REH4MAT AKVOSEGO User manual

AKVOSEGO™
User manual
BATH CHAIR

5°C
70%
45%
Manufacturer takes responsibility for proper usage of the device only when
the product was purchased from qualified REH4MAT employee or at
specialized medical store!
REH4MAT reserve the right to introduce technical and trading changes in the
content of the instruction without warning.
35°C
Product marked with the CE sign is Class I medical device, of
rule 1, consistent with the requirements of Regulation (EU)
2017/745 of the European Parliament and of the Council of 5
April 2017 on medical devices.
REH4MAT introduced quality management system ISO 13485
regarding production, sales and service. The system is certified
by Det Norske Veritas.

AKVOSEGO
10. Safety rules........................................................................................................................19
4. Size table ...............................................................................................................................7
CONTENTS
3.2. Additional equipment............................................................................................6
7 . Additional equipment........................................................................................................14
1. The purpose of user manual...............................................................................................5
5. Detailed description of how to apply the lounger upholstery............................................8
6. The adjustment of bath chair.............................................................................................11
3. General characteristics of bath chair..................................................................................6
3.1. Standard equipment..................................................................................6
8. How to fix bodymap cushion on chair..............................................................................16
2. Indications for use................................................................................................................5
9. Using of chair......................................................................................................................18
11. Maintenance and cleaning...............................................................................................21
11. Labelling.............................................................................................................................23

Its upholstery and frame are available in different colours – it depends on its size.
AKVOSEGO™ bath chair is simple and innovative solution that is helpful while
taking care of disabled people. The bath chair consists of solid frame that is
made of aluminium and, moreover, it protects from adverse effects of water.
Furthermore, frame is equipped with foam covers that protect bathtub or kids
bath tub from scratching. Unique construction of frame makes it possible to
adjust the tilt angle of footrest and backrest.
Furthermore, it is also possible to change distance as well as seat’s tilt angle
towards floor. It is highly beneficial due to the fact that product is correctly
adjusted to user’s needs which is very helpful while e.g. washing little user’s hair.
Concerning upholstery, it is made of impermeable net. AKVOSEGO™ bath chair
can be used together with BodyMap® cushion either in a room or during bath
because all BodyMap® cushions are totally waterproof! The use of BodyMap®
cushion makes the stabilization of patient more efficient during bath.
INTRODUCTION
AKVOSEGO
Before using the product, user is obliged to familiarize himself/herself
with user manual. Remember that complying with guideline is highly
important. It assures safety and extends durability as well as
aesthetics of the device.

AKVOSEGO
5
This manual contains information necessary for correct use of
AKVOSEGO™ bath chair for children, preparation of the device before the use,
maintenance and cleaning as well as the guarantee conditions. Manual should
be kept in an easy accessible place.
The manual is addressed to the parents, doctors and physicaltherapistis
who take direct care of handicap children.
Please, remember that following the rules of the manual enables safe use of the
product, its extended life and esthetics.
THE PURPOSE OF USER MANUAL
Before using the product, user is obliged to familiarize himself/herself with
user manual.
źcerebral palsy (CP)
źMuscular dystrophy
źSpina bifida
źOther neurological diseases with movement deficits in the form of paralysis and
paresis of the limbs and / or trunk
Indications for use:
INDICATIONS AND CONTRINDICATIONS FOR USE
źMax. user's weight: size 0 - 25 kg, size 1 - 30 kg, size 2 - 50 kg, size 3 - 75 kg
Contrindications for use:
źIncorrect positioning of the person with the use of bathing products may lead to
deformation of the joints, and long-term keeping of the person in one position
significantly increases the risk of pressure ulcers.
Intended purpose of the product with a defined target group: Disabled people
(children / adolescents) with cerebral palsy, muscular dystrophy, spina bifida, spinal cord
injuries and neurological deficits.

3.1 Standard equipment
AKVOSEGO
6
GENERAL CHARACTERISTICS OF BATH CHAIR
Adaptation set used for
assembling BodyMap cushion BodyMap cushion
3.2. Additional equipment
AKVO - Active waterproof
platform for bath devices for
disabled children
Pelivic support
2
3
1
5
4
Pelvic-thigh belt
5. Leg support
4. Upholstery not absorbing the water
2. Head support
3. Trunk support
1. Frame

Symbol Measurement Unit Size 1 Size 2
A Seat width [cm]
B Seat depth [cm]
C Head rest height [cm]
C1 Back rest height [cm]
C2 Lower leg length [cm]
C3 Floor to seat distance [cm]
User weight (max) [kg]
Weight and dimensions of the device
Product width [cm]
After folding width [cm]
Product length [cm]
After folding length [cm]
Product height [cm]
After folding height [cm]
Product weight [kg]
Note: Dimensional tolerance in the table is +/-1 cm.
7
AKVOSEGO
Size 3
Size 3
SIZE TABLE
[kg]
4
42 45
28-33 32-40
16 19
40 44
31 36
11-44 13-49
30 50
50
37-50
23
50
41
15-54
75
37
23-28
16
31
26
11-44
25
Size 0
Size 1 Size 2
Size 0
42 45
42 45
75 91
67 76
85 96
28 29
50
50
97
88
113
31
4 4,5 8
42
42
70
64
80
28
4

AKVOSEGO
1
2
3
4 Joints
Frame of bath deckchair x 1
Footrest frame
Upholstery x 1
5 Head support x 1
6
Backrest Frame
8
DETAILED DESCRIPTION OF HOW TO APPLY THE LOUNGER
5
6
1
4
5
5
UP
DOWN
2 3
5.1. Components :

AKVOSEGO
first you must :
adjust the angle between the backrest
-Push the bottom part of the upholstery onto the footrest frame (fig. 4),
on the frame of the back support (fig. 2, 3),
- Press joints (G and F) at the same time
To put on the upholstery on the frame
and the footrest (according to fig. 1),
-Insert the upper part of upholstery
Fasten all straps with velcro closures from the underside of the lounger (fig. 5, 6).
Please keep in mind that the straps should cover the seat frame.
9
fig.6
fig.5
fig.2 fig.3 fig.4
GF
fig.1

AKVOSEGO
10
-lounger with upholstery set to the
usable position (fig.9).
- choose the appropriate height of the stabilizer on the backrest of the
lounger,
To mount the head stabilizer you must:
- next using straps with velcro closures fasten the stabilizer on the back of the
lounger (fig. 7, 8).
fig.7 fig.8
fig.9

AKVOSEGO
THE ADJUSTMENT OF BATH CHAIR
6
It is necessary to use special joints so as to adjust bath chair AKVOSEGO™.
It is possible to adjust following parts of bath chair AKVOSEGO™ :
BACKREST
FOOTREST
11

AKVOSEGO
STEP 1. Fix belt with head stabilizing pelottes at chosen height. Belt should be
fastened at the back of seat by means of Velcro tapes. The distance of pelottes
can be adjusted.
Every standard bath chair AKVOSEGO™ is equipped with head support, trunk
stabilizing belt and feet stabilizing belts. All these parts secure the patient while
using the product. Please follow these steps mentioned below to use the
product:
THE TILT ANGLE OF BATH CHAIR
12

AKVOSEGO
STEP 2. Fix trunk stabilizing belt. Belt is fastened with the aid of Velcro tapes and
it can be fixed at any height. It is necessary to thread belt through grommets
which are situated on either backrest or seat. Next, fasten the belt.
STEP 3. Fix feet stabilizing belts. Belts are fastened with the aid of Velcro tapes
and they can be fixed at any height. It is necessary to thread belts through
grommets which are situated on footrest. Next, fasten belts.
13

AKVOSEGO
6.2. Seat depth adjustment
In order to adjust the depth of seat,
there is necessary to press the
buttons on both sides at the same
time.
6.3. Upholster
Tension of upholster can be easily adjusted by straps with Velcros that are
located under the chair.
ADDITIONAL EQUIPMENT
7
The pelvic-thigh belt ensures an adequate level of stability and safety while
sitting in the seat. To attach the belt, the bottom strap with buckles must be put
under the seat and then fastened.
Afterwards, insert the two side straps into regulators as explained below.
Properly attached belt is shown in the last picture.
bottom strap
with buckles
14

AKVOSEGO
side straps with regulators
15

HOW TO FIX BODYMAP CUSHION ON CHAIR
AKVOSEGO
8
STEP 1. Disassemble head support, trunk stabilizing belt and feet stabilizing
belts.
STEP 2. Fix BodyMap cushions with the aid of fastening set that is included in
optional equipment for bath chair AKVOSEGO™. Each set is equipped with
pelvic-thigh belt, two wide belts that stabilize the patient and three Velcro tapes
®
that are used to place BodyMap cushion on seat .
®
All BodyMap cushions are waterproof and highly thanks to which it is
recommended to use them together with bath chair AKVOSEGO™ so as to
enhance upright standing and secure the patient while performing nursing
activities.
®
Please follow steps mentioned below to fix BodyMap cushion:
16

AKVOSEGO
®
Before fixing the BodyMap cushion on the both seat, it is necessery to assemble
special Velcros in lower, medium and upper part of the seat. Self-adhesive
surface of BodyMap cushion makes it possible to fix it quickly on bath seat.
STEP 3. Then fix belts stabilizing the patient. Belts are fastened by Velcro tapes
and buckle. Below you can see the conect assembling process:
®
STEP 4. To fix BodyMap cushion it is necessary to
unfasten stabilizing belts. Place cushion on bath
chair AKVOSEGO™ in a way that its self-adhesive
surface touches bath seat's upholstery. Next, place
the patient on cushion and fasten stabilizing belts.
®
Please remember that BodyMap cushion has to be
shaped according to patient's body because only
then cushion correctly stabilizes the patient both in
sitting. Please familiarize yourself with the
guidelines concerning shaping the cushions which
are included in user manual for cushions.
17

USING OF CHAIR
our device works correctly only when the product is adjusted according
to patient's height as well as weight. Remember to take all these
measurements into account while purchasing the product. Correct
adjustment of bath chair is the most important thing due to the fact that
only then the product is safe. It is forbidden to force child to keep
specific position because he/she will feel uncomfortable and it may lead
to wrong posture.
AKVOSEGO
9
· Place the patient in bath seat and secure him/her by set of belts from
standard equipment.
· Adjust bath seat and head support to patient's measurements,
If product is used together with BodyMap cushion; first fix cushion on bath
chair with the set of fastening and then shape it according to patient's body.
· Unfasten trunk stabilizing belt and feet stabilizing belts,
· Unfold the device,
Please follow these steps below before the use of product:
· Place the device on even surface, without slopes,
· Make sure that all parts are serviceable, correctly mounted and stable,
18
The product has to be used with compliance to guidelines included in this
user manual and with trained person. Before every using, there is necessery
to prepare the patient and the device!
Befor using, remember to make sure that all belts and locking are correctly
adjusted and fastened.

1. Before using the product, it is essential to make sure that:
· make sure that buckles are operating correctly;
· always use stabilizing belts: Velcro tapes from these belts has to overlap
min. 8cm;
· adjust the product to patient's measurements as well as needs;
· secure the patient with the aid of head support, trunk stabilizing belt and
feet stabilizing belts. It is necessary due to the fact that it protects the
patient against falling out of the device.
· make sure that all screws, nuts and other threaded, glued and sewn parts
are firmly tightened;
It is highly important to consult either doctor or physiotherapist in order to make
right decision concerning the choice of chair AKVOSEGO™ and its size. It is
essential to familiarize with the guidelines described in instruction manual
before using the device.
2. It is forbidden to use bath chair for different purposes than it is intended to.
3. It is forbidden to use bath chair if it is destroyed or any part is missing.
4. It is forbidden to leave the patient unattended.
5. It is forbidden to use the product without trained person or medical staff.
· make sure that there are no damages or different faults which could
endanger patient's life. Make sure that all parts are operating correctly and
are properly mounted. Moreover, make sure that there are no cracks as
well as deformities,
6. It is necessary to fold and secure bath child seat during transportation in
order to avoid any possible damages. Manufacturer doesn't take
responsibility for damages which appeared due to improper preparation of
the device during transportation.
AKVOSEGO
CAUTION! AKVOSEGO™ bath chair should be used in compliance with
guidelines described in instruction manual.
SAFETY RULES
10
19

8. Before using the chair remove all paper and plastic package .The package is
not a toy. Keep away from children and animals.
7. It is forbidden to place and use the product close to fire or high temperatures.
Bath child seat cannot be stored as well as used in rooms with high humidity.
AKVOSEGO
20
Do not use a product that has any signs of damage, tearing or wear.
Only an undamaged product and proper use guarantee its right and
safe working. If the product is damaged, discontinue use and
contact the manufacturer.
Under no circumstances should an unqualified person repair or
alter the product and its construction, as the health and safety of
the user depend on it as well as it will lead to the loss of warranty.
The weight of user should not be bigger than maximal weight
described on page 7 where you will find information regarding this
issue.
Serious incidents involving this device should be reported both to
manufacturer and to the competent authority in your country
Incorrect product adjustment can lead to such side effects as
fainting, body deformities, joint overload, etc. If the
abovementioned symptoms occur, stop using the product
immediately, take the user out of the product and lay them down. If
the undesirable symptoms persist, contact a physician immediately.
If the symptoms have disappeared, inform the attending physician
about this fact in order to make a decision about the further
rehabilitation process. It is forbidden to place the patient in the
device while being in car, bus or train.
This device can be only used inside the buildings.
The product contains small parts which children may swallow.
Other manuals for AKVOSEGO
2
Table of contents
Other REH4MAT Wheelchair manuals
Popular Wheelchair manuals by other brands

Otto Bock
Otto Bock B400b400 Instructions for use

aidapt
aidapt VA135S Fitting and Maintenance Instructions

SUMED
SUMED Syst'am Polyair Setup guide

Bischoff & Bischoff
Bischoff & Bischoff S-VR instruction manual

Invacare
Invacare Action 4NG series user manual

Columbia Medical
Columbia Medical 5050 instructions

Golden Technologies
Golden Technologies Compass TRO GP615 SS owner's manual

Taiwan King Strong
Taiwan King Strong TP01-S owner's manual

Enigma
Enigma ENERGI Owner's handbook

Airgo
Airgo 700-3 series owner's manual

Sunrise Medical
Sunrise Medical Quickie LXI User instruction manual

Invacare
Invacare FDX user manual
