Regency GF1500LST-NG Quick start guide

WARNING:
If the information in these instructions are not followed
exactly, a re or explosion may result causing property
damage, personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use petrol or other ammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualied
installer, service agency or the gas supplier.
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance.
Do not touch any electrical switch.
Do not use any phone in your
building.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the re department.
919-670
Greenre®GF1500LST
Gas Fireplace
December 8, 2016
Owners &
Installation Manual
www.regency-re.com.au
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
MODELS: GF1500LST-NG
GF1500LST-LP
GF1500LST-ULPG
LISTINGS AND CODE APPROVALS
These gas appliances have been tested
in accordance with AS4553 / NZS5262
/ NZS5266 and have been certied by
IAPMO R&T Oceana for installation and
operation as described in these Installation
and Operating Instructions.
Must be installed as per AS/NZS 5601
Your unit should be serviced annually by
an authorised service person.

2Regency GF1500LST Gas Fireplace
To the New Owner:
Congratulations!
You are the owner of a state-of-the-art Gas Fireplace by REGENCY®. The GF1500LST has been designed to provide you with
all the warmth and charm of a wood replace at the ick of a switch. The model GF1500LST has been approved by IAPMO
R&T Oceana for both safety and e󰀩ciency. As it also bears our own mark, it promises to provide you with economy, comfort
and security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and
the many features of your Regency®Fireplace.
PAIRING THE REMOTE HANDSET AND CONTROL BOX ID CODE
The Remote Control Handset has a set of unique ID codes that is pre-programmed into its memory. This set of ID codes helps to di󰀨erentiate one Remote
Control Handset from another so that only the control box with a matching ID code will respond to the appropriate Remote Control Handset.
The control box will only learn the Remote ID codes during the rst 30 seconds after power is applied and will ignore this special command
from the Remote after the rst 30 seconds.
To match the control box to the remote, the following steps are to be followed;
1. Remove a battery from the remote handset.
2. Remove main power to the control box by turning o󰀨 the isolation switch or switch o󰀨 the GPO to the heater.
3. Wait 30 seconds (approx.)
4. Reconnect main power to the control box.
5. Immediately put the battery back in the remote and point hte remote in the general direction of the heater.
6. Press and hold the PROG and FAN buttons simultaneously. The display will show the letters "LC" momentarily indicating the ID codes have been
transmitted.
7. Release both the PROG and FAN buttons.
8. The display will revert back to the normal o󰀨 mode display. The heater should start—ignition and fan, even though the remote screen says the heater is o󰀨.
9. Press the OFF button on the remote. The heater should turn o󰀨.
10. Wait approximately 30 seconds, turn on again and check that all the functions work—fan speed can be adjusted, ame height can be adjusted, etc.
Note: The pairing up process can be carried out by anyone.
Note: In addition; please also go to: www.regency-re.com.au "Care and Tip video" to see the pairing up video.
Note: In an event of power failure when power is restored, the unit will initiate an automatic restart sequence if the remote is still indicating that the heater is on.

Regency GF1500LST Gas Fireplace 3
table of
contents
Installation
Pairing the Remote Handset and Control Box ID Code . 2
Copy of data badge .......................................................4
Unit Dimensions ............................................................5
Important Message ......................................................6
General Safety Information ............................................6
Installation Checklist ......................................................7
Locating Your Gas Fireplace ..........................................7
Clearances ....................................................................8
Mantel Clearances .........................................................9
Mantel Leg Clearances ..................................................9
Unit Assembly Prior To Installation ..............................10
Nailing Strips........................................................10
Installation Access panel .....................................10
Framing Dimensions ....................................................11
Optional framing kit ......................................................12
Non combustible facing installation .............................14
Framing & Finishing .....................................................15
Combustible Requirements .........................................16
Exterior Flue Termination Locations ............................17
Clearances ..................................................................18
Flue Restrictor settings ................................................19
Flueing Arrangements ................................................20
Horizontal Termination (Flex) ...............................20
Rigid Pipe Flueing Systems .........................................21
Basic Horizontal & Vertical Terminations .............21
Flueing Introduction .....................................................22
Flueing Arrangement for Horizontal Terminations .......22
Horizontal Venting with Two (2) 90o Elbows .........23
Direct flue zero Clearance top exit vertical flue Kit
installation instructions GF1500LST ............................24
Venting Arrangements ................................................25
Allowable Vertical Terminations ............................25
Unit Installation with Horizontal Termination ................26
Unit Installation with Vertical Termination ....................27
Unit Installation ............................................................28
High Elevation ..............................................................29
Gas Line Installation ....................................................29
Pilot Adjustment ...........................................................29
Gas Pipe Pressure Testing ..........................................29
Wiring Diagram ............................................................30
845 S.I.T. Valve Description .........................................30
Aeration Adjustment ....................................................30
Conversion Kit from NG to LP/ULPG...........................31
Optional fan ducting kit installation ..............................33
Log Set Installation ......................................................36
Front trim removal / Installation ...................................38
End panel removal / Installation ..................................38
Faceplate and deflector installation .............................39
Screen & inner Door frame Installation ........................40
Optional finishing Trim installation ...............................41
Operating Instructions
Operating Instructions ................................................42
Lighting Instructions ....................................................42
Shutdown Instructions .................................................42
First fire ........................................................................42
Remote Control ..........................................................42
Summary Of Controls .................................................42
Fan Operation ..............................................................42
Copy of Lighting Plate Instructions ..............................43
Normal Operating Sounds Of .....................................43
Gas Appliances ...........................................................43
Resetting the unit .........................................................43
Fan Service .................................................................44
Maintenance
Maintenance Instructions ............................................45
General Flue Maintenance ..........................................45
Glass Gasket ...............................................................45
Glass Door ...................................................................45
Glass Replacement .............................................45
Troubleshooting ...........................................................46
Glass door Installation .................................................47
Valve tray replacement ................................................48
Electronic components parts list ..................................49
Parts
Main Assembly ............................................................50
Accessories .................................................................52
Warranty
Warranty ......................................................................54

4Regency GF1500LST Gas Fireplace
SAFETY LABEL
safety decal
This is a copy of the data badge that accompanies each GF1500LST Direct Vent Gas Fireplace. We have printed a copy of the contents here for your review.
NOTE: Regency® units are constantly being improved. Check the badge on the unit and if there is a difference, the badge on the unit is the correct one.
COPY OF DATA BADGE
DO NOT
DO NOT
DO NOT
DO NOT
DO NOT
DO NOT
OPERATETHIS APPLIANCE BEFOREREADINGTHE
INSTRUCTIONSBOOKLET.
PLACEARTICLESONORAGAINST THIS APPLIANCE
STORE CHEMICALS OR FLAMMABLEMATERIALS
SPRAY AEROSOLSINTHE VICINITY OF THIS
APPLIANCE WHILEINOPERATION.
OPERATEWITH PANELS,COVERSORGUARDS
REMOVED FROM THIS APPLIANCE.
ENCLOSE THIS APPLIANCE.
DO NOTMODIFY THIS APPLIANCE.
NEAR THIS APPLIANCE.
DO NOT
908-602a
Part #: 919-671
Serial # sequence - start @ 446000001
Colour: Black on Grey
Size: 100% 7" W x 2.7" H
June 2/16: Created Decal
Oct. 3/16: Updated data + added approval #
Oct. 19/16: Added Min. supply pressure
Serial
Number
Regency Gas Fireplace
446
Distributed by:
Western Australia:
Air Group Australia
28 Division St
Welshpool, WA 6106
Eastern Australia
Fireplace Products
Australia Pty. Ltd.
1-3 Conquest Way
Hallam, VIC 3803
New Zealand:
Aber Holdings
17 Main Street Place
Te Rapa, HA 3200
To be installed by an authorised person in
accordance with installation instructions provided
with the appliance.
Electrical: 240V 50 Hz
919-671
Gas Type NG LP ULPG
Model GF1500LST-NG GF1500LST-LP GF1500LST-ULPG
Gas Consumption 50 MJ/hr 49 MJ/hr . 44 MJ/hr
Manifold Pressure 0.87kPa 2.49kPa 2.49kPa
Injector Size 1 x #27 1 x #47 1 x #49
3.66mm 1.95mm 1.05mm
Model
Approval No. GMK10431
Code AS4553 / NZS5262 / NZS5266
Min. Supply Press. (±0.5kPa) 1.13kPa 2.75kPa 2.75kPa

Regency GF1500LST Gas Fireplace 5
DIMENSIONS
dimensions
UNIT DIMENSIONS
1439mm
920mm
1152mm
346mm
844mm
1532mm
39mm
39mm
1005mm
241mm
699mm
516mm
325mm
258mm
1267mm
SIDE A
SIDE ASIDE B
SIDE B
Dimension drawings shown without fascias
SIDE A
NOTE: DUE TO NATURE AND DESIGN OF THE GF1500LST DOUBLE
SIDED UNIT, SIDE A PROJECTS MORE HEAT THAN SIDE B ON THE
UNIT. PLEASE NOTE THIS BEFORE COMMENCING THE INSTALLATION
PROCESS.

6Regency GF1500LST Gas Fireplace
installation
11. Under no circumstances should this
appliance be modified. Parts that have to be
removed for servicing should be replaced
prior to operating this appliance.
12. Installation and any repairs to this appliance
should be done by an authorized service
person. A professional service person should
be called to inspect this appliance annually.
Make it a practice to have all of your gas
appliances checked annually.
13. Do not slam shut or strike the glass door.
14. Under no circumstances should any solid
fuels (wood, paper, cardboard, coal, etc.) be
used in this appliance.
15. The appliance area must be kept clear and
free of combustible materials, (gases and
other flammable vapours and liquids).
GENERAL SAFETY
INFORMATION
1. The appliance installation must conform with
local codes or, in the absence of local codes,
with the current Installation and Building
Codes.
2. The appliance when installed, must be elec-
trically grounded in accordance with local
codes.
3. See general construction and assembly
instructions. The appliance and flue should
be enclosed.
4. This appliance must be connected to the
specified flue and termination cap to the
outside of the building envelope. Never vent to
another room or inside a building. Make sure
that the flue is fitted as per Flue instructions.
5. Inspect the flue system annually for blockage
and any signs of deterioration.
6. Flue terminals shall not be recessed into a
wall or siding.
7. Any safety glass removed for servicing must
be replaced prior to operating the appliance.
8. To prevent injury, do not allow anyone who
is unfamiliar with the operation to use the
fireplace.
9. Wear gloves and safety glasses for protection
while doing required maintenance.
10. Be aware of electrical wiring locations in
walls and ceilings when cutting holes for
termination.
"THIS UNIT MUST ALWAYS
TERMINATE / FLUE
DIRECTLY TO THE
OUTDOORS."
IMPORTANT MESSAGE
SAVE THESE INSTRUCTIONS
The GF1500LST™ Direct Vent Fireplace must be
installed in accordance with these instructions. Carefully
read all the instructions in this manual rst. Consult the
"authority having jurisdiction" to determine the need
for a permit prior to starting the installation. It is the
responsibility of the installer to ensure this replace is
installed in compliance with manufacturers instructions
and all applicable codes and complies with AS/NZS
5601.
CLOTHING OR OTHER
FLAMMABLE MATERIAL SHOULD
NOT BE PLACED ON OR NEAR THE
APPLIANCE.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACETEMPERATURES,ESPECIALLY
THE FIREPLACE GLASS, AND SHOULD
STAYAWAY TOAVOID BURNS OR CLOTH-
ING IGNITION.
INSTALLATION AND REPAIR SHOULD
BE DONE BY AN AUTHORISED SERVICE
PERSON. THE APPLIANCE SHOULD BE
INSPECTED BEFORE USE AND AT LEAST
ANNUALLY BY APROFESSIONAL SERVICE
PERSON. MORE FREQUENT CLEANING
MAY BE REQUIRED DUE TO EXCESSIVE
LINT FROM CARPETING, BEDDING
MATERIAL, ETC. IT IS IMPERATIVE THAT
CONTROL COMPARTMENTS, BURNERS
AND CIRCULATING AIR PASSAGEWAYS
OF THE APPLIANCE BE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED OUT
OF TRAFFICANDAWAY FROM FURNITURE
AND DRAPERIES.
WARNING: FAILURE TO INSTALL THIS
APPLIANCE CORRECTLY WILLVOID YOUR
WARRANTY AND MAY CAUSE A SERIOUS
HOUSE FIRE.
YOUNG CHILDREN SHOULD BE
CAREFULLY SUPERVISED WHEN
THEY ARE IN THE SAME AREA AS
THE APPLIANCE. TODDLERS,
YOUNG CHILDREN AND OTHERS
MAY BE SUSCEPTIBLE TO AC-
CIDENTAL CONTACT BURNS. A
PHYSICAL BARRIER IS RECOM-
MENDED IF THERE ARE AT RISK
INDIVIDUAL IN THE HOUSE. TO
RESTRICT ACCESS TO A FIRE-
PLACE OR STOVE, INSTALL AN
ADJUSTABLE SAFETY GATE
TO KEEP TODDLERS, YOUNG
CHILDREN AND OTHER AT RISK
INDIVIDUALS OUT OF THE ROOM
AND AWAY FROM HOT SURFACES.
The gas appliance connected to the
electricity supply shall be provided with
the means of electrical isolation that is
adjacent to the appliance location and
accessible with the appliance installed.
Per AS/NZS 5601.

Regency GF1500LST Gas Fireplace 7
installation
This includes:
1. Clocking the appliance to ensure the correct
firing rate (rate noted on label) after burning
appliance for 15 minutes.
2. If required, adjusting the primary air to ensure
that the flame does not carbon. First allow
the unit to burn for 15-20 min. to stabilize.
CAUTION: Any alteration to the product that
causes sooting or carboning that results
in damage is not the responsibility of the
manufacturer.
LOCATING YOUR
GAS FIREPLACE
1. When selecting a location for your fireplace,
ensure that the clearances are met.
2. The appliance must be installed on a at solid
continuous surface, for example a wood,
metal or concrete oor. In a raised application
e.g. on wall, the appliance must be installed
on a sturdy metal, wood or concrete surface
extending the full width and depth of the
appliance.
INSTALLATION CHECKLIST
1. Locate appliance
a) Room location (Refer to "Locating Your
Gas fireplace" section)
b) Clearances to Combustibles (Refer to
"Clearances" section)
c) Mantle Clearances (Refer to "Mantel
Clearances" section)
d) Framing & Finishing Requirements
(Refer to "Framing & Finishing" section)
e) Flueing Requirements (Refer to "Flue"
section)
2. Assemble the standoffs and nailing strips
(Refer to "Unit Assembly Prior to Installation).
3. Slide unit into place.
4. Install flue (Refer to "Flue Arrangement"
sections).
5. Make gas connections (Refer to "Gas Line
Installation section).
6. Pair up Remote Control (Refer to "Pairing up
Remote Handset" section)
7. Test the pilot (Refer to "Pilot Adjustment"
section).
8. Test Gas Pressure (Refer to "Gas Pipe Pres-
sure Testing" section).
9. Install standard and optional features. Refer
to the following sections:
a) Log Install
b) Faceplate / Door Frame Overlay
c) Remote Control
10. Final check.
Before leaving this unit with the customer, the
installer must ensure that the appliance is ring
correctly and operation fully explained to
customer.
3. The GF1500LST Direct Vent Gas Fireplace
can be installed as follows:
Glass
914mm
914mm 114mm
Glass
914mm 914mm
914mm walkway
Glass Glass
Warmer
side
Warmer
side
4. The GF1500LST Direct Vent Gas Fireplace
is approved for alcove installations, see
"Clearances" section for details.
5. We recommend that you plan your installation
on paper using exact measurements for
clearances and floor protection before
actually installing this appliance. Have an
authorized inspector, dealer, or installer
review your plans before installation.
Note: For ue terminations refer to "Exterior
Flue Termination Locations" section.
NOTE: DUE TO NATURE AND DE-
SIGN OF THE GF1500LST DOUBLE
SIDED UNIT, SIDE A PROJECTS
MORE HEAT THAN SIDE B ON THE
UNIT. PLEASE NOTE THIS BEFORE
COMMENCING THE INSTALLATION
PROCESS.

8Regency GF1500LST Gas Fireplace
Caution Requirements
The sides of the replace are dened by stando󰀨s. The
metal ends of the stando󰀨 may NOT be recessed into
combustible construction.
WARNING
Fire hazard is an extreme risk
if these clearances (air space) to combustible materials are not
adhered to. It is of greatest importance that this replace and ue
system be installed only in accordance with these instructions.
CLEARANCES
The clearances listed below are Minimum distances unless otherwise stated:
A major cause of chimney related res is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance
that this replace and ue system be installed only in accordance with these instructions.
Clearance: Dimension Measured From:
A: Mantel Height (min.) 330 mm Top of Fireplace Opening
B: Sidewall (on one side) 203 mm Side of Fireplace Opening
C: Ceiling (min.)
(room and/or alcove)
1162 mm Top of Fireplace Opening
D: Mantel Depth (max.) 305mm 730mm Above Fireplace Opening
E: Alcove Width 1676 mm Sidewall to Sidewall (Minimum)
F: Alcove Depth 914 mm Front to Back Wall (Maximum)
G: From Floor (min.) 702 mm Top of Fireplace Opening
Note: 0No hearth required
F
E
D
A
B
Installed Close
to Floor
G
Flue Clearances to Combustibles
Horizontal - Top 76mm
Horizontal - Side 51mm
Horizontal - Bottom 51mm
Vertical 51mm
Alcove
E
F
Installed close
to ceiling.
IMPORTANT: If installing a television above
this appliance, the television must be either
fully recessed into the wall above the
replace and or have a mantle below the
television. If the television is left unprotected,
the extreme heat being emitted from this
appliance will result in damage to the
television. See clearance requirements for
mantle.
installation

Regency GF1500LST Gas Fireplace 9
MANTEL CLEARANCES
Due to the extreme heat this replace emits, the mantel clearances
are critical. Combustible mantel clearances from top of front facing
are shown in the diagram on the right.
Note: Ensure the paint that is used on the mantel and the facing
is "high quality" or the paint may discolour.
MANTEL LEG CLEARANCES
Combustible mantel leg clearances as per diagram:
203mm
146mm
219mm
295mm
178mm
102mm
203mm
178mm 178mm
102mm
146mm
219mm
295mm
330mm
Top of
Fireplace
Opening
0
To Unit
Base
22”
702mm
330
Combustible Material
0
Top of
Fireplace
Opening
Standoff
Combustible
Stud
(On Edge)
0
Non-combustible
Facing
25mm
330mm
0
Top of
Fireplace
Opening
305mm
0
To Unit
Base
25mm 559mm
702mm
305mm
559mm
330mm
MM
330mm
25mm 25mm
559 559
330
MM
installation

10 Regency GF1500LST Gas Fireplace
installation
tooltip
UNIT ASSEMBLY PRIOR TO
INSTALLATION
The nailing Strips must be correctly positioned and attached before unit is
slid into position.
NAILING STRIPS
The nailing strips come attached to the unit.
The top and side nailing strips are secured to the framing.
IMPORTANT NOTE
Framing depth measurement is noted with the nailing strips
set as far forward on the rebox as possible. The nailing
strips can be adjusted back up to 38mm to allow for varying
thicknesses in non-combustible material & wall nishes.
Nailing Strips
(DO NOT REMOVE NAILING STRIPS)
INSTALLATION ACCESS PANEL
The unit is equipped with a removable access panel for pre-finish installa-
tion of optional components. This panel is located on the lower front face
of Side B only.
1. Remove 8 screws to remove access panel.
2. Easier access to gas connection with panel removed.
3. Install any optional components with access panel removed.
4. Reinstall access panel with 8 screws.
Note: Access panel is no longer accessible once facing material installed.
Installation Access Panel-Side B only.
tooltip
