Remington PRECISION PERFORMER HC2000AU User manual

the neck. Be careful not to touch ears or
to press too hard.
5. Final trim can be made with the hair
clipper or the scissors. Make sure to
check over the entire head for any uneven
areas. For styled hair or giving quick trims,
you may prefer using your hair
clipper without the trimming guide.
6. The adjustable taper level allows you
to gradually change the closeness
of the cut, either with or without a
trimming guide. When the lever is
fully forward the blades will give the
closest cut. Moving the lever
gradually backwards increases the
cutting length.
SHORT TAPERED STYLES - “FLAT TOPS” & SHORT CUTS
1. Starting with the longest attachment comb (25mm), cut from
the back of the neck to the crown. Hold the attachment comb
flat against the head and slowly move
the clipper through the hair, as shown.
2. Use the same procedure from the
lower side to the upper side of the
head, as illustrated. Then cut the hair
against the direction in which it grows
and level with the sides.
3. To give a “flat top” look, the hair on top
of the head must
be cut over the top of a flat comb.
4. Use closer cutting attachment combs to taper the hair down
to the neckline as desired.
Part No. T22-0001303 10
REMINGTON SERVICE HOTLINE

Australia 1800 623 118 (toll free)

New Zealand 0800 736 776 (toll free)
AUTHORISED REPAIR CENTRES
Visit www.remington-products.com.au for Authorised repair centre details.
® Registered Trademark of Spectrum Brands, Inc. (SBI), or one of its subsidiaries
Manufactured to Spectrum Brands specifications in the PRC
© 2013 SBI
Rev. 04/13
87 9
Spectrum Brands Australia Pty Ltd and Spectrum Brands New Zealand Limited
WARRANTY AGAINST DEFECTS
In this warranty:
Australian Consumer Law means the Australian consumer law set out in Schedule 2
to the Competition and Consumer Act 2010;
CGA means the New Zealand Consumer Guarantees Act 1993;
Goods means the product or equipment which was accompanied by this warranty and
purchased in Australia or New Zealand, as the case may be;
Manufacturer, We or us means:
1. for Goods purchased in Australia, Spectrum Brands Australia Pty Ltd
ACN, 007 070 573; or
2. for Goods purchased in New Zealand, Spectrum Brands New Zealand Limited,
as the case may be, contact details as set out at the end of this warranty;
Supplier means the authorised distributor or retailer of the Goods that sold you the Goods
in Australia or in New Zealand; and
You means you, the original end-user purchaser of the Goods.
1. Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law, or the CGA. You are entitled to a replacement or refund for a major failure
and compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
2. The benefits provided by this Warranty are in addition to all other rights and remedies in
respect of the Goods which the consumer has under either the Australian Consumer Law
or the CGA. The original purchaser of the Goods is provided with the following Warranty
subject to the Warranty Conditions:
3. We warrant the Goods for all parts defective in workmanship or materials for the period
of two (2) years from the date of purchase (Warranty Period). If the Goods prove
defective within the Warranty Period by reason of improper workmanship or material,
we may, at our own discretion, repair or replace the Goods without charge.
Warranty Conditions
4. The Goods must be used in accordance with the manufacturer’s instructions. This
Warranty does not apply should the defect in or failure of the Goods be attributable to
misuse, abuse, accident or non-observance of manufacturer’s instructions on the part of
the user. As far as the law permits, the manufacturer does not accept liability for any
direct or consequential loss, damage or other expense caused by or arising out of any
failure to use the Goods in accordance with the manufacturer’s instructions.
5. Exhaustible components (such as shaver heads, cutters and foils) of the Goods
are included under this Warranty only where there is a defect in workmanship or
materials used.
6. The warranty granted under clause 3 is limited to repair or replacement only.
7. Any parts of the Goods replaced during repairs or any product replaced remain the
property of the manufacturer. In the event of the Goods being replaced during the
Warranty Period, the warranty on the replacement Goods will expire on the same date
as for the Warranty Period on the original Goods which are replaced.
8. In order to claim under the warranty granted under clause 3 you must:
(a) Retain this warranty with your receipt/proof of purchase; and
(b) Return the Goods to us at the relevant address below or to the Supplier by prepaid
freight within the Warranty Period accompanied with (i) the legible and unmodified
original proof of purchase, which clearly indicates the name and address of the
Supplier, the date and place of purchase, the product name or other product serial
number and (ii) this warranty.
9. This warranty is immediately void if:
(a) Any serial number or appliance plate is removed or defaced;
(b) The Goods have been serviced or otherwise repaired by a person not authorised to
do so by us or where non approved replaced parts are used.
10. The Goods are designed for domestic use only. A limited 90-day Warranty applies to any
industrial or commercial use of the Goods. The Goods must be connected to the electrical
voltage requirements as specified in the ratings label located on the Goods.
11. This warranty does not cover the cost of claiming under the warranty or transport of the
Goods to and from the Supplier or us.
12. This warranty is only valid and enforceable in Australia against Spectrum Brands
Australia Pty Ltd and in New Zealand against Spectrum Brands New Zealand Limited.
Contact us or the Supplier for further details.
Spectrum Brands Australia Pty Ltd
Chifley Business Park
1 Chifley Drive
Mentone, VIC 3194 Australia
Customer service in Australia: 1800 623 118
E-mail: consumer[email protected]
Website: www.remington-products.com.au
Spectrum Brands New Zealand Limited
Building C, Ground Floor
600 Great South Road,
Greenlane, Auckland 1051 New Zealand
Customer service in New Zealand: 0800 736 776
E-mail: [email protected]
Website: www.remington-products.com.au
This product is not suitable to use in a bath or shower.
The Hair Clipper conforms to radio frequency
interference requirements.
STORAGE
When not in use, unplug it and store out of reach of children
in a safe, dry location. Never wrap the cord around the
appliance as this will cause the cord to wear prematurely
and break. Handle the cord carefully for long life, and avoid
jerking, twisting or straining especially at plug connections.
WARRANTY
2 YEAR WARRANTY HC2000AU
USE & CARE
MANUAL
PLEASE READ
PRIOR TO USE
PRECISION
PERFORMER
Professional
HAIRCUT KIT

HC2000AU REMINGTON PRECISION PERFORMER HAIRCUT KIT
®
Use and Care Instructions
Thank you for purchasing your new Remington® Precision
Performer Haircut Kit. Your hair clipper is designed to help you
maintain a range of hairstyles for years to come.
For best cutting performance we recommend you read these
instructions thoroughly and keep them in a safe place.
BEFORE CUTTING HAIR
The blades of this clipper are designed to remain
permanently lubricated. They do not need oiling. We have
aligned the blades on your hair clipper prior to shipment.
It is possible the blades may be bumped out of alignment
whilst in transit. Correct blade alignment is essential for
effective cutting.
Compare the blade position on your hair clipper with the
images shown on the left. If the blades are out of alignment
they can be easily adjusted.
1. The end of the top blade should be closer to the body of the
HC2000AU SPECIFICATIONS
Power System Cord
Voltage Type Single
hair clipper than the bottom blade. This is important so that
the clipper doesn’t cut too close or allow the moving (top)
blade to touch the skin.
2. The bottom blade should be as closely aligned as possible
to the centre of the top blade.
3. If the blades are not correctly aligned, turn the clipper on for
a few moments, turn off and unplug. Loosen the two screws
slightly and manually adjust the bottom blade until it is aligned.
Re-tighten the screws.
4. Ensure the hair clipper is running smoothly, with a slight
vibration, before attempting to cut any hair.
GETTING STARTED
1. Make sure your clipper is operating correctly.
2. Place a cape around the neck of the person whose hair
is being trimmed or cut.
3. This person should be seated so that the top of their head
is at your eye level.
4. Comb the hair as it is normally styled.
5. Comb out all knots and tangles.
6. Hold the hair clipper in the palm of one hand and with your
thumb resting firmly on the top of the hair clipper. This grip
proves comfortable cutting control. Although the hair clipper
456
may be used left or right handed, using it right handed allows
you to access the taper lever more easily.
7. Ensure the hair is dry. Hair clippers perform best with dry hair,
making it easier to see how much hair is being cut.
TO ATTACH TRIMMING GUIDES
1. Select an appropriate length trimming guide to match the
desired length of hair to remain after the cut. The trimming
guides are numbered and marked with 3mm, 6mm, 9mm,
12mm, 16mm, 18mm and 25mm.
2. Hold comb with teeth up, slide the attachment firmly onto
the bottom clipper blade.
FOR UNIFORM CUTTING
Allow the clipper to cut through the hair without forcing it at
a faster rate, as this may create a pulling sensation.
Use short strokes when cutting and initially use the longest
trimming guide. You can always use a closer trimming guide
later if you want a closer cut.
HOW TO GIVE A HAIRCUT
1. Start at the back of the head. Holding the clipper as shown,
lightly stroke upwards making sure you are taking off the
desired amount of hair. Work your way up to the crown of the
head in layers. When completed, comb the
area to remove any loose hair and determine
if you need any further cutting.
2. Repeat the same procedure for each side of
the head. Make sure the length of the hair is
trimmed the same on both sides of the head.
3. To cut the top of the head, hold the hair
between your fingers and cut a small
amount at a time. Cut from the front to
the back.
4. To trim around the ears and short hairs at
the nape of the neck, you must remove the
trimming guide. Angle the clipper and
lightly stoke around each ear to the back of
HAIR CLIPPER PARTS
1. Storage case
2. Clipper
3. Taper Lever
4. 25mm Trimming Guide
5.
6.
18mm Trimming Guide
7.
16mm Trimming Guide
8.
12mm Trimming Guide
9.
9mm Trimming Guide
10.
6mm Trimming Guide
3mm Trimming Guide
11. Left & Right Ear Trimming Guides
12. Styling Comb
13. Scissors
14. Cape
15. Cleaning Brush
16. Neck Brush
17. 4 Sectioning Clips
Also included blade guard
& instruction manual.
2
3
10
9
8
7
6
5
4
1
16
17
15
11
12
13
14
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, especially when children
are present, basic safety precautions should always be
followed, including the following.
KEEP AWAY FROM WATER
•Always unplug it immediately after using.
•Do not place or store the appliance where it can fall or be
pulled into a bath or sink.
•Do not use while bathing.
•Do not place or drop into water or other liquid.
•Remington strongly recommends that an approved Safety
Switch (residual current device) be fitted to protect all bathroom
power outlets. Ask an electrical contractor for advice.
WARNING – TO REDUCE THE RISK OF BURNS, FIRE, ELECTRIC
SHOCK OR INJURY TO PERSONS:
•Do not reach for an appliance that has fallen into water.
Unplug it immediately.
•Do not use while bathing or in the shower.
•Do not place or drop into water or other liquid.
•Do not place or store this appliance where it can fall or be
pulled into a bath or sink.
•Always unplug this appliance from the electrical outlet
immediately after using.
•Unplug this appliance before cleaning it.
•This appliance is for household use only.
•Do not leave the appliance unattended when it is plugged in.
•Keep this product out of reach of children. This appliance can
be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities
SAVE THESE INSTRUCTIONS
or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children
shall not play with the appliance.
•Use this appliance only for its intended use as described in
this manual.
•Do not use attachments not recommended by Remington.
•Keep the cord away from heated surfaces.
•Never operate this appliance if it has a damaged cord or plug,
if it is not working properly, if it has been dropped or
damaged, or if it has been dropped into water. If any of these
things happen, return the appliance to an authorised service
centre for examination and repair.
•Never drop or insert any object into any of the appliance’s
openings.
•Do not use outdoors or operate where aerosol (spray)
products are being used, or where oxygen is being
administered.
•Make sure the cord is disconnected from the electrical outlet
while storing this appliance in a moisture-free area. Do not store
it in temperatures exceeding 60°C (140°F).
•Do not use this appliance with a damaged or broken cutter
unit, as injury may occur. Always make sure blades are
aligned properly.
•To disconnect, turn all controls to OFF, then remove the cord
from the electrical outlet.
•Do not use an extension cord or a voltage converter with this
appliance.
•Do not wrap the cord around the appliance.
2 3
