Retekess TD110 User manual

TD110
Watch Receiver
User Manual

CONTENTS
Overview of Watch Receiver---------------------
Instruction of Buttons -----------------------------
Operation Instruction-------------------------------
Package Includes----------------------------------------
01
01
02
11
DE(19-39)
FR(40-59)
IT(60-79)
ES(80-98)
RU(99-120)
PT(121-144)
EU Importer：Germany Retevis Technology
GmbH
Address：Uetzenacker 29,38176 wendeburg

Overview of Watch Receiver
20 16 -1 1- 11 A
Battery Level
Date
Indicator
Light
Week
Signal Status
01
Pager ID
Setting
Up
Down Time
Back
Staturday
Instruction of Buttons
【Setting】button, long press the button to enter
the setting mode, and short press to enter the
sub-menu.
【Up】button, short press to skip one step to the
last menu, and long press to continuously skip.
【Down】button, short press to skip one step to
the next menu, and long press to continuously
skip.
【Back】button, In standby mode, short press to
clear the current calling information, long press to
delete all calling information. When in the setting
mode, short press to return to previous menu,
long press to return to main interface.
【Indicator Light】: Light a twinkle green when
there is a call; Light turns red when the watch in
1

charging mode; Light turns green when it is fully
charged.
Operation Instruction
1. Turn on/off
A.Turn on: Press【Back】button for 3s until the
LCD screen light up, then it is turned on and
showing the current time.
B.Turn off: Long press 【Back】button for 3s
when the watch is on, short press【Up/Down】
button to select Turn off , then short press【Setting】button to turn it off. Nothing is displayed
on the display after shutting down. (The
presetting date, time, alarm and timer switch are
still available when the watch turned again).
C. Reboot: Long press 【Back】button for 3s
when it is on, short press 【Up/Down】button to
select Reboot, then short press"Setting" button
to restart the watch.
2. Function Setting
2.1 Caller Setting
●Add/ Delete Caller
Long press【Setting】button to enter Menu list
and select Caller Setting.
Short press【Setting】button to enter the
sub-menu and select Add/Delete Caller.
2

Short press【Setting】button into the caller
adding interface, it shows ID:0001 on the
display.
Short press【Up/Down】buttons to choose the
ID number to be registered.
Long press【Setting】button to move the cursor
position, the letter can be selected among 0- 9,
A-Z and -,_ or blank. Each ID number can add
one or more caller (max 999pcs). After setting
the ID number, the screen displays "Press
Caller" in the bottom, then press any button of
the caller, the watch will beep when it receives
the signal, it means the registration is successful.
The screen will display an ID increased, ( The
number before the / icon represents the quantity
of the callers that have been added for the
current ID, the number after the / icon represents
the quantity of the callers that have been added
in total for all the IDs). Then the ID number will
automatically go to the next.
If you have not pressed the transmitter, but the
number is automatically increased during adding
callers, it means that you added a caller from
someone else.
Short press【Down】button to return to the
previous ID
Short press 【Setting】button to delete the
3

wrong transmitters. Every short press【Setting】button will delete one.
Note: The repeated registration of the same call
button will default to the last ID, because each
call button can only register one ID
●Delete All
Long press【Setting】button to enter Menu list
and select Caller Setting.
Short press【Setting】button to enter the
sub-menu and select Delete All.
Short press【Setting】button, it will appear "
confirm ? Yes"
Short press【Setting】button again to delete all
transmitters (Note: please use this step with
caution as it cannot be restored)
Short press【Back】button to return to Menu list
2.2 Key Function Setting
Long press【Setting】button to enter Menu list
and select Key Function Setting.
Short press【Setting】button to enter the
sub-menu.
Set the ID number first, long press【Setting】button to move the cursor position
Short press【Up/Down】button to select the
desired value.
Short press【Setting】button twice to enter the
4

keys function setting , when it display "water",
press the corresponding key on the call button,
the watch beeps "di" and it shows "Succeeded"
on the display, it means it has been set up
successfully.
Short press【Up/Down】button again to set
other call buttons (with custom key value) in the
same way.
If you need the same key function of all callers
under this ID, you can copy the key function of
this caller to all other callers after setting up the
caller (Note: you have to add the caller before
setting the key function).
2.3 Pager ID Setting
Long press【Setting】button to enter Menu list
and select Pager ID
Short press【Setting】button to enter the
sub-menu
Short press【Up/Down】button to select the
desired value (01-99 optional)
Short press【back】button to return to Menu list
2.4 Prompt Setting
Long press【Setting】button to enter Menu list
and select Prompt setting
Short press【Setting】button to enter the
5

sub-menu
Short press【Up/Down】button to select the
prompt modes (Light/Vibrate/Beeps)
Short press【Setting】button to Confirm /Cancel
Short press【Back】button to return to Menu list
2.5 Repeat Time Setting
Long press【Setting】button to enter Menu list
and select Repeat Time
Short press【Setting】button to enter the
sub-menu
Short press【Up/Down】button to select repeat
time (3/6/9/12/15 times)
Short press【setting】button to Confirm
Short press【back】button to return to Menu list
2.6 Auto Clear Time Setting
Long press【Setting】button to enter Menu list
and select Auto Clear Setting
Short press【Setting】button to enter the
sub-menu
Short press【Up/Down】button to set the time of
auto clearing, "000" means that the call records
won't be deleted automatically.
Short press【Back】button to return to Menu list
2.7 Timing Boot
Long press【Setting】button to enter Menu list
6

and select Timing Boot
Short press【Setting】button to enter the
sub-menu, the pager can set up to 10 groups of
timing
●Add timing switch
Short press【Up/Down】button to select "add"
Short press【Setting】button to enter the
sub-menu
Short press【Setting】button to set hours,
minutes, weeks and choose timing on or timing
off
Short press【Up/Down】button to select the
desired value
Short press【back】button to return to Menu list
●Edit timing switch
Short press【Up/Down】button to select the
added timing that need to be edited
Short press【Setting】button to enter the
sub-menu
Short press【Setting】button to set hours,
minutes, weeks and choose timing on or timing
off
Short press【Up/Down】button to select the
desired value
Short press【Back】button to return to Menu list
7

●Delete timing switch
Short press【Up/Down】button to move to the
added timing which need to be deleted
Long press【Setting】button to delete the
selected value
2.8 Alarm Setting
Long press【Setting】button to enter Menu list
and select Alarm setting
Short press【Setting】button to enter the
sub-menu.
Users can set up to 10 groups of the alarm
clock. The alarm is still active even when the
pager watch is off
●Add alarm
Short press【Up/Down】button to move to "add"
Short press【Setting】button to enter the
sub-menu.
Short press【Setting】button to move to
hours,minutes,and the weeks
Short press【Up/Down】button to select the
desired value
Short press【Back】button to return to Menu list
●Edit alarm
Short press【Up/Down】button to move to the
added alarm which need to be edited
8

Short press【Setting】button to enter the
sub-menu
Short press【Setting】button to move to hours,
minutes, and weeks
Short press 【Up/Down】button to select the
desired value
Short press【Back】button to return to Menu list
●Delete alarm
Short press【Up/Down】button to select the
value that need to be deleted
Long press【Setting】button to delete it
2.9 12H/24H Setting
Long press【Setting】button to enter Menu list
and select 12H/24H setting
Short press【Setting】button to enter the
sub-menu
Short press【Up/Down】button to select time
mode (12H/ 24H) ,
Short press【Setting】button to Confirm
Short press【back】button to return to Menu list
2.10 Date&time setting
Long press【Setting】button to enter Menu list
and select Date&time setting
Short press【Setting】button to enter the the
9

setting menu
Short press【Setting】button to move to hours,
minutes, seconds, year, month and day
Short press【Up/Down】button to select the
value
Short press【back】button to return to Menu list
2.11 Language setting
Long press【Setting】button to enter Menu list
and select Language setting
Short press【Setting】button to enter the
sub-menu
Short press【Up/Down】button to select the
desired language (EN/CH/RU/PT/IT/ES/DE/FR )
Short press【Setting】button to confirm and
return to Menu list
2.12 About
It shows the software version of this product.
2.13 Default setting
Long press【Setting】button to enter Menu list
and select Default setting
Short press【setting】button to enter the
sub-menu
Short press【Up/Down】button to select
Recover/cancel
10

Short press【Setting】button to confirm
Short press【Back】button to return to Menu list
Package Includes
Watch receiver*1
USB charging cable*1
User manual*1
11

ATTENTION!
RF ENERGY EXPOSURE AND PRODUCT
SAFETY GUIDE
Before using this radio, read this guide
which contains important operating
instructions for safe usage and rf energy
awareness and control for compliance with
applicable standards and regulations.
Local Government Regulations
When radios are used as a consequence of
employment, the Local Government Regulations
requires users to be fully aware of and able to
control their exposure to meet occupational
requirements. Exposure awareness can be
facilitated by the use of a product label directing
users to specific user awareness information.
Your Retekess radio has a RF Exposure Product
Label. Also, your Retekess user manual, or
separate safety booklet includes information and
operating instructions required to control your RF
exposure and to satisfy compliance
requirements.
Unauthorized modification and adjustment
Changes or modifications not expressly
approved by the party responsible for
compliance may void the user’s authority
granted by the local government radio
12

management departments to operate this radio
and should not be made. To comply with the
corresponding requirements, transmitter
adjustments should be made only by or under
the supervision of a person certified as
technically qualified to perform transmitter
maintenance and repairs in the private land
mobile and fixed services as certified by an
organization representative of the user of those
services.
Replacement of any transmitter component
(crystal, semiconductor, etc.) not authorized by
the local government radio management
departments equipment authorization for this
radio could violate the rules.
FCC Requirements:
•This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
•(If applicable) This equipment has been tested
and found to comply with the limits for a Class B
13

digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio communica-
tions. However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the
equipment and receiver.
-- Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV
technician for help.
CE Requirements:
•(Simple EU declaration of conformity) Henan
14

Eshow Electronic Commerce Co.,Ltd declares
that the radio equipment type is in compliance
with the essential requirements and other
relevant provisions of RED Directive 2014/53/EU
and the ROHS Directive 2011/65/EU and the
WEEE Directive 2012/19/EU; the full text of the
EU declaration of conformity is available at the
following internet address: www.retekess.com.
•Disposal
The crossed-out wheeled-bin symbol on your
product, literature, or packaging reminds you
that in the European Union, all electrical and
electronic products, batteries, and accumulators
(rechargeable batteries) must be taken to
designated collection locations at the end of their
working life.
Do not dispose of these products as
unsorted municipal waste. Dispose of
them according to the laws in your area.
IC Requirements:
Licence-exempt radio apparatus
This device contains licence-exempt
transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is
subject to the following two conditions:
15

(1) This device may not cause interference.
(2) This device must accept any interference,
including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR
d’Industrie Canada applicables aux appareils
radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le
fonctionnement.
RF Warning Statements
The device has been evaluated to meet general
RF exposure requirement. The device can be
used in portable exposure condition without
restriction.
RF Exposure Information(if appropriate)
•DO NOT operate the radio without a proper
antenna attached, as this may damage the radio
and may also cause you to exceed RF exposure
limits. A proper antenna is the antenna supplied
with this radio by the manufacturer or an antenna
specifically authorized by the manufacturer for use
16

with this radio, and the antenna gain shall not
exceed the specified gain by the manufacturer
declared.
•To avoid interference, turn off the radio in areas
where signs are posted to do so.
•DO NOT operate the transmitter in areas that are
sensitive to electromagnetic radiation such as
hospitals, aircraft, and blasting sites.
Avoid Choking Hazard
Small Parts. Not for children under
3 years.
Protect your hearing:
• Use the lowest volume necessary to
do your job.
• Turn up the volume only if you are in
noisy surroundings.
• Turn down the volume before adding
headset or earpiece.
• Limit the amount of time you use
headsets or earpieces at high volume.
• When using the radio without a
headset or earpiece, do not place the
radio's speaker directly against your
ear
WARNING
17

• Use careful with the earphone maybe
possible excessive sound pressure
from earphones and headphones can
cause hearing loss
Note: Exposure to loud noises from
any source for extended periods of
time may temporarily or permanently
affect your hearing. The louder the
radio's volume, the less time is
required before your hearing
could be affected. Hearing
damage from loud noise is
sometimes undetectable at first and
can have a cumulative effect.
•This radio meets the RF exposure
guidelines when used with the
Retekess accessories supplied or
designated for the product. Use of
other accessories may not ensure
compliance with the RF exposure
guidelines and may violate regulations.
•For a list of Retekess-approved
accessories for your radio model, visit
the following website: http://www.Rete-
kess.com
WARNING
Approved Accessories
18
