Regency Horizon HZ30E-NG10 Quick start guide

FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
919-362a 09.15.15
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
www.regency-fire.com
Horizon HZ30E Product Video
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach you gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
Regency Horizon®HZ30E
Gas Fireplace
Owners &
Installation Manual
MODELS: HZ30E-NG10 Natural Gas
HZ30E-LP10 Propane

2 | Regency Horizon® HZ30E-10 Gas Fireplace
2 |
This appliance can only be used with the type of gas indicated on the rating plate.
This appliance is not convertible for use with other gases.
This appliance may be installed as an OEM installation in a manufactured home (USA only) or mobile home and must be
installed in accordance with the manufacturer's instruction and the Manufactured Home Construction and Safety Standard,
Title 24 CFR, Part 3280, in the Untied States, or the Standard for Installation in Mobile Homes, CAN/CSA Z240 MH, in
Canada.
MANUFACTURED MOBILE HOME REQUIREMENTS
INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE
This Regency® product has been tested and listed by Warnock Hersey/Intertek as a Direct Vent Wall Furnace to the following
standards: VENTED GAS FIREPLACE HEATERS ANSI Z21.88-2014 / CSA 2.33-2014 and GAS-FIRED APPLIANCES FOR
USE AT HIGH ALTITUDES CAN / CGA 2.17-M91.
This appliance may only be installed in an aftermarket permanently located, manufactured (U.S.A only) or mobile home,
where not prohibited by local codes.
This Direct Vent System Appliance must be installed in accordance with the manufacturer's installation instructions and the
Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or the current Standard of Fire Safety Criteria
for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240-MH Mobile Home
Standard in Canada.
This appliance installation must comply with the manufacturer's installation instructions and local codes, if any. In the absence
of local codes follow the current National Fuel Gas Code, ANSI Z223.1 and the current National Electrical Code ANSI/NFPA
70 in the U.S.A., and the current CAN/CGA B149 Gas Installation Code and the current Canadian Electrical Code CSA C22.1
in Canada.
This appliance comes equipped with a dedicated #8 Ground Lug for attachment of the ground wire to the steel chassis as
applicable to local codes.
The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the
National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1.
Ensure that structural members are not cut or weakened during installation.

Regency Horizon® HZ30E-10 Gas Fireplace | 3
| 3
To the New Owner:
Congratulations!
You are the owner of a state-of-the-art Gas Fireplace by REGENCY®. The HZ30E has been designed to provide you with
all the warmth and charm of a fireplace at the flick of a switch. The model HZ30E has been approved by Warnock Hersey/
Intertek for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and
security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and the
many features of your Regency® Fireplace.

4 | Regency Horizon® HZ30E-10 Gas Fireplace
4 |table of contents
Unit Dimensions .....................................................................7
Faceplate and door frame Dimensions ...................................7
Important Message ...............................................................8
Before You Start ......................................................................8
General Safety Information .....................................................8
Installation Checklist ...............................................................9
Locating Your Gas Fireplace ...................................................9
Clearances .............................................................................10
Mantel Clearances ..................................................................11
Mantel Leg Clearances ...........................................................11
Unit Assembly Prior To Installation .........................................12
Wall mount On / Off Switch and receiver installation ..............13
Framing Dimensions ...............................................................14
Optional Framing kit ................................................................15
Framing & Finishing ................................................................16
Non-Combustible Requirements.............................................17
Exterior Vent Termination Requirements ................................18
4” x 6-5/8” Rigid Pipe .............................................................19
Cross Reference Chart only ...................................................19
Vent Restrictor Position ..........................................................21
Venting Introduction ................................................................22
Venting Arrangement for Horizontal Terminations ..................22
Horizontal Terminations ..........................................................23
Flex Vent 4" x 6-7/8 horizontal terminations ........................24
Rigid Pipe 4" x 6-5/8" Horizontal Terminations....................25
Rigid Pipe 4" x 6-5/8" ..........................................................25
Venting Arrangement for Vertical Terminations .......................28
Venting Arrangements - Vertical Terminations .......................29
Vertical Termination
with Co-Linear Flex System ...............................................30
Vertical Terminations ..............................................................31
Rigid Pipe 4" x 6-5/8" ..........................................................31
Unit Installation with Horizontal Termination ..........................33
4" x 6-5/8" venting ..................................................................33
Unit Installation with Horizontal Termination ..........................34
Dura-Vent Horizontal Termination ...........................................35
Unit installation with Vertical Termination ................................36
4" x 6-5/8" venting ..................................................................36
High Elevation .........................................................................37
Gas Line Installation ...............................................................37
Pilot Adjustment ......................................................................37
Gas Pipe Pressure Testing .....................................................37
880 S.I.T. Valve Description ....................................................37
Aeration Adjustment ...............................................................37
Wiring Diagram .......................................................................38
Optional fan Installation ..........................................................39
Proflame remote system GTMF with optional fan ..................42
Optional wall thermostat installation .......................................43
Reflective Panel Installation ....................................................44
Glass Crystals or optional stones ...........................................45
Installation On Burner .............................................................45
Optional Pebbles / Glass crystal Installation-Firebox Base ....45
Optional log set Installation ....................................................46
Glass door Installation ............................................................48
Safety Screen / Inner door Frame removal/Installation ...........49
Outer door frame Installation ..................................................50
Verona / 4 piece Faceplate Installation ...................................51
Operating Instructions ............................................................52
First Fire .................................................................................52
Normal Operating Sounds of Gas Appliances ........................52
Lighting Procedure .................................................................53
Shutdown Procedure ..............................................................53
Copy of Lighting Plate Instructions .........................................54
Maintenance Instructions........................................................55
Glass Gasket ..........................................................................55
Glass Door ..............................................................................55
General Vent Maintenance .....................................................55
Valve assembly Replacement .................................................56
Main Assembly .......................................................................58
Accessories ............................................................................60
Warranty .................................................................................63

Regency Horizon® HZ30E-10 Gas Fireplace | 5
| 5
safety decal
This is a copy of the label that accompanies each
HZ30E-NG10 and HZ30E-LP10 Direct Vent Gas
Fireplace. We have printed a copy of the contents
here for your review.
NOTE: Regency® units are constantly being
improved. Check the label on the unit and if
there is a difference, the label on the unit is the
correct one.
COPY OF SAFETY DECAL
For the State of Massachusetts, installation
and repair must be done by a plumber or
gasfitter licensed in the Commonwealth of
Massachusetts.
For the State of Massachusetts, flexible con-
nectors shall not exceed 36 inches in length.
For the State of Massachusetts, the appli-
ances individual manual shut-off must be a
t-handle type valve.
The State of Massachusetts requires the
installation of a carbon monoxide alarm in
accordance with NFPA 720 and a CO alarm
with battery back up in the same room where
the gas appliance is installed.
