Cochlear Nucleus 7 Aqua+ User manual

Nucleus®7Aqua+
User Guide
CP1000

Contents
Cochlear™ Nucleus® 7 Aqua+
— Instructions
1
Cochlear™ Nucleus® 7 Aqua+:
Instrucciones
21
Cochlear™ Nucleus® 7 Aqua+
— Instructions
41
Instruções do Cochlear™
Nucleus® 7 Aqua+
61

1NUCLEUS®7 AQUA+ USER GUIDE
Nucleus®7 Aqua+
Cochlear Nucleus 7
Aqua+
Nucleus Safety Line
(optional)
Cochlear Nucleus
Mic Lock-Stirrup
(optional)
Cochlear Nucleus 7
Aqua+ Coil

2NUCLEUS®7 AQUA+ USER GUIDE
The Cochlear™Nucleus® 7 Aqua+ is a re-usable sealable
cover that, when used with the Cochlear Nucleus 7 Aqua+
Coil, keeps your Cochlear Nucleus 7 Sound Processor (model
number: CP1000) dry during use in or around water (e.g. when
swimming, surfing, or just having fun splashing around). It is
worn behind the ear with your sound processor sealed inside.
The Nucleus 7 Aqua+ is intended for use by recipients using
the Nucleus 7 Sound Processor with rechargeable batteries. It
should only be used by recipients who can either remove the
sound processor themselves if it’s causing discomfort or who
can indicate any discomfort to their parent or caregiver.
You must use a Cochlear Standard Rechargeable Battery
Module or Cochlear Compact Rechargeable Battery
Module for your sound processor to work inside Aqua+.
Zinc air batteries will not work as they need air and there is no
air inside Aqua+ when it’s sealed.
The Nucleus 7 Aqua+ Coil is used in place of your usual
coil while your sound processor is inside your Aqua+. It has a
special plug that creates a seal when connected to your sound
processor’s coil socket through the coil plug hole in Aqua+. As
with your usual coil, a coil magnet screws into the Aqua+ coil
and holds it against your implant.
NOTES
• You cannot use your Nucleus 7 Sound Processor in Hybrid™
mode with Aqua+.
• You cannot use your Nucleus 7 Sound Processor with any of
the Cochlear retention accessories (e.g. Snugfit, Hugfit) with
Aqua+.

3NUCLEUS®7 AQUA+ USER GUIDE
The Cochlear Nucleus Mic Lock-Stirrup is a retention
option to hold Aqua+ more securely behind your ear. The
stirrup connects to the base of Aqua+ and the Mic Lock tube
(when cut to size) passes under the ear lobe and connects to
the Aqua+ earhook.
The Nucleus Safety Line is a retention option to help prevent
accidental loss of your Aqua+ by securing it to your clothing
with a snap-lock clip.
Remotes, wireless accessories and compatible iOS devices can
be used with Aqua+, however they should be protected from
water and kept dry.
You may notice a difference in sound quality when using
Aqua+.
Testing shows Aqua+ can be used at depths of up to 3 metres
for up to 2 hours.
Testing shows Aqua+ can be re-used up to 50 times, but this
may vary depending on your particular use of it.
There have been no reported undesirable side effects from
using Aqua+.
For more information, refer to the Nucleus 7 Sound Processor
User Guide.

4NUCLEUS®7 AQUA+ USER GUIDE
Nucleus 7 Aqua+ instructions
Before you get wet...
TIP
Don‘t forget you must be using rechargeable batteries for your
sound processor to work inside Aqua+.
1. Carefully unplug your
usual coil from the sound
processor. Hold the coil
cable grip and firmly
pull it straight out of the
processor.
CAUTION
Do not pull on the coil
cable or twist when you
pull it out.
2. Insert your sound
processor into Aqua+
(leave your earhook on).
CAUTION
Be careful to avoid
bending the earhook, or
detaching it from the
sound processor.

5NUCLEUS®7 AQUA+ USER GUIDE
3. Insert the plug into the
base of Aqua+. To make a
good seal, push the plug
in as far as it will go.
4. Plug the blue Aqua+
coil (with magnet)
straight into your sound
processor through the
hole in Aqua+. Grip the
black ring on the coil
connector. Do not twist.
The coil plug should feel
securely connected.
(See page 10 for magnet
instructions)

6NUCLEUS®7 AQUA+ USER GUIDE
5. If you’re concerned about losing your Aqua+, use one of
these retention options:
• Safety Line clips to your
clothing.
(See page 11 for instructions)
• Mic Lock-Stirrup holds
your processor on your
ear.
(See page 12 for instructions)

7NUCLEUS®7 AQUA+ USER GUIDE
6. Finally, do the Aqua+ Checklist to make sure you’re ready
to get wet!
Using Blue Aqua+ coil
Aqua+ tightly sealed
Mic Lock-Stirrup or
Safety Line attached if
required
Using rechargeable
batteries
7. Have fun!

8NUCLEUS®7 AQUA+ USER GUIDE
After you get wet...
Care and storage
1. Rinse Aqua+ and the Aqua+ coil with clean fresh water and
dry with a soft cloth.
2. Unplug the blue Aqua+
coil. Grip the black ring
on the coil connector.
Pull the plug straight out.
CAUTION
Do not pull on the coil
cable or twist when you
pull it out.
3. Open Aqua+ and remove
your sound processor.

9NUCLEUS®7 AQUA+ USER GUIDE
4. Re-attach your usual
coil. Push your coil cable
into the processor until it
clicks. Do not twist.
5. Place Aqua+ and the blue
Aqua+ coil in your dry aid
kit overnight.
6. Once they’re thoroughly
dry, store Aqua+, the
blue Aqua+ coil and
any accessories in the
Nucleus 7 Activity Kit’s
waterproof case.

10 NUCLEUS®7 AQUA+ USER GUIDE
Aqua+ coil magnet instructions
1. Insert the Cochlear Magnet
into the hole in the blue
Aqua+ coil.
2. Turn the magnet clockwise
until it stops.
3. Turn the magnet a little
more until you feel a click.
TIP
The tamper-resistant lock
marker aligns with the coil
cable when locked.

11NUCLEUS®7 AQUA+ USER GUIDE
Safety Line instructions
WARNING
Retention lines longer than the Safety Line (standard length)
are not recommended for use by children as they may present
a risk of strangulation.
1. Thread the Safety Line loop end through the Aqua+ ring.
2. Create a knot by passing the clip end of the line through
the line loop. Pull it tight.
3. Lift the lever to open the clip. Place the clip over your
clothing and press the lever down to close the clip.

12 NUCLEUS®7 AQUA+ USER GUIDE
Mic Lock-Stirrup instructions
Before using Mic Lock-Stirrup for the first time, cut it to the
right length to suit your ear.
1. Snap the stirrup into the dimples at the base of Aqua+.
2. Find the right length of tubing to hold Aqua+ in place
comfortably behind your ear. Cut the tubing to the
required length.


13NUCLEUS®7 AQUA+ USER GUIDE
3. Push the cut end of the tubing over the earhook, as far as
you can.
4. Wear your Aqua+ with Mic Lock-Stirrup.
TIP
Once fitted, you can leave your Mic Lock-Stirrup on your
Aqua+.

14 NUCLEUS®7 AQUA+ USER GUIDE
Warnings
• If your sound processor becomes warmer than usual,
remove it immediately and seek advice from your clinician.
Parents/caregivers: if your recipient indicates discomfort,
check if their sound processor is warmer than usual.
• Small parts (e.g. magnets, Safety Line) may be a choking or
strangulation hazard.
• The Aqua+ and sound processor should be protected
from excessive heat sources such as prolonged exposure
to bright sunlight. Before wearing the Aqua+ and sound
processor, check the surface to ensure it is not too hot to
wear without discomfort to skin.
• Exposure of the sound processor and Aqua+ to
temperatures above the operating range (+5° C – +40° C,
+41° F – +104° F) could lead to increased risk of sound
processor shutdown or malfunction due to overheating.

15NUCLEUS®7 AQUA+ USER GUIDE
• If you experience tightness or pain at the implant site, or
develop significant skin irritation, stop using your sound
processor and contact your clinician.
• If the coil magnet is too strong, pressure sores may
develop at the implant site. If this happens, or if you
experience any discomfort in this area, contact your
clinician.
• Store spare magnets safely and away from cards that may
have a magnetic strip (e.g. credit cards, bus tickets, etc).
• No modification of this equipment is allowed.
• Use only as intended.
• Report unexpected problems to your clinician.

16 NUCLEUS®7 AQUA+ USER GUIDE
Cautions
• Always use Aqua+ with the blue Aqua+ coil, never with
your usual coil.
• When connecting the coil cable, always push the plug
straight in; do not screw or twist the plug.
• Where possible, avoid pressing the processor button with
your fingernail as this can damage your Aqua+.
• If your Aqua+ appears damaged or worn, replace it with a
new one.
• If your sound processor does get wet, dry it with a soft dry
cloth and place it in your dry aid kit for at least eight hours.

17NUCLEUS®7 AQUA+ USER GUIDE
Other Information
Environmental conditions
CONDITION MINIMUM MAXIMUM
Storage & transport temperature -10° C (+14° F) +55° C (+131° F)
Storage & transport humidity 0% RH 90% RH
Operating temperature +5° C (+41° F) +40° C (+104° F)
Operating relative humidity 0% RH 90% RH
Operating pressure 700 hPa 1060 hPa
Environmental protection
Your Aqua+ coil contains electronic components subject to
the Directive 2002/96/EC on waste electrical and electronic
equipment. Help protect the environment by not disposing of
your Aqua+ coil with your unsorted household waste. Please
recycle your Aqua+ coil according to your local regulations.

18 NUCLEUS®7 AQUA+ USER GUIDE
Warranty
Your Nucleus Global Limited Warranty will not be void in
circumstances where Aqua+ is used in water with Nucleus 7
Sound Processors, in accordance with the Aqua+ instructions.
