Renewal Technologies LaserTouchOne User manual

User Manual

2
Introduction – e LaserTouchOne™...................................... 3
Device Features and Controls (Photo of device) ..................... 4
Product Contents ................................................................... 4
Laser Safety............................................................................ 4
Electrical Safety...................................................................... 5
Instructions for Using the LaserTouchOne™
Charging the Unit.................................................................. 5
Holding the Device................................................................ 5
Treatment Steps................................................................... 6-7
Areas to Avoid ........................................................................ 8
Indications for Use ................................................................. 8
Contraindications................................................................... 8
Warnings................................................................................ 9
Precautions............................................................................10
Care and Maintenance ..........................................................11
Warranty ...............................................................................12
Service...................................................................................12
More Questions? ...................................................................13
Technical Specications ........................................................14
Glossary ................................................................................15
User Manual
Table of Contents

3
e LaserTouchOne™(OTC) (referred to further as simply
LTO) is a rechargeable hand-held pain therapy device. It
has a single diode laser for delivery of low level laser therapy,
referred to by some as a ‘cold laser’ or LLLT. e single laser
source is extremely low power (< 1mW) and in the Class IIa
regulatory classication for laser lights. It operates at the 670
nm wavelength. e second therapy delivered by the device is
a micro-current electrical stimulation, similar to devices that
are referred to as transcutaneous electrical nerve stimulators
(TENS), but at a much lower level. e device contains a
rechargeable lithium ion battery.
e combined therapies are activated with an on/o power
button, which when pressed is set for a 2-minute cycle.
Depending on the severity of pain, you can treat a single area
with 4 to 5 treatment cycles (8 to 10 minutes), up to 5 times
each day. e electrical stimulation and the laser light therapies
are activated at the same time by pushing the on/o switch.
e pulse width (e.g. intensity) of the electrical stimulation is
variable and is controlled by you, the user. is is described in
the Treatment Steps on pages 6 and 7. It is recommended that
the intensity of the electrical stimulation be kept very low, so
that you barely feel it. e combination of low level laser and
micro-current electrical stimulation will facilitate pain relief.
is combination of therapies has been shown to be eective
at very low levels of stimulation, so setting the electrical
stimulation dial to a higher intensity is not necessary.
It is important that the cause of your pain be identied before
you start treating it with any device, including the LTO.
Introduction –
The LaserTouchOne™ (OTC)

4
Power
(On/Off) Button
Rechargeable
Power Cord Insert
Treatment End:
Laser Output in Center
Electrode Contacts on each side of laser
Product Contents
e shipping box should contain the following device
components:
• LaserTouchOne™treatmentunit
• Powercordforrechargingthebattery
• Tubeofelectroconductivegel
• Warrantycard
• UserManual
Inspect contents to ensure there is no obvious damage to the
LTO treatment device or the gel tube.
Device Features and Controls
e following photograph shows the LTO device and the
electroconductive gel used for treatment. e steps for using
the device follow on page 6. If this is your rst use, be sure the
device is fully charged prior to use.
Safety
Laser Safety – Caution: Do not stare into the visible
light. Laser light is emitted from this device. Avoid extreme
exposure. Do not point the device at anyone’s eyes.
Wheel to control
stimulation

5
Holding the Device
Generally, the LTO device is best held
as you would a pen, with the index
nger on top to operate the power (on/
o) button. is allows the middle
nger (right hand) or thumb (left hand)
to manipulate the electrical stimulation
(e-stim) wheel (or dial) to control the
pulse width (intensity). However, you
may nd it is more comfortable to hold in another position.
Charging the Unit
e device will need to be fully charged for at least 5 hours prior
to the rst use. Plug the AC recharging power cord into the unit
and then into the wall socket. e unit will not operate unless
the battery is charged. When the device is not in
use, do not store the device plugged into the charger
unless it needs to be charged. Do not use the device
while it is plugged in. Recharge the device at least
once every 3 weeks for 5 hours if you are using it
daily. Charge the device once every two months if
you are only using it occasionally. Do not let the
LTO completely lose its battery charge.
is is the charging unit which is supplied with
your device. Do not attempt to use another power
recharger – it may fail to recharge or can damage
your device.
5
HOURS
Instructions For Use:
Electrical Safety – Use care when plugging the power cord
into the wall outlet for recharging the LTO device. See the
picture below for the power charging unit which is provided
with the device. It is UL certied as safe for use with this device.

6
Treatment Steps:
Step 2: Apply Gel
Apply a small amount of gel to
the area you wish to treat.
Step 3: Turn on the LaserTouchOne™
Push the on/o button on the LTO once.
Step 4: Apply the LaserTouchOne™
Use a paint-stroke or circular
motion to treat the painful
area. Adjust the dial toward the
positive (+) sign until you feel
a slight tingle. Remove your
nger from the dial leaving it at
that setting.
Step 1: Adjust the E-Stim Wheel
Turn the dial (e-stim wheel)
on the side of the device
completely toward the minus (-)
sign (as shown by the arrow).

7
NOTES REGARDING SETTING THE ELECTRICAL
STIMULATION INTENSITY:
• Ifyouhavelimitedornoskinsensitivityintheareayou
plan to treat, test the intensity of the stimulation on a
sensitive area (such as between your thumb and rst
nger, or on top of your hand) before starting treatment.
is will ensure that you do not turn the setting too high.
• Eectivetreatmentcanbeachievedwithonlya
slight tingle sensation of the micro-current electrical
stimulation. Be sure to treat the area
of immediate pain and also surrounding areas that may
also be aected by the immediate area of pain.
Step 5: Continue For Up To Five
Treatment Sessions Per Day
Continue moving the unit in a paint-stroke or circular motion
in the desired area until the LTO and red light turn o after
2 minutes. You can continue your treatment by pressing the
power button again. If you desire to stop the unit at any point,
simply push the power button to turn it
o.
It is recommended that you start
with four to ve 2-minute cycles for a
particular area of pain, and repeat this
up to ve times throughout the day. You
can do this for each area of pain you
wish to treat.
Usually, treatment with the LTO
requires little or no pressure to the area
being treated. However, in areas with a lot of muscle or fat, a
more rm application may be necessary, although the pressure
applied should not be painful.

8
Areas to Avoid
Parts of the head, face and front of the neck:
CAROTID SINUS – e location
of the carotid sinus is illustrated in
this drawing. Care should be taken to
avoid the carotid sinus, as the electrical
stimulation may cause a muscle spasm.
THE EYE – Take particular care to
avoid treatment of and around the eye.
Avoid direct exposure of the laser light
to the eyeball.
Remember – do not look into the laser light and
do not point the light at anyone’s eyes. You can tell
that the device is on by seeing the light from the side
through the plastic tip.
Carotid Sinus
Indications for Use
e LaserTouchOne™ device combines a low level
laser and micro-current electrical stimulation.
is combination of low level light and electrical
stimulation provides symptomatic relief of chronic,
intractable pain, and is indicated for adjunctive
treatment of post-surgical and post-traumatic acute
pain and for adjunctive use in providing temporary
relief of minor chronic neck and shoulder pain of
musculoskeletal origin.
Contraindications
is device is contraindicated in patients with
cardiac pacemakers, implanted debrillators or other
implanted devices.

9
Warnings
• Becausethedevicecontainsalaser,donotshineit
directly into your eyes or look directly at the laser
light. Do not point the LTO device at your or
another person’s eyes.
• esafetyofTENSdevicesonpregnantwomenhas
not been established.
• edeviceshouldbeappliedonlytonormal,intact
clean skin. Note that the device may be applied
to bruised skin, although care should be taken to
reduce any pressure. Avoid use over open wounds or
swollen, infected or inamed areas or skin eruptions.
• AvoiduseoftheLTOdevicealongtheeyearea,or
on the front or sides of the neck at the carotid artery
(shown at left).
• AvoiduseoftheLTOdeviceover,orintheareaof,
cancerous lesions.
• edeviceshouldnotbeusedduringthefollowing
activities:
• bathingorshowering
• sleeping
• drivingoroperatingmachinery
Do not look
into the laser
light and do
not point
the light at
anyone’s eyes.

10
Precautions
• Ifyouhaveasuspectedordiagnosedheartcondition
(such as irregular heart beat, cardiac arryhthmia)
or epilepsy, you should consult with your physician
before using the LTO device to treat any pain
condition.
• elong-termeectsofprolongedexposureto
non-thermal laser and electrical stimulation are
unknown.
• Electricalstimulation(TENS)isnotknowntobe
eective in treating pain of central origin, including
headache.
• TENSdevicesarenotasubstituteforpain
medications and other pain management therapies.
• Sincetheeectsofstimulationofthebrainare
unknown, avoid use across the head.
• TENSdeviceshavenocurativevalue.
• TENSisasymptomatictreatmentand,assuch,
suppresses the sensation of pain that would
otherwise serve as a protective mechanism. is is
particularly important in the use following surgical
procedures.
• Keepthedeviceoutofthereachofchildren
• Somepatientsmayexperienceskinirritationor
hypersensitivity to the electrical stimulation or the
electrical conductive medium (gel).
• Careshouldbetakenbypatientswhoseskininareas
lack normal sensation.

11
Care and Maintenance
Like any electronic product, the LTO requires proper
care and handling. e following is recommended:
• Donotdisassemblethedevice.Donottrytoremove
the clear cover at tip of unit.
• Donotdropthedeviceorhandleitroughly.
• Donotimmersethedeviceinwateroranyliquid.
• Usethegelsparingly–onlyasmallamountis
needed on the skin.
• Aftereachtreatment,wipethetreatmentendofthe
device clean of any gel with a slightly damp cloth.
• Ifusingthedeviceonmorethanoneperson,
carefully decontaminate the treatment end,
including the stainless steel electrodes with a moist
alcohol wipe.

12
Warranty
e LaserTouchOne™ carries a 1-year warranty. If your
device should malfunction due to defective materials
and/or workmanship, it is fully guaranteed for one year
from the date of purchase, providing:
• theenclosedwarrantycardismailedtoRenewal
Technologies within 10 days of purchase;
• theLTOisreturnedforservicingtoRenewal
Technologies;
• theLTOisnotmisused,altered,orservicedbyany
person or entity other than Renewal Technologies;
• theelectroconductivegelprovidedwiththeproductis
the only type of gel to be used with the LTO device;
• theLTOisusedaccordingtotheseinstructionsand
in the manner intended.
Use of a dierent recharging unit or a dierent type of
electroconductive gel will void the 1-year warranty.
Service
If servicing is needed for your LTO, please call
1-877-751-7665 for the shipping address to send the
LaserTouchOne and the charger.
Include the following information with your unit:
name, address for return, phone number, and a brief
description of the issue.
Renewal Technologies will contact you with an estimate
of cost to complete any repairs, if not under warranty,
and arrange for payment.

13
More Questions?
Call or e-mail Renewal Technologies for
any additional information at 877-751-7665 or
[e-mail].
View instructional videos at
www.LaserTouchOne.com.

14
Laser
LASER Type Laser Diode
Wavelength 670nm +/- l0nm
Power 1.2mW
Transcutaneous Electrical Nerve
Stimulation
Waveform, shape Pulsed, rectangular
Maximum output
voltage
15V @ 500 ohm load
150V@10Kohmload
Maximum output
current
30 mA peak at 500 ohm
load
Pulse width 6 – 80 µsec
Frequency 45 Hz+/- 10%
Pulse period 22 mS
Maximum current
density
0.23 mA/cm2 average @
500 ohms
Maximum power
density
0.0034 W/cm2 average @
500 ohms
Maximum charge per
pulse
36 µJ @ 500 ohms or
2.4 µC @ 500 ohms
Power
Rechargeable Battery Lithium Ion
LaserTouchOne™ Specifications

15
Glossary
ADJUNCTIVE TREATMENT – Treatment used
together with the primary treatment. Its purpose is to
assist the primary treatment.
CARDIAC ARRHYTHMIA – An abnormal rate of
muscle contractions in the heart.
CONTRAINDICATIONS – To make (a treatment or
procedure) inadvisable.
DIODE – An electrical device with two active
terminals, an anode and a cathode, through which
current passes more easily in one direction.
ELECTROCONDUCTIVE – Having the property or
capability of conducting electricity.
FDA – Food and Drug Administration.
INTRACTABLE PAIN – Pain that is hard to treat,
relieve, dicult to solve, alleviate, or cure.
LLLT – Low Level Laser erapy, often referred to as
Cold Laser.
OTC – Available without a prescription, “Over e
Counter.”
TENS – Transcutaneous electrical nerve stimulators.

Renewal Technologies
3315 West Buckeye Road, Suite A
Phoenix, AZ 85009
Phone: [phone]
[e-mail]
www.LaserTouchOne.com
