with 2 screws on each side.
Part A Install
Orientation to Unit
Screw Locations $%DFN)URQW7RS9LHZ2ULHQWDWLRQRI3DUW$WR8QLWVWDQGRIIVWDQGRIINote: Extra screws are provided to assemble this kit.
Tools/hardware needed are as follows:
- Level
- Stud fi nder
- Cordless screwdriver
- Phillips bit
- 5/16 inch hex head bit
- 2'' to 3'' wood screws (minimum 16)
- Self tapping screws
- Circuit/receptacle tester
- Flashlight

20 | City Series
installation
Part J install to Part B1 + B2
Part J screw locations
Secure Framing to Wall Studs with wood screws
Install Part O (x2) with 1 screw each
Install Part Q (x2) with 1 screw each
Part B1 to A - screws go in from front
2. Install Part B1 + B2 to Part A with 2 screws on each side from the front of
the unit. -3. Install Part J (x 2) to Parts B1 + B2 with 4 screws each (2 top - 2 bottom) -
screw locations shown below.
4. Slide unit into position.Check to ensure that the unit is level from front to back
and side to side and Parts A + B are square. Secure the unit with framing
to the wall studs with 2-1/2"-3" wood screws. Use 8 screws and secure to 4
studs minimum. Install venting before proceeding further with framing
kit construction. Refer to manual for venting instructions.
5. Install Part O to the top of Part B2 with one screw each in location shown
below - swing inward to keep the part out of the way until further in the
installation.
6. Install Part Q (x2) to the top of Part B2 (may have to move Part O slightly
to access screw hole on part B2).
B1/B2 must be
secured to framing/
studs with a minimum
of 8 screws.
