1 of 21 May 5, 2011
Notes
®
Introduction
This application note provides system design guidelines for IDT’s PCI Express® 2.0 base specification
compliant System Interconnect switch device family. Information provided in this document is applicable to
the following devices: 89HPES32NT24A[B]G2, 89HPES32NT8A[B]G2, 89HPES24NT24[A]G2,
89HPES24NT6AG2,89HPES22NT16G2,89HPES16NT16G2,89HPES16NT2G2and89HPES12NT12G2.
In this document, the PES32NT24AG2 is used as the primary reference. The letters “G2” within the device
names indicate that these devices are capable of GEN2 (5.0 GT/S) serial data speeds. The
PES32NT24AG2 device offers 32 PCIe lanes divided into 24 ports. The PES24NT24G2 device offers 24
PCIe lanes divided into 24 ports, and so on.
This document also describes the following device interfaces and provides relevant board design
recommendations:
1) PCI Express Interface
2) Reference Clock (REFCLK) Circuitry
3) Reset (Fundamental Reset) Schemes
4) SMBus Interfaces
5) GPIO and JTAG pins
6) Power and Decoupling Scheme
7) Switch Partitioning
PCI Express Interface
Port Configuration
Eight of the twenty four ports of the PES32NT24AG2 are statically allocated 2 lanes with ports labeled
from 0 through 7 and the remaining 16 ports are statically allocated 1 lane with ports labeled from 8 through
23. In a default configuration, SWMODE[3:0] = 0x0, Port 0 is always the upstream port while the remaining
ports are always downstream ports. In a Multi-partition configuration, SWMODE[3:0] = 0xC, or a Multi-parti-
tionwithSerialEEPROMinitializationconfiguration,SWMODE[3:0] = 0xD, all portscomeupas unattached.
Through a Serial EEPROM or Slave SMBus interface, ports can be configured as an upstream port,
upstream port with NT function, upstream port with NT and DMA functions, NT function, NT with DMA func-
tions, or as downstream ports. All ports can operate at a maximum link width of x2 (i.e. 2 lanes) or x1 (i.e. 1
lane) and support both 2.5 GT/S (Gen1) and 5.0 GT/S (Gen2) speeds.
Per the PCIe® specification, each switch port is viewed as a virtual PCI-PCI bridge device. In the
PES32NT24AG2, PCI device numbering follows the port numbering. Port 0 corresponds to Device 0 on the
upstream bus. Port 1 corresponds to Device 1 on the PES32NT24AG2 virtual PCI bus, Port 2 to Device 2,
and so on.
Note: Unused PCIe TX and RX lanes are not required to have a termination and can be left
open.
Application Note
AN-727
By Bryan Le
IDT PCI Express®
24-Port 32-Lane Gen 2 Switch
Hardware Design Guide

2 of 21 May 5, 2011
IDT AN-727
Notes
Figure 1 Port Numbering and Device Numbering
The switch contains four stack blocks labeled Stack 0, Stack 1, Stack 2, and Stack 3. Stacks 0 and 1
have four ports each, and stacks 2 and 3 have eight ports each. This provides a total of 24 ports in the
device, labeled port 0 through port 23. Table 1 lists the ports associated with each stack.
Stacks0 and1may be configuredasfour x2 ports, twox4ports, onex8 port, and combinations inbetween.
Stacks 2 and 3 may be configured as eight x1 ports, four x2 ports, two x4 ports, one x8 port, and
combinations in between. The configuration of each stack is controlled by the Stack
Configuration(STK[3:0]CFG) registers. These registers are located in the Switch Configuration and Status
space (see Device User Manual Chapter 20). Stacks 0 and 1 support five possible configurations each.
Stacks 2 and 3 support 26 possible configurations each. Tables 3.4 through 3.7 below show the possible
configurations for each stack.
◆Each STKxCFG register controls the configuration of the corresponding stack (e.g., STK0CFG
controls the configuration of Stack 0, STK1CFG for Stack 1, etc.)
◆Stack configurations not shown in thetable are not allowed. Programming the STKxCFG register to
values not shown in the table produces undefined results.
Stack Port Associated with the Stack
Stack 0 0, 1, 2, 3
Stack 1 4, 5, 6, 7
Stack 2 8, 9, 10, 11, 12, 13, 14, 15
Stack 3 16, 17, 18, 19, 20, 21, 22, 23
Table 1 Ports in Each Stack
PES32NT24AG2
PE8T[0]
PE8R[0] RX
TX
PE9T[0]
PE9R[0]
PE23T[0]
PE23R[0]
(Port 8, Device8)
(Port 9, Device9)
(Port 23,Device 23)
RX
TX PE0T [1:0] PE0R [1:0]
PE1R [1:0]
PE1T [1:0]
PE7R [1:0]
PE7T [1:0]
(Port 0, Device 0)
(Port 1, Device 1)
(Port 7, Device 7)
RX
TX
RX
TX
RX
TX
RX
TX

3 of 21 May 5, 2011
IDT AN-727
Notes
STKCFG Field in the
STK0CFG Register Stack Configuration
Hex Binary Port 3 Port 2 Port 1 Port 0
0x0 0b00000 x8
0x1 0b00001 x4 x4
0x2 0b00010 x2 x2 x4
0x3 0b00011 x2 x2 x2 x2
0x6 0b00110 x4 x2 x2
Others Reserved
Table 2 Possible Configuration for Stack 0
STKCFG Field in the
STK1CFG Register Stack Configuration
Hex Binary Port 7Port 6 Port 5 Port 4
0x0 0b00000 x8
0x1 0b00001 x4 x4
0x2 0b00010 x2 x2 x4
0x3 0b00011 x2 x2 x2 x2
0x6 0b00110 x4 x2 x2
Others Reserved
Table 3 Possible Configuration for Stack 1
STKCFG Field in the
STK2CFG Register Stack Configuration
Hex Binary P15 P14 P13P12 P11 P10 P9 P8
0x0 0b00000 x8
0x1 0b00001 x4 x4
0x2 0b00010 x2 x2 x4
0x3 0b00011 x2 x2 x2 x2
0x6 0b00110 x4 x2 x2
0x8 0b01000 x4 x1 x1 x2
0x9 0b01001 x4 x1 x1 x1 x1
0xA 0b01010 x2 x2 x2 x1 x1
0xB 0b01011 x2 x2 x1 x1 x2
0xC 0b01100 x1 x2 x2 x4
0xD 0b01101 x1 x1 x1 x1 x4
0xE 0b01110 x2 x1 x1 x2 x2
Table 4 Possible Configuration for Stack 2 (Page 1 of 2)

4 of 21 May 5, 2011
IDT AN-727
Notes
0xF 0b01111 x1 x1 x2 x2 x2
0x10 0b10000 x2 x2 x1 x1 x1x 1
0x11 0b10001 x2 x1 x1 x1 x1 x2
0x12 0b10010 x2 x1 x1 x1 x1 x1 x1
0x13 0b10011 x1 x1 x2 x1 x1 x1 x1
0x14 0b10100 x1 x1 x1 x1 x2 x2
0x15 0b10101 x1 x1 x2 x2 x1x x1
0x16 0b10110 x1 x1 x1 x1 x2 x1 x1
0x17 0b10111 x1 x1 x1 x1 x1 x1 x2
0x18 0b11000 x4 x2 x1 x1
0x19 0b11001 x2 x1 x1 x2 x1 x1
0x1A 0b11010 x1 x1 x2 x1 x1 x2
0x1B 0b11011 x1 x1 x1 x1 x1 x1 x1 x1
0x1C 0b11100 x2 x1 x1 x4
Others Reserved
STKCFG Field in the
STK3CFG Register Stack Configuration
Hex Binary P23 P22 P21 P20 P19 P18 P17 P16
0x0 0b00000 x8
0x1 0b00001 x4 x4
0x2 0b00010 x2 x2 x4
0x3 0b00011 x2 x2 x2 x2
0x6 0b00110 x4 x2 x2
0x8 0b01000 x4 x1 x1 x2
0x9 0b01001 x4 x1 x1 x1 x1
0xA 0b01010 x2 x2 x2 x1 x1
0xB 0b01011 x2 x2 x1 x1 x2
0xC 0b01100 x1 x2 x2 x4
0xD 0b01101 x1 x1 x1 x1 x4
0xE 0b01110 x2 x1 x1 x2 x2
0xF 0b01111 x1 x1 x2 x2 x2
0x10 0b10000 x2 x2 x1 x1 x1x 1
0x11 0b10001 x2 x1 x1 x1 x1 x2
0x12 0b10010 x2 x1 x1 x1 x1 x1 x1
Table 5 Possible Configuration for Stack 3 (Page 1 of 2)
STKCFG Field in the
STK2CFG Register Stack Configuration
Table 4 Possible Configuration for Stack 2 (Page 2 of 2)

5 of 21 May 5, 2011
IDT AN-727
Notes
A stack may be configured statically using the corresponding Stack Configuration (STKxCFG) pins.
These pins are sampled by the switch as part of the boot-configuration vector during switch fundamental
reset. The STKxCFG pins determine the initial value of the STKCFG field in the corresponding STKxCFG
register. The encoding of the STKxCFG pins is identical to that of the STKCFG field shown in Tables 2
through 5.•For Stacks 0 and 1, the STKxCFG pins have 2 bits each (i.e., STK0CFG[1:0] and
STK1CFG[1:0]). These bits correspond to the two least significant bits of the STKCFG field in
the correspondingSTKxCFG register. Therefore, for these stacks, configurations 0x0 through
0x3maybeselectedstatically.OtherconfigurationsmustbeselecteddynamicallyviaEEPROM
or Slave SMBus interface.
•For Stacks 2 and 3, the STKxCFG pins have 5 bits each. Therefore, all 26 possible configura-
tionsmay be selected statically.
•Notethatforall stacksthe STKxCFG[2]pin canbeusedtoselect betweena stackconfiguration
anditsmirrorimage.Forexample,whentheSTKxCFGpinsaresetto0b00010,thestackiscon-
figuredperconfiguration0x2(portsareconfiguredasx4,x2,x2).Thesetting0b00110yieldsthe
mirror image which corresponds to stack configuration 0x6 (ports are configured as x2, x2, x4).
Lane Reversal
The PES32NT24AG2 supports automatic lane reversal outlined in the PCIe specification. This allows
trace routing flexibility to avoid crossovers and potentially reduces the number of trace vias required for
signal routing. Lane reversal must be done for both the transmitter and the receiver of a port.
Lane reversal mappings for the variousnon-trivial x8 maximum link width configurations are illustrated in
Figures 2 through 4. In the figures, PExRP[n] refers to the pin associated with lane 0 of port’x’.
0x13 0b10011 x1 x1 x2 x1 x1 x1 x1
0x14 0b10100 x1 x1 x1 x1 x2 x2
0x15 0b10101 x1 x1 x2 x2 x1x x1
0x16 0b10110 x1 x1 x1 x1 x2 x1 x1
0x17 0b10111 x1 x1 x1 x1 x1 x1 x2
0x18 0b11000 x4 x2 x1 x1
0x19 0b11001 x2 x1 x1 x2 x1 x1
0x1A 0b11010 x1 x1 x2 x1 x1 x2
0x1B 0b11011 x1 x1 x1 x1 x1 x1 x1 x1
0x1C 0b11100 x2 x1 x1 x4
Others Reserved
STKCFG Field in the
STK3CFG Register Stack Configuration
Table 5 Possible Configuration for Stack 3 (Page 2 of 2)

6 of 21 May 5, 2011
IDT AN-727
Notes
Figure 2 Lane Reversal for Highest Achievable Link Width of x2
Figure 3 Lane Reversal for Highest Achievable Link Width of x4

7 of 21 May 5, 2011
IDT AN-727
Notes
Figure 4 Lane Reversal for Highest Achievable Link Width of x8
Polarity Inversion
Each port of the PES32NT24AG2 supports automatic polarity inversion defined by the PCIe specifica-
tion. This allows trace routing flexibility to avoid crossovers and potentiallyreduces the number of trace vias
required for signal routing. Polarity inversion is a function of the receiver and not the transmitter. The trans-
mitter never inverts its data. During link training, the receiver examines symbols 6 through 15 of the TS1
and TS2 ordered sets for inversion of the PExRP[n] and PExRN[n] signals. If an inversion is detected, then

8 of 21 May 5, 2011
IDT AN-727
Notes logic for the receiving lane automatically inverts received data. Polarity inversion is a lane function and not
a link function. Therefore, it is possible for some lanes of link to be inverted and for others not to be
inverted.
Figure 5 Polarity Inversion
Tx Capacitors
The PCIe specification requires that each lane of the link is AC coupled between its corresponding
transmitter and receiver. The AC coupling capacitors for the PES32NT24AG2 are discrete components
located along each transmitter link on the PCB. These AC coupling capacitors allow the transmitter and
receiver on a link to be biased at separate voltages. Table 1 summarizes the guidelines for implementing
the PCIe AC coupling capacitors on a system board.
Parameter Implementation Guideline
AC Coupling AC coupling capacitors are required on the Tx pairs originating
from the PES32NT24AG2
Capacitor Value Between 75nF and 200nF
Capacitor Tolerance Specified minimum/maximum range must be met when capacitor
toleranceisconsideredalongwitheffectsduetotemperatureand
voltage
Capacitor Type Size 603 ceramic capacitors are acceptable, however, size 402
capacitors are strongly encouraged. The smaller the package
size, the less ESL is introduced into the topology. The same
package and capacitor size should be used for each signal in a
differential pair. Do not use capacitor packs for PCIe AC coupling.
Capacitor Pad Size To minimize parasitic impacts, pad sizes for each capacitor
should be the minimum allowed per PCB manufacturer.
Capacitor Placement AC coupling capacitors should be located at the same place
within the differential pair. They should not be staggered in dis-
tance from one trace of the differential pair to the other. Capaci-
tors should be placed as close to each other as possible to avoid
creating large uncoupled sections within the differential pair
traces. Relative location from one differential pair to another is
not important.
Capacitor Location –
Chip-to-Connector Routing Capacitors should be placed such that they are not located in the
center point of a trace route (for example, capacitors should be
placed next to the connector or 1/3 the distance between the con-
nector and the PES32NT24AG2.
Capacitor Location –
Chip-to-Chip Routing Capacitors should be located off-center within the interconnect
(for example, placing the capacitors next to the Rx pins of one
device is generally better than locating the capacitors in the mid-
point of the interconnect).
Table 6 PCIE Interface AC Coupling Capacitor Guidelines
PExT[n]
+
-
+
-
PExR[n]
RX
+
-
+
-
TX

9 of 21 May 5, 2011
IDT AN-727
Notes Routing Differential Pairs
The switch includes 50 Ohm resistor on-die terminations on both the transmit and the receive pins. No
externalterminationisrequired. Individual traces within a given differential pair (positive and negative) must
be matched in length to a tolerance of 5 mils. Length matching within a differential pair should occur on a
segment-by-segment basis, as opposed to length matching across the total distance of the overall route. In
addition, the spacing between traces of adjacent pairs must be at least 20 mils edge-to-edge to reduce
crosstalk effects.
Note that trace length matching between pairs is not required because the PCIe 2.0 specifications allow
up to 8ns of skew between differential pairs. AC coupling capacitors are associated with the Tx differential
pairs and should be located symmetrically on the top or bottom layer between the switch and the PCIe
connectors/devices.
Figure 6 AC Capacitor Placement
Every effort should be made to avoid vias on the PCIe differential pairs since they can result in a signal
loss of up to 0.25 dB. When a via is unavoidable, its pad size should be less than 25 mils, its hole size
should be less than 14 mils, and its anti-pads should be 35 mils or smaller. No extra vias should be added
over and above those needed for IC pads or a connector. Vias in a differential pair should always be at the
same relative location and placed in a symmetrical fashion along the differential pair as shown in Figure 7.
Figure 7 Via Placement
Avoid 90-degree bends or turns on traces. Wherever possible, the number of left and right bends should
be matched as closely as possible. Alternatingleft and right turns helps tominimize length skew differences
between each signal of a differential pair.
Figure 8 Acceptable Bends and Unacceptable Bends
Depending on the system topology and the maximum targeted trace length, regular FR4 material is
appropriatedielectric material. In case of a backplane type of application, higherquality, lower loss material,
such as Nelco 4000-13, may be used.
A HSPICE simulation kit for the switch can be requested by emailing [email protected].
Device Breakout Area
Within the breakout areas of thePES32NT24AG2, the PCIe signal pairs should maximize thedifferential
routing while minimizing any discontinuities or trace length skew. Length matching of the differential traces
should occur as close as possible to the pad or pin while avoiding the addition of tight bends within the
AC Cap Pads
Via Pair
Bottom Layer Top Layer
Preferred Bad

10 of 21 May 5, 2011
IDT AN-727
Notes traces. The breakout area should not exceed 250 mil in length for the PCIe interface. Within the breakout
areas, the trace routing guidelines ofthe differential pairs canbe slightly relaxed (if absolutely necessary) to
facilitate successful breakout of the signals. A width and spacing geometry of 6/4.5/6 (6 mil trace width and
4.5 mil spacing edge to edge) are used on PES32NT24AG2 evaluation board.
Figure 9 PCIe Differential Trace Breakout Bottom Layer
Figure 10 PCI Different Trace Breakout Top Layer
Serdes Reference Resistor Pins
The switch has one Serdes Reference Resistor pin per port. The 3.0K +/- 1% reference bias resistor
should be located as close to these pins as possible and should be tapped immediately to the GROUND
plane. This resistor must be isolated from anysource of noise injection. One way to achieve this is to place
the resistor on the back-side of the board, directly underneath the device. No bypass capacitors must be
placed on these pins.

11 of 21 May 5, 2011
IDT AN-727
Notes Reference Clock (REFCLK) Circuitry
The switch has two differential global reference clock inputs (GCLKP[1:0]/GCLKN[1:0]) that are used to
generate all of the clocks required by the internal switch logic and the SerDes. The differential clock inputs
require the signal source to drive a 0V common-mode and the REFCLK signal must meet the electrical
specificationsdefined in the PCI Express Card Electromechanical Specification. AC coupling is notrequired
on reference input clocks.
The reference clock inputs support spread spectrum clocking (SSC) for reducing EMI. The required
method is to adjust the spread technique to prevent modulation above the nominal frequency. This tech-
nique is often called “down-spreading.” If SSC is used, all clocks must come from a single source. This
includes the clock for the switch itself, the clock for the devices connected to the downstream ports of the
switch, and the clocks for the root complex chipset or other devices (switch or bridge) connected to the
upstream port of the switch. If SSC is not used, multiple clock sources are allowed for each PCI Express
device in the tree.
Global Reference Clock Selection
The frequency of the global reference clock inputs can be either 100 MHz or 125 Mhz, and the Global
Clock Frequency Select (GCLKFSEL) input is used to indicate the choice of frequency. The PCIe CEM
specification requires a nominal frequency of 100 MHz for the reference clock pair. Thus, in the majority of
applications, the 100 MHz clock input should be selected.
–For the 100 MHz clock input, GCLKSEL input pin must be asserted low.
–For the 125 MHz clock input, GCLKSEL input pin must be tied to a pull-up resistor of 3.3V power.
Figure 11 Simplified GCLK Circuit
The switch provides two clock operation modes for each side of the switch: Global Clock and Local Port
Clock. System designers must configure the CLKMODE[2:0] pins depending on which mode is chosen for
the upstream side and the downstream side of the switch.
Global Port Clocked Mode
Figures 12 and 13 show the implementation of common clock mode and non-common clock mode,
respectively. The Spread Spectrum Clock must be disabled when the non-common clock is used on either
the upstream port or downstream port.
Note: The downstream port's reference clock must be controlled by the power good signal or an
appropriate control signal if downstream slots support hot-plug operation.
HCSL Clock
Source
GCLKP0
GCLKN0
GCLKP1
GCLKN1
Termination specified by
clock source vendor PES32NT24AG2

12 of 21 May 5, 2011
IDT AN-727
Notes
Figure 12 Example of Common Clock Mode with SSC
Figure 13 Example of Non-Common Clock Mode
Local Port Clocked Mode
Associated with some ports is a port reference clock input (PxCLK). Depending on the port clocking
mode, a differential reference clock is driven into the device on the corresponding PxCLKP and PxCLKn
pins. Table 7 lists the ports that must operate in the same port clock mode (i.e., Global Clocked or Local
Port Clocked). This allows support for Spread Spectrum Clocking (SSC) either globally or independently on
a per port basis. Figure 14 shows implementation of Local Port Clock mode with SSC on root complex via
P0CLK.
Ports
0,1
2,3
4,5
6,7
8,9,10,11
Table 7 Ports that must operate with the same Port Clock Mode
Switch
RC
100 MHz Or 125 MHz
SSC
Port 0
Upstream
GCLK0 GCLK1
Port 2
Port 3 EP2
EP1
RefClk
RefClk
Switch
RC Port 0
Upstream
GCLK0 GCLK1
Port 2
Port 3
EP1
RefClk
EP2
RefClk
100 MHz nonSSC
(Mandatory)
100 MHz nonSSC
(Mandatory) 100 MHz nonSSC
(Mandatory)
Switch
RC Port 0
Upstream
GCLK0 GCLK1
Port 2
Port 3
EP1
RefClk
EP2
RefClk
100 MHz nonSSC
(Mandatory)
100 MHz nonSSC
(Mandatory) 100 MHz nonSSC
(Mandatory)

13 of 21 May 5, 2011
IDT AN-727
Notes
Figure 14 Example of Local Port Clock mode with SSC on Root Complex
Reset (Fundamental Reset) Schemes
The PERSTN pin is used to reset all logic inside the switch and is a Schmitt Trigger Input which can be
connected to the PERST# from the system or a power-on reset circuit. In a system, the values of Tpvperl
and Tperst-clk depend on the mechanical form factor in which the switch is used. For example, the PCIe
Card Electromechanical Specification, Revision 2.0, specifies the minimum value of Tperst-clk=100µs and
Tpvperl=100ms.
Figure 15 Fundamental Reset
For the reset signals to downstream ports, reset schemes listed below can be implemented.
–Simplified Reset Scheme
–Reset Scheme for Hot Plug Support
Simplified Reset Scheme
If Hot Plug support is not required, the simplified reset scheme canbe implemented as shown in Figure
16. Add a buffer on the PERST# signal if the output from system is not able to drive a number of fan-out
loads for all downstream ports.
12,13,14,15
16,17,18,19
20,21,22,23
Ports
Table 7 Ports that must operate with the same Port Clock Mode
Switch
RC
100 MHz SSC
(Mandatory)
Port 0
Upstream
GCLK0 GCLK1
Port 2
Port 3
P0CLK
100 MHz nonSSC
(Mandatory)
EP1
RefClk
EP2
RefClk
Switch
RC
100 MHz SSC
(Mandatory)
Port 0
Upstream
GCLK0 GCLK1
Port 2
Port 3
P0CLK
100 MHz nonSSC
(Mandatory)
EP1
RefClk
EP2
RefClk
REFCLK*
Vdd
PERSTN
Tpvperl
Tperst-clk

14 of 21 May 5, 2011
IDT AN-727
Notes
Figure 16 Simplified Reset Scheme
Reset Scheme for Hot Plug Support
Figure 17 shows an implementation where downstreamendpoints have independent fundamentalreset.
This scheme should be used if Hot-Plug support is needed selectively on the downstream ports.
Figure 17 Reset Scheme for Hot Plug Support
RSTHALT
When this signal is asserted high during a PCI Express fundamental reset, the switch continuously
returns Configuration Request Retry Completion Status (CRS) to Configuration Requests during the
enumeration process. This allows the system BIOS via the SMBus to access internal registers before
normal device operation begins. The device exits the RSTHALT state when the RSTHALT bit is cleared in
the SWCTL register by a SMBus master. This RSTHALT mode is not required in most applications. The
RSTHALT pin should be pulled down externally if the application does not use a SMBus master to initialize
internal registers.
SMBus Interfaces
The switch provides two SMBus interfaces.
–The Master SMBus interface provides connection for an external serial EEPROM used forinitial-
ization and optional external I/O expanders.
–The slave SMBus interface provides full access to all software visible registers in the
PES32NT24AG2,allowingevery registerinthedevicetoberead orwrittenby anexternalSMBus
master. The slave SMBus may also be used to preload the serial EEPROMused for initialization.
The Master SMBus interface consists of an SMBus clock pin and data pin. The Slave SMBus interface
consists of an SMBus clock pin, data pin and 2 SMBus address pins. In the slave interface, these address
pins allow the SMBus address to which the device responds to be configured. In the master interface, the
address of the serial configuration EEPROM from which data is loaded to be configured is fixed to 0x50.
This interface operates using a basic I2C protocol, at a rate of 400 KHz (i.e., I2C Fast Mode). The SMBus
address is set up on negation of PERSTN by sampling the corresponding address pins.
System
Switch Port 1 Port2Port 23
PERSTN
…..
System
Switch Port 1 Port2Port 23
PERSTN
PERSTN
…..
System
Switch Port 1 Po rt 2 Port 23
Generation Reset
Generation
PERSTN PERSTN PERSTN
….
Port 1 Po rt 2 Port 23
PERSTN
Reset
Ge neratio n Reset
PERSTN PERSTN PERSTN
….
PERSTN
Switch
System

15 of 21 May 5, 2011
IDT AN-727
Notes Initialization from Serial EEPROM
During a fundamental reset, an serial EEPROM is required to initialize any software visible register
withinthedevice. Serial EEPROM loading occurs ifthe Switch Mode (SWMODE [3:0]) field selects an oper-
ating mode that performs serial EEPROM initialization (e.g., Normal switch mode with Serial EEPROM
initialization).
Any serial EEPROM compatible with those listed in Table 8 can be used to store switch initialization
values. EEPROM space may not be fully utilized because some of these devices are larger than the total
available PCI configuration space that can be initialized in the switch.
Table 8 PES32NT24AG2 Compatible Serial EEPROMs
Configuring the I/O Expander Address
The switch utilizes external SMBus / I2C-bus I/O expanders connected to the master SMBus interface
for hot-plug and port status signals. The switch is designed to work with Phillips PCA9555 compatible I/O
expanders (i.e., PCA9555, PCA9535, and PCA9539). See the Phillips PCA9555 data sheet for details on
the operation of this device. For applications that require more than 8 I/O expanders, the MAX7311 is
recommended since it is compatible with the Phillips PCA9555 and supports 64 slave addresses.
The switch supports up to 22 external I/O expanders numbered 0 to 22.Table 9 summarizes the alloca-
tion of functions to I/O expanders. Figure 18 illustrates an example of the interface for I/O expanders 0, 2,
and 12. During switch initialization, the SMBus/I2C-bus address allocated to each I/O expander used in that
system configuration should be written to the corresponding I/O Expander Address (IOE[0,2,12]ADDR)
field. The IOE[0,2]ADDR fields are contained in the I/O Expander Address 0 (IOEXPADDR0) register while
the IOE[12]ADDR fields are contained in the SMBus I/O Expander Address 3 (IOEXPADDR3) register.
Hot-plug outputs and I/O expanders may be initialized via serial EEPROM. Since the I/O expanders and
serial EEPROM both utilize the master SMBus, no I/O expander transactions are initiated until serial
EEPROM initialization completes.
Serial EEPROM Size
24C32 4 KB
24C64 8 KB
24C128 16 KB
24C256 32 KB
24C512 64 KB
SMBus I/O
Expander Section Functionality
0 Lower Port 0 hot-plug
Upper Port 4 hot-plug
1 Lower Port 8 hot-plug
Upper Port 16 hot-plug
2 Lower Port 2 hot-plug
Upper Port 6 hot-plug
Table 9 I/O Expander Functionality Allocation (Page 1 of 2)

16 of 21 May 5, 2011
IDT AN-727
Notes
3 Lower Port 12 hot-plug
Upper Port 20 hot-plug
4 Lower Port 1 hot-plug
Upper Port 3 hot-plug
5 Lower Port 5 hot-plug
Upper Port 7 hot-plug
6 Lower Port 10 hot-plug
Upper Port 14 hot-plug
7 Lower Port 18 hot-plug
Upper Port 22 hot-plug
8 Lower Port 9 hot-plug
Upper Port 11 hot-plug
9 Lower Port 13 hot-plug
Upper Port 15 hot-plug
10 Lower Port 17 hot-plug
Upper Port 19 hot-plug
11 Lower Port 21 hot-plug
Upper Port 23 hot-plug
12 Lower / Upper Hot-plug MRL inputs (port0 through 7, 8, 10, 12, 14, 16, 18,
20, 22)
13 Lower Hot-plug MRL inputs (port9, 11, 13, 15, 17, 19, 21, 23)
14 Lower / Upper Hot-plug electromechanical interlock (Ports 0, 2, 4, 6, 8,
12, 16, 20)
15 Lower / Upper Hot-plug electromechanical interlock (Ports 1, 3, 5, 7, 10,
14, 18, 22)
16 Lower / Upper Hot-plug electromechanical interlock (Ports 9, 11, 13, 15,
17, 19, 21, 23)
17 Lower / Upper Link status (Ports 0 through 15)
18 Lower / Upper Link activity (Ports 0 through 15)
19 Lower / Upper Link status (Ports 16 through 23) / Link activity (Ports 16
through 23)
20 Lower / Upper Port reset outputs (Ports 0, 2, 4, 6, 8, 12, 16, 20) / Partition
fundamental reset inputs (partitions 0 to 7)
21 Lower / Upper Port reset outputs (Ports 1, 3, 5, 7, 9, 10, 11, 13, 14, 15,
17, 18, 19, 21, 22, 23)
SMBus I/O
Expander Section Functionality
Table 9 I/O Expander Functionality Allocation (Page 2 of 2)

17 of 21 May 5, 2011
IDT AN-727
Notes
Figure 18 Example of I/O Expander Interface
Slave SMBus Address Interface
The slave SMBus interface provides the switch with a configuration, management, and debug interface.
Using the slave SMBus interface, an external master can read or write any software visible register in the
device. The address is specified by the SSMBADDR[2:1] signals as shown in Table 10.
Address
Bit Address Bit Value
1 SSMBADDR[1]
2 SSMBADDR[2]
31
40
51
61
71
Table 10 Slave SMBus Address
MSMBCLK
A2 A1 A0
SCL SDA
000
A2 A1 A0
SCL SDA
010
A2 A1 A0
SCL SDA
001
MSMBDAT
IO Expander0
(Addr. = 0x0) IO Expander2 (addr. =0x24) IOExpander4 (addr.=0x58)
/INT
GPIO2
GPIO4
/INT /INT
Switch
Register IOE0ADDR[7:1]
IOExpander00M AX 73 1 1 Add r es s 1 0 0 A 2 A 1 A0 r / w
0100000
0100000
7Offset0x1198bits 654321
Register IOE0ADDR[23:17]
IOExpander20100010
0100010
23O ffse t 0 x 1 19 8 bit s 2 2 21 20 19 18 17
Register IOE3ADDR[7:1]
IO Expander12 0100100
0100100
7654321Of fs et 01 1 A4 x bi ts
MSMBCLK
A2 A1 A0
SCL SDA
000
A2 A1 A0
SCL SDA
010
A2 A1 A0
SCL SDA
001
MSMBDAT
IO Expander0
(Addr. = 0x0) IO Expander2 (addr. =0x24) IOExpander4 (addr.=0x58)
/INT
GPIO2
GPIO4
/INT /INT
Switch
Register IOE0ADDR[7:1]
IOExpander00M AX 73 1 1 Add r es s 1 0 0 A 2 A 1 A0 r / w
0100000
0100000
7Offset0x1198bits 654321
Register IOE0ADDR[23:17]
IOExpander20100010
01000
MSMBCLK
A2 A1 A0
SCL SDA
000
A2 A1 A0
SCL SDA
010
A2 A1 A0
SCL SDA
001
MSMBDAT
IO Expander0
(Addr. = 0x0) IO Expander2 (addr. =0x24) IOExpander4 (addr.=0x58)
/INT
GPIO2
GPIO4
/INT /INT
Switch
Register IOE0ADDR[7:1]
IOExpander00M AX 73 1 1 Add r es s 1 0 0 A 2 A 1 A0 r / w
0100000
0100000
7Offset0x1198bits 654321
Register IOE0ADDR[23:17]
IOExpander20100010
0100010
23O ffse t 0 x 1 19 8 bit s 2 2 21 20 19 18 17
Register IOE3ADDR[7:1]
IO Expander12 0100100
0100100
7654321Of fs et 01 1 A4 x bi ts

18 of 21 May 5, 2011
IDT AN-727
Notes Power and Decoupling Scheme
The switch has five different types of power supply pins:
1. VDDCORE (1.0V) powers the digital core of the switch.
2. VDDPEA (1.0V) power the SERDES core and analog circuits. VDDPEA should have no more than
25mVpeak-peak AC power supply noise superimposed on the 1.0V nominal DC value.
3. VDDPEHA(2.5V)powertheSERDES coreandanalogcircuits.VDDPEHAshouldhavenomorethan
50mVpeak-peak AC power supply noise superimposed on the 2.5V nominal DC value.
4. VDDPETA (1.0V) is the termination voltage used on the SERDES TX lanes. VDDPETA can be
adjusted to modify the TX common mode voltage as well as the voltage swing.
5. VDDI/O (3.3V) powers the low speed IOs of the switch.
VDDCORE, VDDPEA, and VDDPETA can be derived from the same voltage source with appropriate
bypass capacitors and a ferrite bead. If all voltages can not be handled by a single voltage regulator, they
can be derived from separate voltage regulators.
A ferrite bead can be used to attenuate the power noise andimprove the analog circuit performance in a
noisy environment. The following three parameters should be considered when you select a ferrite bead for
power rails:
–Very low DC resistance
–Impedance of 50 ~ 120 ohms at 100 MHz
–Provides enough DC current
Figure 19 Board Power Supply Arrangement
Power Consumption
The typical and maximum power consumption can be found in the appropriate switch data sheet (see
Reference Documents at the end of this guide).
Power-Up/Power-Down Sequence
During power supply ramp-up, VDDI/O mustremain at least 1.0V above VDDCORE at all times. If VDDI/O
is brought up first, then there is no problem. There are no other power-up sequence requirements for the
various operating supply voltages. The power-down sequence can occur in any order.
PES16T4 2
VDDCORE
Bypass
1.0V-5%/+10%
Bypass/
Ferrite Bead
Bypass
2.5V+/- 10%
VDDPEA
VDDPETA
VDDPEHA
Bypass
3.3V+/- 5%
VDDI/O
32NT24AG2
Bypass/
Ferrite Bead

19 of 21 May 5, 2011
IDT AN-727
Notes Decoupling Scheme
1) One bypass capacitor per power pin is recommended if board layout allows. 0402 package ceramic
capacitors are recommended for 0.1µF and 0.01µF capacitors.
2) Bypass Capacitors must be placed as close to the device pins as possible based on space avail-
ability. Note that some of the vias need to be shared in order to create space for placing a capacitor next to
a pin.
3) A bigger capacitor should be used to filter out low frequency noise. Larger 1µF and 47µF capacitors
should be added around the part. Two bigger capacitors per voltage supply are appropriate. One option is
to spread out the big capacitors at four corners, top and bottom layers of the chips.
4) Short and wide traces should be used to minimize resistance and inductance.
5) Prioritize the bypass capacitors in the following order for each power supply:
1. VDDCORE
2. VDDPEA / VDDPETA
3. VDDPEHA
4. VDDI/O
GPIO and JTAG Pins
GPIO Pins
The switch has a number of General Purpose I/O (GPIO) pins that may be individually configured as
general purpose inputs, general purpose outputs, or alternate functions. GPIO pins are controlled by the
General Purpose I/O Function (GPIOFUNC), General Purpose I/O Configuration (GPIOCFG), and General
Purpose I/O Data (GPIOD) registers in the upstream port's PCI configuration space. Please refer to the
device data sheet for additional details.
The internal pull-up resistors value for the GPIO pins under typical condition is about 92K ohm.
JTAG Pins
The switch provides the JTAG Boundary Scan interface to test the interconnections between integrated
circuit pins after they have been assembled onto a circuit board. For details of the interface, please refer to
to the appropriate switch user manual (see Reference Documents below).
The JTAG_TRST_N pin must be asserted low when the switch is in normal operation mode (i.e. drive
this signal low with an external pull-down or control logic on the board if the JTAG interface is not used).
Switch Partitioning
Switch partitioning allows the logical division of the PCIe switch into multiple partitions (up to 8), each of
which is composed of a configurable number of ports, and each of which connects to a separate PCIe
domain1. Each switch partition is logically isolated from the other partitions.
From the switch’s perspective, a switch partition represents a logical containerthat contains switch ports
associated with a PCIe domain. Any switch port can be configured to belong to one partition. The assign-
ment of ports to partitions is left to the system designer. A partition may be configured with zero, one, or
many ports, although certain rules apply (see below) regarding valid partition configurations. Figure 20
shows a PES32NT24AG2 configured with 3 partitions.
1. A PCIe domain is the collection of PCIe devices under a common processor/memory complex (i.e., root-complex), and
sharing common PCIe memory, I/O, and configuration spaces.

20 of 21 May 5, 2011
IDT AN-727
Notes A partition can be placed in one of three modes: disabled, active, and reset. When a partition is
disabled, all ports associated with the partition (if any) are disabled and can’t be used. When a partition is
active, all ports associated with the partition are active. When a partition is reset, all ports associated with
the partition are in PCIe fundamental reset.
Figure 20 The PES32NT24AG2 Configured with 3 Switch Partitions
As shown in Figure 20, each port can be placed in one of several modes. Dependingon the mode, ports
may contain between one and three PCIe functions. The PCI-to-PCI bridge function allows the port to
forward packets across the same partition. By placing two or more ports with a PCI-to-PCI bridge function
within a partition, a PCI Express switch is logically created within that partition. On the other hand, the NT
endpoint function serves as a gateway to other PCIe domains via the non-transparent interconnect (shown
in blue in Figure 20). Finally, the DMA endpoint function provides a DMA engine to off-load the partition’s
host during data transfers. Table 11 lists the port operating modes and the PCIe functions in each mode.
Not all possible partition configurations are valid. For example, it is not valid to configure a partition with
more than one upstream port. The following are the common partition configurations supported by the
PES32NT24AG2:
–Aswitch partition with oneupstreamswitch port (with or without NT orDMA functions) and one or
more downstream switch ports.
–A switch partition with an NT endpoint port (with or without DMA function).
Port Mode PCIe Functions in the Port
Function 0 Function 1 Function 2
Disabled The port is not operational
Upstream switch port PCI-to-PCI bridge
Upstream switch port with
NT function PCI-to-PCI bridge NT Endpoint
Upstream switch port with
NT and DMA functions PCI-to-PCI bridge NT Endpoint DMA Endpoint
NT function NT Endpoint
NT with DMA function NT Endpoint DMA Endpoint
Downstream switch port PCI-to-PCI bridge
Unattached The port is not associated with any partition. The port accepts configura-
tion requests that allow for switch management.
Table 11 Port Operating Modes1
1. Not all switch ports support all modes. Refer to the PES32NT24AG2 User Manual for further de-
tails.
NT Interconnect
EP EP
RC
P2P
EP
RC
P2P NT
EP EP
RC
Partition 0 Partition 1 Partition 2
P2P P2P P2P P2P P2P
PES32NT24G2
RC – Root Complex
P2P – PCI-PCI Bridge
NT – NT Endpoint
DMA – DMA Endpoint
EP – Endpoint Device
NT DMA
