Research HIS-3 User manual

For further questions, please contact the
resEARch hotline at [phone].
www.stethoscope-for-hearing-loss.com
Hearing aids
1. Connect your hearing aid to the audio output port of the
stethoscope, e.g. by means of a euro cable and audio
adapter or with a jack via a streamer, e.g. Oticon StreamerPro,
Phonak ComPilot or Siemens EasyTec. A connection with a
telecoil (inductive coil) can be an option, however this is not
or not always possible in hospitals or large surgeries because
of interfering magnetic fields. The connection of a 2.4 GHz
ReSound MultiMic and jack adapter is another alternative.
2. Reduce background noises by adjusting the volume by
pressing the + or - button.
3. As soon as the maximum or minimum volume is reached,
a signal tone will beep.
4. You can now start the auscultation.
Headphone
1. Connect a headphone or earphone to the audio output port
of the stethoscope.
2. Reduce background noises by adjusting the volume by
pressing the + or - button.
3. As soon as the maximum or minimum volume is reached,
a signal tone will beep.
4. You can now start the auscultation.
Dimensions:
132 x 55 x 36 mm
Filter display
Heart, lungs and both areas
Battery state
Filter selector
button
Device status (no function)
On/Off
Volume (-+)
Micro-USB
charging port
Audio output
State of
charge
Colour code
above 80%
between 20% and 80%
below 20%
Heart Lungs Both areas
Filter (auscultation)
1First Steps
1. Screw the auscultation probe into the thread.
2. Switch on the HIS-3.
Before using the HIS-3, charge the device for
about 2 hours with power in the off position.
See item 3.
4Connection Options
Filter Selection
1. Press the filter selector button several times to
differentiate between heart and lungs.
2. In some cases it is advisable to set the filter to
both areas to obtain more volume levels.
2
Subject to change without notice - errors excepted. resEARch Individuelle Hörsysteme GmbH & Co. KG | 1/2018
3Battery
1. The battery life is approximately 10 hours.
The time needed to charge it is approximately 2 hours.
2. Before charging the battery, switch off the stethoscope.
3. Connect the supplied Micro-USB charging cable to the
Micro-USB charging port on the inner side of the stethoscope.
4. The red LED lights up while the battery is being charged.
It goes off as soon as the battery is fully charged.
5. Always switch off the device after each use.
Weight:
85 g approx.,
incl. battery, without bell
Carrying strap
Frequency response
-40
-30
-20
-10
0
10
20
30
20 200 2000
Volume (dB)
Frequency (Hz)
5Care Instructions
Switch off the HIS-3 and clean the auscultation probe and the
plastic casing with a non alcoholic swab (e.g. Hartmann
Microbac Tissues, REF 981387). !
Make sure that no excess liquid
enters the device. Never immerse
the stethoscope in any cleaning
fluids. Do not insert any objects
into the openings of the stetho-
scope.
Warranty: 2 years (excluding the battery)
resEARch Individuelle Hörsysteme GmbH & Co. KG Telephone: +49 25 57 / 38 48 58
Rothenberger Str. 59 Telefax: +49 25 57 / 38 48 88
48493 Wettringen, Germany Email: [e-mail]
resEARch HIS-3eKuore Pro
A piece of normality regained
HIS-3
