Reid SwiftLift User manual

Rigging
OPERATION - SwiftLift™ Clutches
1. SwiftLift Clutch is attached to the
SwiftLift anchor by;
• lowering the clutch slot over
the anchor
• then rotation the clutch tab
until it rests on the concrete
surface
2. As the load is raised, the
anchor takes the full load of
tension

Rigging
OPERATION - SwiftLift™ Clutches
3. As the panel rotates to the vertical
position, the clutch comes in contact
with the concrete surface;
• this transfers the lifting force into
the concrete
• the anchor prevents the clutch from
slipping out of the void
4. Lifting away from the tab
is also safe provided the
tab does not rise more
than 30°from the
concrete surface

Rigging
Check for wear and tare - SwiftLift™ Clutches

Rigging
Effective Rigging
Using a triangular
spreader beam with
shackles and two sets of
chains will ensure legs
are equally loaded.
Using a spreader beam
with two sets of chains
will ensure the legs are
equally loaded.

Rigging
Effect of sling angle
1. The longer the slings. The lower
the load on the anchors.
•
For example, at an angle of
•
For example, at an angle of
170°the load on each sling
is six times the weight of the
actual load being lifted
2. Never make sling length shorter
than the distance between two
anchors.
3. Never set the sling up with a
greater angle than 60°.

Rigging - Configurations
