Remco 3200 SERIES Quick start guide

3200 SERIES PUMPS
Operational and Installation Guidelines
Please read these Operational and Installation Guidelines before
installing the PowerRV™ Series Pumps. If additional help is needed,
please consult the Factory.
CAUTIONS
yWater pipe connections and fixtures directly connected to a potable
water supply shall be sized, installed and maintained in accordance
with Federal, State, and local codes.
yDo not operate the pump above the pressure limitations specified
on the data label.
yNever operate the pump in a harsh environment or hazardous
atmosphere, since motor brush and switch may cause electrical
arcing.
yDo not pump gasoline or other flammable liquids. Do not use
with petroleum products.
yDo not assume fluid compatibility. If the fluid is improperly
matched to the pumps’ elastomers, a leak may occur
yAs long as there is inlet water pressure, the pump will not stop
forward flow of water even if the motor is turned o. Be sure the
system has positive means of shutting o water supply.
yAlways consider electrical shock hazard when working with and
handling electrical equipment. If uncertain, consult an Electrician.
Electrical wiring should only be done by a qualified Electrician per
Local and State Electrical Codes.
MOUNTING
yThe pump should be mounted in a dry place and away from any
source of heat. If an enclosure is used, special instructions for
cooling the motor may be necessary. Consult the Factory.
yDo not subject the pump to extreme high or low (freezing)
temperatures while in operation. (Operating ambient temperature
range is 32ºF to 115ºF).
yThe pump may be mounted horizontally with the outlet port on the
right when viewed from the pump end or with the pump above the
mount; or vertically with the pump above or below the motor.
PLUMBING
yThe pump is equipped with either a pressure sensing demand
switch, a bypass relief valve, or both which controls the maximum
safe operating pressure.
yWe recommend use of flexible tubing with proper pressure rating.
yPump will prime only if all pressure is relieved from outlet port.
yIt is recommended that debris-free liquid be pumped or an in-line
sediment filter (50 mesh) be installed at the inlet side to keep
foreign debris out of the system.
yThe pump should always be mounted prior to any components
which could introduce particles to the liquid; thus, preventing them
from entering the pump chambers and possibly causing clogging.
yAvoid any sharp bends which may crimp tubing and restrict flow.
Use 90º elbow fittings if necessary. REMCO provides pumps with
dierent kinds of fittings. Please consult Factory for your needs.
ELECTRICAL
yThe PowerRV™ Series Pumps are designed for intermittent duty, but
may run continuously if the motor temperature does not exceed the
recommended limit. Some PowerRV™ Series Pumps are equipped
with thermally protected motors and in case motor temperature
exceeds thermal cut-out rating, pump will shut down and will not
restart until motor cools down to specified temperature. Please con-
sult the appropriate Data Sheet for continuous running parameters,
noting the eect of rapid On/O Cycling (See section below).
yIf a power supply is used with the system and the supply is not
furnished by REMCO, it will need to be reviewed for correct
application and approval by REMCO.
Installation Procedure
The basic demand pump is controlled by a built-in pressure sensing
demand switch. When a faucet or valve is opened down stream of the
pump, line pressure drops, thus starting the pump automatically.
Conversely, when the valve shuts, the line pressure increases turning the
pump o automatically. The pressure switch actuates in response to the
pump outlet pressure at a predetermined and preset pressure. The pump
label indicates the pre-set OFF pressures. Typically, the OFF pressure is
accurately set at the FACTORY and the ON pressure is within an
allowable range below that value. In response to the characteristics of
the system in which the pump is installed, such as the flexibility and
length of the tubing, and the faucet or valves and the duration that they
are open, these pressure settings may vary. Therefore, change in
pressure settings is expected with use and over time. If the pump does
not have an integral pressure sensing demand switch (i.e. pump is
operated with an external control), pump will be equipped with a bypass
relief valve (bypass is factory preset).
Read the OPERATIONAL AND INSTALLATION GUIDELINES on the
other side carefully before starting to install the pump. Consult the
Factory if there is any question.
Determine the optimum location for your pump before
proceeding.
yTurn o the fluid supply.
yCut the flexible tubing in suicient length to avoid any stress on the
tubing or hose where it connects to the pump or the fitting on any
accessory or hose.
yInsert tubing or hose into pump ports. If compression fittings with
threaded nuts are used, insert tubing until it bottoms out in the port
and hand tighten the compression nut until the connection is tight.
Then use a wrench to tighten the nut 1/2 turn clockwise or follow the
wrench tightening instructions provided by the fitting manufacturer.
yThe PowerRV™ Series pump is now ready for operation. Open the
inlet valve if any to allow fluid to flow to the pump.
yIf the power source is a transformer, plug the appropriate REMCO
supplied or approved transformer into the receptacle and connect
the pump to the transformer. If the power source is not a
transformer, connect the pump to the appropriate power source.
Open the discharge or dispensing valve. Allow water to circulate,
purging any entrapped air.
yThe pump will now start building pressure. Operating pressure will
vary with flow rate, flow valve, feed-water pressure and line voltage.
Check for fitting leaks.
yIf compression fittings with threaded nuts are used, observe any
leaks after pump has run for approximately 15 minutes. Further
tighten compression nuts approximately 1/8 to 1/4 of a turn on all
fittings in the system. Wait 15 minutes and repeat the leak check.
NOTE: Further adjustments should not be necessary although it may
take several days of operation before all the air has been purged
and the system is stabilized.
yRapid On/O Cycling must be limited to no more than 6
times per minute, even if the pump is operating in the
Continuous Duty zone. Cycling could cause the motor to
heat beyond the recommended maximum temperature, and
reduce the operational life of the pump and pressure-
sensing switch.
www.remcoindustries.com

Troubleshooting Guidelines
IF PUMP WILL NOT START CHECK:
yCorrect voltage (±10%) and electrical connections
yFuse or breaker
yPressure switch operation and correct voltage at switch
yRectifier or motor for open or grounded circuit
IF PUMP WILL NOT PRIME (NO DISCHARGE WITH
MOTOR RUNNING) CHECK:
yDebris in strainer
yRestriction (kinks) in inlet/outlet tubes
yDebris in inlet/outlet
yAir leaking in from inlet
IF PUMP WILL NOT SHUT OFF (OUTPUT LINE CLOSED
AND NO LEADS) CHECK:
yAir trapped in outlet line or pump head
yCorrect voltage to pump
yDebris in pump inlet/outlet valves
yLoose drive assembly or pump head screws
yPressure switch operations/adjustments
yLeaks
IF PUMP LEAKS FROM PUMP HEAD OR SWITCH CHECK:
yLoose screws at switch or pump head
ySwitch diaphragm ruptured or pinched
yPunctured diaphragm if fluid is present
Warranty
REMCO warrants its products to be free from defects in material and
workmanship on all products sold by REMCO for resale or for use in
purchasers’ own business or original equipment manufacturer. Under normal
use, maintenance and service (rental use excluded) the following terms apply:
For all REMCO products, the warranty will last for a period of one year from
date of manufacture, or (1) year use with proof of purchase, not to exceed (2)
years in any event. REMCO’s obligation under this warranty shall be limited to
replacing or repairing at REMCO’s discretion, any such product or part which
must be returned to REMCO’s factory with a Return Material
Authorization Number (RMA), transportation charges approved by REMCO
or prepaid, and which upon examination, is found to REMCO’s satisfaction to
have been defective under the terms of this warranty. No credit will be allowed
against future purchases for items returned as defective under the terms of
REMCO’s warranty. This warranty does not extend to any products, which have
been altered or modified outside the REMCO factory, to any products that have
not been properly maintained, nor does it apply to units that are returned in
an unassembled condition. Furthermore, the warranty does not extend to
pumps that are non-compliance with REMCO’s Engineering Standards. This
includes, but is not limited to, pumps ordered without an integral pressure
control mechanism. The warranty guarantees that products will perform to
REMCO’s flow and pressure specifications throughout the life of the warranty.
The warranty does not cover wear, appearance, misuse, abuse, misapplication
or external water damage. If the returned product is found not to be defective
under the conditions of this warranty, a charge will be made for repair or
replacement.
Brush wear may be limited to 1000 hours or less.
This is a Limited Warranty. It covers the product only and the extent of the
coverage is limited to the cost of the product. As the manufacturer has no
control over shipping, handling and installation, the warranty cannot cover
water damage, or any other damage, caused by a leak or other malfunction.
THIS WARRANTY IS IN LIEU OF ALL WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING IMPLIED WARRANTIES OR WARRANTIES OF MERCHANTABILITY AND/
OR FITNESS FOR A PARTICULAR PURPOSE. NO PERSON IS AUTHORIZED TO GIVE
ANY OTHER WARRANTY OR ASSUME OBLIGATION OR LIABILITY ON REMCO’S
BEHALF. REMCO SHALL NOT BE LIABLE FOR ANY INDIRECT, INCIDENTAL,
PUNITIVE OR CONSEQUENTIAL DAMAGES OF ANY KIND INCURRED BY THE
REASON OF THE USE OR SALE OF ANY DEFECTIVE PRODUCT AND PART. THIS
WARRANTY SHALL BE GOVERNED BY THE LAWS OF THE STATE OF MINNESOTA,
WITH ANY DISPUTE OR CLAIM VENUED OR HEARD IN THE STATE OF
MINNESOTA.
www.remcoindustries.com
WARNING: this product can expose you to chemicals including
“carbon black”, which is known to the state of California to cause
cancer. For more information, go to www.P65Warnings.ca.gov.
Winterizing
Warning! If water is not drained from the fresh water system during freezing temperatures, damage to the pump and
plumbing system is likely.
yDrain the fresh water holding tank.
yChlorine or antifreeze will deteriorate the parts. Always rinse the pumps with fresh water to help prolong the life of the
pump components.
yOpen all faucets and run the pump to expel all the water in the plumbing system.
yDisconnect the inlet and outlet plumbing from the pump and run the pump for a minute to remove residual water from
the pump
yLeave plumbing disconnected from the pump until ready to use the plumbing system.
Accessories
PART NUMBER DESCRIPTION
FQ5ES-12HB-R Fitting, Straight, 3/4” QA male to 1/2 barb & Fitting, 90 Elbow, 3/4” QA male to 1/2 barb
MF-34F34M-R Filter 3/4” QA female to 3/4” QA male
PH-3214-KIT-R Complete 3200 accessory kit with fittings and filter
